KA2WA182A1Wireless 802.11ac Dual Band USB Adapter

D-Link Corporation
Wireless 802.11ac Dual Band USB Adapter - FCC ID KA2WA182A1 - D-Link Corporation
Click to zoom

Application Details

Equipment Class
NII - Unlicensed National Information Infrastructure TX
Date of Grant
Aug 19, 2012
Application Purpose
Original Equipment
Date of Application
Aug 19, 2012
Equipment Note
Wireless 802.11ac Dual Band USB Adapter
Frequency Range
5180.00000000 - 5240.00000000
Company
D-Link Corporation
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wireless 802.11ac Dual Band USB Adapter 2 D-Link DWA-182 User Manual Table of Contents Product Overview .............................................................. 3 Package Contents ......................................................................... 3System Requirements ................................................................. 3Introduction ................................................................................... 4Features ............................................................................................ 5Hardware Overview ..................................................................... 6 Installation ......................................................................... 7 Getting Started .............................................................................. 7 Remove Existing Installations .......................................... 7Disable Other Wireless Adapters ..................................... 8 Wireless Installation Considerations ....................................10Adapter Installation ...................................................................11 Configuration ................................................................... 17 D-Link Wireless Connection Manager .................................17 Wireless Networks ..............................................................18Wi-Fi ® Protected Setup (WPS) .........................................19 My Wireless Networks .......................................................23 Add Profile .......................................................................24Modify Profile .................................................................25 Support ..................................................................................26About ......................................................................................27 Connect to a Wireless Network ....................................... 28 Windows® 7 ...................................................................................28Windows® XP ................................................................................29 Wireless Security ............................................................. 30 What is WPA ™ ? ..............................................................................30 Configure WPA/WPA2-Personal .............................................31 Using the D-Link Wireless Connection Manager .....31Windows® 7 ...........................................................................33Windows® XP ........................................................................36 Configure WPA/WPA2-Enterprise .........................................38 Troubleshooting .............................................................. 39 Windows® 7 Troubleshooting ................................................42 Wireless Basics ................................................................. 44 Wireless Modes ............................................................................48 Networking Basics ........................................................... 49 Check your IP address ...............................................................49 Windows® XP Users ............................................................49Windows® 7 Users ...............................................................49 Statically Assign an IP Address ..............................................50 Windows® XP Users ............................................................50Windows® 7 Users ...............................................................51 Technical Specifications .................................................. 52Contacting Technical Support ........................................ 53Warranty ........................................................................... 54Registration ..................................................................... 60 Table of Contents 3 D-Link DWA-182 User Manual Section 1 - Product Overview D-Link DWA-182 Wireless 802.11ac Dual Band USB AdapterCradleCD with drivers and software System Requirements t "DPNQVUFSPSMBQUPQXJUIBOBWBJMBCMF64#QPSUt 8JOEPXT¥PS91 4FSWJDF1BDL t$%30.%SJWFt .)[QSPDFTTPSBOEBUMFBTU.#PG3".t "BD ESBGU O HPSBBDDFTTQPJOU PSXJSFMFTTSPVUFS Product Overview Package Contents 4 D-Link DWA-182 User Manual Section 1 - Product Overview Introduction The Wireless AC1200 Dual Band USB Adapter (DWA-182) delivers powerful wireless AC technology to your desktop or notebook comput er. Simply QMVHUIFBEBQUFSJOUPBOBWBJMBCMF64#QPSUBOEDPOOFDUUPBXJ SFMFTTOFUXPSLUPBDDFTTBTFDVSF IJHITQFFEJOUFSOFUDPOOFDUJ POo()[ .CQT  PS()[ VQUP.CQT "OEXJUIJOUFHSBUFE%VBM#BOEUFDIOPMP HZ ZPVMMIBWFSFEVDFE8J'JJOUFSGFSFODFUPNBYJNJ[FUISPVHIQ VUGPSGBTUFS TUSFBNJOH HBNJOH BOE4LZQFDBMMTInterference-Free Bandwidth5IF8JSFMFTT"$%VBM#BOE64#"EBQUFS %8" EFMJWFST%VB M#BOEUFDIOPMPHZUPZPVSIPNFOFUXPSLGPSJOUFMMJHFOU WFSTBUJ MF JOUFSGFSFODF GSFFCBOEXJEUI$IFDLZPVSFNBJMBOETVSGUIF*OUFSOFUPOUIF ()[CBOEPSHBNF NBLF4LZQFDBMMTBOETUSFBN)%NPWJFTUPN VMUJQMFEFWJDFT VTJOHUIFDMFBOFS JOUFSGFSFODFGSFF()[CBOE8IBUFWFSZPVMJ LFUPEPPOMJOF %VBM#BOEIBTZPVDPWFSFE Easy WPS Push Button Setup2VJDLMZBOEFBTJMZFTUBCMJTIB GBTU TFDVSFIPNFOFU XPSLUIBUX JMMIBWFZPVCSPXTJOH TUSFBNJOH BOEXBUDIJOHJONJOVUFT*UT BTFBTZBTQVTIBOE connect!Compatible With All Your Wireless Products8IJMFUIF8JSFMFTT"$%VBM#BOE64#"EBQUFSEFMJWFSTDVUUJO HFEHFBDTQFFEUPZPVSIPNFOFUXPSL JUTBMTPCBDLXBSE DPNQBUJCMFXJUI BMMPGZPVSDVSSFOUXJSFMFTTQSPEVDUToOPVQEBUFTPSBEBQUFST OFDFTTBSZ What is wireless AC?BDJTBOFXOFUXPSLJOHTUBOEBSEUIBUQSPEVDFTIJHIUISPVH IQVUXJSFMFTTTQFFEPOUIF()[CBOE8IBUEPFTUIJTNFBOGPSZ PVSIPNF OFUXPSL 'MBXMFTT)%WJEFPTUSFBNJOH…

