KA2SR500ACA1AC800 Selectable Dual Band VPN Business Router

Wireless AC Services Router User Manual DSR-150/150N/250/250N/500/500N/1000/1000N/500AC/1000AC Version 3.02 | May 14, 2015 D-Link DSR-Series User Manuali The information in this document is subject to change without notice. The manufacturer makes no representations or warranties with respect to the contents hereof and specifically disclaim any implied warranties of merchantability or fitness for any particular purpose. The manufacturer reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any person of such revision or changes. Manual Revisions RevisionDateDescription 2.00July 31, 2014• DSR Products with firmware version 2.00 2.01November 17, 2014• add License Update section 2.02January 28, 2015• DSR Products with firmware version 2.02 3.02May 06, 2015• applies to new DSR series models, DSR-500AC & DSR-1000AC Trademarks/Copyright Notice D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the United States or other countries. All other company or product names mentioned herein are trademarks or registered trademarks of their respective companies. © 2015 D-Link Corporation, All Rights Reserved This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Limitations of Liability UNDER NO CIRCUMSTANCES SHALL D-LINK OR ITS SUPPLIERS BE LIABLE FOR DAMAGES OF ANY CHARACTER (E.G. DAMAGES FOR LOSS OF PROFIT, SOFTWARE RESTORATION, WORK STOPPAGE, LOSS OF SAVED DATA OR ANY OTHER COMMERCIAL DAMAGES OR LOSSES) RESULTING FROM THE APPLICATION OR IMPROPER USE OF THE D-LINK PRODUCT OR FAILURE OF THE PRODUCT, EVEN IF D-LINK IS INFORMED OF THE POSSIBILITY OF SUCH DAMAGES. FURTHERMORE, DLINK WILL NOT BE LIABLE FOR THIRD-PARTY CLAIMS AGAINST CUSTOMER FOR LOSSES OR DAMAGES. D-LINK WILL IN NO EVENT BE LIABLE FOR ANY DAMAGES IN EXCESS OF THE AMOUNT D-LINK RECEIVED FROM THE END-USER FOR THE PRODUCT. Preface Preface D-Link DSR-Series User Manualii Use the following safety guidelines to ensure your own personal safety and to help protect your system from potential damage. Safety Cautions To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following precautions: • Observe and follow service markings. • Do not service any product except as explained in your system documentation. • Opening or removing covers that are marked with the triangular symbol with a lightning bolt may expose you to electrical shock. • Only a trained service technician should service components inside these compartments. • If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact your trained service provider: • The power cable, extension cable, or plug is damaged. • An object has fallen into the product. • The product has been exposed to water. • The product has been dropped or damaged. • The product does not operate correctly when you follow the operating instructions. • Keep your system away from radiators and heat sources. Also, do not block cooling vents. • Do not spill food or liquids on your system components, and never operate the product in a wet environment. If the system gets wet, see the appropriate section in your troubleshooting guide or contact your trained service provider. • Do not push any objects into the openings of your system. Doing so can cause fire or electric shock by shorting out interior components. • Use the product only with approved equipment. • Allow the product to cool before removing covers or touching internal components. • Operate the product only from the type of external power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your service provider or local power company. • Also, be sure that attached devices are electrically rated to operate with the power available in your location. • Use only approved power cable(s). If you have not been provided with a power cable for your system or for any AC powered option intended for your system, purchase a power cable that is approved for use in your country. The power cable must be rated for the product and for the voltage and current marked on the product’s electrical ratings label. The voltage and current rating of the cable should be greater than the ratings marked on the product. • To help prevent electric shock, plug the system and peripheral power cables into properly grounded electrical outlets. Safety Instructions Preface D-Link DSR-Series User Manualiii • These cables are equipped with three-prong plugs to help ensure proper grounding. Do not use adapter plugs or remove the grounding prong from a cable. If you must use an extension cable, use a 3-wire cable with properly grounded plugs. • Observe extension cable and power strip ratings. Make sure that the total ampere rating of all products plugged into the extension cable or power strip does not exceed 80 percent of the ampere ratings limit for the extension cable or power strip. • To help protect your system from sudden, transient increases and decreases in electrical power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS). • Position system cables and power cables carefully; route cables so that they cannot be stepped on or tripped over. Be sure that nothing rests on any cables. • Do not modify power cables or plugs. Consult a licensed electrician or your power company for site modifications. • Always follow your local/national wiring rules. • When connecting or disconnecting power to hot-pluggable power supplies, if offered with your system, observe the following guidelines: • Install the power supply before connecting the power cable to…

Text truncated - open the document above for the full version.

