1 USER MANUAL Multi-Functional Smartphone Terminal WCA NFC 2.0 2 3 1. System Description Continental Wireless Power Charger is developed for automotive applications under the name WCA NFC 2.0 which includes two functions like: o WPC: Wireless power charger; WPC Function 126.6kHz o NFC: Near Field Communication; NFC Function 13.56MHz The WCA NFC 2.0 module and its implementation inside the vehicle is depicted in Fig. 1. Its assembly instruction is done by professional workers. Therefore, the product cannot be moved or switched to another position by the end user. Fig. 1: WCA NFC 2.0 module and its implementation inside the vehicle WCA NFC 2.0 charger uses Qi standard of Wireless Power Consortium (WPC) for enabling wireless charging from a base station unit to mobile device. The power transfer method is based on near field magnetic induction between coils. 4 System Overview The structure of wireless power transfer proposed in Fig. 2 shows an overview of the system with two kinds of distinguished devices: Base station and Mobile device. Base station comprises two main functional units per mode (WPC and NFC), namely power conversion units and Communications & Control units for delivering, controlling and regulating the transferred power. Mobile device (power receiver) comprises a power pick up unit and a communications & control unit for achieving power requirements and charging the device battery if is chargeable device or establishing an active NFC communication. Fig. 2: Wireless power transfer structure: WPC and NFC 5 1.2 Wireless Power Charger Description The WCA NFC 2.0 is mainly composed of 6 parts as depicted in Fig.3. 1. Top housing 2. Antenna PCB 3. WPC coil + Ferrite + Plastic Holder 4. Main PCB with 8 ways connector: diagram below in Fig 4, pins description in Table1. Fig 4. Connector diagram Table 1. Connector description 5. Bottom Housing + Fan cover 6. Fan 2 3 4 5 6 Fig. 3: WCA NFC 2.0 split view 1 6 A picture of a serial production part is shown in Fig. 5. (a) (b) Fig. 5: Serial product WCA NFC 2.0. (a) top view and (b) side view. 1.3 WCA NFC 2.0 modes According to the Qi standard, a simple operational description of wireless power transfer can be summarized in two principle operational modes: ▪ The first mode with a defined burst sequence allows the transmitter to detect an object on the charging surface: IDLE mode ▪ The second mode allows the power transfer from the base station to the mobile device, placed on the charging surface: Charging mode The transition between these two modes is realized through a transient mode: Detection mode. which only occurs when the Mobile device is placed on the charging surface. 1.4 Product parameters Below in table 2, the technical parameters of the WCA NFC 2.0 product are specified: Parameters Values Supply voltage 12V battery Voltage supply range 8V < Vbat < 16V Max. power consumption 30W Product Operating temperature range -40°C < Temp < 85°C Max.current consumption 3A Vehicle fuse protection 7.5A Product weight 230 g Dimensions (X/Y/Z in mm) 139/80/17.5 (31.5 at FAN level) Table 2: Product technical parameters 1.5 WPC parameters Below in table 3, the technical parameters of the WPC feature are specified: Parameters Values Carrier frequency 126.6 kHz Frequency shift +/- 6 kHz WPC chipset brand IDT Data rate max (FSK) 0.247 kbps WPC litz coil MPA21 Triple coil according to Qi Standard WPC litz coil gain @ 126.6kHz -108.4 dBi Max. output power 15W Max. H field @10m (@ 126.6kHz) 7.3 dBμA/m Table 3: WPC technical parameters of WCA NFC 2.0 7 1.6 NFC Parameters Below in table 4, the technical parameters of the NFC feature of WCA NFC 2.0: Parameters Values Carrier frequency 13.56 MHz Modulation type Amplitude Shift Keying (ASK) Data rate max. 848 kbps NFC chipset brand NXP Semiconductors NFC chipset model number NCF3340EHN Max. H field @10m (@ 13.56 MHz) 4 dBμA/m Table 4: NFC technical parameters of WCA NFC 2.0 1.7 NFC antenna The NFC block is composed of three antennas: Main, Side1 and Side 2 antenna. The electrical parameters of the NFC antenna are listed in the following tables (5,6 and 7): Main NFC antenna: Parameters Values Antenna type Planar printed coil on PCB Number of turns 3 Antenna size 106mm x 52 mm Antenna Gain (dBi) @ 13.56MHz -51.38 Table 5: Main NFC antenna technical parameters Side 1 NFC antenna: Parameters Values Antenna type Planar printed coil on PCB Number of turns 3 Antenna size 59mm x 13.8mm x 10mm Antenna Gain (dBi) @ 13.56MHz -58.58 Table 6: Side 1 NFC antenna technical parameters Side 2 NFC antenna: Parameters Values Antenna type Planar printed coil on PCB Number of turns 3 Antenna size 59mm x 13.8mm x 10mm Antenna Gain (dBi) @ 13.56MHz -57.07 Table 7: Side 2 NFC antenna technical parameters 2. Overview of “WCA NFC 2.0” Here below the product overview of “WCA NFC 2.0”: Ref WPC NFC Top View Bottom View WCA NFC 2.0 Yes Yes Table 7: WCA NFC 2.0 overview. 8 HHHHH-AA-FFFFF 3. Label content BELARUS BRAZIL CANADA This device complies with part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) L’appareil ne doit pas produire de brouillage, et (2) L’utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. INDONESIA MEXICO La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y [certificate no.] [PLG. ID no.] 9 (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación …
