LTQVSM125Immobilizer

Label Placement VSM-125kHz: Label

RESPONSIBLE FOR NAME DATE SIGNATURE Project Management Alex Fink 2020-03-26 SIGN-ID 342415 Authorised Signatory Markus Biberger 2020-03-26 SIGN-ID 342422 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD Product Service document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC 47 CFR Part 15C and ISED Canada RSS-210 and ISED Canada RSS-GEN. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing Alex Fink 2020-03-26 SIGN-ID 342415 Laboratory Accreditation DAkkS Reg. No. D-PL-11321-11-02 Laboratory recognition Registration No. BNetzA-CAB-16/21-15 ISED Canada test site registration 3050A-2 EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with FCC 47 CFR Part 15C, ISED Canada RSS-210 and ISED Canada RSS-GEN:2019, Issue 10 (12-2019) and Issue 05 (03-2019). Report on the FCC and IC Testing of the Aptiv Services Deutschland GmbH Model: VSM-125kHz In accordance with FCC 47 CFR Part 15C and ISED Canada RSS-210 and ISED Canada RSS- GEN Prepared for: Aptiv Services Deutschland GmbH Am Technologiepark 1 42119 Wuppertal Germany FCC ID: LTQVSM125 IC: 3659A-VSM125 COMMERCIAL-IN-CONFIDENCE Date: 2020-03-20 Document Number: TR-00237-70629-02 | Issue: 03 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD Product Service with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD Product Service. No part of this document may be reproduced without the prior written approval of TÜV SÜD Product Service. © 2020 TÜV SÜD Product Service. ACCREDITATION Our BNetzA Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our BNetzA Accreditation. Results of tests not covered by our BNetzA Accreditation Schedule are marked NBA (Not BNetzA Accredited). Document Number: TR-00237-70629-02 | Issue: 03 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 25 Contents 1 Report Summary .........................................................................................................................3 1.1 Report Modification Record ...........................................................................................................3 1.2 Introduction ....................................................................................................................................3 1.3 Brief Summary of Results .............................................................................................................4 1.4 Product Information .......................................................................................................................5 1.5 Deviations from the Standard ........................................................................................................5 1.6 EUT Modification Record ..............................................................................................................6 1.7 Test Location .................................................................................................................................6 2 Test Details ..................................................................................................................................7 2.1 Frequency Tolerance Under Temperature Variations ...................................................................7 2.2 Field Strength of any Emission .....................................................................................................9 2.3 20 dB Bandwidth ........................................................................................................................ 14 2.4 Restricted Band Edges............................................................................................................... 17 2.5 Exposure of Humans to RF Fields and SAR exclusion threshold .............................................. 19 3 Measurement Uncertainty ....................................................................................................... 24 Annex A Document Number: TR-00237-70629-02 | Issue: 03 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 25 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 2020-01-20 2 On request of applicant, model number corrected from “VSM – 125kHz” to “VSM-125kHz” 2020-03-20 3 Updated RSS-210 to Issue 10 and RSS Gen to Issue 5 2020-03-26 Table 1 1.2 Introduction Applicant Aptiv Services Deutschland GmbH Manufacturer Aptiv Services Deutschland GmbH Model Number(s) VSM-125kHz Serial Number(s) 90102042 EUT Version HW: IOD2 SW: 05 Number of Samples Tested 1 Test Specification/Issue/Date FCC 47 CFR Part 15C, ISED Canada RSS-210 and ISED Canada RSS-GEN:2019, Issue 10 (12-2019) and Issue 05 (03-2019), FCC rule Part 2.1093, KDB 447498 D01, RSS- 102 Issue 5 Test Plan/Issue/Date --- Order Number 453208704 Date of Receipt of EUT 2019-11-25 Start of Test 2020-01-08 Finish of Test 2020-01-09 Name of Engineer(s) Alex Fink Related Document(s) ANSI C63.10 (2013) ANSI C63.4: 2014 Document Number: TR-00237-70629-02 | Issue: 03 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 4 of 25 1.3 Brief Summary of Results A brief summary of the tests carried out in accordance with FCC 47 CFR Part 15C and ISED Canada RSS-210, ISED Canada RSS-GEN, FCC rule Part 2.1093, KDB 447498 D01 and RSS-102 Issue 5 is shown below. Section Specification Clause Test Description Result Comments/Base Standard Configuration and Mode: DC Powered 13 V – Transmitting continuously 2.1 15.249 (b)(2), N/A and 6.11 Frequency Tol…

Text truncated - open the document above for the full version.

Document Number: Annex A TR-00237-70629-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 2 1 Annex A 1.1 Equipment Under Test (EUT) Document Number: Annex A TR-00237-70629-02 | Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 2
