FCC Part 15D – APPLICATION FORM & SELF-DECLARATION Applicant Name Unical Enterprises Inc. Address 16960 Gale Ave., City Of Industry, CA Contact person Andy Chung Telephone No. 1-626-965-5588 Fax No. 1-626-965-0970 Manufacturer Name Richhonest (Europe) LTD. Address 8th Floor, St. John’s Building 33 Garden Road, Central, Hong Kong FCC ID LZXDM1500C (for Base unit) , LZXDM150HS (for Handset) Model Number X1500CˈX1500C-2HS, X1500 Series HW version DM1500 ver.F (BS:DM1500BS-F, HS:DM1500HSS-H˅ SW version Antenna Type BS: Loop Antenna HS: Inverted L Antenna Max, Antenna Gain(dBi) +1.5 -4 Mains Power Voltage BS: DC9.5V HS : DC5.0V (Charger) DC2.4V (Battery) Use supplied AC Adaptor Battery Voltage Base(Option):3.7V(Li-ion) Handset:2.4V(Ni-MH) Number of channels 5 Carrier frequency(MHz) 1928.448 1926.720 1924.992 1923.264 1921.536 Nominal Receive Bandwidth 1.724MHz Frame period(ms) 10 Timeslot Plan TX x 12 slots ,RX x 12 slots Operating Temperature Range(DŽC) -10 to +50 ć Does a system built with the EUT that implement the provisions of 47CFR 15.323(c) (5) enabling the use of the upper threshold for deferral? Yes No According to 47CFR 15.323(c) (5).4, does your model not use bandwidth in further cooperation with other devices at any range? Yes No Does a system built using the EUT that operate under the provisions of 47CFR 25.323(c) (6) incorporating provisions for waiting for a channel to clear? Yes No According to 47CFR 15.323(c) (8), does EUT use the same antennas for transmission and reception as for monitoring? Yes No Does a system built with the EUT that operate under the provisions of 47CFR 15.323(c) (10) to test for deferral only in conjunction with a companion device? Yes No Does a system built using the EUT that operate under the provisions of 47CFR 15.323(c) (11) enabling the access criteria check on the receive channel while in the presence of collocated interferers? Yes No According to 47CFR 15.323(c) (12), does EUT not work in a mode with denies fair access to spectrum for other devices. Yes No Does you model have the monitoring made through the radio receiver used for communication? Yes No Does your model transmit control and signaling channels? Yes No According to 47CFR 15.307(b), does the applicant have the affidavit from UTAM Inc.? Yes No According to 47CFR 15.319(b), do all transmissions use only digital modulation techniques? Yes No The provisions within the EUT for self-check, by which compliance with 47CFR 15.319(f) is obtained. A – Connection break down, cease of transmit B – Connection break down, EUT transmits its signaling information C – Connection break down, compare device transmits signaling information N – Not possible Situation Reaction of EUT FP PP Switch-off compare device B N Hook-on by compare device B N Switch-off by EUT N A Hook-on at EUT side N A Remove Power from EUT A A Remove Power from compare device A A Date: 2011-11-12 Andy Chung Assistant to the president
EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS EUT with Adapter View EUT – Front View EUT - Rear View EUT - Port View EUT – Adapter View
EXHIBIT A - FCC ID LABELING AND LOCATION FCC ID Label FCC ID Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)
EXHIBIT C - EUT INTERNAL PHOTOGRAPHS EUT – Battery off View EUT – Cover off View EUT – DM1500-SUB-E Board Top View EUT – DM1500-SUB-E Board Top Shielding off View EUT – DM1500-SUB-E Board Bottom View EUT – DM1500-SUB-E Board Bottom Shielding off View EUT – DM1500-CPU-F Board Top View EUT – DM1500-CPU-F Board Top Shielding Off View EUT – DM1500-CPU-F Board Bottom View EUT – DM1500-CPU-F Board Bottom Shielding Off View EUT – CDMA Module View EUT – Battery View
Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: RSZ110517004-00FP FCC Part 15D Page 9 of 54 FCC §15.319 (i) & §2.1091 - RF RADIATION EXPOSURE Limit According to FCC KDB 447498, section 7 (ii), The antenna separation distance and MPE compliance boundary requirements that enable all simultaneous transmitting antennas incorporated within the host to comply with MPE limits are specified in the application filing of at least one of the certified transmitters incorporated in the host device.32 In addition, when transmitters certified for portable use are incorporated in a mobile host device the antenna(s) must be ≥ 5 cm from all other simultaneous transmitting antennas. All antennas must be at least 20 cm from users and nearby persons. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minute) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *(100) 30 1.34-30 842/f 2.19/f *(180/f\2\) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Test Data Predication of MPE limit at a given distance, Equation from OET Bulletin 65, Edition 97-01 Where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW). G = power gain of the antenna in the direction of interest relative to an isotropic radiator, The power gain factor is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Band Frequency (MHz) EIRP (dBm) Minimum Distance (cm) MPE (mW/cm 2 ) MPE Limit (mW/cm 2 ) Result UPCS 1924.992 19.04 20 0.016 1.0 Pass Cellular 824.70 24.15 20 0.052 0.55 Pass PCS 1851.25 21.27 20 0.027 1.0 Pass Note: 1) The distance between DECT antenna and Cellular/PCS antenna is 10.5 cm > 5 cm. 2) The minimum distance between antennas of product and nearby person is 20 cm. Result: The device meets FCC MPE limit at 20 cm distance.
