L9N-7085-UEUHF Transceiver

TIMCO ENGINEERING, INC. 849 N.W. STATE ROAD 45 NEWBERRY, FL 32669 PHONE: 888-472-2424 FAX: 352-472-2030 EMAIL: info@t imcoengr.com March 7, 2002 Ms. Linda Elliott Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: AES CORPORATION YOUR CORRESPONDENCE ID # 22186 Dear Ms. Elliott: With reference to your request of 3/6/02, the information you need is as follows: MIKE SHERMAN, PRESIDENT EMAIL: [email protected] PHONE: 978-535-7310 X 112 FAX: 978-535-7313 Should you have any questions or require any further information, please advise Regards, Sharon Hoffman TIMCO ENGINEERING, INC.

Timco Engineering Inc. 849 NW State Road 45 Newberry FL 32669 Page 1 of 4 From: Mario de Aranzeta [email protected] To: Stan Lyles [email protected] FCC Application Processing Branch Re: FCC ID L9N-7085-UE Applicant: AES Corporation Correspondence Reference Number: 22487 731 Confirmation Number: EA557675 1.) Please provide the modulation limiting test data using a input signal of 4800 Hz. This is the minimum data rate allowed Per Section 90.203(j)(3) in order to meet the spectrum efficiency standard. Enclosed on page 4 is the modulation limiting plot. 2.) Please recalculate your emission designator for question number 1. Page 2 is a revised test report page that corrects the emission designator. 3.) Your test report indicates an F3E (Voice) mode is available, however there is no indication that the device transmitter information other than data. Please clarify. Page 2 also contains the revised test report page that eliminates the erroneous F3E designator. 4.) Please provide the dBm power levels on page 16 of the radiated spurious emissions measurements. Our test method for the substitutio n method is as described in TIA/EIA 603 (2.2.12) using a dipo le for frequencies below 2.4 GHz. Above 2.4 GHz a do uble ridged antenna is used and referenced back to a dipole. A signal generator capable of 10 Watts of output power is used below 1GHz. We don’t usually keep the dBm power levels info so I’ve had to remeasured it and submitted it as page 3. Some of the dBc numbers wo n’t be exactly the same as the test report. If this information is something we need to include in future reports please let me know so we can preserve and report this information. Sincerely, Mario de Aranzeta Engineer Timco Engineering Inc. 849 NW State Road 45 Newberry FL 32669 Page 2 of 4 GENERAL INFORMATION REQUIRED FOR TYPE ACCEPTANCE 2.1033 AES CORPORATION will sell the (c)(1)(2) MODEL NO. L9N-7085-UE UHF transceiver in quantity, for use under FCC RULES 22 and 90. 2.1033 (c) TECHNICAL DESCRIPTION 2.1033 (3) User Manual See Exhibits 12A-12ZZ 2.1033 (4) Type of Emission: 11K2F2D For 12.5 kHz channel bandwidths Bn = 2M + 2DK M = 9,600 Bits per second D = 825 Hz (Peak Deviation) K = 1 Bn = 2(4800) + 2(825)(1) = 9600 + 1650K = 11.25k 90.209(b)(5) For 25 kHz channel BW ALLOWED AUTHORIZED BANDWIDTH = 20.00 kHz. For 12.5 kHz channel BW ALLOWED AUTHORIZED BANDWIDTH = 11.25 kHz. 2.1033 (5) Frequency Range: 410-512 MHz (6) Power Range and Controls: There are NO user power controls. It is programmed at the factory. (7) Maximum Output Power Rating: HI POWER 6 WATTS LOW POWER 1.5 