M6E-APC630Dual-Band Gigabit ceiling wireless AP

Dual-Band Gigabit ceiling wireless AP VAC Self-Organizing Network Quick Installation Guide V1.0 Thank you for purchasing our product. Hope you will have fun using it! Please read this user manual thoroughly before using, and keep it properly. I. Product Overview Supports the IEEE 802.11ax (WiFi 6) standard, with a dual-band simultaneous transmission rate of up to 3000 Mbps (2.4GHz: 1200 Mbps + 5GHz: 1800 Mbps). The ceiling-mounted design is optimized for enterprise scenarios including office buildings, hotels, exhibition halls and meeting rooms, delivering a signal coverage radius of 15-25 meters and the ability to penetrate 3-4 non-load-bearing walls. It supports simultaneous connection of up to 128 devices; WiFi6 OFDMA and MU-MIMO technologies optimize the concurrent performance of multiple terminals, reduce freezes and latency, and satisfy enterprise high-speed network demands such as HD video conferences, wireless office work and IoT device interconnection. Compatible with Fat/Thin dual operating modes, it supports centralized management of up to 16 APs via the VAC self-organizing network, as well as centralized management of more APs via an AC controller, adapting to various batch deployment scenarios for multiple APs. Notes: 1. In a LAN without an AC controller, the AP with the largest MAC address will be automatically elected as the Master role to manage other APs. 2. If there is only one AP in the LAN, the AP will operate in Slave role by default. 3. This guide does not include instructions for use with an AC controller. For AC-related configuration and usage, please contact the sales team. - 1 - II. Pre-Installation Preparation Optimal Placement Install at the geometric center of the ceiling in office areas, central ceiling of meeting rooms, or top of corridors to ensure uniform signal coverage of the target area and minimize blind spots. For multi-AP deployment, maintain the signal overlap rate of adjacent APs at 20%-30% to avoid interference. - 2 - Installation Cautions Keep a minimum distance of 3 meters from equipment/areas that cause signal interference or shielding, including air conditioner outdoor units, refrigerators, microwaves, elevator shafts, power distribution shafts, large server rooms (strong electromagnetic interference), metal ceilings/keels, ventilation ducts (signal shielding), and Bluetooth speakers (frequency interference). Do not install in humid, dusty or high-temperature areas (e.g., toilets, top of equipment rooms) to ensure long-term stable operation of the device. Installation Requirements 1. The ceiling must be flat and stable with a load-bearing capacity of at least 2kg. 2. A pre-routed PoE network cable port is required (embedded CAT5 or higher specification cable is recommended to improve transmission stability). 3. The installation position should allow easy post-installation maintenance (e.g., avoid enclosed ceiling areas). Power Supply Method The AP supports 48V PoE and 12V DC power supply; select the appropriate power supply mode based on the on-site environment. Network Environment 1. Configure the uplink bandwidth rationally according to the number of APs and concurrent connection requirements. 2. Plan the IP address segments properly and assign static IP addresses to all APs for convenient subsequent management. - 3 - III. Interfaces, Buttons & Indicators Description InterfacesDescription DC UPlink(PoE) 12V DC Power Supply Port, for power supply via a 12V 1.5A or higher adapter. WAN/LAN port: default LAN port, supports PoE power and 10/100/1000Mbps auto-negotiation. Reset LAN UPlink(PoE) DC STAT LANLAN port, support 10/100/1000Mbps auto-negotiation. Button Reset Factory Reset Button: long press for 5+ seconds to reset to factory settings and reboot. Description Description STAT Function Indicator Lights: 1. Start-up phase: Red, blue and green lights flash alternately. 2. Unnetworked & no internet: Red light flashes; Unnetworked & internet: Green light flashes. Networked & no internet: Red light stays solid; Networked & internet: Blue light stays solid. 3. WAN port negotiated speed below 1000 Mbps: Red, green and blue lights flash slowly in a cycle. Indicators LAN LAN Port Indicator: Green steady on when connected; flashes during data transfer. UPlink(PoE) Uplink Port Indicator: Green steady on when connected; flashes during data transfer. - 4 - IV. Installation Guide 1. Confirm the AP installation location. Route the network cable from the 48V PoE switch port to the AP’s position, and terminate the switch-side end with an RJ45 connector following the T568B standard. 2. Remove the ceiling panel at the AP installation position. - 5 - 3. Use the included accessories to secure the mounting bracket to the ceiling. 4. Route the network cable through the ceiling aligned with the AP's port position, then reattach the ceiling panel in place. - 6 - 5. Terminate the network cable with an RJ45 connector per the T568B standard, plug it into the AP’s Uplink Port, then align the AP’s mounting slot with the mounting bracket and twist to snap it into place. V. Preparation 1. Power on the PoE switch. The AP finishes booting in 120 seconds. 2. Connect via computer or phone to the AP’s default WiFi. SSID: "@twifi- XXXX" or "@twifi-XXXX-5G" (XXXX = last 4 digits of the device’s MAC address; for easier identification, 0 → G, 8 → G, B → K, 1 → J). Default WiFi password: "9876543210". VI. Mobile Setup 1. Once WiFi is connected, enter the AP management URL "apc630.tech" in the browser and tap [Go]. The browser will redirect to the device authentication page. Enter the default password "admin", tap [Login] to access the device management - 7 - page. On first login, the system will automatically redirect to the setup wizard (see Figure 1 below). 2. To manage other LAN APs: Toggle on "Enable Controller Function", tap [Next Step] to enter the WiFi setup page (see Figure 2 below). By default, "Dual-Frequency In One" is disabled: 2G and 5G WiFi have different names but t…

