1 Mike Kuo From: S. S. Liou [[email protected]] Sent: October162003Thursday 9:48 PM To: Mike Kuo Subject: Fw: HORNG WOEI ELECTRONIC CO., LTD., FCC ID:Q88IKEYPENDANTTX, AN03T3108 Hi Mike, Did you receive my reply? Our customer asked us the situation of this application. If there are any problems, please contact me. Thank you very much! regards, ================================ S. S. Liou Engineer / EMC Dep. II ETC ----- Original Message ----- From: "S. S. Liou" <[email protected]> To: "Mike Kuo" <[email protected]> Sent: Wednesday, October 08, 2003 4:45 PM Subject: Re: HORNG WOEI ELECTRONIC CO., LTD., FCC ID:Q88IKEYPENDANTTX, AN03T3108 > Hi Mike, > > Fundamental Frequency: 433.92 MHz > Duty cycle: duty factor is -12.6dB, please refer to section 4.6 of the test > report. > Periodical transmission: this device is manually operated. > The IR transmission programs the RF transmitter. Only coding data of the RF > transmitter will be changed. > > Best regards, > > ================================ > S. S. Liou > Engineer / EMC Dep. II > ETC > > ----- Original Message ----- > From: "Mike Kuo" <[email protected]> > To: "'S. S. Liou'" <[email protected]>; "Mike Kuo" <[email protected]> > Sent: Tuesday, October 07, 2003 8:22 AM > Subject: RE: HORNG WOEI ELECTRONIC CO., LTD., FCC ID:Q88IKEYPENDANTTX, > AN03T3108 > > > > Hi Mr. Liou: > > > > Please address the question #5 in term of fundamental frequency, duty > cycle > > and periodical transmission. Based upon your reply to question #1, > Infrared > > is used to program the transmitter, what is the programming sequence and > > what will be changed on the transmitter ? > > > > To find out more information on learned transmitter, please refer to FCC > > public notice:DA-02-2850 for detail information. > > > > Best Regards 2 > > > > Mike Kuo > > > > -----Original Message----- > > From: S. S. Liou [mailto:[email protected]] > > Sent: Monday, October 06, 2003 4:01 AM > > To: Mike Kuo > > Subject: Re: HORNG WOEI ELECTRONIC CO., LTD., FCC ID:Q88IKEYPENDANTTX, > > AN03T3108 > > > > > > Hi Mike, > > > > #1, the explanation of Block Diagram: > > a) Infrared Ray ................ For programming, you can program the > > pendant by programmer by Infrared Ray. > > b) RS-232........................For Programmer, we use RS-232 to connect > > Programmer and PC. PC can enocde the program into Programmer , than > > Programmer program Transmitter by Infrared Ray. > > c) Display........................Only Programmer has Display > > d) DC input & output.........Only Programmer and Receiver has . > > > > #2, As for Infrared Ray of Transmitter and Programmer , the function is > > .............. > > a) Programmer receive data from PC by RS-232. > > b) Programmer program the transmitter by Infrared Ray . > > > > #3, > > Infrared ray is for programming only. As the above mention, Programmer > > program the transmitter by Infrared Ray. > > > > #4, > > The intended usage is : To apply in Barrier , Parking and Rolling gate. > > Customer can use the transmitter to operate the barrier. > > The data will be transmitted to > > PC, that we know, WHEN and WHO had come in and go out. > > > > #5, Could you help us to classify this device? Is it a learned > transmitter? > > If yes, what sould we do with it? > > > > #6, the FCCID label is revised as attached file. > > > > Best regards, > > > > ================================ > > S. S. Liou > > Engineer / EMC Dep. II > > ETC > > > > > > ----- Original Message ----- > > From: "Mike Kuo" <[email protected]> > > To: "Will Yauo (E-mail)" <[email protected]>; "ETC/Iris (E-mail)" > > <[email protected]> > > Sent: Wednesday, September 03, 2003 5:35 AM > > Subject: FW: HORNG WOEI ELECTRONIC CO., LTD., FCC ID:Q88IKEYPENDANTTX, > > AN03T3108 > > > > > > > > > > > > > -----Original Message----- > > > From: CERTADM > > > Sent: Tuesday, September 02, 2003 1:34 PM > > > To: '[email protected]' > > > Subject: HORNG WOEI ELECTRONIC CO., LTD., FCC ID:Q88IKEYPENDANTTX, > > AN03T3108 3 > > > > > > > > > Notice_content > > > ------------- > > > Question #1: The functional block diagram contains additional functions > > > which may not applicable to this transmitter. For example: Infrared, > > RS232, > > > display, DC input and output. Please submit the functional block > diagram > > > which is only applicable to this device. > > > > > > Question #2: In the submitted schematic diagram, it contains Infrared > > > circuitry. Please explain the purpose of IR circuitry and location of > IR > > on > > > the internal photos. > > > > > > Question #3: In the operational description, " the transmission is by IR > " > > . > > > What does this statement mean ? Please provide more detail technical > > > information in the operational description to fully describe the device. > > > > > > Question #4: What is the intended usage of this transmitter ? > > > > > > Question #5: In the submitted user manual, it provides the description > on > > > how to program this transmitter. There is no description on the purpose > > of > > > programming. If this transmitter is learned transmitter, this device > can > > > not be approved by TCB. Only FCC can approve such device. In order to > > > qualify for TCB review, please address the programming function in terms > > of > > > fundamental frequency, duty cycle, modulation, and periodical > > transmission. > > > > > > Question #6: FCC DoC logo is used on the proposed FCC ID label format. > > This > > > device is intentional transmitter which can not use FCC DoC procedure. > > > Please remove FCC DoC logo from FCC ID label format. > > > > > > Best Regards > > > > > > Mike Kuo > > > The items indicated above must be submitted before processing can > continue > > > on the above referenced application. Failure to provide the requested > > > information within 30 days of the original e-mail date may result in > > > application dismissal and forfeiture of the filing fee. Also, please > note > > > that partial responses increase processing time …

Text truncated - open the document above for the full version.

