Technical Description The Equipment Under Test (EUT), is a portable 2.4GHz Transceiver (Controller Unit) for a RC Dog. The sample supplied operated on 27 channels, normally at 2407 - 2475MHz. The channels are shown in below table. 2407 2409 2411 2413 2415 2417 2419 2421 2423 2431 2433 2435 2437 2439 2441 2443 2445 2447 2459 2461 2463 2465 2467 2469 2471 2473 2475 Antenna Type: Internal, Integral antenna Antenna Gain: 0dBi Nominal rated field strength is 77.9dBμV/m at 3m (Peak), 59.8dBμV/m at 3m (Average) Maximum allowed production tolerance: +/- 3dB The brief circuit description is listed as follows: 1. U4 acts as RF Module 2. U1 (SOP16) acts as PCB Adapter 3. Y1 acts as 16MHz Oscillator 4. C2 and C4 act as antenna matching circuit

Analysis Report The Equipment Under Test (EUT), is a portable 2.4GHz Transceiver (Controller Unit) for a RC Dog. The sample supplied operated on 27 channels, normally at 2407 - 2475MHz. The channels are shown in below table. 2407 2409 2411 2413 2415 2417 2419 2421 2423 2431 2433 2435 2437 2439 2441 2443 2445 2447 2459 2461 2463 2465 2467 2469 2471 2473 2475 The EUT is powered by 2 x 1.5V AAA batteries. After switching on the EUT, the dog will be moved forward or backward, turned left and right and emit sounds based on the switches pressed in the controller. Antenna Type: Internal, Integral antenna Antenna Gain: 0dBi Nominal rated field strength is 77.9dBμV/m at 3m (Peak), 59.8dBμV/m at 3m (Average) Maximum allowed production tolerance: +/- 3dB According to the KDB 447498: Based on the maximum average field strength of production tolerance was 62.8dBμV/m at 3m in frequency 2.475GHz. Thus, it below calculated field strength according to minimum SAR exclusion threshold level as follows: The worst case of SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.483.5) mW = 9.52 mW According to the KDB 412172 D01: EIRP = [(FS*D) ^2*1000 / 30] Calculated Field Strength for 9.52mW is 105dBuV/m @3m Since maximum average field strength plus production tolerance < = 105dBuV/m @3m and antenna gain is > = 0.0dBi, it is concluded that maximum Conducted Power and Field Strength are well below the SAR Exclusion threshold level, so the EUT is considered to comply with SAR requirement without testing.

11 22 33 44 55 66 77 88 D D C C B B A A Title Number Revision Size A3 Date: 2021/6/4 Sheet of File: E:\#MGA 657719 830604\..\657719 0402 SCH.SchDo c Drawn By: SPK 16R 0.25W 29mm 小头 C01104 -+ MT1MOTOR BAT VDD 1 INA 2 INB 3 VCC 4 OUTB 5 AGND 6 PGND 7 OUTA 8 U5TDM001 IOA9IOA10 SW1 SS23E02G4-N 6.0VAA*4 BAT IOA13 Try me Play OFF TRA120 PTC C02104C03104 MGA 狗 657719 Vin 2 GND 1 Vout 3 U3 GPY0029C v00 VDD3V3 C1 220uF C44 220uF C30.1uF R340R CS# 1 SO 2 WP# 3 GND 4 SI 5 SCLK 6 HOLD# 7 VDD 8 U9TM1003 R1 BEAD R2 BEAD R71 BEADR72 BEAD DVDD3V VDDIO PVDD VDD_REGIN VDD3V3 R73 BEADR74 BEADR75 BEAD AVSSPVSSDVSS VDD3V3 IOB3IOB4IOB5DVSS