Re: Certification for Lear MY04D186 Receiver Model: MY04D186 FCC ID: KOBFR04D186 IC: 3521A- FR04D186 USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: KOBFR04D186 IC: 3521A- FR04D186 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

- LNA Low Noise Amplifier Mixer 10.7MHz IF Filter Multi-Stage IF Amp PLL Synthesiser Crystal Oscillator Matching Networks Carrier Freq. Pre- Selector Antenna Data Slicer Envelope Detector Super-Heterodyne Receiver Block Diagram Demodulated Data BlockPurposeExample AntennaCapture radiated RF energy and couple energy into receiver front end. PCB trace, Rigid wire, External wire Frequency Pre-SelectorSuppress image frequency and out of band jamming sources. SAW (Surface Acoustic Wave) Filter. Matching NetworksTransfer maximum energy between the different stages LC network, Integrated filter components. Low Noise AmplifierProvide RF signal amplification with minimum noise. Cascode Amplifier. MixerConvert the input frequency (RF) to an intermediate frequency (IF). Double Balanced Mixer IF FilterSet System BandwidthCeramic, LC networks. IF Cascaded AmplifiersProvide IF signal amplification Cascode Amplifiers Envelope DetectorConvert IF frequency to DC voltage levels. Diode detector with low pass filter. Data SlicerCondition demodulated data to logic levels for microprocessor decoding. Operational Amplifiers using RC timing components

Re: Certification for Lear MY04D186 Receiver Model: MY04D186 FCC ID: KOBFR04D186 IC: 3521A- FR04D186 REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Lear requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Lear has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan January 4, 2003 Re: Certification for Lear MY04D186 Receiver Model: MY04D186 FCC ID: KOBFR04D186 IC: 3521A- FR04D186 STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Lear MY04D186 Receiver Model: MY04D186 FCC ID: KOBFR04D186 IC: 3521A- FR04D186 GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Lear Corporation 3521A- FR04D186 5200 Auto Club Drive Dearborn, MI 48126 Gerard Grabowski Tel: 313-593-9604 Fax: 313-240-3832 It will be manufactured by: Lear Corporation 5200 Auto Club Drive Dearborn, MI 48126 Gerard Grabowski Tel: 313-593-9604 Fax: 313-240-3832 Canadian Contact: Ford Motor Company of Canada Limited The Canadian Road P.O. Box 2000 Oakville, Ontario, Canada L6J 5E4 HR Personell 800-565-3673 905-845-4642 Re: Certification for Lear MY04D186 Receiver Model: MY04D186 FCC ID: KOBFR04D186 IC: 3521A- FR04D186 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested.

RE: Lear Corporation FCC ID: KOBFR04D186 This is in response to the comments made on the above application. 1) The 731 form shows that this application is for a receiver. However, from the operational and internal photographs this is not easily determined. Please provide a photograph that shows/labels the portion of the device that is the RX and also the antenna for the RX. Additional internal photographs have been uploaded demonstrating the RX circuitry and the antenna. 2) The block diagram should show the frequencies of the oscillator within the device (CFR 2.1033(a)(5)). Please provide an updated version that includes this information. A revised Block Diagram has been uploaded. 3) Please provide a higher resolution schematic. The values/designators were not distinguishable. A higher resolution schematic has been requested from the manufacturer and will be uploaded as soon as possible. 4) The label appears to show the FCC ID as KOBFR04D186, while the label appears as KOBFRO4D186. Please confirm which FCC ID Number is correct using a ‘0’ or ‘O’. This is a simple typo, the FCC ID is KOBFR04D186 and a revised ID label has been uploaded. 5) Please provide a photograph that shows the placement of the label on the device. See revised ID Label & Location Exhibit.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 January 5, 2003 RE: Lear Corporation FCC ID: KOBFR04D186 or KOBFRO4D186 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The 731 form shows that this application is for a receiver. However, from the operational and internal photographs this is not easily determined. Please provide a photograph that shows/labels the portion of the device that is the RX and also the antenna for the RX. 2) The block diagram should show the frequencies of the oscillator within the device (CFR 2.1033(a)(5)). Please provide an updated version that includes this information. 3) Please provide a higher resolution schematic. The values/designators were not distinguishable. 4) The label appears to show the FCC ID as KOBFR04D186, while the label appears as KOBFRO4D186. Please confirm which FCC ID Number is correct using a ‘0’ or ‘O’. 5) Please provide a photograph that shows the placement of the label on the device. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

FCC ID: KOBFR04D186 IC: 3521A-FR04D186 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES AND WITH RSS-210 OF INDUSTRY CANADA. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING UNDESIRED OPERATION

Date Created: September 11, 2002 D186 MY04 Smart Junction Box The SJB described herein forms the foundation of the Body Electrical/Electronic Subsystem. The SJB combines the Generic Electronics Module (GEM) and Junction Box (JB) into a single entity for the 2004 Taurus. The SJB is an electronic assembly consisting of two separate PCBs – one for high current loads (HCB) and the other for the low current electronics (LCB). The HCB is single sided with components populated on one side while the LCB is doubled sided with components populated on both sides. All relays are located on the HCB or external to the SJB in the Power Distribution Center (PDC). The SJB monitors and controls vehicle functions as described below: • Replaces currently used Junction Box/Electronic module combinations • Uses standard 4 Layer PCB that supports the low current electronics • Uses 400 micron PCB that supports the high current loads • Provides diagnostic capability via the ISO-9141 protocol • Flash micro-controller allows software updates via the vehicles OBDII connector using standard Ford tools. • Provides features such as battery saver, courtesy lighting, remote keyless entry, daytime running lamps, front wiper and washer control, front fog lighting, CAN Bus communication, driver’s one- touch-down and power door locks via solid state electronics and electromechanical relays. • Provides fused pass through circuits from 5A to 30A for power distribution • Reduces vehicle assembly time by reducing the number of components - Size, weight, and cost of multiple modules is optimized • Vehicle key off load is optimized when combining multiple sleep nodes such as RF and GEM into a single module. • Compliant with Ford’s Electronic Component Electromagnetic Compatibility (EMC) standard ES- XW7T-1A278-AB Contact Person: Gerald Grabowski, Project Leader Ford SJB Junction Box Engineering Phone (313) 593-9604
