KA2WM158D1DC-HSPA+USB ADAPTER

DC‐HSPA+ USB Adapter DWM‐158 User Manual Index DC‐HSPA+ USB Adapter Introduction ............................ 2 Internet service .............................................................. 5 SMS service .................................................................... 6 Contacts ....................................................................... 10 Voice Call ...................................................................... 13 USSD ............................................................................. 14 Settings ........................................................................ 15 FAQs ............................................................................. 19 DC‐HSPA+ USB ADAPTER INTRODUCTION 1. To launch the Network Connect, double‐click the shortcut icon on the desktop. It should be noted that:  If the PIN code enabled, enter the correct one, then click OK. The (U)SIM will be locked after three retries of incorrect PIN code inputting;  Enter the correct PUK to retrieve the default PIN code. After ten retries of incorrect PUK code inputting, please contact with your service provider;  With the wrong PIN and PUK, all the network services are unavailable. 2. Main interface introduction : Connection : Access to the Text Message : Access to the Phonebook interface ：Access to Voice call interface : Access to USSD : Access to check usage statistics : Set parameters options : Help (User Manual) 3. Status information Status Description New message New message(s) arrived. Message full Indicates the (U)SIM’s storage of SMS No device Indicates that system cannot find the device. Initializing Indicates that the device is in the process Searching The device is searching for the network. No service No suitable network. No (U)SIM card (U)SIM card not inserted or the device Invalid (U)SIM card The (U)SIM is out of service. Network signal Indicate the signal strength of Network type GSM/GPRS, UMTS. Data service EDGEavailable,HSPA 4. LED Indicator description State of LED indicator Description RED Solid On No SIM card/ Error Green Solid On Register to network (not connect) Green blinking Connected to network *Green blinking: Flash once every 0.5 seconds) INTERNET SERVICE 1. Connecting with the default connection profile  Click to set up the connection; 2. Statistics information The following window will be displayed at lower right corner of main interface when connecting to the internet. 3. Disconnect from the internet Click to disconnect the internet connection. SMS SERVICE Click to enter SMS (Short Message Service) service interface. 1. Creating and sending a message. Click :  Input the recipient number by one of the following options:  Enter the number directly;  Click Send to, choose the recipient number from the phonebook and add to the sending list , then click OK.  Enter the message content;  Click Send or Save to Draft. The message will be saved in the Draft when failed to send. Note:  You can group send a message at most 100 recipients;  Each number should be separated by “,”;  The message cannot expand 2,048 characters at most. 2. Inbox  The following prompt box will be displayed when received a new message;  Reply : Access the edit interface, write the content, click Send or Save to Draft;  Forward : Forward the selected message;  Delete : Delete the selected message. Note:  The new message will be saved in PC when Connect running only, else in (U)SIM instead.  You can use “Shift” or “Ctrl” to selected several messages; 3. Outbox The message in the Outbox can be deleted or forwarded. 4. Draft  The MSG sent unsuccessfully will be saved in the Draft .  Click the selected message;  Confirm the recipient and the content, and click Send or Save to Draft. 5. Recycle All deleted information will be saved in the Recycle. 6. The selected SMS can be operated as follows:  Save number: To save the sender’s information to the (U)SIM card or PC.  Delete text message: To delete the selected message.  Move to: To move the selected message to Outbox or Draft.  Copy to: To copy the selected message to Outbox or Draft.  SMS Export  Right‐click the selected the message;  Click SMS Export ;  Specify the path and the file name, and click Save. Note: The exported message will be saved as a *.csv file. CONTACTS Click to enter Contacts interface. 1. New  Click ;  Enter the Name and Mobile, and save it in the (U)SIM card or PC. 2. Searching a contact  Click;  Enter the key characters of you want to find in the ;  The result will be displayed in turn. 3. Viewing a contact  Click Local or (U)SIM to display the contacts interface accordingly;  Select a contact, then you can operate as follows:  Edit : Modify the selected contact;  Delete: Delete the selected contact;  Send SMS : Send a message to the selected contact;  Copy to: Copy the contact between (U)SIM card and PC. Note: The deleted contact information cannot be retrieved. 4. Import  Right‐click the mouse;  Click Contacts Import;  Select the *.vcf or *.csv file and click Open;  The import file will be saved in the current interface. 5. Export  Right‐click the selected contact;  Click Contacts Export;  You can saved the contact file as *.csv file or *.vcf file;  Confirm the name and the path the file saved, then click Save. VOICE CALL Click to enter voice call interface. 1. Dial operation Enter voice call interface, you can enter the call number by dial number pad, then click to dial. When connected, you can click volume button to adjust the volume; when you click, you can hang up the current call. 2. Incoming call operation The following prompt box will be displayed when incoming call. Click “Answer” button to answer the call; Click “Hangup” button to reject the call USSD Click to enter USSD interface. You can add, edit, delete, and send USSD operation. The result of sending will display on the edit box. SETTINGS Click to list the functions. 1. PIN Management  Enable PIN  Click Ena…