Report No. : EP4N2636 SPORTON International Inc. Page No. : 1 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Photographs of EUT Report No. : EP4N2636 SPORTON International Inc. Page No. : 2 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 3 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 4 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 5 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973

80.00 mm H/W Ver.:A1 F/W Ver.:X.XXXXX_XX MADE IN CHINA 35.0 mm SCP S/N:XXXXXymXXXXXX P/N:XXXXXXXXXX...A1 MAC ID:XXXXXXXXXXXX (C) FCC ID:KA2SR500ACA1 IC:4216A-SR500ACA1 DSR-500AC This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1)this device may not cause harmful interference and (2)this device must accept any interference received, including interference that may cause undesired operation. Model:DSR-500AC CAN ICES-3(B)/NMB-3(B) Label Location

Report No. : EP4N2636 SPORTON International Inc. Page No. : 6 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 7 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 8 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 9 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 10 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 11 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 12 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 13 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 14 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 15 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 16 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 17 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 18 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973 Report No. : EP4N2636 SPORTON International Inc. Page No. : 19 of 19 TEL : 886-3-327-3456 FAX : 886-3-327-0973

RF Exposure Report Report No. : FA4N2636 SPORTON INTERNATIONAL INC. Page No. : 1 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1 Maximum Permissible Exposure 1.1 Maximum Permissible Exposure 1.1.1 Limit of Maximum Permissible Exposure Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 Note 1: f = frequency in MHz ; *Plane-wave equivalent power density Note 2: For the applicable limit, see FCC 1.1310 RF Exposure Report Report No. : FA4N2636 SPORTON INTERNATIONAL INC. Page No. : 2 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 RF Field Strength Limits for Controlled Use Devices (Controlled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 600 4.9 - 6 1-10 600/ƒ 4.9/ƒ - 6 10-30 60 4.9/ƒ - 6 30-300 60 0.163 10* 6 300-1500 3.54 ƒ 0.5 0.0094 ƒ 0.5 ƒ/30 6 1500-15000 137 0.364 50 6 15000-150000 137 0.364 50 616000/ƒ 1.2 150000-300000 0.354 ƒ 0.5 9.4 x 10-4 ƒ 0.5 3.33 x 10-4 ƒ 616000/ƒ 1.2 RF Field Strength Limits for Devices Used by the General Public (Uncontrolled Environment) Frequency Range (MHz) Electric Field (V/m rms) Magnetic Field (A/m rms) Power Density (W/m2) Averaging Time (minutes) 0.003-1 280 2.19 - 6 1-10 280/ƒ 2.19/ƒ - 6 10-30 28 2.19/ƒ - 6 30-300 28 0.073 2* 6 300-1500 1.585 ƒ 0.5 0.0042 ƒ 0.5 ƒ/150 6 1500-15000 61.4 0.163 10 6 15000-150000 61.4 0.163 10 616000/ƒ 1.2 150000-300000 0.158 ƒ 0.5 4.21 x 10 -4 ƒ 0.5 6.67 x 10 -5 ƒ 616000/ƒ 1.2 Note 1: ƒ is frequency in MHz. Note 2: For the applicable limit, see IC RSS-102 1.1.2 MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m 2 ) = 377 E 2 E = Electric field (V/m) P = RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 d377 GP30   RF Exposure Report Report No. : FA4N2636 SPORTON INTERNATIONAL INC. Page No. : 3 of 3 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 1.1.3 Result of Maximum Permissible Exposure Worst Maximum RF Output Power Result Exposure Environment General Population / Uncontrolled Exposure Separation Distance (cm) 20 Frequency Range (MHz) RF Output Power (dBm) Antenna Gain (dBi) EIRP Power (dBm) PD (S) (mW/cm²) Limit (mW/cm²) 2400-2483.5 22.89 2 24.890 0.061 1 5150-5250 23.07 2 25.070 0.064 1 5725-5850 23.92 2 25.920 0.078 1 Note 1: RF output power specifies that Maximum Conducted (Average) Output Power. MPE of Co-location evaluation: 2.4 and 5GHz can transmit at the same time, MPE evaluation is as below formula PD1 / Limit1 + PD2 / Limit 2 + ..... < 1 PD = Power density MPE of 2.4 + 5GHz = 0.061 / 1 + 0.078 / 1 = 0.139< 1

