KR5ALFA434Radio frequency transmitter used in vehicle locking/unlocking systems

Continental Automotive Camelia Teicu I BS AS EE/RF 1 of 6 User Manual of the Continental ALFA434 (ASK/FSK 433.92MHz) Continental Automotive Camelia Teicu I BS AS EE/RF 2 of 6 1. SYSTEM OVERVIEW The ALFA434 is a transmitter designed to provide remote keyless entry, passive entry, passive engine start, and immobilization functionality, it is part of a larger system provided by Continental which allows the customer to: • Remotely start the engine. • Remotely lock the doors. • Remotely unlock the doors. • Remotely open the trunk. • Remotely find the car. • Remotely activate the alarm (panic mode). • Remotely unlock and lock doors in passive mode (PASE). • Start engine in passive mode (PASE). • Start the car via push button (IMMO immobilization). • Use mechanical emergency key as back-up to access to the vehicle. • The system consists of PASE FOBIK, RFHM, and IMMO. The Remote Keyless Entry (RKE) and Start uses a Radio Frequency (RF) link for communication between the end user and the vehicle; For Passive Entry and Passive Start function, FOBIK receives LF command from RFHM via a Low Frequency (LF) link and responses back via RF link. The Immobilization uses a Low Frequency (LF) link for communication/authentication between FOBIK and IMMO. Continental Automotive Camelia Teicu I BS AS EE/RF 3 of 6 2. ALFA434 VARIANTS A2C97635100 A2C97634900 A2C97635000 The pictures are showing the housing variants with the Continental product numbers. The homologation reference number of all versions is the “ALFA434”. The Fobik variants only differ in quantity of switch buttons and keypad design appearances. Continental Automotive Camelia Teicu I BS AS EE/RF 4 of 6 3. LABEL INFORMATION 3.1 EC Continental Model: ALFA434 3.2 USA/CANADA Continental Model: ALFA434 FCC ID: KR5ALFA434 IC:7812D-ALFA434 3.3 LABEL LOCATION The label is located in the battery department. There are not required any special tools for access to the label. To get access to the label, do the following: Remove the lower housing cover which is the cover of the battery department. Continental Automotive Camelia Teicu I BS AS EE/RF 5 of 6 Additionally remove the emergency key blade to see the whole label content. Label area Continental Automotive Camelia Teicu I BS AS EE/RF 6 of 6 4. OWNER MANUAL STATEMENTS 4.1 OWNER MANUAL CANADA IC:7812D–ALFA434 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with the safety requirements for RF exposure in accordance with RSS-102 Issue 5 2015 for portable use conditions. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Cet équipement est conforme avec les exigences de sécurité pour l'exposition aux RF conformément aux RSS - 102 Issue 5 2015 pour des conditions d'utilisation portables. 4.2 OWNER MANUAL USA FCC ID: KR5ALFA434 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. No changes shall be made to the equipment without the manufacturer’s permission as this may void the user’s authority to operate the equipment. This equipment complies with FCC radiation exposure limits set forth for portable use conditions.

1/1 Continental Automotive GmbH | Siemensstraße 12, 93055 Regensburg | P.O. Box: 10 09 43 | 93009 Regensburg www.continental-corporation.com Registered office: Hanover | Registered Court: Amtsgericht Hanover HRB: 59424 | VAT ID No.: DE 814950663 Chairman of the Supervisory Board: Helmut Matschi Directors: Georg Sistermanns, Harald Stuhlmann Account at: Deutsche Bank AG, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | IBAN: DE07 5007 0010 0096 5103 00 10/12/2015 Telecommunication Certification Body UL VS Ltd Offices 18-26 Grove House Lutyens Close Chineham Court Basingstoke Hampshire RG24 8AG United Kingdom ATTN: Reviewing Engineer Date: Oct. 15, 2015 Ref: Attestation letter regarding label location for FCC ID: KR5ALFA434; IC: 7812D-ALFA434 To whom it may concern: We, Continental Automotive GmbH Siemensstrasse 12 93055 Regensburg Germany , hereby declares about the device: MODEL: ALFA434 FCC ID: KR5ALFA434 IC: 7812D-ALFA434 the following: 1. The device is handheld 2. The FCC identifier and IC number are visible at the time of purchase. They are located in the battery compartment. The user’s guide includes indications to easily find the label. 3. The user does not require any special tools for access to the label and is not be placed on a removable part of the device. Yours faithfully, _______________________ By: Sven Kubeil Title: Manager RF Homologation Company: Continental Automotive GmbH Telephone: +49 941 790 90292 e-mail: [email protected]

