KR5FBD4Keyless Entry System

Continental Automotive GmbH FCC-ID:KR5FBD4 IC:7812D-FBD4 1 Label Information Continental Model: FBD4 FCC ID:KR5FBD4 IC:7812D-FBD4 2 Owner Manual 2.1 Owner Manual Canada IC:7812D-FBD4 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Continental Automotive GmbH FCC-ID:KR5FBD4 IC:7812D-FBD4 2.2 Owner Manual USA FCC ID:KR5FBD4 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

1/1 Continental Automotive GmbH |Siemensstr.12, 93055 Regensburg | P.O. Box 100943, 93009 Regensburg | Germany Phone +49 941 790-0 | Fax +49 941 790-4999 | www.continental-corporation.com Chairman of the Supervisory Board: Helmut Matschi | Registered Office: Hannover | Registered Court: Amtsgericht Hannover HRB No. 59424 | VAT ID No.: DE814950663 Executive Board: Georg Sistermanns, Harald Stuhlmann To whom it may concern: We the undersigned, hereby authorize CSA Group Bayern GmbH, Mr. Thomas Ring, Ohmstrasse 1-4, 94342 Strasskirchen, Germany to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by CSA Group Bayern GmbH on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Continental Automotive GmbH. Sincerely, Dagmar Kolar Manager RF Homologation Date Your message dated Our reference Your reference December 09, 2013 Corporate Quality and Environment Continental Automotive GmbH, Siemensstr.12, D-93055 Regensburg Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Dagmar Kolar RF Homologation / QL RBG 43 Phone +49 941 790-6699 Fax +49 941 790-996699 dagmar.kolar@continental- corporation.com

Request for Confidentiality Date: 08.04.2015 Subject: Confidentiality Request for: FCC ID: FCC ID:KR5FBD4 and IC:7812D-FBD4 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 6.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual *Note: ______(Insert Explanation as Necessary)______ Continental Automotive GmbH has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___(specify number of days not to exceed 180 ) 2 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: Manager RF Homologation Dagmar Kolar (Signature/Title 3 ) (Print name) 1 - The asterisked items (*) require further justification before permanent confidentiality will be allowed. These also currently require review by the FCC under their Permit-But-Ask policy before the grant is issued and can delay completion of an application. Further justification should be added to the note above. One such example for a potted device would be: “The EUT is FULLY potted using a non-removable epoxy based material. Removal of potting material causes irreparable damage to internal circuitry. See photographs exhibits that outline the device before and after potting.” 2 - Please refer to http://acbcert.com/documents/misc-docs/Memo-Short-Term-Vs-Standard-Confidentiality.pdf for complete details. 3 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead .

