KA2WA582A1Wireless AC1200 Dual Band PCI Express Adapter

Version 1.0 06/12/2014 Wireless AC1200 Dual Band PCI Express Adapter DWA-582 User Manual 2D-Link DWA-582 User Manual Table of Contents Product Overview ..............................................................3 Package Contents ...........................................................................3 System Requirements ...................................................................3 Introduction .....................................................................................4 Features ..............................................................................................5 Hardware Overview .......................................................................6 LEDs .................................................................................................6 Installation .........................................................................7 Getting Started ................................................................................7 Remove Existing Installations ................................................7 Disable Other Wireless Adapters ...........................................8 Wireless Installation Considerations ......................................10 Driver/Software Installation .....................................................11 Hardware Installation ..................................................................14 Connect to your Wireless Network .....................................15 Manual Connect ........................................................................17 Configuration ...................................................................20 D-Link Wireless Connection Manager ...................................20 Wireless Networks ....................................................................21 My Wireless Networks .............................................................22 Support ........................................................................................25 About ............................................................................................26 Connect to a Wireless Network .......................................27 Using Windows® 7 ........................................................................27 Connect to a Wireless Network .......................................28 Using Windows Vista® .................................................................28 Using Windows® XP .....................................................................29 Wireless Security .............................................................30 What is WPA™? ...............................................................................30 Configure WPA/WPA2-Personal ...............................................31 Using the D-Link Utility ..........................................................31 Using Windows Vista® .............................................................36 Using Windows ® XP ..................................................................38 Configure WPA/WPA2-Enterprise ...........................................40 Using the D-Link Utility ..........................................................40 Troubleshooting ..............................................................41 Windows ® 7 Troubleshooting ...................................................46 Wireless Basics .................................................................48 Networking Basics ...........................................................52 Check your IP address .................................................................52 Windows ® XP/2000 Users .......................................................52 Windows 7/Vista ® Users ..........................................................52 Statically Assign an IP address .................................................53 Windows ® XP/2000 Users .......................................................53 Windows 7/Vista ® Users ..........................................................54 Technical Specifications ..................................................55 Table of Contents 3D-Link DWA-582 User Manual Section 1 - Product Overview System Requirements • A desktop computer with an available 64-bit PCI Express slot • 1Ghz processor / 512 MB RAM / 200 MB available space / CD-ROM drive • Windows® 7, Vista®, or XP (Service Pack 2 or higher) • An access point or wireless router Product Overview Package Contents If any of the above items are missing, please contact your reseller. D-Link DWA-582 Wireless AC1200 Dual Band PCI Express Adapter Two Antennas Low Profile Bracket CD with drivers and software 4D-Link DWA-582 User Manual Section 1 - Product Overview Introduction The Dwa-582 Wireless AC1200 Dual Band PCI Express Adapter is a convenient wireless connectivity solution for desktops. The device installs into a desktops PCI Express slot. The Dwa-582 provides a fast wireless connection and a superior reception, 802.11n. The Dwa-582 is designed for use in homes and small businesses that demand higher networking. Maximize wireless performance by connecting the Wireless N 300 Dual band PCIe Desktop Adapter to a wireless N router and stay connected. The Dwa-582 supports WEP, WPA and WPA2 enhanced security. This feature greatly enhances personal data and prevents outside intrusion. The dual band technology in the Dwa-582 supports 2.4GHz or 5GHz wireless signals. This allows you to check e-mail and browse the Internet using the 2.4GHz band or stream HD movies and other media on the 5GHz band. The 5GHz band helps avoid interference by providing a cleaner wireless band for HD signals. • Maximum wireless signal rate derived from IEEE Standard 802.11g and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signa…

Text truncated - open the document above for the full version.

