LW2-RMCTWireless Pressure Transmitter

Reference Manual 00809-0100-4102, Rev AA June 2012 Rosemount 2051 Wireless Series Pressure, Level, and Flow Solutions with WirelessHART™ Protocol Reference Manual 00809-0100-4102, Rev AA Title Page June 2012 i Rosemount 2051 Wireless Series Scalable Pressure, Flow, and Level Solutions Read this manual before working with the product. For personal and system safety, and for optimum product performance, make sure you thoroughly understand the contents before installing, using, or maintaining this product. For technical assistance, contacts are listed below: Customer Central Technical support, quoting, and order-related questions. United States - 1-800-999-9307 (7:00 am to 7:00 pm CST) Asia Pacific- 65 777 8211 Europe/ Middle East/ Africa - 49 (8153) 9390 North American Response Center Equipment service needs. 1-800-654-7768 (24 hours—includes Canada) Outside of these areas, contact your local Rosemount ® representative. The products described in this document are NOT designed for nuclear-qualified applications. Using non-nuclear qualified products in applications that require nuclear-qualified hardware or products may cause inaccurate readings. For information on Rosemount nuclear-qualified products, contact your local Rosemount Sales Representative. ii Reference Manual 00809-0100-4102, Rev AA Title Page June 2012 Failure to follow these installation guidelines could result in death or serious injury: Make sure only qualified personnel perform the installation. Explosions could result in death or serious injury: Installation of this transmitter in an explosive environment must be in accordance with the appropriate local, national, and international standards, codes, and practices. Please review the approvals section of this manual for any restrictions associated with a safe installation. Before connecting a Field Communicator in an explosive atmosphere, ensure the instruments are installed in accordance with intrinsically safe or non-incendive field wiring practices. Verify that the operating atmosphere of the transmitter is consistent with the appropriate hazardous locations certifications. Process leaks could result in death or serious injury. Install and tighten process connectors before applying pressure. Do not attempt to loosen or remove process connectors while the transmitter is in service. Electrical shock can result in death or serious injury. Avoid contact with the leads and terminals. High voltage that may be present on leads can cause electrical shock. The Rosemount 2051 and all other wireless devices should be installed only after the Smart Wireless Gateway has been installed and is functioning properly. Wireless devices should also be powered up in order of proximity from the Smart Wireless Gateway, beginning with the closest. This will result in a simpler and faster network installation. Shipping considerations for wireless products (Lithium Batteries: Green Power Module, model number 701PGNKF): The unit was shipped to you without the Power Module installed. Please remove the Power Module from the unit prior to shipping. Primary lithium batteries are regulated in transportation by the U. S. Department of Transportation, and are also covered by IATA (International Air Transport Association), ICAO (International Civil Aviation Organization), and ARD (European Ground Transportation of Dangerous Goods). It is the responsibility of the shipper to ensure compliance with these or any other local requirements. Please consult current regulations and requirements before shipping. Using the Rosmeount 3051 Wireless Pressure Transmitter in a manner other than what is specified by the menufacturer may impair the protection provided by the equipment. iii Reference Manual 00809-0100-4102, Rev AA Table of Contents June 2012 Ta b le of Co n tent s 1Section 1: Introduction 1.1Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.2Models Covered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.3Service Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 1.4Product Recycling/Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2Section 2: Configuration 2.1Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 2.2Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 2.2.1Warnings (). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 2.3Required Bench Top Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 2.3.1Connection Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 2.4Device Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2.4.1Join Device to Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2.4.2Configure Update Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.4.3Remove Power Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.5Review Configuration Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.5.1Review Pressure Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.5.2Review Device Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.5.3Review Sensor Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 2.5.4Review Radio Information . . . . . . …

Text truncated - open the document above for the full version.

Rosemount Inc. 8200 Market Boulevard Chanhassen, MN 55317 USA Attention: Application Examiner Re: Request for confidentiality Applicant: Rosemount, Inc. FCC ID: LW2RMCT To whom it may concern, Permanent Confidentiality Request is hereby submitted by Rosemount, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts list • Internal photos This de v i c e is a non-consumer device inaccessible to general public and is only accessable by qualified technical personnel in the industrial control industry. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request is hereby submitted by Rosemount Inc. to withhold from public review for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 45 days from the date of Authorization: • Test setup photos • External photos • User m an ual Rationale for request for confidentiality: Rosemount Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Principal Approvals Engineer Rosemount, Inc.

