LTQVTSEMNARTruck Infotainment Unit

TABLE OF CONTENTS 01 Infotainment Overview............................................. 2 MEDIA................................................. 5 COMMUNICATION........................... 12 VEHICLE........................................... 15 SETTINGS........................................ 16 Specifications.................................... 18 Assembly date filter: w2037 (2020-09-07). Variant filter on: TYPE-FH,STWPOS-L,CRUISEC,HWSS-ACB,AUD-HIGH,CO-USB3,COD-BRA,COD-NS. Project filter: No Filter. 01 Infotainment Overview Overview of the infotainment system The infotainment system includes for example the truck's audio system and Bluetooth ® connectivity. In the side display you can see all the available menus and functions of the infotainment system. Some information is also shown in the instrument display. You can control the infotainment system with the steering wheel keypads, the control panel or the touchscreen on the side display. There are three USB ports in the instrument panel, for you to connect and charge your devices. 1 Instrument display 2 USB ports 3 Side display 4 Control panel 5 Steering wheel keypads 6 Microphone WARNING Do not use the infotainment system in such a way that it interferes with safe and attentive operation of the truck. When driving, keep your attention to the road. Infotainment tasks that require your attention should be done when the truck is stationary. Examples of such tasks are managing connected devices or planning a route in the navigation system. 01 Infotainment 2 Assembly date filter: w2037 (2020-09-07). Variant filter on: TYPE-FH,STWPOS-L,CRUISEC,HWSS-ACB,AUD-HIGH,CO-USB3,COD-BRA,COD-NS. Projectfilter: No Filter. Overview Controlling the infotainment system In the side display you can see all the available menus and functions of the infotainment system. Some information is also shown in the instrument display. You can use the following controls to control the functions in the infotainment system: • The touchscreen on the side display • The control panel • The steering wheel keypads Some functions can be controlled only by the touchscreen. Usually, there are several ways to start or control a function. Communication, for example, can be started in the following ways: • Press the Communication key on the control panel. • Select Communication in the secondary display. • Press the Accept key on the steering wheel keypad. All ways of controlling a function are not described in this handbook. Side display At start-up, the home screen is shown in the side display. Use the icons in the bottom bar of the display to access the apps and functions in your truck. 1 Status bar 2 Clock 3 Notifications 4 Bottom bar 5 MEDIA 6 COMMUNICATION 7 VEHICLE 8 MY APPS 9 SETTINGS 10 Back 11 Home 12 Collapsed menu General controls in the side display Some controls in the side display are common for several apps. The Back icon. Select Back when you want to return to the previously viewed screen. If there is no save option on the screen, any changes that have been done are automatically saved when you select Back. If there is a save option, and if you do not select Save before you select Back, any changes are disregarded. The Home icon. To return to the home screen, select Home. The Collapsed Menu icon. When you are using an app, select Collapsed Menu to open or close the menu of the app. 01 Infotainment 3 Assembly date filter: w2037 (2020-09-07). Variant filter on: TYPE-FH,STWPOS-L,CRUISEC,HWSS-ACB,AUD-HIGH,CO-USB3,COD-BRA,COD-NS. Projectfilter: No Filter. Overview Control panel 1 Volume. 2 On/off. When in function mode Living, press On/off to start the infotainment system and long-press to turn it off. When listening to radio or media files, press On/off to mute or unmute. 3 MEDIA. 4 COMMUNICATION. 5 NAVIGATION. 6 VISION CAMERA. 7 Preset. Preset stations 1 to 4. 8 Previous. 9 Next. Steering wheel keypads 1 Left. Navigate left in the display. 2 Up. Navigate up in the display. 3 Right. Navigate right in the display. 4 Down. Navigate down in the display. 5 OK. Select a highlighted item. 6 Home. Return to the display's home screen. 7 Menu. Open the main menu. 8 Push to talk. Activate voice control. 9 Accept. Open the app PHONE or answer an incoming call. 10 End/reject. End a call or reject an incoming call. 11 Back. Return to the previously viewed screen. 12 Switch focus. Switch between controlling the side display and controlling the instrument display. The Switch focus icon is briefly shown in the selected display. 1 Mute. 2 Reduce volume. 3 Increase volume. 01 Infotainment 4 Assembly date filter: w2037 (2020-09-07). Variant filter on: TYPE-FH,STWPOS-L,CRUISEC,HWSS-ACB,AUD-HIGH,CO-USB3,COD-BRA,COD-NS. Projectfilter: No Filter. MEDIA A short introduction to MEDIA The MEDIA icon. In MEDIA, you can for example listen to radio or to music from a connected device. Devices can be connected to the infotainment system through Bluetooth ® or USB. Opening MEDIA To open MEDIA, select MEDIA in the bottom bar. Adjusting the volume Use the volume control keys on the left steering wheel keypad to adjust the volume. You can also turn the knob on the control panel clockwise or counterclockwise. If you want to mute the speakers, press the Mute key on the steering wheel keypad. To unmute, press the Mute key on the steering wheel keypad again or raise the volume. Selecting a source When you open MEDIA, the last selected source will show in the display. If you want to change source, if the source that you selected last is not available or if you previously have not selected a source, open the MEDIA menu. To open the MEDIA menu, press the Menu key on the right steering wheel keypad. Select the source you want from the list. When you make a selection, the MEDIA menu closes and the selected source is shown in the display. If you want to listen from a Bluetooth ® device, select Bluetooth. The menu expands and all paired devices that are within reach are shown in the list. Select one of the paired …
