KA2IR822A1AC1200 Wi-Fi Router

Version 1.0 | 18/May/2015 AC1200 Wi-Fi Router User Manual DIR-822 iD-Link DIR-822 User Manual D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Trademarks D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. iPhone, iPad, and iPod touch are registered trademarks of Apple Inc. Android is a trademark of Google, Inc. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. Copyright © 2015 by D-Link Corporation. All rights reserved. This publication may not be reproduced, in whole or in part, without prior expressed written permission from D-Link Corporation. RevisionDateDescription 1.0May 18, 2015• Initial release Preface iiD-Link DIR-822 User Manual Table of Contents Preface .................................................................................i Manual Revisions ...........................................................................i Trademarks ......................................................................................i Package Contents .........................................................................1 System Requirements .................................................................2 Introduction ...................................................................................3 Features ............................................................................................4 Hardware Overview .....................................................................5 Connections ...........................................................................5 LEDs ...........................................................................................6 Installation .........................................................................7 Before you Begin ...........................................................................7 Wireless Installation Considerations ......................................8 Manual Setup .................................................................................9 Configuration ...................................................................10 Quick Setup Wizard ....................................................................11 QRS Mobile App ..........................................................................16 Web-based Configuration Utility ..........................................20 Internet Connection Setup .............................................21 Internet Connection Setup Wizard ...............................22 Internet (Manual) ................................................................28 Static (assigned by ISP) ................................................30 PPPoE (DSL) ......................................................................31 PPTP ....................................................................................33 L2TP ....................................................................................35 DS-Lite ...............................................................................37 Wireless Connection Setup Wizard ..............................38 Wi-Fi Protected Setup Wizard .........................................41 Manual Wireless Network Setup ...................................42 W ireless Security .................................................................51 What is WPA? ...................................................................51 Network Settings ................................................................52 Router Settings ...............................................................52 DHCP Server Settings ...................................................53 DHCP Reservation .........................................................55 IPv6 ..........................................................................................56 IPv6 Internet Connection Setup Wizard ................57 IPv6 Manual Setup.........................................................62 Advanced ...............................................................................71 Virtual Server ...................................................................71 Port Forwarding .............................................................72 Application Rules ...........................................................73 QoS Engine .......................................................................74 Net work Filters ................................................................76 Access Control .................................................................77 Website Filters .................................................................80 Inbound Filters ................................................................81 Firewall Settings .............................................................82 Routing ..............................................................................83 Advanced Wireless ........................................................84 Wi-Fi Protected Setup (WPS) .....................................85 Table of Contents iiiD-Link DIR-822 User Manual Table of Contents Advanced Network Settings ......................................87 Guest Zone .......................................................................88 IPv6 Firewall .....................................................................89 IPv6 Routing ....................................................................90 Tools ........................................................................................91 Admin.................................................................................91 Time ....................................................................................92 SysLog ............................................…

Text truncated - open the document above for the full version.

Report No.: 150428E01 Page No. 1 / 9 CONSTRUCTION PHOTOS OF EUT Report No.: 150428E01 Page No. 2 / 9 Report No.: 150428E01 Page No. 6 / 9 Adapter 1 – Model No.: 2AAR006F US Report No.: 150428E01 Page No. 7 / 9 Report No.: 150428E01 Page No. 8 / 9 Adapter 2 – Model No.: MU06-T120050-A1 Report No.: 150428E01 Page No. 9 / 9

Colors: K100 Background Material: 50μ白亮特多龍(PET) Glossy White Polyester Film  Modified drawing Coated: 25μ霧面特多龍(PET) Matte Clear Polyester Film Unit: mm Adhesive: 壓克力膠 Acrylic Scale: 1:1 Rev.: 1.0 Original drawing 外印印刷稿 for printing 8mm Date: 2015/05/08 Date: 2015/05/08 Date: 2015/05/08 Drawn by: Ario Hsieh Checked by: Mandy Chou Approved by: Mandy Chou Title: DIR-822 Device Label Cutting and Printing Tolerance: ±0.15mm Contents Tolerance: ±0.15mm Part No.: 970000012997GTask ID: 5625 Output 3mm 2 mm2 mm 6mm Default router settings:http://192.168.0.1 or http://dlinkrouter.local./Username: AdminPassword: (leave the field blank) DIR-822 FCC ID: KA2IR822A1IC: 4216A-IR822A1Model: DIR-822A1CAN ICES-3 (B)/NMB-3(B) 0.5 Made In China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Default router settings:http://192.168.0.1 or http://dlinkrouter.local./Username: AdminPassword: (leave the field blank) DIR-822 FCC ID: KA2IR822A1IC: 4216A-IR822A1Model: DIR-822A1CAN ICES-3 (B)/NMB-3(B) 0.5 Made In China This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID： KA2IR822A1 IC : 4216A-IR822A1 LABEL LOCATION Brad name : D-Link Model name : DIR-822, DIR-822A1

Report No.: 150428E01 Page No. 3 / 9 Report No.: 150428E01 Page No. 4 / 9 Report No.: 150428E01 Page No. 5 / 9

