M4SPBX-990XPCORDLESS TELEPHONE

EXHIBIT C User Manual TABLE OF CONTENTS IMPORTANT SAFTY INSTRUCTIONS LOCATION AND DISCRIPTION OF CONTROLS Base unit(Desk-top) Base unit(Wall-mount) Handset Charger stand INSTALLATION Base unit Handset Charger stand Batteries LCD DISPLAY & MESSAGE OPERATION Turn ON/OFF Making calls Answering calls Last number redial Speed dial mode Call Transfer Intercom Group paging Transmitting (TX) power control Volume control Voice scramble Free channel scan on handset Talking time control Handset microphone sensitivity adjustment PABX (multi-base) operation PPOGRAMING INSTRUCTION Introduction Base unit Handset DISA AND DIGITAL ANSWERING MACHINE Introduction Outgoing messages DISA operation Voice mail operation Listen to Message and Delete Message Memo Message Option Important TIPS FOR OPERATION PROBLEM 1 2 3 4 5 6 7 7 8 9~10 11 11 11 11 12 12 13 13 13 13 13 14 14 14 14 15 16 17 18 18 19 20 20 21 21 22 Thank you for purchasing “Voyager” Cordless Telephone System. To ensure that you enjoy the full capacities of this product, please read this user’s manual before operating. IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: 1. Read and follow all instructions carefully. 2. Follow all warning and instructions on the product. 3. Unplug this product from the host telephone equipment before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. 4. Do not use this product near water. 5. Do not place this product on top of metal surface or an unstable cart, stand, or table. 6. Do not allow anything to rest on the power cords. Do not locate this product where the cords will be abused by person’s walking on them. 7. Do not use this product in the vicinity of gas leak or any explosive fumes. To report such a hazardous condition, use a telephone away from the area in question. 8. Do not place this product near or over a radiator or heat source. 9. This product should only be operated with the Mains Power Unit supplied. 10. Do not overload the Mains wall outlets and extension cords as this can result in a risk of fire or electric shock. 11. Do not open this product. No user serviceable parts are inside. Take it to a qualified serviceman when service or repair work is required. Opening the product may expose yourself to dangerous voltage or other risks. Incorrect reassemble may result in electric shock when the product is subsequently used. 12. Never spill liquid on the product or push object of any kind through its ventilation slots. 13. Avoid using this product during an electrical storm. There may be a remote risk of electrical shock from lighting. 14. Use only the recommended by the manufacturer and only with the equipment provided by the manufacture. Do not break open batteries or bum them. Dispose of batteries safely. Batteries contain materials that are hazardous to persons and the environment. 1 CONTROL PANEL INDICATION Base unit (Desk-top) 1. Fixed antenna 2. Telephone jack 3. CO Line jack 4. DC power jack 5. Speaker 6. LCD Display 7. “OK”: OK(Confirm/Send) key 8. “HOLD” key 9. “C”: C(Clear/End) key 10. Dialing keys 11. Function keys MENU: Function select key F’SH: Flash key /Back space while dialing R/P: Redial/Pause key INT: Intercom key CID: Caller ID operation /Store and recall speed dial number. DAM: Digital answering Machine operation : Volume & select up key Volume & select down key 12. Microphone 13. Charging contact point (for charge handset) 2 Base unit (Wall-mount) 1. Fixed antenna 2. Telephone jack 3. CO. Line jack 4. Line slot 5. DC power jack 6. Connecting slot 7. Speaker 8. Display 9. “C“: C(Clear/End) key 10. Hold key 11. “OK”: OK(Confirm/Send) key 12. Dialing keys 13. Function keys MENU: Function select key F’SH: Flash key / back space While dialing R/P: Redial/Pause key INT: Intercom key CID: Caller ID operation/ Store And recall speed dial Number. DAM: Digital answering Machine : Volume & select up key Volume & select down key 14. Microphone 3 Handset 1. Fixed antenna 2. Speaker 3. LCD Display 4. Function keys OK: OK(Confirm/Send) key CO / SCN: CO key at Standby/Scan clear channel while talking C: Clear (End) key DAM / F’SH: Flash key / Back space while dialing / DAM view function at standby MIC / HOLD: Hold key/ Microphone sensitivity adjustment at standby INT: Intercom key SCR / MENU: Voice scramble operation / Function key MEMO: Store key R/P: Redial/Pause key : Volume & select up key Volume & select down key 5. Dialing keys 6. Microphone 7. Releasing latch 8. Battery charging contact point 9. Ringer 10. Audio jack 11. Battery pack *CO: for wireless PBX operation, please refer to operation section. 4 Charger Stand 1. Power indicator 2. Handset charging indicator (front slot) 3. Battery charging indicator (rear slot) 4. Charging cradle for handset 5. Charging slot for spare battery 6. DC power jack 7. Discharge button 8. Discharge indicator 5 INSTALLATION BASE UNIT 1. Gently rotate the flexible base antenna until it is positioned vertically. Note: Incorrect installation of the antennas will affect the communication range. 2. Connect the telephone line cord supplied. Plug one end into the RJ11 jack marked "LINE" at the back of the base unit and the other end into the power outlet. 3. Connect the Mains Power adapter supplied. Plug one end of the adapter into the 120/230V AC power socket and insert its mini-plug into the DC power socket at the back of the base unit. The base unit will show “STBY ICM”(standby) on LCD display when power is connected. Note: Use only the adapter supplied. Use of any other adapter could cause serious damage to the base unit 4. The system is preset for Tone dialing. Changing to Pulse dialing can be adjusted in some countries – refer to “Programming Instruction”. 5. It is allowed to connect a telephone to the base by connecting a line cord into the “TEL” jack. (Telephone se…