Text truncated - open the document above for the full version.

External Photos

Report No.: 120702E04 1 of 4 CONSTRUCTION PHOTOS OF EUT Report No.: 120702E04 2 of 4 Report No.: 120702E04 3 of 4

ID Label/Location Info

FCC ID: KA2WA182A1 LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. LABEL Location LABEL Drawing

Internal Photos

Report No.: 120702E04 1 of 2 CONSTRUCTION PHOTOS OF EUT Report No.: 120702E04 2 of 2

RF Exposure Info

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 22 Report No. : SA120702E04 Issued Date : Jul. 26, 2012 Revision : R01 FCC SAR Test Report Report No. : SA120702E04 Applicant : D-Link Corporation Address : No. 289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. Product : Wireless 802.11ac Dual Band USB Adapter FCC ID : KA2WA182A1 Brand : D-Link Model No. : DWA-182 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1991 / IEEE 1528:2003 FCC OET Bulletin 65 Supplement C (Edition 01-01) KDB 248227 D01 v01r02 / KDB 447498 D01 v04 / KDB 447498 D02 v02 Date of Testing : Jul. 09, 2012 ~ Jul. 26, 2012 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch - Taiwan HwaYa Lab, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Pettie Chen / Specialist Approved By : Roy Wu / Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 22 Report No. : SA120702E04 Issued Date : Jul. 26, 2012 Revision : R01 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ................................................................................................................ 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot .................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 12 3.4 SAR Measurement Procedure ................................................................................................................................... 13 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 13 3.4.2 Volume Scan Procedure ................................................................................................................................... 13 3.4.3 Power Drift Monitoring ...................................................................................................................................... 13 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................................... 14 3.4.5 SAR Avera…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF120702E04 1 of 91 Report Format Version 5.0.0 Cancels and replaces the report No.: IC120322E03 dated Apr. 10, 2012 FCC TEST REPORT (15.247) REPORT NO.: RF120702E04 MODEL NO.: DWA-182 FCC ID: KA2WA182A1 RECEIVED: July 02, 2012 TESTED: July 03 to 17, 2012 ISSUED: July 31, 2012 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120702E04 2 of 91 Report Format Version 5.0.0 Cancels and replaces the report No.: IC120322E03 dated Apr. 10, 2012 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 8 3. GENERAL INFORMATION ..................................................................................... 9 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 9 3.2 DESCRIPTION OF TEST MODES ....................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 16 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 17 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 18 4. TEST TYPES AND RESULTS (FOR 2.4GHZ, 2.400 ~ 2.4835GHZ BAND)........... 19 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 19 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 19 4.1.2 TEST INSTRUMENTS .......................................................................................... 19 4.1.3 TEST PROCEDURES .......................................................................................... 20 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 20 4.1.5 TEST SETUP ....................................................................................................... 21 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 21 4.1.7 TEST RESULTS ................................................................................................... 22 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 24 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 24 4.2.2 TEST INSTRUMENTS .......................................................................................... 25 4.2.3 TEST PROCEDURES .......................................................................................... 27 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 27 4.2.5 TEST SETUP ....................................................................................................... 28 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 28 4.2.7 TEST RESULTS ................................................................................................... 29 4.3 6DB BANDWIDTH MEASUREMENT ................................................................... 