KA2SL6300VA1VDSL2+ Bridge

DSL-6300V USER MANUAL FEBRUARY 2011 ISSUE 1 All other trademarks are the property of their respective owners.. The information presented is subject to change without notice. D-Link Corporation assumes no responsibility for inaccuracies contained herein. Copyright © 2011 D-Link Corporation. All Rights Reserved. Conformance statements The device complies with Part 68 of the Federal Communications Commission (FCC) statements and UL. iii Issue 1 February 2011 ............................................................................................................................................................................................................................................................ Contents About this document Purpose ......................................................................................................................................................... v Reason for revision ....................................................................................................................................... v Intended audience ......................................................................................................................................... v Supported systems ........................................................................................................................................ v Safety information ........................................................................................................................................ v Conventions used ......................................................................................................................................... vi Eco-environmental statements ..................................................................................................................... vi Technical support ......................................................................................................................................... vi 1Installation Guide Install the CPE ........................................................................................................................................... 1-1 ATroubleshooting BTCP/IP configuration CProduct conformance ............................................................................................................................................................................................................................................................ iv Issue 1 February 2011 ............................................................................................................................................................................................................................................................ v Issue 1 February 2011 ............................................................................................................................................................................................................................................................ About this document Purpose The purpose of the User Manual is to provide installation information, procedures for installation, service activation and system reconfiguration for the DSL-6300V VDSL2 Bridge. Additionally the User Manual contains status indicators and troubleshooting information and a comprehensive description of safety guidelines. Reason for revision This version 1.0 of the User Manual is the first issue. Intended audience The intended audience of the User Manual primarily is for individuals who install, configure and maintain this customer premises equipment (CPE) and in addition responsible for the supervision of transmission operation. Supported systems For theDSL-6300V VDSL2 gateway operation as described in this manual, a specific hardware consists of the following components is required: •One DSL-6300V VDSL2 Bridge •One standard telephone cable •One category 5 UTP network cable •One power adapter Safety information Important! The following information lists the safety reminders for installation and maintenance personnel. Read all instructions before attempting to unpack, install, operate, or connect power to this CPE. Please remember the following when you unpack and install this equipment: •Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury. •To prevent fire or shock hazard, do not expose the CPE to rain, moisture or install this equipment near water. Never spill any form of liquid on or into this product. ............................................................................................................................................................................................................................................................ About this document vi Issue 1 February 2011 ............................................................................................................................................................................................................................................................ •Do not insert any sharp object into the products module openings or empty slots. Doing so may accidentally damage its parts. •Do not attach the power supply cable on building surfaces or floorings. Rest the power cable freely without any obstacle or heavy items piled on top of it. Refrain from abusing, stepping or walking on the cable. •To protect the equipment from overheating, do not block the slots and openings in the module housing that provide ventilation. •Exercise caution when installing or modifying telephone lines. Never install telephone wiring during inclement weather conditions (i.e., storm). •Electrostatic discharge (ESD) can permanently damage semiconductor devices. Always follow ESD-prevention guidelines for equipment handling and storage. Conventions used Important! Introduces important additional information. CAUTION: Warns that a failure to follow the recommended proced…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

64.5mm 49.5mm R1 BACK LABEL DSL-6300V FCC ID: KA2SL6300VA1 US: 3P7DL01BSL6300VA1 THIS PRODUCT COMPLIES WITH 47 CFR PART 68 15V 1A Polarity: Input: P/N:BSL6300VAUS..A1 MADE IN CHINA HW Ver.:A1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received,including interference that may cause undesired operation.

Page 2 Page 3 Page 4 Page 5 Page 6

FCC ID: KA2SL6300VA1 Report No.: RF110324C08 Operational Description This device is a VDSL2+ Bridge, which is powered by 12Vac by the power adapter. The highest operating frequency is 133MHz. The other instruction, please have a look at the users manual.

Report No.: FC110324C08 1 Report Format Version 4.0.0 FCC CERTIFICATION TEST REPORT REPORT NO.: FC110324C08 MODEL NO.: DSL-6300V FCC ID: KA2SL6300VA1 RECEIVED: Mar. 24, 2011 TESTED: Apr. 11 ~ Apr. 18, 2011 ISSUED: Apr. 19, 2011 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmann, Fountain Valley, CA, United States, 92708 ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. This test report consists of 28 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval or endorsement by TAF, NVLAP, NIST or any government agency. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. Report No.: FC110324C08 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD............................................................................................3 1 CERTIFICATION.....................................................................................................4 2 SUMMARY OF TEST RESULTS.............................................................................5 2.1 MEASUREMENT UNCERTAINTY...........................................................................5 3 GENERAL INFORMATION......................................................................................6 3.1 GENERAL DESCRIPTION OF EUT........................................................................6 3.2 DESCRIPTION OF TEST MODES..........................................................................7 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS..........................................7 3.4 DESCRIPTION OF SUPPORT UNITS....................................................................7 3.5 CONFIGURATION OF SYSTEM UNDER TEST......................................................8 4 TEST TYPES AND RESULTS.................................................................................9 4.1 CONDUCTED EMISSION MEASUREMENT...........................................................9 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................9 4.1.2 TEST INSTRUMENTS............................................................................................9 4.1.3 TEST PROCEDURES...........................................................................................10 4.1.4 DEVIATION FROM TEST STANDARD..................................................................10 4.1.5 TEST SETUP........................................................................................................11 4.1.6 EUT OPERATING CONDITIONS..........................................................................11 4.1.7 TEST RESULTS....................................................................................................12 4.2 RADIATED EMISSION MEASUREMENT..............................................................14 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................14 4.2.2 TEST INSTRUMENTS..........................................................................................15 4.2.3 TEST PROCEDURES...........................................................................................17 4.2.4 DEVIATION FROM TEST STANDARD..................................................................18 4.2.5 TEST SETUP........................................................................................................19 4.2.6 EUT OPERATING CONDITIONS..........................................................................19 4.2.7 TEST RESULTS....................................................................................................20 5 PHOTOGRAPHS OF THE TEST CONFIGURATION............................................24 6 INFORMATION ON THE TESTING LABORATORIES...........................................27 7 APPENDIX A – MODIFICATION RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB....................................................................................28 Report No.: FC110324C08 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Apr. 19, 2011 Report No.: FC110324C08 4 Report Format Version 4.0.0 1 CERTIFICATION PRODUCT: VDSL2+ Bridge BRAND: D-Link Corporation MODEL NO.: DSL-6300V APPLICANT: D-Link Corporation TESTED: Apr. 11 ~ Apr. 18, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARD: FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ICES-003: 2004, Class B ANSI C63.4: 2003 The above equipment (Model: DSL-6300V) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE : Apr. 19, 2011 Suntee Liu / Specialist APPROVED BY : , DATE : Apr. 19, 2011 David Liu / Senior Engineer Report No.: FC110324C08 5 Report Format Version 4.0.0 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications. EMISSION Standard Test Type Result Remarks Conducted emission test PASS Meet the requirement of limit Minimum passing margin is -14.04dB at 0.166MHz FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ICES-003: 2004, Class B Radiated emission test (30MHz~18GHz) PASS Meet the requirement of limi…

Text truncated - open the document above for the full version.

Report No.: FC110324C08 24 Report Format Version 4.0.0 5 PHOTOGRAPHS OF THE TEST CONFIGURATION Conducted Emission Test Report No.: FC110324C08 25 Report Format Version 4.0.0 Radiated Emission Test (Frequency range 30MHz~1GHz) Report No.: FC110324C08 26 Report Format Version 4.0.0 Radiated Emission Test (Frequency range above 1GHz)