Text truncated - open the document above for the full version.

EXHIBIT E Block Diagram

EXHIBIT E Block Diagram

EXHIBIT F Photographs of EUT

List of Exhibit EXHIBIT A Sample Label EXHIBIT B Test Report EXHIBIT C User Manual EXHIBIT D Circuit Diagram EXHIBIT E Block Diagram EXHIBIT F Photographs of EUT EXHIBIT A Sample Label LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : M4SPBX-990XP Model No.: CL-2200XP, PBX-990XP-B LABEL Size: 45 X20 mm LABEL Position: LABEL LABEL

List of Exhibit EXHIBIT A Sample Label EXHIBIT B Test Report EXHIBIT C User Manual EXHIBIT D Circuit Diagram EXHIBIT E Block Diagram EXHIBIT F Photographs of EUT EXHIBIT A Sample Label LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : M4SPBX-990XP Model No.: CL-2200XP, PBX-990XP-B LABEL Size: 45 X20 mm LABEL Position: LABEL LABEL

EXHIBIT D Circuit Diagram

Test Report --------------------------------------------------------------------------------- 6/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 1.4 Configuration of System Under Test . Fig. 1 Configuration of system under test During testing the EUT was connected with a terminated. A diagram of the complete test configuration was shown in Fig 1. 1.5 Test Procedure All measurements contained in this report were performed mainly according to the techniques described in Measurement procedure ANSI C63.4 (1992). 1.6 Location of the Test Site The radiated emissions measurements required by the rules were performed on the OATS. Complete description and measurement data have been placed on file with the commission. The conducted power line emissions tests and other test items were performed in a anechoic chamber located at Training Research Co., Ltd. No. 15, Lane 530, Pa-Lian RD., Sec. 1, Hsichih City, Taipei Hsien, Taiwan, R.O.C.. Training Research Co., Ltd. is listed by the FCC as a facility available to do measurement work for others on a contract basis. HANDSET BASE To Far-end PABX Telephone PABX 120V AC SOURCE Test Report --------------------------------------------------------------------------------- 9/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 2.3 Test Configuration of Conducted Emission Fig. 1 Conducted Emissions Test Configuration (Handset Charging only) Fig. 1 Conducted Emissions Test Configuration (Handset Charging only) Test Report --------------------------------------------------------------------------------- 10/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Fig. 1 Conducted Emissions Test Configuration (Base Charging only) Fig. 2 Conducted Emissions Test Configuration (Base Charging only) Test Report --------------------------------------------------------------------------------- 11/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Fig. 1 Conducted Emissions Test Configuration (Operating only) Fig. 2 Conducted Emissions Test Configuration (Operating only) Test Report --------------------------------------------------------------------------------- 17/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 3.3 Test Configuration of Radiated Emission Picture 1 Front View of the Test Configuration (BASE) Picture 2 Rear View of the Test Configuration (BASE) Test Report --------------------------------------------------------------------------------- 18/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Picture 1 Front View of the Test Configuration (HANDSET) Picture 2 Rear View of the Test Configuration (HANDSET) Test Report --------------------------------------------------------------------------------- 41/41 Report No.: G0615197, Wireless Phone, FCC Part 15 Class B Test date: 12/13/2000, Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778