1/1 Continental Automotive GmbH | Siemensstraße 12, 93055 Regensburg | P.O. Box: 10 09 43 | 93009 Regensburg www.continental-corporation.com Registered office: Hanover | Registered Court: Amtsgericht Hanover HRB: 59424 | VAT ID No.: DE 814950663 Chairman of the Supervisory Board: Helmut Matschi Directors: Georg Sistermanns, Harald Stuhlmann Account at: Deutsche Bank AG, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | IBAN: DE07 5007 0010 0096 5103 00 09/21/2015 Telecommunication Certification Body UL VS Ltd Offices 18-26 Grove House Lutyens Close Chineham Court Basingstoke Hampshire RG24 8AG United Kingdom Subject: Authorisation Letter To whom it may concern This is to certify that Continental Automotive GmbH hereby authorises UL VS Ltd. to act as the TCB for the application of the ALFA434, FCC ID: KR5ALFA434 to the FCC. We certify that we are not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Yours faithfully, _______________________ By: Dagmar Kolar Title: Homologation Manager Company: Continental Automotive GmbH Telephone: +49 941 790 6699 e-mail: [email protected]

1/1 Continental Automotive GmbH | Siemensstraße 12, 93055 Regensburg | P.O. Box: 10 09 43 | 93009 Regensburg www.continental-corporation.com Registered office: Hanover | Registered Court: Amtsgericht Hanover HRB: 59424 | VAT ID No.: DE 814950663 Chairman of the Supervisory Board: Helmut Matschi Directors: Georg Sistermanns, Harald Stuhlmann Account at: Deutsche Bank AG, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | IBAN: DE07 5007 0010 0096 5103 00 10/20/2015 Telecommunication Certification Body UL VS Ltd Offices 18-26 Grove House Lutyens Close Chineham Court Basingstoke Hampshire RG24 8AG United Kingdom Subject: Permanent Confidentiality Request Certification Application FCC ID: KR5ALFA434 To whom it may concern Pursuant to Sections 0.457 and 0.459 of CFR 47 , Continental Automotive GmbH request that the following information, provided to support the FCC application for the ALFA434, FCC ID: KR5ALFA434 be held permanently confidential: • Schematics • Block Diagrams • Parts List/Bill of Material • Operational Description/Theory of Operation • Tune up document The above material contains trade secrets not customarily released to public that are judged to have the potential to cause detriment to the applicant and provide unjustified benefits to its competitors. This information should not be available for public disclosure for an indefinite period of time. Yours faithfully _______________________ By: Dagmar Kolar Title: Homologation Manager Company: Continental Automotive GmbH Telephone: +49 941 790 6699 e-mail: [email protected]

1/1 Continental Automotive GmbH | Siemensstraße 12, 93055 Regensburg | P.O. Box: 10 09 43 | 93009 Regensburg www.continental-corporation.com Registered office: Hanover | Registered Court: Amtsgericht Hanover HRB: 59424 | VAT ID No.: DE 814950663 Chairman of the Supervisory Board: Helmut Matschi Directors: Georg Sistermanns, Harald Stuhlmann Account at: Deutsche Bank AG, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | IBAN: DE07 5007 0010 0096 5103 00 09/21/2015 Telecommunication Certification Body UL VS Ltd Offices 18-26 Grove House Lutyens Close Chineham Court Basingstoke Hampshire RG24 8AG United Kingdom Subject: Short Term Confidentiality Request FCC ID:KR5ALFA434 To whom it may concern In accordance with §0.457 and §0.459 of CFR 47, requests the short term confidentiality of the items listed below until 03/14/2016 for our device, FCC ID:KR5ALFA434 • External Photos • Internal Photos • Test Set Up Photos • User Guide These items contain proprietary information related to the design of the product which has not yet been released to the market. The public disclosure of this information prior to public launch may be harmful to Continental Automotive GmbH and provide unjust benefits to its competitors. A period up to 03/14/2016 is requested to protect this information before formal market launch. If the launch date is rescheduled to be earlier than 03/14/2016, Continental Automotive GmbH will inform again to cancel this restriction. Please contact the undersigned if there are any further questions or additional information needed in this matter. Yours faithfully, _______________________ By: Dagmar Kolar Title: Homologation Manager Company: Continental Automotive GmbH Telephone: +49 941 790 6699 e-mail: [email protected]