WATTS (8) DC Voltages and Current into Final Amplifier: POWER INPUT FINAL AMPLIFIER ONLY Vce = 12 Volts IC = HIGH 1.68 A LOW .840 A INPUT POWER - HIGH: (12V)(1.68A) = 20.16 Watts INPUT POWER – LOW: (12V)(0.84A) = 10.08 Watts Timco Engineering Inc. 849 NW State Road 45 Newberry FL 32669 Page 3 of 4 Signal Frequencygenerator MHzdBmdBc High Power 460.5 +37 0 921 -33 70 1382 -28 65 1842 -40 77 2302 -41 78 2763 -50 87 3223 -45 82 3684 -50 87 4144 ** * 4605 -50 87 Low Power 460.5 +31 0 921 -36 67 1381 -39 70 1842 -36 67 2302 -37 68 2763 -38 69 3223 -43 74 3684 -40 71 4144 -50 81 4605 -50 81 ** Below measurement limit of equipment Timco Engineering Inc. 849 NW State Road 45 Newberry FL 32669 Page 4 of 4 Modulation Limiting AES Corp. 0 200 400 600 800 1000 -30-25-20-15-10-50 dB Deviation 4800 Hz

APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: TABLE OF CONTENTS TABLE OF CONTENTS LIST APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTINUED & RF POWER OUTPUT PAGE 3......RF POWER OUTPUT & AUDIO FREQUENCY RESPONSE PLOT PAGE 4......AUDIO LOW PASS FILTER GRAPH PAGE 5-6....AUDIO INPUT VERSES MODULATION GRAPH PAGE 7......OCCUPIED BANDWIDTH PAGE 8......OCCUPIED BANDWIDTH MEASUREMENT PAGE 9-13...OCCUPIED BANDWIDTH PLOT PAGE 14.....SPURIOUS EMISSIONS AT ANTENNA TERMINALS PAGE 15.....METHOD OF MEASURING SPURIOUS EMISSIONS AT ANTENNA TERM. PAGE 16.....FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 17.....FREQUENCY STABILITY PAGE 18-19..TRANSIENT FREQUENCY STABILITY PAGE 20-23..TRANSIENT FREQUENCY RESPONSE PLOTS PAGE 24.....LIST OF TEST EQUIPMENT PAGE 25.....RF EXPSOURE ASSESSMENT EXHIBITS CONTAINING: EXHIBIT 1.........FCC ID LABEL SAMPLE & SKETCH OF LOCATION EXHIBIT 2.........SCHEMATICS EXHIBIT 3.........BLOCK DIAGRAMS EXHIBIT 4.........OPERATIONAL DESCRIPTION EXHIBIT 5.........EXTERNAL PHOTOGRAPH FRONT VIEW EXHIBIT 6.........EXTERNAL PHOTOGRAPH REAR VIEW EXHIBIT 7.........EXTERNAL PHOTOGRAPH CONNECTOR VIEW EXHIBIT 8.........INTERNAL PHOTOGRAPH COMPONENT VIEW EXHIBIT 9.........INTERNAL PHOTOGRAPH COPPER VIEW EXHIBIT 10........TEST SETUP PHOTOGRAPH EXHIBIT 11........TUNING PROCEDURE EXHIBIT 12........SERVICE MANUAL EXHIBIT 13........PARTS LIST APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 1 of 25 GENERAL INFORMATION REQUIRED FOR TYPE ACCEPTANCE 2.1033 AES CORPORATION will sell the (c)(1)(2) MODEL NO. L9N-7085-UE UHF transceiver in quantity, for use under FCC RULES 22 and 90. 2.1033 (c) TECHNICAL DESCRIPTION 2.1033 (3) User Manual See Exhibits 12A-12ZZ 2.1033 (4) Type of Emission: 11K0F2D For 12.5 kHz channel bandwidths Bn = 2M + 2DK M = 3,000 Bits per second D = 2.5 kHz (Peak Deviation) K = 1 Bn = 2(3k) + 2(2.5k)(1) = 6.0K + 5.0K = 11.0k Type of Emission: 11K0F3E For 25 kHz & 12.5 kHz channel bandwidths Bn = 2M + 2DK M = 3,000 Hz D = 2.5 kHz (Peak Deviation) K = 1 Bn = 2(3k) + 2(2.5k)(1) = 6.0k + 5.0k = 11.0k 90.209(b)(5) For 25 kHz channel BW ALLOWED AUTHORIZED BANDWIDTH = 20.00 kHz. For 12.5kHz channel BW ALLOWED AUTHORIZED BANDWIDTH = 11.25 kHz. 2.1033 (5) Frequency Range: 410-512 MHz (6) Power Range and Controls: There are NO user power controls. It is programmed at the factory. (7) Maximum Output Power Rating: HI POWER 6 WATTS LOW POWER 1.5 WATTS (8) DC Voltages and Current into Final Amplifier: POWER INPUT FINAL AMPLIFIER ONLY Vce = 12 Volts IC = HIGH 1.68 A LOW .840 A INPUT POWER - HIGH: (12V)(1.68A) = 20.16 Watts INPUT POWER – LOW: (12V)(0.84A) = 10.08 Watts APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 2 of 25 (9) Tune-up procedure. The tune-up procedure is given in EXHIBIT 11. 