Report No.: SA150428E01 Page No. 1 / 6 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150428E01 FCC ID: KA2IR822A1 Test Model: DIR-822 Received Date: Apr. 28, 2015 Test Date: May 04, 2015 Issued Date: May 21, 2015 Applicant: D-Link Corporation Address: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by any government agencies. Report No.: SA150428E01 Page No. 2 / 6 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Antenna Gain ......................................................................................................................................... 5 4 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SA150428E01 Page No. 3 / 6 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150428E01 Original release. May 21, 2015 Report No.: SA150428E01 Page No. 5 / 6 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 24cm away from the body of the user. So, this device is classified as Mobile Device. 3 Antenna Gain The antenna provided to the EUT, please refer to the following table: 2.4GHz Band No. Transmitter Circuit Brand Model Ant. Gain(dBi) <Including cable loss> Frequency range (GHz to GHz) Cable Length (mm) Antenna Type Connecter Type 1 Chain (0) HL Technology Group Limited 290-20208 2.5 2.4~2.4835 70 Dipole NA 2 Chain (1) 290-20210 2.5 2.4~2.4835 260 5GHz Band No. Transmitter Circuit Brand Model Ant. Gain(dBi) <Including cable loss> Frequency range (GHz to GHz) Cable Length (mm) Antenna Type Connecter Type 3 Chain (0) HL Technology Group Limited 290-20207 2.5 5.15~5.85 70 Dipole NA 4 Chain (1) 290-20209 2.5 5.15~5.85 280 Report No.: SA150428E01 Page No. 6 / 6 Report Format Version: 6.1.1 4 Calculation Result of Maximum Conducted Power Frequency Band (MHz) Max Power (mW) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 726.158 5.51 24 0.35678 1 5180-5240 208.543 5.51 24 0.10246 1 5745-5825 264.383 5.51 24 0.12990 1 NOTE: 2.4GHz : Directional gain = 2.5dBi + 10log(2) = 5.51dBi 5GHz : Directional gain = 2.5dBi + 10log(2) = 5.51dBi Conclusion: The formula of calculated the MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density WLAN 2.4GHz + WLAN 5GHz = 0.35678 + 0.12990 = 0.487 Therefore the maximum calculations of above situations are less than the “1” limit. --- END ---

Report No.: RF150428E01 Page No. 1 / 58 Report Format Version: 6.1.1 FCC Test Report (15.247) Report No.: RF150428E01 FCC ID: KA2IR822A1 Test Model: DIR-822 Received Date: Apr. 28, 2015 Test Date: Apr. 30 to May 05, 2015 Issued Date: May 21, 2015 Applicant: D-Link Corporation Address: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150428E01 Page No. 2 / 58 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Duty Cycle of Test Signal .................................................................................................................. 12 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 13 3.5 General Description of Applied Standards ........................................................................................ 14 4 Test Types and Results ...................................................................................................................... 15 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 15 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 15 4.1.2 Test Instruments ................................................................................................................................ 16 4.1.3 Test Procedures ................................................................................................................................. 18 4.1.4 Deviation from Test Standard ............................................................................................................ 18 4.1.5 Test Set Up ........................................................................................................................................ 19 4.1.6 EUT Operating Conditions ................................................................................................................. 19 4.1.7 Test Results ....................................................................................................................................... 20 4.2 Conducted Emission Measurement .................................................................................................. 33 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 33 4.2.2 Test Instruments ................................................................................................................................ 33 4.2.3 Test Procedures ...............................…

Text truncated - open the document above for the full version.

Report No.: RF150428E01-1 Page No. 1 / 58 Report Format Version:6.1.1 FCC Test Report (15.407) Report No.: RF150428E01-1 FCC ID: KA2IR822A1 Test Model: DIR-822 Received Date: Apr. 28, 2015 Test Date: May 01 to 05, 2015 Issued Date: May 21, 2015 Applicant: D-Link Corporation Address: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150428E01-1 Page No. 2 / 58 Report Format Version:6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail ........................................................................... 10 3.3 Duty Cycle of Test Signal .................................................................................................................. 12 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 13 3.5 General Description of Applied Standard .......................................................................................... 14 4 Test Types and Results ...................................................................................................................... 15 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 15 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 15 4.1.2 Test Instruments ................................................................................................................................ 16 4.1.3 Test Procedure .................................................................................................................................. 18 4.1.4 Deviation from Test Standard ............................................................................................................ 18 4.1.5 Test Setup .......................................................................................................................................... 19 4.1.6 EUT Operating Condition .................................................................................................................. 19 4.1.7 Test Results ....................................................................................................................................... 20 4.2 Conducted Emission Measurement .................................................................................................. 39 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 39 4.2.2 Test Instruments ................................................................................................................................ 39 4.2.3 Test Procedure ...............................…

Text truncated - open the document above for the full version.

Report No.: 140717E01A-1 1 of 3 Reference No.: 140805E09 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Mode 1) Report No.: 140717E01A-1 2 of 3 Reference No.: 140805E09 CONDUCTED EMISSION TEST (Mode 2) Report No.: 140717E01A-1 3 of 3 Reference No.: 140805E09 RADIATED EMISSION TEST