DFS client device channel plan and software operational declaration Date: 2014‐07‐21 We, D‐Link Coporation, declare that the device, FCC ID: KA2WA582A1Model Name: DWA‐582, does not have “Ad Hoc on non‐US frequencies” and/or “on DFS frequencies. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad‐hoc peer‐to‐peer modes. Below is the channel / frequency plan for the device Also, on DFS channels, the WLAN driver in the device operates under the control of an AP at all times, except when in ad‐hoc mode, on US non‐DFS channels. The device passively scans DFS frequencies until a master device is detected. The control of this functionality is not accessible to anyone under any conditions. Furthermore, the firmware is protected by special signature and CRC checksum. Signature and CRC checksum will be calculated and verified before firmware upgrade. Unauthorized modification to firmware will lead the failure of verification thus firmware upgrade is not allowed. Sincerely yours, ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ Shinglin Chung/ Director D‐Link Coporation Tel: +886‐2‐66000123#5819 Fax: +886‐55509988 E‐mail: [email protected] Monday, July 21, 2014 CH 1 2 3 4 5 6 7 8 9 10 11 Frequency (MHz) 2412 2417 2422 24272432 2437 2442 2447 2452 2457 2462 Scan Type Active Active Active ActiveActiveActiveActiveActive Active ActiveActive CH 36 38 40 42 44 48 52 54 56 58 60 Frequency (MHz) 5180 5190 5200 52105220 5240 5260 5270 5280 5290 5300 Scan Type Active Active Active ActiveActiveActivePassivePassive Passive PassivePassive CH 62 64 Frequency (MHz) 5310 5320 Scan Type Passive Passive CH 100 102 104 106 108 110 112 116 132 134 136 Frequency (MHz) 5500 5510 5520 55305540 5550 5560 5580 5660 5670 5680 Scan Type Passive Passive Passive PassivePassivePassivePassivePassive Passive PassivePassive CH 140 Frequency (MHz) 5700 Scan Type Passive CH 149 151 153 155 157 159 161 165 Frequency (MHz) 5745 5755 5765 57755785 5795 5805 5825 Scan Type Active Active Active ActiveActiveActiveActiveActive

Date: 2014‐07‐18 FCC ID: KA2WA582A1 To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Software Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours,

Report No.: 140612E02 Page 1 CONSTRUCTION PHOTOS OF EUT

Date: 2014/7/24 Date: 2014/7/24 Date: 2014/7/24 Title: DWA-582 Device Label Material: 50μ白亮特多龍(PET) Glossy White Polyester Film Modified drawing Drawn by: Vicky Su Checked by: Joyce Chiou Approved by: Joyce Chiou Coated: 25μ亮面特多龍(PET) Clear Polyester Film Unit: mm Cutting and Printing Tolerance: ±0.3mm Contents Tolerance: ±0.25mm Adhesive: 壓克力膠 Acrylic Scale: 1:1 Part No.: 9700000447DLG Rev.: 1.30Task ID: 4578 Original drawing 外印印刷稿 for printing 尺寸圖 outline dimension 44.62 36.62 7.6mm 5.2mm 6mm Colors: White Background & Texts Black Texts and logos FCC ID： KA2WA582A1 IC : 4216A-WA582A1 LABEL LOCATION Brad name : D-Link Model name : DWA-582A1

Report No.: 140612E02 Page 2 Report No.: 140612E02 Page 3 Report No.: 140612E02 Page 4 Report No.: 140612E02 Page 5