TEST REPORT Report Number: 100454947MIN-003 Project Number: G100454947 Testing performed on the Rosemount 2051 Wireless and Rosemount 3051 Wireless FCC ID: LW2-RMCT Industry Canada ID: 2731A-RMCT to 47 CFR Part 15. 247:2010 RSS- 210, Issue 8, 2010 For Emerson Process Management Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA Emerson Process Management 8200 Market Blvd. Mail Stop PM17 Chanhassen, MN 55317 Prepared by: Date: October 2, 2012 Uri Spector Reviewed by: Date: October 2, 2012 Norman Shpilsher This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. This report must not be used to claim product endorsement by A2LA, NIST nor any other agency of the U.S. Government. EMC Report No: 100454947MIN-003 FCC ID: LW2-RMCT IC ID:2731A-RMCT Page 2 of 55 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION.......................................................................................................... 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions.................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation................................................................................................... 6 2.0 TEST SUMMARY.......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS........................................................................................ 8 3.1 Maximum peak output power.............................................................................................. 8 3.2 6dB bandwidth of the digital modulation........................................................................... 12 3.3 Power spectral density ...................................................................................................... 16 3.4 Antenna conducted spurious emissions ........................................................................... 20 3.5 Radiated spurious emissions............................................................................................ 32 3.6 RF Exposure Compliance ................................................................................................. 48 3.7 Transmitter power line conducted emissions ................................................................... 49 3.8 Receiver/digital device radiated emissions....................................................................... 50 3.9 Digital device conducted emissions.................................................................................. 54 4.0 TEST EQUIPMENT..................................................................................................................... 55 EMC Report No: 100454947MIN-003 FCC ID: LW2-RMCT IC ID:2731A-RMCT Page 3 of 55 1.0 GENERAL DESCRIPTION Model: Rosemount 2051 Wireless and Rosemount 3051 Wireless Type of EUT: Wireless Pressure Sensor Serial Number: Demo FCC ID: LW2-RMCT Industry Canada ID: 2731A-RMCT Related Submittal(s) Grants: None Company: Emerson Process Management Customer: Mr. Merritt Pulkrabek Address: 8200 Market Blvd. Mail Stop PM17 Chanhassen, MN 55317 Phone: 952-949-5193 Fax: 952-949-7626 e-mail: [email protected] Test Standards: 47 CFR, Part 15:2010, §15.247 RSS–210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2010, §15.107 and §15.109, Class B ICES-003, Issue 4:2004 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: July 12, 2011 Test Work Started: July 12, 2011 Test Work Completed: July 18, 2011 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 100454947MIN-003 FCC ID: LW2-RMCT IC ID:2731A-RMCT Page 4 of 55 1.1 Product Description; Test Facility Product Description: 2.4 – 2.4835GHz Wireless Pressure Sensor Transmitter Type: FHSS Digital Modulation WiFi Blue Tooth Operating Frequency Range(s): Range: From 2400 to 2483.5 MHz Number of Channels: 16 Modulation: QPSK Emission Designator: 1M55G7D Antenna(s) Info: Antenna Type: Omni directional Gain: 2.0dBi Connector Type: Solder direct to circuit board via coax Antenna Installation: User Professional Factory Transmitter power configuration: Internal battery External power source 120VAC 230VAC 400VAC 3.6VDC Other: Amp. 50Hz 60Hz Special Test Arrangement: None Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 and FCC DTS Measurement Guide EMC Report No: 100454947MIN-003 FCC ID: LW2-RMCT IC ID:2731A-RMCT Page 5 of 55 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous transmissions (modulated signal) - Continuous transmissions (un-modulated signal) - Continuous receiving - Test program (customer specific) - Operating modes of the EUT: N…
