KR5A2C978066Remote Control Car Key

Continental Automotive GmbH FCC-ID: KR5A2C978066 IC: 7812D-A2C978066 1 Label Information Continental Model: A2C978066 FCC ID: KR5A2C978066 IC:7812D- A2C978066 Label is located in the battery compartment. To access to the label, please follow the instructions included in this manual to replace the battery. 2 Owner Manual 2.1 Owner Manual Canada IC: 7812D- A2C978066 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Continental Automotive GmbH FCC-ID: KR5A2C978066 IC: 7812D-A2C978066 2.2 Owner Manual USA FCC ID: KR5A2C978066 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL RF exposure information Date: June 12, 2015 FCC ID: KR5A2C978066; IC: 7812D-A2C978066 1. Introduction: The device with FCC ID: KR5A2C978066; IC: 7812D-A2C978066 is designed to be used in portable exposure conditions. This product integrates a transmitter operated in 433.92 MHz frequency band. 2. Output power considerations: Worst case output power transmitter: 80.05 dBμV/m@3m = 0,030 mW eirp 3. Compliance criteria: Transmitter is deeded to comply with FCC § 2.1093 requirements and IC RSS-102 Issue 5 as the output power of the device meets the conditions specified in section 4.3.1 (SAR test exclusion) considerations of the document “KDB 447498 D01 General RF Exposure Guidance v05r02” and in section 2.5.1 (Exemption from Routine Evaluation Limits – SAR Evaluation) of RSS-102 Issue 5. FCC: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3 [0.030/5] · [√0.43392] = 0.004 ≤ 3 IC: Max output power (mW) ≤ 54.0368 mW (limit at 433.92 MHz resulting of the linear interpolation of the limits at 300 MHz and 450 MHz specified in table 1 of section 2.5.1 of RSS-102 Issue 5) 0.030 mW ≤ 54.0368 mW Sincerely, p.a. Name: Dagmar Kolar Position: Manager RF Homologation Company: Continental Automotive GmbH Phone: +49 941 790-6699 e-mail: [email protected]

AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 2015-05-21 FCC LISTED, REGISTRATION NUMBER: 720267 IC LISTED REGISTRATION NUMBER IC 4621A-1 Informe de ensayo nº: Test report No: NIE: 45541RRF.003 Test report USA FCC Part 15.231, 15.209 CANADA RSS-210, RSS-Gen Radio Frequency Devices. Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. Licence-Exempt Radio Apparatus (All Frequency Bands): Category I Equipment. General Requirements and Information for the Certification of Radio Apparatus. Identificación del objeto ensayado ...................... : Identification of item tested Remote control car key Marca ................................................................... : Trademark Continental Modelo y/o referencia tipo .................................. : Model and /or type reference A2C978066 Other identification of the product .................... : Commercial name: A2C978066 FCC ID: KR5A2C978066 IC: 7812D-A2C978066 Final HW version ................................................ : A2C978066 Final SW version ................................................. : --- Serial number ...................................................... : --- Características ..................................................... : Features Immobilizer, RKE, PASE. Fabricante ............................................................ : Manufacturer Continental Automotive GmbH Siemensstr. 12, 93055 Regensburg, Germany. Método de ensayo solicitado, norma ................... : Test method requested, standard USA FCC Part 15.231 10-1-14 Edition: Periodic operation in the band 40.66-40.70 MHz and above 70 MHz. USA FCC Part 15.209 10-1-14 Edition: Radiated emission limits; general requirements. CANADA RSS-210 Issue 8 (December 2010). CANADA RSS-Gen Issue 4 (November 2014). ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices. Resultado .............................................................. : Summary IN COMPLIANCE Aprobado por (nombre / cargo y firma) ........... : Approved by (name / position & signature) A. Llamas / RF Lab. Manager Fecha de realización ........................................... : Date of issue 2015-05-21 Formato de informe No. ...................................... : Report template No FDT08_16 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 2 of 21 2015-05-21 Index Competences and guarantees ......................................................................................................................... 3 General conditions ......................................................................................................................................... 3 Uncertainty .................................................................................................................................................... 3 Usage of samples ........................................................................................................................................... 3 Test sample description ................................................................................................................................. 4 Identification of the client ............................................................................................................................. 4 Testing period ................................................................................................................................................ 4 Environmental conditions .............................................................................................................................. 4 Remarks and comments ................................................................................................................................. 5 Testing verdicts ............................................................................................................................................. 6 Appendix A – Test result ............................................................................................................................... 7 AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 3 of 21 2015-05-21 Competences and guarantees AT4 wireless is a laboratory with a measurement facility in compliance with the requirements of Section 2.948 of the FCC rules and has been added to the list of facilities whose measurements data will be accepted in conjuction with applications for Certification under Parts 15 or 18 of the Commission's Rules. Registration Number: 720267. AT4 wireless is a laboratory with a measurement site in compliance with the requirements of RSS 212, Issue 1 (Provisional) and has been added to the list of filed sites of the Canadian Certification and Engineering Bureau. Reference File Number: IC 4621A-1. In order to assure the traceability to other national and international laboratories, AT4 wireless has a calibration and maintenance program for its measurement equipment. AT4 wireless guarantees the reliability of the data presented in this report, which is the result of the measurements and the tests performed to the item under test on the date and under the conditions stated on the report and, it is based on the knowledge and technical facilities available at AT4 wireless at the time of performance of the test. AT4 wireless is liable to the client for the maintenance of the confidentiality of all information related to the item under test and the results of the test. The results presented in this Test Report apply only to the particular item under test established in this document. IMPORTANT: No par…

Text truncated - open the document above for the full version.

AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 1 of 7 2015-05-21 Appendix B - Photographs AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 2 of 7 2015-05-21 EQUIPMENT FOR RADIATED MEASUREMENTS AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 3 of 7 2015-05-21 EQUIPMENT FOR CONDUCTED MEASUREMENTS AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 4 of 7 2015-05-21 GENERAL SET-UP FOR RADIATED MEASUREMENTS AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 5 of 7 2015-05-21 TEST SET-UP FOR RADIATED MEASUREMENTS BELOW 1 GHz AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 6 of 7 2015-05-21 TEST SET-UP FOR RADIATED MEASUREMENTES ABOVE 1GHz AT4 wireless, S.A. Parque Tecnológico de Andalucía, c/ Severo Ochoa nº 2 · 29590 Campanillas · Málaga · España www.at4wireless.com · C.I.F. A29 507 456 Report No: (NIE) 45541RRF.003 Page 7 of 7 2015-05-21 TEST SET-UP FOR CONDUCTED MEASURMENTS