Report No.: SA140612E02 1 of 8 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA140612E02 MODEL NO.: DWA-582 FCC ID: KA2WA582A1 RECEIVED:June 12, 2014 TESTED:June 17 to 26, 2014 ISSUED:July 17, 2014 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA140612E02 2 of 8 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT ............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN ...................................................................................................... 6 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER .......................... 7 Report No.: SA140612E02 3 of 8 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA140612E02 Original release July 17, 2014 Report No.: SA140612E02 5 of 8 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA140612E02 6 of 8 Report Format Version 5.0.0 5. ANTENNA GAIN The antennas provided to the EUT, please refer to the following table: Antenna No. Transmitter Circuit Antenna Gain(dBi) < including cable loss> Frequency range (GHz ~ GHz) Antenna Type Connecter Type 1 Chain (0) 3.5 2.4~2.4835 Dipole R-SMA 4.5 5.15~5.850 2 Chain (1) 3.5 2.4~2.4835 Dipole R-SMA 4.5 5.15~5.850 Report No.: SA140612E02 7 of 8 Report Format Version 5.0.0 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For WLAN: 15.247(2.4GHz) 802.11b FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 126.183 3.50 20 0.05620 1.00 802.11g FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 430.527 3.50 20 0.19175 1.00 802.11n (HT20) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412 - 2462 738.584 3.50 20 0.32895 1.00 802.11n (HT40) FREQUENCY BAND (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2422 - 2452 483.42 3.50 20 0.21530 1.00 Report No.: SA140612E02 8 of 8 Report Format Version 5.0.0 For WLAN: 15.407(5GHz) 802.11a FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 5180 - 5240, 5260 - 5320, 5470 – 5600, 5650 - 5725 & 5745 - 5825 191.867 4.50 20 0.10758 1.00 NOTE: Directional gain = 10 log[(10 G1/20 + 10 G2/20 ) 2 / 2] = 6.33dBi. 802.11ac (VHT20) FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 5180 - 5240, 5260 - 5320, 5470 – 5600, 5650 - 5725 & 5745 - 5825 236.671 4.50 20 0.13270 1.00 NOTE: Directional gain = 10 log[(10G1/20 + 10G2/20)2 / 2] = 6.33dBi. 802.11ac (VHT40) FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 5190 - 5230, 5270 - 5310…

Text truncated - open the document above for the full version.

Report No.: RF140612E02-2 1 of 26 Report Format Version 5.0.0 DFS TEST REPORT REPORT NO.: RF140612E02-2 MODEL NO.: DWA-582 FCC ID: KA2WA582A1 RECEIVED: June 12, 2014 TESTED: July 01, 2014 ISSUED: July 17, 2014 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140612E02-2 2 of 26 Report Format Version 5.0.0 Table of Contents RELEASE CONTROL RECORD ............................................................................. 3 1. CERTIFICATION ........................................................................................... 4 2. EUT INFORMATION ..................................................................................... 5 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT .......................... 5 2.2 EUT SOFTWARE AND FIRMWARE VERSION ............................................ 5 2.3 DESCRIPTION OF AVAILABLE ANTENNAS TO THE EUT.......................... 5 2.4 EUT MAXIMUM CONDUCTED POWER ...................................................... 6 2.5 EUT MAXIMUM EIRP POWER ..................................................................... 7 2.6 TRANSMIT POWER CONTROL (TPC) ........................................................ 8 2.7 STATEMENT OF MAUNFACTURER ............................................................ 8 3. U-NII DFS RULE REQUIREMENTS ............................................................. 9 3.1 WORKING MODES AND REQUIRED TEST ITEMS .................................... 9 3.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS ................................. 11 4. TEST & SUPPORT EQUIPMENT LIST ...................................................... 14 4.1 TEST INSTRUMENTS ................................................................................ 14 4.2 DESCRIPTION OF SUPPORT UNITS ....................................................... 14 5. TEST PROCEDURE ................................................................................... 15 5.1 BVADT DFS MEASUREMENT SYSTEM: ................................................... 15 5.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL: .................... 16 5.3 DEVIATION FROM TEST STANDARD ....................................................... 17 5.4 CONDUCTED TEST SETUP CONFIGURATION ....................................... 17 5.4.1 CLIENT WITHOUT RADAR DETECTION MODE ....................................... 17 6. TEST RESULTS ......................................................................................... 18 6.1 SUMMARY OF TEST RESULTS ................................................................ 18 6.2 DETAILED TEST RESULTS ....................................................................... 19 6.2.1 TEST MODE: DEVICE OPERATING IN CLIENT WITHOUT RADAR DETECTION MODE. .................................................................................. 19 6.2.1.1 DFS DETECTION THRESHOLD ............................................................... 19 6.2.1.2 CHANNEL CLOSING TRANSMISSION AND CHANNEL MOVE TIME ...... 20 6.2.1.3 NON- OCCUPANCY PERIOD .................................................................... 21 6.2.1.4 NON-ASSOCIATED TEST ......................................................................... 23 6.2.1.5 NON- CO-CHANNEL TEST ....................................................................... 23 7. INFORMATION ON THE TESTING LABORATORIES ................................ 24 8. APPENDIX-A .............................................................................................. 25 9. APPENDIX B - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB ...................................................... 26 Report No.: RF140612E02-2 3 of 26 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF140612E02-2 Original release July 17, 2014 Report No.: RF140612E02-2 5 of 26 Report Format Version 5.0.0 2. EUT INFORMATION 2.1 OPERATING FREQUENCY BANDS AND MODE OF EUT TABLE 1: OPERATING FREQUENCY BANDS AND MODE OF EUT OPERATIONAL MODE OPERATING FREQUENCY RANGE 5250~5350MHz 5470~5725MHz (5600~5650MHz will be disable) Client without radar detection and ad hoc function   2.2 EUT SOFTWARE AND FIRMWARE VERSION TABLE 2: THE EUT SOFTWARE/FIRMWARE VERSION PLATFORM NO. PRODUCT MODEL NO. SOFTWARE/FIRMWARE VERSION Windows 7 1 Wireless AC1200 Dual Band PCI Express Adapt…

