Re: Certification for Lear FR06U251 Receiver Model: FR06U251 FCC ID: KOBFR06U251 IC: 3521A- FR06U251 USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: KOBFR06U251 IC: 3521A- FR06U251 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

Attestation Statements

Re: Certification for Lear FR06U251 Receiver Model: FR06U251 FCC ID: KOBFR06U251 IC: 3521A- FR06U251 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Lear FR06U251 Receiver Model: FR06U251 FCC ID: KOBFR06U251 IC: 3521A- FR06U251 REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Lear requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Lear has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan January 22, 2005 Re: Certification for Lear FR06U251 Receiver Model: FR06U251 FCC ID: KOBFR06U251 IC: 3521A- FR06U251 STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Lear FR06U251 Receiver Model: FR06U251 FCC ID: KOBFR06U251 IC: 3521A- FR06U251 GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Lear Corporation 5200 Auto Club Drive Dearborn, MI 48126 Bill Lusa Tel: 734-484-1387 Fax: 734-484-1389 It will be manufactured by: Lear Corporation 5100 West Waters Avenue Tampa, FL 33634 Bill Lusa Tel: 734-484-1387 Fax: 734-484-1389 Canadian Contact: John J. Jackson Vehicle Safety and Regulatory Affairs Daimler-Chrysler Canada- Automotive Research & Development Ctr. (ARDC) 3939 Rhodes Drive Windsor, ON. N8W 5B5 Tel: (519) 973 - 2870 Email: [email protected]

Block Diagram

ENGINEER David Sivako Document I/O Block Diagram DATE 4/9/2003 5200 Auto Club Drive Dearborn, Michigan 48126-9982 313/593-9000 APPROVED BYProject U251 MY2006 SJB Page 2 of 2VERSION 1.0 MC9S12DG128 Microprocessor 85degC 112pin LQFP Internal PLL Ram: ??KB of 4KB EEPROM: ??KB of 1KB Flash: ??KB of 128KB 5V Voltage Regulator 5V x 100mA 1 A/D Feedback for overvoltage 3 Active High Digital Inputs Isink < 0.13mA/ea. Ign_run_start, Ign_run_accy, Brake_On/Off (BOO) 28 Active Low Digital Inputs Wetting Current t < 28mA/ea. (Switches: lfd_ajar, rfd_ajar, rrd_ajar, lrd_ajar, liftgate_ajar, liftgate_release, park_brake, door_lock, door_unlock, dome_lamp, headlamps_off, headlamp_wiper_link, key pad_9/0,7/8,5/6, ignition_start, hood_ajar, rear defrost, heated_windscreen, Parklamp_on, hazard, auto_lamp, flash-to-pass, low_beam, high_beam, right_turn, left_turn, front_fog_lamp) Analog Inputs (Rear Park Lamps Current Sense, Instrument Illumination Potentiometer) 1 RF Inputs 1 Input Capture used to decode the signal 1 Sensor input Auto Lamp 4Mhz +/- 0.5% Oscillator PLL to 16Mhz protects for TPMS. 4Mhz or greater required for MS_CAN Communication Bus Protocol: MS_CAN Bit Width: 6.66uS 16 High side drivers (6 PWM HSD) (1 Digital Output and 1 A/D Feedback per driver) Battery Saver, Interior Lamps, Left and Right High Beam, Left and Right Low Beam, Trailer Left and right Turn/Stop, Left and Right Rear Turn/Stop, Left and Right Front Turn, Instrument Illumination Bulb, Insturment Illumination LED. 2 additional HSD for Japan Tri-color(Stop Lamps, Trailer Stop Lamps) 15 Low Current Loads using 1 Octal Low Side Driver, 1 Octal Low/High Side Driver, (1 SPI Port, 4 Digital Outputs for CSB', SFPD', RESET', and CS') 13 Relay Coils: (Delayed _ Accesory, Rear_Defrost, Puddle_Lamps, Horn_Relay, Park_lamps, Reverse_Lamps, All-Lock, All_Unlock, Driver_Unlock, Front_Fog, 3rd_Row_Seat_Sw, Front_Window_Heater, Liftgate_Release) Keypad Illlumination, Door_Ajar_4x4 Daytime Running Lamps (1 PWM output, 1Key Interupt, 1A/D feedback) PWM Duty Cyle: 72-90% PWM Frequency: 100Hz (?) Notes: Active High Sink Current = (18.83V - 5.6V)/100K = 0.13mA assuming internal clamp diodes. Active Low Wetting Current = (18.83V)/680 = 28mA current provides by a switched battery supply. 3 Switched Supplys Vccsw: 50mA Max ** Vbatsw1: 300mA Max ** Vbatsw2: 300mA Max ** ** Approx need WCA 3 Digital Outputs, 2 A/D feedbacks for vbatsw1&2 TPMS Pre-processor wakeup IRQ every 50ms. Ties to Octal SPI port, 3 digital I/O for handshakes, and ASK/FSK modulation selection. 8M Hz +/- 0.5% and 32.768K Hz Oscillator

Cover Letter(s)

January 22, 2005 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: KOBFR06U251 Please find enclosed application materials for certification of Lear FR06U251 Receiver. Note: 1) portions of this submittal are filed Confidential 2) a list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

Cover Letter(s)

Operational Description

- LNA Low Noise Amplifier Mixer 10.7MHz IF Filter Multi-Stage IF Amp PLL Synthesise r Cryst a l Oscillator Matching Networks Carrier Freq. Pre- Selector Antenna Data Slicer Envelope Detector Super-Heterodyne Receiver Demodulated Data Block Purpose Example Antenna Capture radiated RF energy and couple energy intoreceiver front end. PCB trace, Rigid wire,External wire Frequency Pre-Selector Suppress image frequencyand out of band jammingsources. SAW (Surface AcousticWave) Filter. Matching Networks Transfer maximum energy between the different stages LC network, Integratedfilter components. Low Noise Amplifier Provide RF signal amplification withminimum noise. Cascode Amplifier. Mixer Convert the input frequency (RF) to an intermediatefrequency (IF). Double Balanced Mixer IF Filter Set System Bandwidth Ceramic, LC networks. IF Cascaded Amplifiers Provide IF signal amplification Cascode Amplifiers Envelope Detector Convert IF frequency to DC voltage levels. Diode detector with lowpass filter. Data Slicer Condition demodulated datato logic levels formicroprocessor decoding. Operational Amplifiersusing RC timingcomponents