ETC Report No.:ET92R-06-046-03 FCC ID.: M6DIKEYPENDANTTX Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Top View of EUT Rear View of EUT

Model: i-Key Pendant FCC ID:M6DIKEYPENDANTTX REAR VIEW 30 x 15 mm

ETC Report No.:ET92R-06-046-03 FCC ID.: M6DIKEYPENDANTTX Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Internal View of EUT Component View of Main PCB ETC Report No.:ET92R-06-046-03 FCC ID.: M6DIKEYPENDANTTX Rev. No 1.0 CONSTRUCTED PHOTOS of EUT Solder View of Main PCB

1. The frequcncy is 433.92MHZ(SAW). 2. The transmission is by IR, Do not need to open the casing that we can encode it. (Including programmer and transmitter). 3. Receiver has waterproof , transmitter has water resistant

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : i-Key FCC ID. : M6DIKEYPENDANTTX MODEL : i-Key Pendant Working Frequency : 433.920MHz for APPLICANT : HORNG WOEI ELECTRONIC CO., LTD. ADDRESS : No.30-29, Wan Ho Rd. Sec.1, Taichung 408, Taiwan R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34, LIN 5, DING FU TSUN, LINKOU HSIANG TAIPEI HSIEN, TAIWAN, R.O.C. Tel:(02)26023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail : [email protected] Report Number : ET92R-06-046-03 ETC Report No.:ET92R-06-046-03 FCC ID.: M6DIKEYPENDANTTX Rev. No 1.0 TEST REPORT CERTIFICATION Applicant : HORNG WOEI ELECTRONIC CO., LTD. No.30-29, Wan Ho Rd. Sec.1, Taichung 408, Taiwan R.O.C. Manufacturer : HORNG WOEI ELECTRONIC CO., LTD. No.30-29, Wan Ho Rd. Sec.1, Taichung 408, Taiwan R.O.C. Description of EUT : a) Type of EUT : i-Key b) Trade Name : Horng Woei c) Model No. : i-Key Pendant d) FCC ID : M6DIKEYPENDANTTX e) Working Frequency : 433.920MHz f) Power Supply : DC12V Regulation Applied : FCC Rules and Regulations Part 15 Subpart C (2002) I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note : 1. The results of the testing report relate only to the items tested. 2. The testing report shall not be reproduced except in full, without the written approval of ETC. Issued Date : Jul. 16, 2003 Test Engineer : ( Eric Chen) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.:ET92R-06-046-03 FCC ID.: M6DIKEYPENDANTTX Rev. No 1.0 Table of Contents Page 1. GENERAL INFORMATION.....................................................................................................................................................1 1.1 PRODUCT DESCRIPTION...........................................................................................................................................................1 1.2 CHARACTERISTICS OF DEVICE:...............................................................................................................................................1 1.3 TEST METHODOLOGY..............................................................................................................................................................1 1.4 TEST FACILITY..........................................................................................................................................................................1 2. DEFINITION AND LIMITS.......................................................................................................................................................2 2.1 DEFINITION................................................................................................................................................................................2 2.2 RESTRICTED BANDS OF OPERATION.....................................................................................................................................2 2.3 LIMITATION...............................................................................................................................................................................2 2.4 LABELING REQUIREMENT.......................................................................................................................................................4 2.5 USER INFORMATION.................................................................................................................................................................4 3 SYSTEM TEST CONFIGURATION.........................................................................................................................................5 3.1 JUSTIFICATION..........................................................................................................................................................................5 3.2 DEVICES FOR TESTED SYSTEM...............................................................................................................................................5 4. RADIATED EMISSION MEASUREMENT.............................................................................................................................6 4.1 APPLICABLE STANDARD.........................................................................................................................................................6 4.2 MEASUREMENT PROCEDURE..................................................................................................................................................6 4.3 TEST DATA.................................................................................................................................................................................8 4.3.1 Tx Fundamental and Harmonics..................................................................................................................................8 4.3.2 Other Emissions...............................................................................................................................................................9 4.4 FIELD STRENGTH CALCULATION........................................................................................................................................10 4.5 ACTIVATE TIME......................................................................................................................................................................10 4.6 CALCULATION OF DUTY FACTOR.......................................................................................................................................10 4.7 RADIATED TEST EQUIPMENT.....................................................................................................................................…

Text truncated - open the document above for the full version.

ETC Report No.:ET92R-06-046-03 FCC ID.: M6DIKEYPENDANTTX Rev. No 1.0 Radiated Measurement Photos
