Image1.jpg D-Link DWA-110 Quick Install Guide A computer or laptop with an available USB 2.0 port Windows ® 2000 or XP 300MHz processor and at least 64MB of RAM Properly installed and working USB Controller An 802.11g or 802.11b access point (for Infrastructure mode), or another 802.11g or 802.11b wireless adapter (for Ad-Hoc networking mode.) Package Contents System Requirements If any of the above items are missing, please contact your reseller. D-Link DWA-110 Wireless G USB 2.0 Adapter Cradle Manual, software, and warranty on CD 3D-Link DWA-110 Quick Install Guide Hardware Overview USB Port Used to connect the DWA-110 to your computer. 4D-Link DWA-110 Quick Install Guide The DWA-110 lets you access your stored data and media files using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines: 4 Keep the number of walls and ceilings between the DWA-110 other network devices to a minimum - each wall or ceiling can reduce your DWA-110’s range from 3-90 feet (1-30 meters.) Position your devices so that the number of walls or ceilings is minimized. 1 Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception. 2 3 Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise. Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect on range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use. 5 Wireless Installation Considerations

5D-LinkDWA-110 Quick Install Guide TurnonthecomputerandInserttheD-LinkDWA-110DriverCDinthe CD-ROMdrive. Thestep-by-stepinstructionsthatfollowareshownin Windows ® XP.ThestepsandscreensaresimilarfortheotherWindows ® operatingsystems. Note: Do NOTinstall the DWA-110 Wireless G USB Adapter into your computer before installing the driver software from the D-Link CD! Click Install Drivers. IftheCDAutorunfunctiondoesnotautomaticallystartonyourcomputer, type“D:\Drivers\setup.exe”.Ifitdoesstart,proceedtothenextscreen. Software Installation DWA-110 6D-LinkDWA-110 Quick Install Guide The InstallShield Wizard window will appear. Click Next to continue. By default setup will install to the default location: C:\Program Files\ Wireless G DWA-110, where C: represents the drive letter of your hard drive. To install to a different location click Browse and specify the location. Click Next. Select the Program Files folder location. Click Next to continue. DWA-110 DWA-110 DWA-110

7D-Link DWA-110 Quick Install Guide The D-Link configuration wizard will now appear. If you are using Windows ® XP (SP2), you will have the option to use either the D-Link utility or the built-in Windows ® Wireless utility. Click Next to continue. Insert the adapter into an available USB port on your computer. Optional: If desired or necessary, attach the cradle between the DWA- 110 and your computer. If the Found New Hardware Wizard appears, click Cancel. Click Next to continue. Enter the network name (SSID). If you enter the SSID incorrectly, you will automatically be brought to the site survey page. Click Next to continue or click Scan to display the site survey page. DWA-110 DWA-110 DWA-110 8D-Link DWA-110 Quick Install Guide Click the Scan button to display a list of wireless networks (site survey). Click on the network name (SSID) and click Connect. If the wireless network you are trying to connect to is encrypted, enter the WEP key or WPA-PSK passphrase. Click Next to continue. Click Finish to continue. If you are prompted to reboot your computer, select Yes, I want to restart my computer now. DWA-110 DWA-110 DWA-110 D-Link DWA-110 Quick Install Guide Hold the USB adapter with both hands. Apply little force to slowly pull out the cover from both sides. Insert th e DWA-110 into an available USB port on your computer. Optional: If desired or necessary, attach the cradle between the DWA-110 and your computer. USB Installation 10D-Link DWA-110 Quick Install Guide Connect to a Wireless Network The DWA-110 uses the Configuration Utility as the management software. The utility provides the user an easy interface to change any settings related to the wireless adapter. After you have completed the installation of the DWA-110 and whenever you start the computer, the Configuration Utility starts automatically and the system tray icon is loaded in the toolbar. Clicking on the utility icon will start the Configuration Utility. If you are using Windows ® XP, please skip to page 11. This window will allow you to see available wireless networks in your area. Simply click the network (SSID) you want to connect to and click the Connect button. If you are connecting to a secure network, you will be prompted to enter the encryption key. Please refer to the Wireless Security section in the manual located on the D-Link CD. 11D-Link DWA-110 Quick Install Guide Windows ® XP users may use the built-in wireless utility. The following instructions are for Service Pack 2 users. If you receive the Wireless Networks Detected bubble, click on the center of the bubble to access the utility. Yo u may also right-click on the wireless computer icon in your system tray (lower-right corner next to the time). Select View Available Wireless Networks. The utility will display any available wireless networks in your area. Click on a network and click the Connect button. Refer to the manual for information on connecting to a secure network. Windows ® XP Configuration Utility FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. RF exposure warning: The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. SAR has been evaluated with a laptop as host and the maximum SAR value is as below. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter. SAR Value: 802.11b: 0.075 W/kg 802.11g:0.08 W/kg Industry Canada regulatory information Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The user is cautioned that this device should be used only as specified within this manual to meet RF exposure requirements. Use of this device in a manner inconsistent with this manual could lead to excessive RF exposure conditions. D-Link DWA-110 Quick Install Guide Technical Support D-Link’s website contains the latest user documentation and software updates for D-Link products. U.S. and Canadian customers can contact D-Link Technical Support through our website or by phone. United States Telephone (877) 453-5465 Twenty four hours a day, seven days a week. World Wide Web http://support.dlink.com E-mail [email protected] Canada Telephone (800) 361-5265 Monday through Friday, 7:30am to 9:00pm EST. World Wide Web http://support.dlink.ca E-mail [email protected] Version 1.0 Revised 12/15/2005 6WUA1340Q.01G Copyright ©…