Text truncated - open the document above for the full version.

Report No.: RF140612E02 1 of 59 Report Format Version 5.2.0 FCC TEST REPORT (15.247) REPORT NO.: RF140612E02 MODEL NO.: DWA-582 FCC ID: KA2WA582A1 RECEIVED: June 12, 2014 TESTED: June 17 to 19, 2014 ISSUED: July 17, 2014 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF140612E02 2 of 59 Report Format Version 5.2.0 Table of Contents RELEASE CONTROL RECORD .......................................................................................... 4 1. CERTIFICATION ....................................................................................................... 5 2. SUMMARY OF TEST RESULTS .............................................................................. 6 2.1 MEASUREMENT UNCERTAINTY ............................................................................ 7 3. GENERAL INFORMATION ....................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ......................................................................... 8 3.2 DESCRIPTION OF TEST MODES ......................................................................... 10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ......................... 11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ........................................ 14 3.4 DUTY CYCLE OF TEST SIGNAL ........................................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS ................................................................... 16 3.6 CONFIGURATION OF SYSTEM UNDER TEST .................................................... 16 4. TEST TYPES AND RESULTS ................................................................................ 17 4.1 CONDUCTED EMISSION MEASUREMENT ......................................................... 17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ....................................... 17 4.1.2 TEST INSTRUMENTS ............................................................................................ 17 4.1.3 TEST PROCEDURES ............................................................................................ 18 4.1.4 DEVIATION FROM TEST STANDARD................................................................... 18 4.1.5 TEST SETUP .......................................................................................................... 18 4.1.6 EUT OPERATING CONDITIONS ........................................................................... 19 4.1.7 TEST RESULTS ..................................................................................................... 20 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................. 22 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 22 4.2.2 TEST INSTRUMENTS ............................................................................................ 23 4.2.3 TEST PROCEDURES ............................................................................................ 24 4.2.4 DEVIATION FROM TEST STANDARD................................................................... 24 4.2.5 TEST SETUP .......................................................................................................... 25 4.2.6 EUT OPERATING CONDITIONS ........................................................................... 25 4.2.7 TEST RESULTS ..................................................................................................... 26 4.3 6dB BANDWIDTH MEASUREMENT ...................................................................... 39 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ................................................... 39 4.3.2 TEST INSTRUMENTS ............................................................................................ 39 4.3.3 TEST PROCEDURE ............................................................................................... 39 4.3.4 DEVIATION FROM TEST STANDARD................................................................... 39 4.3.5 TEST SETUP ..........................................…

Text truncated - open the document above for the full version.

Report No.: RF140612E02-1 1 of 95 Report Format Version 5.3.0 FCC TEST REPORT (WLAN 15.407) REPORT NO.: RF140612E02-1 MODEL NO.: DWA-582 FCC ID: KA2WA582A1 RECEIVED: June 12, 2014 TESTED: June 18 to 26, 2014 ISSUED: July 17, 2014 APPLICANT: D-Link Corporation ADDRESS: No.289, Sinhu 3rd Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or no…
