KA2IR802A1Wireless AC600 Dual Band Home Router

Version 1.0 | 12/09/2013 Wireless AC600 Dual Band Router User Manual DIR-802 iD-Link DIR-802 User Manual D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. Copyright © 2013 by D-Link Systems, Inc. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Systems, Inc. RevisionDateDescription 1.0August 22, 2013• Initial release for Revision A1 Preface iiD-Link DIR-802 User Manual Table of Contents Preface..................................................................................i Manual Revisions ...........................................................................i Trademarks ......................................................................................i Product.Overview...............................................................1 Package Contents .........................................................................1 System Requirements .................................................................2 Introduction ...................................................................................3 Features ............................................................................................4 Hardware Overview .....................................................................5 Connections ...........................................................................5 LEDs ...........................................................................................6 Installation..........................................................................7 Before you Begin ...........................................................................7 Wireless Installation Considerations ......................................8 Manual Setup .................................................................................9 Configuration....................................................................11 Quick Setup Wizard ....................................................................12 QRS Mobile App ..........................................................................17 Web-based Configuration Utility ..........................................18 Internet Connection Setup .............................................19 Internet Connection Setup Wizard ...............................20 Internet (Manual) ................................................................26 Static (assigned by ISP) ................................................28 PPPoE (DSL) ......................................................................29 PPTP ....................................................................................31 L2TP ....................................................................................33 DS-Lite ...............................................................................35 Wireless connection setup wizard ................................36 Wi-Fi Protected Setup Wizard .........................................39 Manual wireless network setup .....................................40 Wireless Security .................................................................49 What is WPA? ...................................................................49 Network Settings ................................................................50 Router Settings ...............................................................50 DHCP Server Settings ...................................................51 DHCP Reservation .........................................................53 IPv6 ..........................................................................................54 IPv6 Internet Connection Setup Wizard ................55 IPv6 Manual Setup.........................................................60 Advanced ...............................................................................69 Virtual Server ...................................................................69 Port Forwarding .............................................................70 Application Rules ...........................................................71 QoS Engine .......................................................................72 Network Filters ................................................................74 Access Control .................................................................75 Website Filters .................................................................78 Inbound Filters ................................................................79 Firewall Settings .............................................................80 Routing ..............................................................................82 Table of Contents iiiD-Link DIR-802 User Manual Table of Contents Advanced Wireless ........................................................83 Wi-Fi Protected Setup (WPS) .....................................84 Advanced Network Settings ......................................86 Guest Zone .......................................................................87 Tools ........................................................................................88 Admin.................................................................................88 Time ....................................................................................89 SysLog ................................................................................90 Email Settings..................................................................91 System ..................................…

Text truncated - open the document above for the full version.

Report No.: 130802E07 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 130802E07 Page 2 Model No.: AMS47-0501000FU Report No.: 130802E07 Page 3 Report No.: 130802E07 Page 4 Model No.: F05W-050100SPAU Report No.: 130802E07 Page 5

FCC ID： KA2IR802A1 IC : 4216A-IR802A1 LABEL LOCATION Brad name : D-Link Model name : DIR-802A1 Natasha_lai Jaylin_Lin Jaylin_Lin 2013/7/22 2013/7/22 2013/7/22 970000012362G A1 DIR-802 Device Label 注意： 1.015mm Outline and aperture Cut Tooling Tolerence:+-0.15mm 2. Please refer to the material construction. Color: Background: Black 白亮特多龍 50μ Glossy White Polyester Label 25μ霧面特多龍(PET) Matte Clear Polyester Film 8.0 mm 5.5 mm ID2850 FCC ID: KA2IR802A1 IC: 4216A-IR802A1 CAN ICES-3 (B)/NMB-(B) Model: DIR-802A1 DIR-802

Report No.: 130802E07 Page 1 CONSTRUCTION PHOTOS OF EUT Report No.: 130802E07 Page 2 Report No.: 130802E07 Page 3 Report No.: 130802E07 Page 4

Report No.: SA130802E07 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA130802E07 MODEL NO.: DIR-802 FCC ID: KA2IR802A1 RECEIVED: Aug. 02, 2013 TESTED: Aug. 21, 2013 ISSUED: Oct. 15, 2013 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA130802E07 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA130802E07 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA130802E07 Original release Oct. 15, 2013 Report No.: SA130802E07 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Wireless AC600 Dual Band Home Router BRAND NAME: D-Link MODEL NO.: DIR-802 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: D-Link Corporation TESTED DATE: Aug. 21, 2013 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: DIR-802) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Oct. 15, 2013 ( Elsie Hsu, Specialist ) APPROVED BY : , DATE: Oct. 15, 2013 ( May Chen, Manager ) Report No.: SA130802E07 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA130802E07 6 of 6 Report Format Version 5.0.0 5. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER 15.247(2.4GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 287.740 3.93 20 0.14149 1 15.247(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 532.108 3.91 20 0.26045 1 15.407(5GHz): FREQUENCY (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 47.643 3.91 20 0.02332 1 CONCLUSION: Both of the 2.4GHz and 5GHz WLAN can transmit simultaneously, the formula of calculated the MPE is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.14149 / 1 + 0.25926 / 1= 0.401, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit. --- END ---