Text truncated - open the document above for the full version.



Report No： 071H061-RFUSP05V01 Page: 69 of 75 Version:1.0 Attachement ÿ EUT Photograph (1) EUT Photo (2) EUT Photo

FCC ID Label The FCC ID Label will be placed on the equipment as shown in the photograph below. Wireless G USB Adapter Model No.: DWA-110, WUA-1340, WUS-G14 F F C C C C I I D D : : KA2WA110A1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

FCC ID Label The FCC ID Label will be placed on the equipment as shown in the photograph below. Wireless G USB Adapter Model No.: DWA-110, WUA-1340, WUS-G14 F F C C C C I I D D : : KA2WA110A1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

Report No： 071H061-RFUSP05V01 Page: 70 of 75 Version:1.0 (3) EUT Photo (4) EUT Photo Report No： 071H061-RFUSP05V01 Page: 71 of 75 Version:1.0 (5) EUT Photo (6) EUT Photo Report No： 071H061-RFUSP05V01 Page: 72 of 75 Version:1.0 (7) EUT Photo (8) EUT Photo Report No： 071H061-RFUSP05V01 Page: 73 of 75 Version:1.0 (9) EUT Photo Report No： 071H061-RFUSP05V01 Page: 74 of 75 Version:1.0 (10) EUT Photo Report No： 071H061-RFUSP05V01 Page: 75 of 75 Version:1.0 (11) EUT Photo

Report No： 071H061-RFUSP05V01 Page: 6 of 75 Version:1.0 1.2. Operational Description The EUT is an 802.11g /802.11b access point (for Infrastructure mode), or another 802.11g or 802.11b wireless adapter (for Ad-Hoc networking mode).It lets you access your stored data and media files using a wireless connection from virtually anywhere within the operating range of your wireless network. Keep in mind, however, that the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. Keep your product away (at least 3-6 feet or 1-2 meters) from electrical devices or appliances that generate RF noise. Building Materials make a difference. A solid metal door or aluminum studs may have a negative effect on range. Try to position access points, wireless routers, and computers so that the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (fish tanks), mirrors, file cabinets, brick, and concrete will degrade your wireless signal. If you are using 2.4GHz cordless phones or X-10 (wireless products such as ceiling fans, lights, and home security systems), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.