FCC Test Report Report No. : FR4N2636AN SPORTON INTERNATIONAL INC. Page No. : 1 of 49 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 FCC Test Report Equipment : AC800 Selectable Dual Band VPN Business Router Brand Name : D-Link Model No. : DSR-500AC FCC ID : KA2SR500ACA1 Standard : 47 CFR FCC Part 15.407 Operating Band : 5150 MHz – 5250 MHz FCC Classification : NII Applicant : D-Link Corporation 17595 Mt. Herrmann, Fountain Valley, CA 92708 U.S.A. The product sample received on Aug. 27, 2014 and completely tested on Jan. 05, 2015. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: James Fan / Assistant Manager FCC Test Report Report No. : FR4N2636AN SPORTON INTERNATIONAL INC. Page No. : 2 of 49 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 Table of Contents 1 GENERAL DESCRIPTION ............................................................................................................... 5 1.1 Information ........................................................................................................................................ 5 1.2 Accessories and Support Equipment ................................................................................................. 7 1.3 Testing Applied Standards ................................................................................................................ 7 1.4 Testing Location Information ............................................................................................................. 7 1.5 Measurement Uncertainty ................................................................................................................. 8 2 TEST CONFIGURATION OF EUT .................................................................................................... 9 2.1 The Worst Case Modulation Configuration ........................................................................................ 9 2.2 The Worst Case Power Setting Parameter ........................................................................................ 9 2.3 The Worst Case Measurement Configuration .................................................................................. 10 2.4 Test Setup Diagram ........................................................................................................................ 11 3 TRANSMITTER TEST RESULT ..................................................................................................... 12 3.1 AC Power-line Conducted Emissions .............................................................................................. 12 3.2 Emission Bandwidth ........................................................................................................................ 15 3.3 RF Output Power ............................................................................................................................ 17 3.4 Peak Power Spectral Density .......................................................................................................... 20 3.5 Transmitter Radiated Unwanted Emissions and Band Edge ............................................................ 23 3.6 Frequency Stability.......................................................................................................................... 46 4 TEST EQUIPMENT AND CALIBRATION DATA ............................................................................. 48 APPENDIX A. TEST PHOTOS .............................................................................................................A1-A5 FCC Test Report Report No. : FR4N2636AN SPORTON INTERNATIONAL INC. Page No. : 3 of 49 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna Requirement Antenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions [dBuV]: 0.3751190MHz 49.39 (Margin 9.00dB) - QP 45.12 (Margin 3.27dB) - AV FCC 15.207 Complied 3.2 15.407(a) Emission Bandwidth Bandwidth [MHz] 20M: 48.04 / 40M: 93.33 80M: 90.44 Information only Complied 3.3 15.407(a) RF Output Power (Maximum Conducted (Average) Output Power) Power [dBm] 5150-5250MHz: 23.07 Power [dBm] 5150-5250MHz: 30 Complied 3.4 15.407(a) Peak Power Spectral Density PPSD [dBm/MHz] 5150-5250MHz: 10.32 PPSD [dBm/MHz] 5150-5250MHz: 17 Complied 3.5 15.407(b) Transmitter Unwanted Emissions and Band Edge Restricted Bands [dBuV/m at 3m]: 5150.00MHz 52.99 (Margin 1.01dB) – AV Non-Restricted Bands: ≤ -27dBm (68.2dBuV/m@3m) Restricted Bands: FCC 15.209 Complied 3.6 15.407(g) Frequency Stability 3.0885 ppm Signal shall remain in-band Complied FCC Test Report Report No. : FR4N2636AN SPORTON INTERNATIONAL INC. Page No. : 4 of 49 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 Revision History Report No. Version Description Issued Date FR4N2636AN Rev. 01 Initial issue of report Feb. 04, 2015 FR4N2636AN Rev. 02 Modify ANSI C63.10 version May 21, 2015 FCC Test Report Report No. : FR4N2636AN SPORTON INTERNATIONAL INC. Page No. : 5 of 49 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) RF Output Power (dBm) Co-location 5150-5250 a 5180-5240 36-48 [4] 2 23.03 No 5150-5250 n(HT20) 5180-5240 36-48 [4] 2 23.03 No 5150-5250 n(HT40) 5190-5230 38-46 [2] 2 22.45 No 5150-5250 ac(VHT20) 5180-5240 36-48 [4] 2 23.07 No 5150-5250 a…

Text truncated - open the document above for the full version.