Report No.: RF130802E07 1 of 97 Report Format Version 5.2.0 FCC TEST REPORT (15.247) REPORT NO.: RF130802E07 MODEL NO.: DIR-802 FCC ID: KA2IR802A1 RECEIVED: Aug. 02, 2013 TESTED: Aug. 07 to 26, 2013 ISSUED: Oct. 15, 3013 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF130802E07 2 of 97 Report Format Version 5.2.0 Table of Contents RELEASE CONTROL RECORD..............................................................................6 1. CERTIFICATION ...........................................................................................7 2. SUMMARY OF TEST RESULTS ...................................................................8 2.1 MEASUREMENT UNCERTAINTY ..............................................................10 3. GENERAL INFORMATION ......................................................................... 11 3.1 GENERAL DESCRIPTION OF EUT ............................................................ 11 3.2 DESCRIPTION OF TEST MODES ..............................................................14 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ..............15 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................18 3.4 DESCRIPTION OF SUPPORT UNITS ........................................................19 3.5 CONFIGURATION OF SYSTEM UNDER TEST .........................................19 4. TEST TYPES AND RESULTS (fOR 2.4GHz, 2.400 ~ 2.4835GHz Band) ....20 4.1 CONDUCTED EMISSION MEASUREMENT ..............................................20 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................20 4.1.2 TEST INSTRUMENTS ................................................................................20 4.1.3 TEST PROCEDURES .................................................................................21 4.1.4 DEVIATION FROM TEST STANDARD .......................................................21 4.1.5 TEST SETUP ..............................................................................................21 4.1.6 EUT OPERATING CONDITIONS ................................................................22 4.1.7 TEST RESULTS (MODE 1) .........................................................................23 4.1.8 TEST RESULTS (MODE 2) .........................................................................25 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ......................27 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ...27 4.2.2 TEST INSTRUMENTS ................................................................................28 4.2.3 TEST PROCEDURES .................................................................................29 4.2.4 DEVIATION FROM TEST STANDARD .......................................................29 4.2.5 TEST SETUP ..............................................................................................30 4.2.6 EUT OPERATING CONDITIONS ................................................................30 4.2.7 TEST RESULTS ..........................................................................................31 4.3 6dB BANDWIDTH MEASUREMENT ..........................................................44 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................44 4.3.2 TEST INSTRUMENTS ................................................................................44 4.3.3 TEST PROCEDURE ...................................................................................44 4.3.4 DEVIATION FROM TEST STANDARD .......................................................44 4.3.5 TEST SETUP ..............................................................................................44 4.3.6 EUT OPERATING CONDITIONS ................................................................44 4.3.7 TEST RESULTS ..........................................................................................45 Report No.: RF130802E07 3 of 97 Report Format Version 5.2.0 4.4 CONDUCTED OUTPUT POWER MEASUREMENT ..................................46 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREM…

Text truncated - open the document above for the full version.

Report No.: RF130802E07-1 1 of 56 Report Format Version 5.2.0 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 FCC TEST REPORT (15.407) REPORT NO.: RF130802E07-1 MODEL NO.: DIR-802 FCC ID: KA2IR802A1 RECEIVED: Aug. 02, 2013 TESTED: Aug. 07 to Oct. 15, 2013 ISSUED: Oct. 15, 2013 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF130802E07-1 2 of 56 Report Format Version 5.2.0 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 16 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 17 4. TEST TYPES AND RESULTS .............................................................................. 18 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 18 4.1.2 TEST INSTRUMENTS .......................................................................................... 18 4.1.3 TEST PROCEDURES .......................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 19 4.1.5 TEST SETUP ....................................................................................................... 19 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 20 4.1.7 TEST RESULTS (MODE 1) .................................................................................. 21 4.1.8 TEST RESULTS (MODE 2) .................................................................................. 23 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 25 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 25 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 25 4.2.3 TEST INSTRUMENTS .......................................................................................... 26 4.2.4 TEST PROCEDURES .......................................................................................... 27 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 27 4.2.6 TEST SETUP ....................................................................................................... 28 4.2.7 EUT OPERATING CONDITION ............................................................................ 28 4.2.8 TEST RESULTS ................................................................................................... 29 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 39 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 39 4.3.2 TEST INSTRUMENTS .......................................................................................... 39 4.3.3 TES…

Text truncated - open the document above for the full version.

Report No.: 120702E04 1 of 3 PYHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (MODE 1) Report No.: 120702E04 2 of 3 CONDUCTED EMISSION TEST (MODE 2) Report No.: 120702E04 3 of 3 RADIATED EMISSION TEST