2.1033 (10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBITS 2A-2B. The block diagram is included as EXHIBITS 3A-3B. (11) Function of each electron tube or semiconductor device or other active circuit device: -SEE EXHIBITS 12 AND 13. (8) Instruction book. The instruction manual is included as EXHIBIT 12. (10) Description of all circuitry and devices provided for determining and stabilizing frequency is included in the circuit, -SEE EXHIBITS 4A-4I. 2.1033(c)(11) A photograph or drawing of the equipment identification label is shown in Exhibit 1. 2.1033(c)(12) Photographs of the equipment of sufficient clarity to reveal equipment construction and layout and label location are shown in Exhibits 5-9. 2.1033(c)(13) For equipment employing digital modulation, a detail description of the modulation technique. This UUT uses FSK to modulate the transmitter. 2.1033(c)(14) Data required for 2.1046 to 2.1057 See Below. 2.1046(a) RF power output. RF power is measured by connecting a 50 ohm, resistive wattmeter to the RF output connector. With a nominal battery voltage of 12 VDC, and the transmitter properly adjusted the RF output measures: OUTPUT POWER: HIGH = 6 Watts LOW = 1.5 Watts APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 3 of 25 METHOD OF MEASURING RF POWER OUTPUT Transmitter 50 ohm under test Resistive Wattmeter Power Supply 2.987(a) Modulation Characteristics: AUDIO FREQUENCY REPSONSE The audio frequency response was measure in accordance with EIA Specification RS-152B, Paragraph 7. The audio frequency response curve is shown below. Audio Frequency Response AES Corp. L9N-7085-UE -30 -25 -20 -15 -10 -5 0 100100010000 Frequency dBmV data APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 4 of 25 2.987 (b) AUDIO LOW PASS FILTER The audio low pass filter is required per FCC Rules 90.211 (c) & (d) for mobile stations with a power output of more than 2.0 watts. A plot of the audio low pass filter is shown below. APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 5 of 25 2.987 (b) AUDIO INPUT VERSES MODULATION A plot of the audio input versus deviation is shown below. Modulation Limiting AES Corp. L9N-7085-UE 0 500 1000 1500 2000 2500 -40-30-20-100 dBmV Deviation 300 Hz Modulation Limiting AES Corp. L9N-7085-UE 0 500 1000 1500 2000 2500 -40-30-20-100 dBmV deviation 1000 Hz APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 6 of 25 Modulation Limiting AES Corp. L9N-7085-UE 0 500 1000 1500 2000 2500 3000 -35-25-15-5 dB Deviation 3000 Hz APPLICANT: AES CORPORATION FCC ID: L9N-7085-UE REPORT #: T:\A\AES\179AU1\179AU1RPT.DOC PAGE #: Page 7 of 25 2.10 Measurement Procedures for Type Acceptance: Measurement techniques have been in accordance with TIA/EIA STD 603-1992. 2.1049 Occupied bandwidth: 90.210(c,) For transmitters that are not equipped with an…