FCC Test Report Report No. : FR4N2636AI SPORTON INTERNATIONAL INC. Page No. : 1 of 50 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 FCC Test Report Equipment : AC800 Selectable Dual Band VPN Business Router Brand Name : D-Link Model No. : DSR-500AC FCC ID : KA2SR500ACA1 Standard : 47 CFR FCC Part 15.407 Operating Band : 5725 MHz – 5850 MHz FCC Classification : NII Applicant : D-Link Corporation 17595 Mt. Herrmann, Fountain Valley, CA 92708 U.S.A. The product sample received on Aug. 27, 2014 and completely tested on Jan. 05, 2015. We, SPORTON, would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.10-2009 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: James Fan / Assistant Manager FCC Test Report Report No. : FR4N2636AI SPORTON INTERNATIONAL INC. Page No. : 2 of 50 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 Table of Contents 1 GENERAL DESCRIPTION ............................................................................................................... 5 1.1 Information ........................................................................................................................................ 5 1.2 Accessories and Support Equipment ................................................................................................. 7 1.3 Testing Applied Standards ................................................................................................................ 7 1.4 Testing Location Information ............................................................................................................. 7 1.5 Measurement Uncertainty ................................................................................................................. 8 2 TEST CONFIGURATION OF EUT .................................................................................................... 9 2.1 The Worst Case Modulation Configuration ........................................................................................ 9 2.2 The Worst Case Power Setting Parameter ........................................................................................ 9 2.3 The Worst Case Measurement Configuration .................................................................................. 10 2.4 Test Setup Diagram ........................................................................................................................ 11 3 TRANSMITTER TEST RESULT ..................................................................................................... 12 3.1 AC Power-line Conducted Emissions .............................................................................................. 12 3.2 Emission Bandwidth ........................................................................................................................ 15 3.3 RF Output Power ............................................................................................................................ 18 3.4 Peak Power Spectral Density .......................................................................................................... 21 3.5 Transmitter Radiated Unwanted Emissions and Band Edge ............................................................ 24 3.6 Frequency Stability.......................................................................................................................... 47 4 TEST EQUIPMENT AND CALIBRATION DATA ............................................................................. 49 APPENDIX A. TEST PHOTOS .............................................................................................................A1-A5 FCC Test Report Report No. : FR4N2636AI SPORTON INTERNATIONAL INC. Page No. : 3 of 50 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 Summary of Test Result Conformance Test Specifications Report Clause Ref. Std. Clause Description Measured Limit Result 1.1.2 15.203 Antenna Requirement Antenna connector mechanism complied FCC 15.203 Complied 3.1 15.207 AC Power-line Conducted Emissions [dBuV]:0.3751190MHz 49.31 (Margin 9.08dB) – QP 45.23 (Margin 3.16dB) – AV FCC 15.207 Complied 3.2 15.407(a) Emission Bandwidth 26dB Bandwidth [MHz] 20M: 52.09 / 40M: 84.26 80M: 89.04 6dB Bandwidth [MHz] 20M: 16.35 / 40M: 36.17 80M: 76.29 Information only for 26dB bandwidth 500kHz for 6dB bandwidth Complied 3.3 15.407(a) RF Output Power (Maximum Conducted (Average) Output Power) Power [dBm] 5725-5850MHz: 23.92 Power [dBm] 5725-5850MHz: 30 Complied 3.4 15.407(a) Peak Power Spectral Density PPSD [dBm/MHz] 5725-5850MHz: 7.27 PPSD [dBm/500kHz] 5725-5850MHz: 30 Complied 3.5 15.407(b) Transmitter Unwanted Emissions and Band Edge Restricted Bands [dBuV/m at 3m]: 5715.00MHz 52.96 (Margin 1.04dB) – AV Non-Restricted Bands: ≤ -27dBm (68.2dBuV/m@3m) Restricted Bands: FCC 15.209 Complied 3.6 15.407(g) Frequency Stability 3.7373 ppm Signal shall remain in-band Complied FCC Test Report Report No. : FR4N2636AI SPORTON INTERNATIONAL INC. Page No. : 4 of 50 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 Revision History Report No. Version Description Issued Date FR4N2636AI Rev. 01 Initial issue of report Feb. 04, 2015 FR4N2636AI Rev. 02 Modify ANSI C63.10 version May 21, 2015 FCC Test Report Report No. : FR4N2636AI SPORTON INTERNATIONAL INC. Page No. : 5 of 50 TEL : 886-3-3273456 Report Version : Rev. 02 FAX : 886-3-3270973 1 General Description 1.1 Information 1.1.1 RF General Information RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Freq. (MHz) Channel Number Transmit Chains (N TX ) RF Output Power (dBm) Co-location 5725-5850 a 5745-5825 149-165 [5] 2 23.66 No 5725-5850 n(HT20) 5745-5825 149-165 [5] 2 23.86 No 57…

Text truncated - open the document above for the full version.

Test Photos Report No. : FR4N2636 SPORTON INTERNATIONAL INC. Page No. : A1 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Appendix A. TEST PHOTOS 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Test Photos Report No. : FR4N2636 SPORTON INTERNATIONAL INC. Page No. : A2 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 SIDE VIEW Test Photos Report No. : FR4N2636 SPORTON INTERNATIONAL INC. Page No. : A3 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 2 Photographs of Radiated Emissions Test Configuration Below 1GHz test: FRONT VIEW REAR VIEW Test Photos Report No. : FR4N2636 SPORTON INTERNATIONAL INC. Page No. : A4 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 Above 1GHz test: FRONT VIEW REAR VIEW Test Photos Report No. : FR4N2636 SPORTON INTERNATIONAL INC. Page No. : A5 of A5 TEL : 886-3-327-3456 Report Version : Rev. 01 FAX : 886-3-327-0973 CLOSE VIEW