Report No：071H061 Page: 1 of 22 Version:1.0 SAR Test Report Product Name ： Wireless G USB Adapter Model No. ：DWA-110, WUA-1340, WUS-G14 Applicant ： D-Link Corporation Address ： No.289, Sinhu 3rd Rd, Neihu District, Taipei 114, Taiwan, R.O.C. Date of Receipt ：2007/01/19 Issued Date ：2007/03/23 Report No. ：071H061 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：071H061 Page: 2 of 22 Version:1.0 Test Report Certification Issued Date: 2007/03/23 Report No.: 071H061 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Product Name ： Wireless G USB Adapter Applicant ： D-Link Corporation Address ： No.289, Sinhu 3rd Rd, Neihu District, Taipei 114, Taiwan, R.O.C. Manufacturer ： Alpha Networks Inc. Model No. ： DWA-110, WUA-1340, WUS-G14 FCC ID : KA2WA110A1 Trade Name ： D-Link, Non-brand Applicable Standard ： FCC Oet65 Supplement C June 2001 Test Result ： Max. SAR Measurement (1g) 802.11b: 0.075 W/kg 802.11g: 0.08 W/kg Application Type Certification Documented By ： (Engineering Adm. Assistant / Eva Huang) Tested By ： (Senior Engineer / Shine Hsu) Approved By ： (President / Gene Chang) Report No：071H061 Page: 3 of 22 Version:1.0 TABLE OF CONTENTS Description Page 1. General Information.............................................................................. 5 1.1 EUT Description ............................................................................................................5 1.2 Test Environment ...........................................................................................................5 2. SAR Measurement System .................................................................. 6 2.1 ALSAS-10U System Description .................................................................................. 6 2.1.1 Applications ................................................................................................................ 6 2.1.2 Area Scans................................................................................................................... 6 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 7 2.1.4 ALSAS-10U Interpolation and Extrapolation Uncertainty......................................... 7 2.2 Isotropic E-Field Probe .................................................................................................. 7 2.2.1 Isotropic E-Field Probe Specification ......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device ................................................. 9 2.4 Daq-Paq (Analog to Digital Electronics) ..................................................................... 10 2.5 Axis Articulated Robot ................................................................................................ 10 2.6 ALSAS Universal Workstation.................................................................................... 11 2.7 Universal Device Positioner......................................................................................... 11 2.8 Phantom Types............................................................................................................. 11 2.8.1 APREL SAM Phantoms ........................................................................................... 12 2.8.2 APREL Laboratories Universal Phantom ................................................................. 12 3. Tissue Simulating Liquid ................................................................... 13 3.1 The composition of the tissue simulating liquid .......................................................... 13 3.2 Tissue Calibration Result ............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms ....................................... 14 4. SAR Measurement Procedure ........................................................... 15 4.1 SAR System Validation................................................................................................ 15 4.1.1 Validation Dipoles..................................................................................................... 15 4.1.2 Validation Result ....................................................................................................... 15 4.2 SAR Measurement Procedure ...................................................................................... 16 5. SAR Exposure Limits ......................................................................... 17 6. Test Equipment List............................................................................ 18 7. Measurement Uncertainty .................................................................. 19 8. Test Results ......................................................................................... 20 Report No：071H061 Page: 4 of 22 Version:1.0 8.1 SAR Test Results Summary ......................................................................................... 20 Appendix A. SAR System Validation Data........................................................................ 22 Appendix B. SAR measurement Data................................................................................ 22 Appendix C. Test Setup Photographs & EUT Photographs............................................... 22 Appendix D. Probe Calibration Data ................................................................................. 22 Appendix E. Dipole Calibration Data ................................................................................ 22 Report No：071H061 Page: 5 of 22 Version:1.0 1. General Information 1.1 EUT Description Product Name Wireless G USB Adapter Trade Name D-Link, Non-b…