Model: ALFA 434 Page 1 of 4 Remove lower housing cover of ALFA434 to access the label locations Additionally remove the emergency key blade t Model: ALFA 434 - Label Content and Label location Remove lower housing cover of ALFA434 to access the label locations . t o see the whole label content. Model: ALFA 434 - Label Content and Label location Page 2 of 4 Remove the emergency key blade to see the whole label content. Model: ALFA 434 - Label Content and Label location Page 3 of 4 Model: ALFA 434 - Label Content and Label location Page 4 of 4 Model: ALFA434 FCC ID: KR5ALFA434 IC:7812D - ALFA434

1/1 Continental Automotive GmbH | Siemensstraße 12, 93055 Regensburg | P.O. Box: 10 09 43 | 93009 Regensburg www.continental-corporation.com Registered office: Hanover | Registered Court: Amtsgericht Hanover HRB: 59424 | VAT ID No.: DE 814950663 Chairman of the Supervisory Board: Helmut Matschi Directors: Georg Sistermanns, Harald Stuhlmann Account at: Deutsche Bank AG, Frankfurt | BIC/SWIFT: DEUTDEFFXXX | IBAN: DE07 5007 0010 0096 5103 00 RF Exposure Analysis FCC ID: KR5ALFA434 Analysis for FCC portable use Standalone SAR test exclusion considerations are defined in KDB 447498D01 (v05r02) Chapter 4.3.1 where the 1-g head or body and 10-g extremity SAR exclusion threshold is defined by the following formula: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] * [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison For the ALFA434_Fobik the maximum conducted output power is +0.8dBm (1.2mW) at 433MHz. Applying the above data using the given KDB 447498 D01 formula, and minimum separation distance of 5mm, the following results: (1.2mW / 5 mm) x √0.433 GHz = 0.16 (i.e.: ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR) Conclusion This demonstrates the ALFA434_Fobik meets the criteria for 1-g head/ body and 10-g extremity SAR test exemption. Signature: ________________________________________ Date: __16.Oct.2015________ By: Sven Kubeil Title: Manager RF Homologation Company: Continental Automotive GmbH Telephone: +49 941 790 90292 e-mail: [email protected]