42 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT ................................................. 42 4.3.2 TEST INSTRUMENTS .......................................................................................... 42 4.3.3 TEST PROCEDURE ............................................................................................. 42 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 42 4.3.5 TEST SETUP ......................................................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF120702E04-1 1 of 61 Report Format Version 5.0.0 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 FCC TEST REPORT (15.407) REPORT NO.: RF120702E04-1 MODEL NO.: DWA-182 FCC ID: KA2WA182A1 RECEIVED: July 02, 2012 TESTED: July 02 to 09, 2012 ISSUED: July 31, 2012 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF120702E04-1 2 of 61 Report Format Version 5.0.0 Cancels and replaces the report No.: IC120210E05-1 dated Apr. 10, 2012 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 16 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 17 4. TEST TYPES AND RESULTS .............................................................................. 18 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 18 4.1.2 TEST INSTRUMENTS .......................................................................................... 18 4.1.3 TEST PROCEDURES .......................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 19 4.1.5 TEST SETUP ....................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 20 4.1.7 TEST RESULTS ................................................................................................... 21 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 23 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 23 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 24 4.2.3 TEST INSTRUMENTS .......................................................................................... 25 4.2.4 TEST PROCEDURES .......................................................................................... 27 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 27 4.2.6 TEST SETUP ....................................................................................................... 28 4.2.7 EUT OPERATING CONDITION ............................................................................ 28 4.2.8 TEST RESULTS ................................................................................................... 29 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 39 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 39 4.3.2 TEST INSTRUMENTS .......................................................................................... 39 4.3.3 TEST PROCEDURE ............................................................................................. 39 4.…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: 120702E04 1 of 3 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 120702E04 2 of 3 RADIATED EMISSION TEST (Below 1GHz) Report No.: 120702E04 3 of 3 RADIATED EMISSION TEST (Above1GHz)

Test Setup Photos

FCC SAR Test Report Report Format Version 5.0.0 Issued Date : Jul. 20, 2012 Report No. : SA120702E04 Revision : R01 Appendix D. Photographs of EUT and Setup FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA120702E04 Revision : R01 <Photographs of EUT> EUT Front View EUT Rear View EUT Front View EUT Rear View Ant‐0 Ant‐1 FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA120702E04 Revision : R01 USB Horizontal Up with 0.5 cm Gap USB Horizontal Down with 0.5 cm Gap USB Vertical Front with 0.5 cm Gap USB Vertical Back with 0.5 cm Gap Dongle Tip with 0.5 cm Gap

Contact Information

Applicant

Brett Adair(General Counsel)
[email protected]714-885-6000Fax: 866-743-4589

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchHank Chung
[email protected]886-3-593-5343

81-1, Lu Laio Keng, 9th Ling, Wu Lung Tsuen, Chiun · Hsinchu Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchCeline Chou
[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-3-3183232Fax: 886 3 2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
115E5.18 GHz - 5.24 GHz44.00 mW
Confidentiality
Long Term
Grant Notes
Power listed is the maximum combined conducted output power. SAR compliance has been established in the laptop computer(s) configurations with USB slot(s) configurations as tested in this filing, and can be used in laptop computers with substantially similar physical dimensions, construction, and electrical and RF characteristics. Compliance of this device in all final host configurations is the responsibility of the Grantee. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz channel bandwidth modes. The highest reported SAR value for body-worn use condition is 1.18 W/kg.
