LZ6ALPHA3000MODELIndustrial Radio Remote Control

1 T T A A B B L L E E O O F F C C O O N N T T E E N N T T S S Page 1. INTRODUCTION ....................................................................................................... 2 2. SAFETY INSTRUCTION ............................................................................................. 3 3. TRANSMITTER ILLUSTRATION 3.1 Alpha 3000 External Assembly ......................................................................... 4 3.2 Alpha 3000 Internal Assembly ......................................................................... 5 4. RECEIVER ILLUSTRATION 4.1 External Assembly ............................................................................................... 6 4.2 Alpha 3000 Internal Assembly ......................................................................... 7 5. OUTPUT CONTACT DIAGRAM Alpha 3000 Output Contact ............................................................................. 8 6. SYSTEM CONFIGURATIONS 6.1 Jumper Settings ................................................................................................... 9 6.2 Security ID Code Settings ..................................................................................... 10 6.3 Pushbutton Contact Settings ................................................................................. 11 6.4 Voltage Settings ..................................................................................................... 11 7. RECEIVER INSTALLATION 7.1 Preparation For Installation ................................................................................... 12 7.2 Step By Step Installation ....................................................................................... 12 7.3 System Testing ....................................................................................................... 13 8. TRANSMITTER OPERATION ................................................................................... 14 9. TROUBLE SHOOTING ............................................................................................... 15 10. SYSTEM SPECIFICATION ......................................................................................... 16 11. PARTS LIST ................................................................................................................. 17 2 1 1 . . I I N N T T R R O O D D U U C C T T I I O O N N The Alpha 3000 System is a highly reliable industrial radio remote control system. The versatile features of the Alpha 3000 system permit its use in many different remote control applications that required 3-step control. The system can be used to control factory cranes, multiple hoists, trolleys, mining equipment, building construction equipment, automatic control systems, and many others. The Alpha 3000 Radio Remote Control System incorporates numerous redundant safety circuits that guaranty maximum security and ensure the system is resistant to outside interference. The major features of the Alpha 3000 system are as follow: * The system uses advanced microprocessors with highly evolved software that has redundant error checking and correcting capabilities to ensure 100% error-free transmission, decoding, and control of all output relays. This highly evolved software includes CRC (cyclical redundancy check codes) and Hamming Codes (error recovery). * To insure maximum operating safety, the Alpha 3000 system incorporates numerous safety features. Some of these built-in safety features include transmitter pushbutton self-diagnosing, transmitter low-voltage detection and warning, receiver self-diagnosing, and MAIN deactivation when the system is in sleep mode. * The transmitter encoder and receiver decoder both utilize advanced microprocessor control. The availability of 65,536 sets of unique ID codes will ensure that only commands from the matching control transmitter can be carried out without any interference from other radio systems. * For added safety, the system also incorporates special Safety MAIN Relay. If the Safety MAIN Relay is defective (fails to open or close during operation), it will signal the system to shut down immediately to avoid the possibility of any accidents occurring. * Water-resistant transmitter and receiver enclosures. The Alpha 3000 Radio Remote Control System consists of a water-resistant handheld transmitter and receiver. The transmitter casing is molded using industrial strength composite materials which are impervious to dust, water, oil, acids, alkaline, heat and sunlight as well as being resistant to deformation due to long term use in harsh environments. The industry’s best 3-step pushbuttons are also constructed from industrial strength composite materials with a minimum of up to one million press cycles. For power savings, the transmitter is designed with an ultra high efficiency power saving circuit that requires only four “AA” size alkaline batteries for more than 200 hours of continuos operation between replacements. 3 2 2 . . S S A A F F E E T T Y Y I I N N S S T T R R U U C C T T I I O O N N The Alpha 3000 system is relatively simple to use, however, it is very important to observe the proper safety procedures before, during, and after operation. When used properly our Alpha 3000 radio remote controls will enhance safety, productivity and efficiency in the workplace. The following procedures should be strictly followed: 1. Check the transmitter casing and pushbuttons daily. Should any damage that could inhibit the proper operation of the transmitter be found the unit should be immediately removed from service. 2. The transmitter voltage should be checked on a daily basis. If the voltage is low (red status light blinking, refer to section 8 on page 14), the four “AA” alkaline batteries should be replaced. 3. The red mushroom type emergency stop button (EMS) should be checked at the beginning of each shift to ensure it is in proper working order and the Stop command is being received. 4. In the event of an emergenc…

Text truncated - open the document above for the full version.

ALPHA 580 TRANSMITTER BLOCK DIAGRAM TX1.VSD 05.15.2001 MOD IN bandpass filter TO : ENCODER Amplitude & double (3356) Osc & triple Amplitude & double (3356) Bandpass filter ` Bandpass filter 5V

Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE...

Alpha 3000 FCC ID Label FCC ID: LZ6ALPHA3000MODEL Fomotech International Corp. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operations. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Alpha 3000 FCC ID Label Location The FCC ID Label is located on the backside (top) of the Alpha 30000 transmitter unit.

Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE... Page 1 of 1 10/24/2001file://C:\TCB%20Certifications\Retlif\Retlif%20NY\Fomotech\LZ6ALPHA3000MODE...

Alpha 3000 Model Operational Description The Alpha 3000 industrial radio remote control system consists of a pushbutton type transmitter unit that operates on four (4) “AA” size alkaline batteries (6 volts) and a receiver unit that is hooked up to AC 110V~120V voltage input. The receiver also provides a terminal output for connection to Ground. The receiver unit is also equipped with an Arial Antennal that operates on 301MHZ range. The receiver unit is hooked up on to an industrial crane system with numerous travel directions and speeds via electrical motors. The output relays in the receiver is rated at DC 250V @ 10A. By pressing the pushbuttons on the transmitter unit will able the contact relays inside the receiver box to energize, thus activate the magnetic contactors inside the crane control panel. When the transmitter pushbutton is pressed, the encoder board will encode the information and then sends it out to the receiver unit via the transmitting circuitry. The receiving module inside the receiver unit then receives this transmitted information. Afterward it sends the received information to the decoding microprocessor for decoding process by numerous software programming (CRC and Hamming code bit checking). After decoding process is completed, the central microprocessor will then enable the intended contact relay or relays to energize. The receiver unit also equipped with Safety MAIN contact relay. When the transmitter unit is not in use, this Safety MAIN contact relays will be disengaged thus provide no power to the receiver unit.

TX2A2_V2.sch-1 - Wed Oct 03 16:34:36 2001 TX2B2_V2.sch-1 - Wed Oct 03 16:35:20 2001

Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL APPLICANT Fomotech International Corporation 2F-1, 286-3, Hsin Ya Road Chein, Chen District, Kaoshing, Taiwan MANUFACTURER SAME AS APPLICANT TEST SPECIFICATION: FCC Rules and Regulations Part 15, Subpart C, Para. 15.231 TEST PROCEDURE: ANSI C63.4:1992 TEST SAMPLE DESCRIPTION BRANDNAME: Fomotech International Corporation MODEL: Alpha 3000 TYPE: 301 MHz RF Remote Transmitter POWER REQUIREMENTS: 4 “AA” Batteries FREQUENCY OF OPERATION: 301.4 MHz TESTS PERFORMED Para. 15.231(b), Radiated Emissions, Fundamental and Harmonics Para. 15.209(c), Radiated Emissions, Spurious Case Para. 15.231(c), Occupied Bandwidth Para. 15.35(b), Duty Cycle Determination REPORT OF MEASUREMENTS Applicant: Fomotech International Corporation Device:301 MHz RF Remote Transmitter FCC ID: LZ6ALPHA3000MODEL Power Requirements: 4 “AA” Batteries Applicable Rule Section:Part 15, Subpart C, Section 15.231 Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL REPORT OF MEASUREMENTS (continued) TEST RESULTS 15.231 (a) -The device is used as a transmitter for Remote Control purposes. 15.231 (a)(1) & -The transmitter is manually operated and ceases transmission within 5 15.231(2)seconds after deactivation. 15.231 (a)(3) -The transmitter does not perform periodic transmissions. 15.231 (a)(4)-Not applicable 15.231 (b) -The fundamental field strength did not exceed 5,460 μV/M (Average) at a test distance of 3 meters. In addition, the requirements of section 15.35 for averaging pulsed emissions and for limiting peak emissions were met. The field strength of harmonic and spurious emissions did not exceed 546 μV/M (AVERAGE). 15.231 (c) -The device operates at 301.4 MHz. The bandwidth of emissions did not exceed 0.25% of the operating frequency (754 kHz). DETERMINATION OF FIELD STRENGTH LIMITS The field strength limits shown below are found in Section 15.231. Frequency Limit F1=2603750=L1 Fo=301.4Lo F2=47012500=L2 The formula below was utilized to determine the limits: Limit = L1 + [(Fo-F1)(L2-L1)/(F2-F1)] Solving yields: Fundamental Limit= 5,460 μV/M (AVERAGE) @ 3 Meters Harmonic Limit= 546 μV/M (AVERAGE) @ 3 Meters Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL REPORT OF MEASUREMENTS (continued) DETERMINATION OF DUTY CYCLE The unit’s RF output was directly coupled to the input of the spectrum analyzer. The analyzer was set for a frequency span of 0Hz. The sweep time was then adjusted in order to display one full pulse train. The transmitter on time was then summed and compared to the time for one full cycle in order to obtain the duty cycle. (See plots for additional information) Transmitter On Time=92.3 milliseconds (maximum- worst case in 100 ms) Transmitter Cycle Time=245 milliseconds Transmitter Duty Cycle=92.3 % SPECTRUM ANALYZER DESENSITIZATION CONSIDERATIONS Due to the nature of the emissions being measured, care was taken to ensure that the resolution bandwidth of the spectrum analyzer was adequate to provide accurate measurements. The following formula was utilized: Setting pulse desensitization equal to zero and utilizing the minimum observed pulse width of 92.3 milliseconds yields a minimum required bandwidth of 7.2 Hz. FCC specified bandwidths of 100kHz and 1MHz were utilized below and above 1GHz, respectively. Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL REPORT OF MEASUREMENTS (continued) GENERAL NOTES 1.All readings were taken utilizing a peak detector function at a test distance of 3 meters. 2.The duty cycle was applied to the peak readings in order to determine the average value of the emissions. 3.All measurements were made with 4 “AA” Batteries. 4.The frequency range was scanned from 30 MHz to 3.1 GHz. All emissions not reported were more than 20 dB below the specified limit. Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL TEST SETUP PHOTOGRAPH RADIATED EMISSIONS Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL EQUIPMENT LIST Radiated Emissions, Transmitter, 30MHz to 3.1GHz ENTypeManufacturerDescriptionModel No.Cal DateDue Date 032FH.P. FilterMicrolab/FXR2 GHz - 3 GHzHD-20N08/20/200108/20/2002 032GH.P. FilterMicrolab/FXR3 GHz - 6 GHzHA-30N04/11/200104/11/2002 067Open Area Test SiteRetlif3 MeterRNY09/20/200009/20/2003 128CDouble Ridge GuideEaton Corporation1 GHz - 18 GHz9600109/18/200009/18/2001 133Broadband Pre-AmplifierElectro-Metrics10 kHz - 1 GHz, 26dBBPA-100006/13/200106/13/2002 141Spectrum AnalyzerHewlett Packard100 Hz - 40 GHz8566B07/02/200101/02/2002 141AGraphics PlotterHewlett PackardN/A7470A03/05/200103/05/2002 141BQuasi-Peak AdaptorHewlett Packard100 Hz - 1 GHz85650A02/20/200101/02/2002 206B6.0 dB AttenuatorTexscan0 - 1.0 GHzFP-50 - 6 dB06/13/200106/13/2002 3116Pre-AmplifierMiteq0.1 GHz - 18 GHzAFS42-3511/07/200011/07/2001 523BiconilogElectro-Mechanics26 - 2000 MHz3142B06/08/200010/08/2001 617Interference AnalyzerElectro-Metrics10 kHz - 1 GHzEMC-3002/27/200102/27/2002 Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL FCC 15.231(b) and FCC 15.231(c) RADIATED EMISSIONS (Please see separate e-file attachment named REfundharm.pdf and REspur.pdf) Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL FCC 15.231(c) OCCUPIED BANDWIDTH (Please see separate e-file attachment named Occbw.pdf) Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL FCC 15.35(b) DUTY CYCLE (Please see separate e-file attachment named Dutycycle.pdf) Retlif Testing Laboratories R Data Sheet 1 of 4 Test Method: FCC Part 15 Subpart C Radiated Emissions, Fundamental & Harmonic Emissions Customer: Fomotech Job No. R-9147-1 Test Sample: RF remote Paragraph: 15.231(b) Model No.: ALPHA3000 FCC ID: LZ6ALPHA3000MODEL Operating Mode: Continuously …

Text truncated - open the document above for the full version.

Retlif Testing Laboratories R Test Report No. R-9147-1 FCC ID: LZ6ALPHA3000MODEL TEST SETUP PHOTOGRAPH RADIATED EMISSIONS
