LW2775-WMWireless Industial Control Field Adapter

Reference Manual 00809-0100-4075, Rev CA March 2014 Smart Wireless THUM ™ Adapter iii Reference Manual 00809-0100-4075, Rev CA Smart Wireless THUM™ Adapter Smart Wireless THUM™ Adapter Hardware Revision 1 HART ® Device Revision 1 Field Communicator Field Device Revision Dev v2.5 DD v4 NOTICE Read this manual before working with the product. For personal and system safety, and for optimum product performance, make sure to thoroughly understand the contents before installing, using, or maintaining this product. The United States has two toll-free assistance numbers and one international number. Customer Central 1 800 999 9307 (7:00 a.m. to 7:00 p.m. CST) National Response Center 1 800 654 7768 (24 hours a day) Equipment service needs International 1 952 906 8888 The products described in this document are NOT designed for nuclear-qualified applications. Using non-nuclear qualified products in applications that require nuclear-qualified hardware or products may cause inaccurate readings. For information on Rosemount nuclear-qualified products, contact an Emerson Process Management Sales Representative. Explosions could result in death or serious injury: Installation of this transmitter in an explosive environment must be in accordance with the appropriate local, national, and international standards, codes, and practices. Please review the Product Certifications section for any restrictions associated with a safe installation. „Before connecting a Field Communicator in an explosive atmosphere, ensure the instruments are installed in accordance with intrinsically safe or non-incendive field wiring practices. Electrical shock can result in death or serious injury: „Avoid contact with the leads and terminals. High voltage that may be present on leads can cause electrical shock. This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions. This device may not cause harmful interference. This device must accept any interference received, including interference that may cause undesired operation. This device must be installed to ensure a minimum antenna separation distance of 20 cm from all persons. iv Reference Manual 00809-0100-4075, Rev CA NOTICE The THUM and all other wireless devices should be installed only after the Smart Wireless Gateway has been installed and is functioning properly. Wireless devices should also be powered up in order of proximity from the Smart Wireless Gateway, beginning with the closest. This will result in a simpler and faster network installation. NOTICE During normal operation, or in fault condition, the THUM will cause a 2.5 V drop in the connected loop. It is important to ensure that the power supply can provide at least 2.5 V more than the lift off voltage of the wired device to make sure it works properly with the THUM installed. To determine the lift off voltage for the wired device, review the wired device operation and installation manual. v Reference Manual 00809-0100-4075, Rev CA Table of Contents March 2014 Table of Contents 1Section 1: Introduction 1.1Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.1.1Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.2Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1.2.1Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 1.2.2Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 1.3.1General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3.2Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3.3Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3.4Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3.5Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.3.6Wireless considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1.4Service support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 1.5Product recycling/disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 2Section 2: Configuration 2.1Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2.1.1Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2.2Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 2.3Device sensor configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.4Connection diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 2.5Device network configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.5.1Join device to network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.5.2Configure update rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 2.5.3Configure THUM long tag . . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Letter of Agency I appoint Intertek Testing Services NA Inc. to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment under the FCC rules until further notice. I further certify that no party (as defined in 1.2002 of CFR 47, 1995) to this application, including myself, is subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.,853A. Equipment: Rosemount Wireless THUM Adapter Dated this _7th__day of March 2014. _ Signature Merritt Pulkrabek_______________________ Name Approvals Engineer_____________________ Title Rosemount Inc.________________________ Company 952.949.5193 _________________________ Telephone

Rosemount Inc. 8200 Market Boulevard Chanhassen, MN 55317 USA Attention: Application Examiner Re: Request for confidentiality Applicant: Rosemount, Inc. FCC ID: LW2775-WM To whom it may concern, Permanent Confidentiality Request is hereby submitted by Rosemount, Inc. to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts list • Internal photos This device is a non-consumer device inaccessible to general public and is only accessable by qualified technical personnel in the industrial control industry. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request is hereby submitted by Rosemount Inc. to withhold from public review for a period of 45 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept confidential for a period of 45 days from the date of Authorization: • Test setup photos • External photos • User manual Rationale for request for confidentiality: Rosemount Inc. has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us.: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development.] Sincerely, Principal Approvals Engineer Rosemount, Inc.