External Photos External Photos External Photos

Model: FBD-4 IC:7812D-FBD4 CAN RSS-Gen/CNR-Gen FCC ID:KR5FBD4

Internal Photos Internal Photos

FCC ID: KR5FBD4 IC: 7812D-FBD4 CSA Group Bayern GmbH File No. T39156-05-00HS, page 1 of 34 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 EMI − T E S T R E P O R T - FCC Part 15.231 - Test Report No. : T39156-05-00HS 01. June 2015 ______________________________________________________________________________________________ Date of issue Type / Model Name : BMW FBD4 TRX Product Description : Keyless entry system Applicant : Continental Automotive GmbH Address : Osterhofener Str. 14 93055 REGENSBURG, GERMANY Manufacturer : Continental Automotive GmbH Address : Osterhofener Str. 14 93055 REGENSBURG, GERMANY Licence holder : Continental Automotive GmbH Address : Osterhofener Str. 14 93055 REGENSBURG, GERMANY Test Result according to the standards listed in clause 1 test standards: POSITIVE The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test results without the written permission of the test laboratory. FCC ID: KR5FBD4 IC: 7812D-FBD4 CSA Group Bayern GmbH File No. T39156-05-00HS, page 2 of 34 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 Contents 1 T E S T S T A N D A R D S 3 2 E Q U I P M E N T U N D E R T E S T 4 2.1 Photo documentation of the EUT – Detailed photos see ATTACHMENT A 4 2.2 Equipment type 4 2.3 Short description of the equipment under test (EUT) 4 2.4 Variants of the EUT 4 2.5 Operation frequency and channel plan 5 2.6 Antenna 5 2.7 Transmit operating modes 5 2.8 Power supply system utilised 5 2.9 Extreme test conditions 5 2.10 Peripheral devices and interface cables 5 2.11 Determination of worst case conditions for final measurement 6 3 T e s t r e s u l t s u m m a r y 7 3.1 FINAL ASSESSMENT: 7 4 T E S T E N V I R O N M E N T 8 4.1 Address of the test laboratory 8 4.2 Environmental conditions 8 4.3 Statement of the measurement uncertainty 8 4.4 Measurement Protocol for FCC and IC 9 5 T E S T R E S U L T S 11 5.1 Conducted emissions 11 5.2 Field strength of the fundamental wave 11 5.3 Spurious emissions (magnetic field) 9 kHz – 30 MHz 13 5.4 Spurious emissions radiated (electric field) 15 5.5 Correction for pulse operation (duty cycle) 20 5.6 Emission bandwidth and OBW99 23 5.7 Frequency tolerance 27 5.8 Signal deactivation 29 6 U S E D T E S T E Q U I P M E N T A N D A C C E S S O R I E S 32 A T T A C H M E N T A 33 FCC ID: KR5FBD4 IC: 7812D-FBD4 CSA Group Bayern GmbH File No. T39156-05-00HS, page 3 of 34 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules and Regulations Part 15, Subpart A - General (September, 2014) Part 15, Subpart A, Section 15.31 Measurement standards Part 15, Subpart A, Section 15.33 Frequency range of radiated measurements Part 15, Subpart A, Section 15.35 Measurement detector functions and bandwidths FCC Rules and Regulations Part 15, Subpart C - Intentional Radiators (September, 2014) Part 15, Subpart C, Section 15.203 Antenna requirement Part 15, Subpart C, Section 15.204 External radio frequency power amplifiers and antenna modifications Part 15, Subpart C, Section 15.205 Restricted bands of operation Part 15, Subpart C, Section 15.207 Conducted limits Part 15, Subpart C, Section 15.209 Radiated emission limits, general requirements Part 15, Subpart C, Section 15.231 Periodic operation in the band 40.66-40.70 MHz and above 70 MHz ANSI C63.4: 2009 Methods of Measurement of Radio-Noise Emissions from Low- Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz. CISPR 16-4-2: 2013 Uncertainty in EMC measurement FCC ID: KR5FBD4 IC: 7812D-FBD4 CSA Group Bayern GmbH File No. T39156-05-00HS, page 4 of 34 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 2 E Q U I P M E N T U N D E R T E S T 2.1 Photo documentation of the EUT – Detailed photos see ATTACHMENT A 2.2 Equipment type Keyless entry system 2.3 Short description of the equipment under test (EUT) The EUT is a remote keyless entry system fix installed in the car. The EUT supports 2 channels. The EUT is manually operated. Additionally the EUT is a receiver for wire pressure surveillance and get the information from all four (WU) “wire units”. A font remote control uses also the receiver of the unit to address the appropriate function unit. The (THS) “Telestarthandsender” use a bidirectional communication with the EUT. System overview: BMW FBD4 TRx FFB ID-Geber THSWU bidirectional communication RKE 8000 bit/s CA 19200 bit/s SDS 19200 bit/s bidirectional communication THS 2000 bit/s unidirectional communication RDC 19200 bit/s unidirectional communication FFB 5000 bit/s Number of tested samples: 1 unmodulated radiated sample, 1 modulated conducted sample, 1 sample in normal mode, radiated; Serial number: 161214, pre-production sample, 161227; Firmware version: 4.90 2.4 Variants of the EUT There are no variants. FCC ID: KR5FBD4 IC: 7812D-FBD4 CSA Group Bayern GmbH File No. T39156-05-00HS, page 5 of 34 Ohmstrasse 1-4  94342 STRASSKIRCHEN  GERMANY Tel.:+49(0)9424-94810  Fax: +49(0)9424-9481440 Rev. No. 3.0, 2014-01-30 2.5 Operation frequency and channel plan The operating frequency is 433 MHz. Channel plan: 2.6 Antenna The following integrated antenna is used with the EUT: Number Characteristic Model number Plug Frequency range (MHz) 1 Wire-antenna - no 433 2.7 Transmit operating modes The equipment under test was operated during the measurement under the following conditions: - TX continuous mode - TX normal mode 2.8 Power supply system utilised Power supply voltage, V nom : 12 VDC (car-battery) 2.9 Extreme test conditions The extreme temperature range for the EUT is: Defined by the manufacturer: -40 °C to +85 °C, T nom = 20 °C; 2.10 Peripheral devices…

Text truncated - open the document above for the full version.

Setup Photos Setup Photos Setup Photos Setup Photos