UL VS LTD Pavilion A, Ashwood Park, Ashwood Way, Basingstoke, Hampshire, RG23 8BG, UK Telephone: +44 (0)1256 312000 Facsimile: +44 (0)1256 312001 TEST REPORT Test Report No. : UL-RPT-RP10952868JD02A V3.0 Manufacturer : Continental Automotive GmbH Model No. : ALFA434 FCC ID : KR5ALFA434 Technology : SRD Test Standard(s) : FCC Parts 15.209(a) & 15.231 1. This test report shall not be reproduced in full or partial, without the written approval of UL VS LTD. 2. The results in this report apply only to the sample(s) tested. 3. The sample tested is in compliance with the above standard(s). 4. The test results in this report are traceable to the national or international standards. 5. Version 3.0 supersedes all previous versions. Date of Issue: 22 October 2015 Checked by: Sarah Williams Engineer, Radio Laboratory Issued by : pp John Newell Quality Manager, UL VS LTD This laboratory is accredited by UKAS. The tests reported herein have been performed in accordance with its terms of accreditation. TEST REPORT SERIAL NO: UL-RPT-RP10952868JD02A VERSION 3.0 ISSUE DATE: 22 OCTOBER 2015 Page 2 of 25 UL VS LTD This page has been left intentionally blank. TEST REPORT SERIAL NO: UL-RPT-RP10952868JD02A VERSION 3.0 ISSUE DATE: 22 OCTOBER 2015 UL VS LTD Page 3 of 25 Table of Contents 1. Customer Information ................................................................................................................ 4 2. Summary of Testing ................................................................................................................... 5 2.1. General Information 5 2.2. Summary of Test Results 5 2.3. Methods and Procedures 5 2.4. Deviations from the Test Specification 5 3. Equipment Under Test (EUT) .................................................................................................... 6 3.1. Identification of Equipment Under Test (EUT) 6 3.2. Description of EUT 6 3.3. Modifications Incorporated in the EUT 6 3.4. Additional Information Related to Testing 6 3.5. Support Equipment 6 4. Operation and Monitoring of the EUT during Testing ............................................................. 7 4.1. Operating Modes 7 4.2. Configuration and Peripherals 7 5. Measurements, Examinations and Derived Results ................................................................ 8 5.1. General Comments 8 5.2. Test Results 9 5.2.1. Transmitter Fundamental Field Strength 9 5.2.2. Transmitter 20 dB Bandwidth 11 5.2.3. Transmitter Timeout 14 5.2.4. Transmitter Duty Cycle 16 5.2.5. Transmitter Radiated Emissions 19 6. Measurement Uncertainty ........................................................................................................24 7. Report Revision History ...........................................................................................................25 TEST REPORT SERIAL NO: UL-RPT-RP10952868JD02A VERSION 3.0 ISSUE DATE: 22 OCTOBER 2015 Page 4 of 25 UL VS LTD 1. Customer Information Company Name: Continental Automotive GmbH Address: Siemensstrasse 12 Regensburg D-93055 Germany TEST REPORT SERIAL NO: UL-RPT-RP10952868JD02A VERSION 3.0 ISSUE DATE: 22 OCTOBER 2015 UL VS LTD Page 5 of 25 2. Summary of Testing 2.1. General Information Specification Reference: 47CFR15.231 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Radio Frequency Devices) - Section 15.231 Specification Reference: 47CFR15.209 Specification Title: Code of Federal Regulations Volume 47 (Telecommunications): Part 15 Subpart C (Intentional Radiators) - Section15.209 Site Registration: 209735 Location of Testing: UL VS LTD, Unit 3 Horizon, Wade Road, Kingsland Business Park, Basingstoke, Hampshire, RG24 8AH, United Kingdom Test Dates: 22 September 2015 to 21 October 2015 2.2. Summary of Test Results FCC Reference (47CFR) Measurement Result Part 15.231(b) Transmitter Fundamental Field Strength Part 15.231(c) Transmitter 20 dB Bandwidth Part 15.231(a)(1) Transmitter Timeout Part 15.35(c) Transmitter Duty Cycle Part 15.231(b) / 15.209 Transmitter Radiated Emissions Key to Results = Complied = Did not comply 2.3. Methods and Procedures Reference: ANSI C63.10-2013 Title: American National Standard of Procedures for Compliance Testing of Unlicensed Wireless Devices 2.4. Deviations from the Test Specification For the measurements contained within this test report, there were no deviations from, additions to, or exclusions from the test specification identified above. TEST REPORT SERIAL NO: UL-RPT-RP10952868JD02A VERSION 3.0 ISSUE DATE: 22 OCTOBER 2015 Page 6 of 25 UL VS LTD 3. Equipment Under Test (EUT) 3.1. Identification of Equipment Under Test (EUT) Brand Name: Continental Model Name or Number: ALFA434 Test Sample Serial Number: UL Sample #2 Hardware Version: ALFA434 Software Version: ALFA434 FCC ID: KR5ALFA434 Brand Name: Continental Model Name or Number: ALFA434 Test Sample Serial Number: UL Sample #5 Hardware Version: ALFA434 Software Version: ALFA434 FCC ID: KR5ALFA434 3.2. Description of EUT The equipment under test was a transmitter designed to provide remote keyless entry, passive entry, passive engine start and immobilization functionality to the Alfa Romeo platform. 3.3. Modifications Incorporated in the EUT No modifications were applied to the EUT during testing. 3.4. Additional Information Related to Testing Power Supply Requirement: Nominal 3 VDC Li-ion battery Type of Unit: Transmitter Modulation: ASK & FSK Data Rate: ASK 2.4 kbps & FSK 9.6 kbps Transmit Frequency Range: 433.92 MHz 3.5. Support Equipment No support equipment was used to exercise the EUT during testing. TEST REPORT SERIAL NO: UL-RPT-RP10952868JD02A VERSION 3.0 ISSUE DATE: 22 OCTOBER 2015 UL VS LTD Page 7 of 25 4. Operation and Monitoring of the EUT during Testing 4.1. Operating Modes The EUT was tested in the following operating test modes, unless otherwise stated: • Continuous transmitting maximum output power at the desired mode, on 433.92 MHz 4.2. Configuration and Periphera…

Text truncated - open the document above for the full version.

Continental Automotive GmbH FCC ID: KR5ALFA434 UL-RPT-10952868JD02 IC: 7812D-ALFA434 UL VS LTD 1 Test Setup Photographs for the ALFA434 1. Radiated Emissions 1.1. Configuration 1 Photo 1 Photo 2 Continental Automotive GmbH FCC ID: KR5ALFA434 UL-RPT-10952868JD02 IC: 7812D-ALFA434 UL VS LTD 2 Radiated Emissions (continued) Photo 3 Continental Automotive GmbH FCC ID: KR5ALFA434 UL-RPT-10952868JD02 IC: 7812D-ALFA434 UL VS LTD 3 Radiated Emissions (continued) 1.2. Configuration 2 Photo 1 Photo 2 Continental Automotive GmbH FCC ID: KR5ALFA434 UL-RPT-10952868JD02 IC: 7812D-ALFA434 UL VS LTD 4 Photo 3