TEST REPORT Report Number: 101507452MIN-001F Project Number: G101507452 Testing performed on the 775 FCC ID: LW2775-WM to 47 CFR Part 15.247:2013 RSS- 210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2013, §15.107 and §15.109, Class / ICES-003, Issue 5:2012 For Emerson Process Management Test Performed by: Test Authorized by: Intertek Testing Services NA, Inc. 7250 Hudson Blvd., Suite 100 Oakdale, MN 55128 USA Emerson Process Management 8200 Market Blvd. Chanhassen, MN 55317 Prepared by: Date: January 31, 2014 Uri Spector Reviewed by: Date: January 31, 2014 Simon Khazon This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. EMC Report No: 101507452MIN-001F FCC ID: LW2775-WM Page 2 of 57 TABLE OF CONTENTS 1.0 GENERAL DESCRIPTION.......................................................................................................... 3 1.1 Product Description; Test Facility ....................................................................................... 4 1.3 Environmental conditions.................................................................................................... 5 1.4 Measurement uncertainty ................................................................................................... 6 1.5 Field Strength Calculation................................................................................................... 6 2.0 TEST SUMMARY.......................................................................................................................... 7 3.0 TEST CONDITIONS AND RESULTS........................................................................................ 8 3.1 6dB DTS bandwidth of the digital modulation .................................................................... 8 3.2 Maximum peak output power............................................................................................ 12 3.3 Power spectral density...................................................................................................... 16 3.4 Antenna conducted spurious emissions ........................................................................... 20 3.5 Radiated spurious emissions............................................................................................ 29 3.6 RF Exposure Compliance ................................................................................................. 46 3.7 Transmitter power line conducted emissions ................................................................... 47 3.8 Receiver/digital device radiated emissions....................................................................... 50 3.9 Digital device conducted emissions.................................................................................. 54 4.0 TEST EQUIPMENT..................................................................................................................... 57 EMC Report No: 101507452MIN-001F FCC ID: LW2775-WM Page 3 of 57 1.0 GENERAL DESCRIPTION Model: 775 Type of EUT: Industrial Wireless communication adapter Serial Number: N/A FCC ID: LW2775-WM Related Submittal(s) Grants: None Company: Emerson Process Management Customer: Mr. Merritt Pulkrabek Address: 8200 Market Blvd., Mail Stop SB4L Chanhassen, MN 55317 Phone: (952) 949-5193 Fax: (952) 949-7626 e-mail: [email protected] Test Standards: 47 CFR, Part 15:2013, §15.247 RSS–210, Issue 8, 2010 RSS-Gen, Issue 3, 2010 47 CFR, Part 15:2013, §15.107 and §15.109, Class B ICES-003, Issue 5:2012 Other Type of radio: Stand -alone Module Hybrid Date Sample Submitted: January 27, 2014 Test Work Started: January 27, 2014 Test Work Completed: January 31, 2014 Test Sample Conditions: Damaged Poor (Usable) Good EMC Report No: 101507452MIN-001F FCC ID: LW2775-WM Page 4 of 57 1.1 Product Description; Test Facility Product Description: 2.4 – 2.4835GHz Transceiver Transmitter Type: FHSS Digital Modulation WiFi Blue Tooth Operating Frequency Range(s): From 2400 to 24835 MHz Number of Channels: 16 Modulation: QPSK Emission Designator: 1M5G7D Antenna(s) Info: Antenna 1. Type: Omni directional Gain: 2dBi Connector Type: Solder direct to circuit board via coax Antenna Installation: User Professional Factory Transmitter power configuration: Internal battery External power source 120VAC 230VAC 400VAC 6VDC Other: Amp. 50Hz 60Hz Special Test Arrangement: None Test Facility Accreditation: A2LA (Certificate No. 1427.01) Test Methodology: Measurements performed according to the procedures in ANSI C63.10- 2009 and FCC 558074 D01 DTS Measurement Guidance EMC Report No: 101507452MIN-001F FCC ID: LW2775-WM Page 5 of 57 1.2 EUT Configuration The equipment under test was operated during the measurement under the following conditions: - Standby - Continuous transmissions (modulated signal) - Continuous transmissions (un-modulated signal) - Continuous receiving - Test program (customer specific) - Operating modes of the EUT: No. Description 1 Test was performed at low channel, middle channel, and upper channel 2 Cables: No. Type Length Designation Note 1 2-wire DC power cable >10ft DC power 2 2-wire communication cable >10ft Support equipment/S…

Text truncated - open the document above for the full version.