IOB0 IOB1 IOB2 V33_REG C571uF C58NC DVSS VR1 SR-085-B50K CB 8 VINP 2 RA 6 VOUT 7 VDD 3 GND 4 CA 1 CE 5 U4 TX5321 C70.1uF R6 270K IOA21 R451R D1 Photo Sensor C16 10uF C5 1uF R5100M C40.1uF R7240K DVSS DVDD3V R28 BEADR29 BEAD AUDNAUDP Touch Head 35*70mmTouch Back 30*70mm IOA0IOA1 12345 J7CON 5P IEC interface VDDIOICE_SCKICE_SDA RESET/SCKIOA24/SDA DVSS IOA16IOA17IOA18IOA19IOA20 IOA21 IOA22IOA23IOA24/SDARESET/SCKADVCMMICIN VDD_REGIN DVSS V33_REG IOB0 IOB1 IOB2 IOB3 IOB4 IOB5 PVDD AUDNAUDPPVSSIOA0IOA1IOA2IOA3IOA4DVSSTESTIOA5IOA6 IOA10 IOA11 IOA12 VDD15 VDDIO DVSS R260R C62.2uF C202.2uF C142.2uF C182.2uF C364.7nF C94.7nF C342.2uF C402.2uF C2847uF DVSS DVSS DVSS DVSS PVSS PVSS PVSS AVSS AVSS VDD15 VDDIO VDD_REGIN V33_REG AUDN AUDP PVDD ADVCM AVDD3V GND 1 VDD 2 PB5 3 PB6 4 PB7 5 PA7 6 PA6 7 PA5 8 PA3 9 PA4 10 PA0 11 PB0 12 U82.4G MODULE_TX GND 1 VDD 2 PB5 3 PB6 4 PB7 5 PA7 6 PA6 7 PA5 8 PA3 9 PA4 10 PA0 11 PB0 12 U12.4G MODULE_RX SW2 SS-12F15G4 VDD3V 3.0V AAA*2 R25470R S1 Dance S2 Stop S3 Right S4 Forward S5 Left R16470R LED1RED VDD3V VDD3V3 RxPower IOA3IOA4IOA5IOA6IOA7 MK-55DB R692.2K C380.22uF C350.1uF 6*5.5mm -55DB （ -54 至 -56DB ） C3710uF R701K AVDD3V MICIN AVSS C04104 -+ MT2MOTOR BAT VDD 1 INA 2 INB 3 VCC 4 OUTB 5 AGND 6 PGND 7 OUTA 8 U6TDM001 IOA11IOA12 C05104C06104 DVDD3V S6 KFC-V-101 C22.2uF R181K R121K IOA17 IOA18 VDD358 AVSS DVSS IOA14 7 + 5 - 6 U7BLM358 + 3 - 2 1 48 U7ALM358 AVSS R1347K VDD358 R1522K C13 0.1uF AVSS IN IN MK-L-55DB R92.2K AVSS C12 0.22uF R1410K VDD358 R24499K C150.1uF R23100KR22100K AVSSVDD358 R20100K C110.1uF R21100K VDD358AVSS IOA20 IOA19 R11499K MK-R-55DB R82.2K AVSS C8 0.22uF R1010K VDD358 Q1SI2301 R17100R R19NC DVDD3V IOA16 VDD358 P-Mosfet S7 D3-S12D22G4Language Bleeder Bleeder IOA16 4 IOA24/ICE_SDA 12 RESET/ICE_SDA 13 ADVCM 15 MICIN 16 VSS_ADC 17 V33_ADC 18 VDD_REGIN 19 VSS 20 V33_REGOUT 21 AUDN 31 IOA13/X32I 1 IOA14/X32O 2 IOA15 3 IOA17 5 IOA18 6 IOA19 7 IOA20 8 IOA21 9 IOA22 10 IOA23 11 VSS 14 IOB0 22 IOB1 23 IOB2 24 IOB3 25 IOB4 26 IOB5 27 PVDD 28 PVDD 29 AUDN 30 AUDP 32 AUDP 33 PVSS 34 PVSS 35 PVSS 36 PVSS 37 VSS 38 IOA0 39 IOA1 40 IOA2 41 IOA3 42 IOA4 43 VSS 44 TEST 45 IOA5 46 IOA6 47 IOA7 48 IOA8 49 IOA9 50 NC 51 NC 52 VDD15 53 IOA10 54 IOA11 55 IOA12 56 VDDIO 57 VSS 58 U2GPCM1F064A_0001 AVSSAVDD3VDVSS PVDD DVSS IOA7IOA8IOA9 R270R RxPower IOA13IOA14IOA15 IOA15 R30BEAD IOB1 IOA2 VDD358 EnglishFrench Bleeder C51NC R31 0R IOB0 PTC4.7R TX Part RX Part 1 2 3 4 ABCD 4 3 2 1 D CBA Teamway LTD Project Name: TIDS2.4G MODULE For reference only C20.5pF/NPO 3.3V ANT Y1 16.00MHz±10ppm/4*7 PA5 9 PA3 10 PA4 11 PA0 12 BP0 13 XC1 14 XC2 15 GND 16 PA6 8 PA7 7 MCUVDD 6 PB7 5 PB6 4 PB5 3 RFVDD 2 ANT 1 U1 C4 1.2pF/NPO 1 ANT1 C3 104 PB5PB6PB7PA7PA6 PA5PA3PA4PA0 PB0 PA6PA5PA3PA4PA0 3.3V 1234567 Programing Pin SOP16 PB5 3 PB6 4 PB7 5 PA7 6 PA6 7 PA5 8 VDD 2 GND 1 PA3 9 PA4 10 PA0 11 PB0 12 TIDS2.4G MODULE
