LB45800NGSYSTEM 5800 NEXT GENERATION

Report No. S7468-08 (FCC ID: LB45800NG) Page 1 of 15 Rev.No 1.0 MEASUREMENT AND TECHNICAL REPORT ORTEL CORPORATION 2015 West Chestnut Street Alhambra, CA 91803 DATE: September 1998 This Report Concerns: Original Grant: XClass II Change: Equipment Type: System 5800 Next Generation (Includes Model 5821A Fiberoptic Transceiver and Model 5851A fiberoptic Antenna) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes: Defer until: No: X Company Name agrees to notify the Commission by: N/A of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes:*No: (*) FCC Part 2, Paragraphs 2.985, 2.989, , 2.991 and 2.993; and Part 24, Paragraph 24.238 Report Prepared by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 619 546 3999 Fax: 619 546 0364 Report No. S7468-08 (FCC ID: LB45800NG) Page 2 of 15 Rev.No 1.0 TABLE OF CONTENTS Pages 1 GENERAL INFORMATION 3 1.1Product Description3 1.2Test Methodology5 1.3Test Facility5 1.4Part 2 Requirements6 Production Quantity Frequency Stability Spur Suppression Limiting RF Power Power Rating Schematics User Manual Series 5800 Photograph, Internal Photograph, External BOM Product Specifications 6 6 6 6 7 Attachment Attachment Attachment Attachment Attachment Attachment 2 PRODUCT LABELING Attachment 15 3 SYSTEM TEST CONFIGURATION 16 3.1Justification16 3.2EUT Exercise Software16 3.3Special Accessories16 3.4Equipment Modifications16 3.5Configuration of Tested System16 Figure 3.1Configuration of Tested System16 4 BLOCK DIAGRAM OF EUT Attachment 17 5GENERAL SUMMARY 18 CONDUCTED MEASUREMENT INFORMATION Attachment RADIATED MEASUREMENT INFORMATION Attachment COVER LETTERS Attachment Report No. S7468-08 (FCC ID: LB45800NG) Page 3 of 15 Rev.No 1.0 1 GENERAL INFORMATION 1.1Product Description System 5800 Next Generation (Includes Model 5821A Fiberoptic Transceiver and Model 5851A fiberoptic Antenna) Components of EUT DescriptionModel No.Serial No.FCC ID No. Transceiver Plug-in RF Splitters 2x1 RF Combiners 2x1 Amps Antenna Chassis with 110 V Power supply 5821A 5832A 5842A 5851A-510 5899A 96020 94148 90149 97033 -- -- -- -- OPERATING MODE(S):Uplink/Downlink EUT CONFIGURATIONS:A hub may have 1 to 8 transceiver plug ins in a rack. The rack consists of a power supply, one RF power splitter, and one RF power combiner. POWER INTERFACE FREQUENCY/AC/DC VOLTAGE:60 Hz/120 Vac PHASES/CURRENT:1/-- OSCILLATOR FREQUENCIES:66.6666 MHz on transceiver for alarm signal POWER SUPPLY110 W Power supply (12V), Phi Hong, Model PSA-110-112; Switching frequency 50 kHz. POWERLINE FILTER: MODEL #:N/A DESCRIPTION OF ENCLOSURE:Antenna unit: plastic radome; hub - plug in modules CRITICAL EMI COMPONENTS: DescriptionModel #Serial #Quantity/Location N/A INTERFACING AND/OR SIMULATORS PERIPHERAL EQUIPMENT: See Components of EUT and Appendix H, Block Diagram of EUT. I/O PORTS: Name of LineType of LineCable Length Status of LineKind of Transmission Antenna Downlink input Fiber optic 0-2kmo Passive n Activen Analog o Digital Uplink outputFiber optic0-2kmo Passive n Activen Analog o Digital Antenna (RF)oShielded nUnshieldedN/An Passive o Activen Analog o Digital Transceiver Downlink output Fiber optic 0-2kmo Passive n Activen Analog o Digital Uplink inputFiber optic0-2kmo Passive n Activen Analog o Digital Downlink input (RF)nShielded oUnshielded*n Passive o Activen Analog o Digital Uplink output (RF)nShielded oUnshielded*n Passive o Activen Analog o Digital Splitter/Combiner Input or output-splitter/combinernShielded oUnshielded**n Passive o Activen Analog o Digital (*) N or SMA connector (**) RF (N or SMA) Report No. S7468-08 (FCC ID: LB45800NG) Page 4 of 15 Rev.No 1.0 1 GENERAL INFORMATION (continued) 1.2Related Submittal/Grant None 1.3Tested System Details The FCC IDs for all equipment, plus descriptions of all cables used in the tested system are: None Report No. S7468-08 (FCC ID: LB45800NG) Page 5 of 15 Rev.No 1.0 1.4Test Methodology Purpose of Test:To demonstrate compliance with the ANSI C63.4 setup. Test Performed:x1. Conducted Emissions, FCC Part 2, Paragraphs 2.985, 2,989, 2.991 & Part 24, Paragraph 24.238 2. Radiated Emissions, EN55022: 1992 Class B limit, 30 - 1,000 MHz, 10 meters x3. Radiated Emission per FCC Part 2, Paragraph 2.993, 1 - 10 GHz 4. Engineering evaluations 1.5Test Facility The open area test site and conducted measurement data were tested by: TÜV PRODUCT SERVICE 10040 Mesa Rim Road San Diego, CA 92121-2912 Phone: 619 546 3999 Fax: 619 546 0364 The Test Site Data and performance comply with ANSI 63.4 and are registered with the FCC, 7435 Oakland Mills Rd, Columbia Maryland 21046. All Measurement Data is acquired according to the content of FCC Measurement Procedure and ANSI C63.4, unless supplemented with additional requirements as noted in the test report. Report No. S7468-08 (FCC ID: LB45800NG) Page 6 of 15 Rev.No 1.0 1.6 Part 2 Requirements Occupied Bandwidth:160 kHz Production Quantity:Antenna (5851A) - 20 units a month Transceiver (5821A): 10 units per month Power Rating 2.983(d)(4) Function of Active Circuit Devices 2.983(d)(6) Schematics 2.983(d)(7) User Manual 2.983(d)(8) Photograph, Internal 2.983(g) Photograph, External 2.983(g) BOM Product Specifications See next page “ Attached “ “ “ “ “ Report No. S7468-08 (FCC ID: LB45800NG) Page 8 of 15 Rev.No 1.0 2PRODUCT LABELING Attached Report No. S7468-08 (FCC ID: LB45800NG) Page 9 of 15 Rev.No 1.0 3.SYSTEM TEST CONFIGURATION 3.1Justification The System 5800 Next Generation (Includes Model 5821A Fiberoptic Transceiver and Model 5851A fiberoptic Antenna) was initially tested for FCC emission in the following configuration: See Block Diagram, attached. 3.2EUT Exercise Software None 3.3Special Accessories None 3.4Modification None 3.5Configuration of Tested System See Block Diagram, attached. 4BLOCK DIAGRAM of System 5800 Next Generation (Includes Model 5821A Fiberoptic Transceiver and Model 5851A fiberoptic Antenna) 4.1Block Diagram D…