Text truncated - open the document above for the full version.

CHENG UEI PRECISION INDUSTRY CO., LTD. Add: No.18, Chung Shan Road, Tu Cheng District, New Taipei City, Taiwan, R.O.C. Tel: (02)2269-9888Fax: (02)2268-9340 E-mail: [email protected] Attestation Letter Date: 2026-07-20 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: Our p roduct Dual-Band Gigabit ceiling wireless AP, Model: APC630, FCC ID: M6E- APC630, for marketing purpose, this product only supports 2.4G Wi-Fi (2412-2462MHz, 802.11b/g/n20/ax20 modes, 2422-2452MHz, 802.11n40/ax40 modes), 5G Wi-Fi(5150-5250MHz, 5725-5850MHz,802.11a/n20/ac20/ax20/n40/ax40/ac40/ac80/ax80 modes), 80 2.11ax mode only supports full RU and doesn't support partial RU. The other functions, bands and modes was disabled to use by manufacturer in the software, the end user has no capability to activate it. Sincerely, Printed Name: Jim Chen Title: Supervisor

CFR 47 §2.911(d)(5)(i)(ii) Attestation Letter CHENG UEI PRECISION INDUSTRY CO., LTD. Add: No.18, Chung Shan Road, Tu Cheng District, New Taipei City, Taiwan, R.O.C. Tel: (02)2269-9888 Fax: (02)2268-9340 E-mail: [email protected] Attestation Letter Date: 2026-07-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i)(ii) Filing FCC ID: M6E-APC630 CHENG UEI PRECISION INDUSTRY CO., LTD. (“the applicant”) certifies that the equipment for which authorization is soughtis not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. CHENG UEI PRECISION INDUSTRY CO., LTD. (“the applicant”) certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. CHENG UEI PRECISION INDUSTRY CO., LTD.certifies that the equipment does not use Kaspersky's software information. Sincerely, Signature: Contact Person: Jim Chen Title: Supervisor

CFR 47 §2.911(d)(7) U.S Agent U.S. AGENT LETTER OF ATTESTATION Date: 2026-08-01 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(7) Filing FCC ID: M6E-APC630 CHENG UEI PRECISION INDUSTRY CO., LTD. (“the Applicant”) certifies that, as of the date of the filing of the application, GLAMORA CREATIONS INC (U.S. agent). is our designated U.S. agent for service of process for the above referenced FCC ID. CHENG UEI PRECISION INDUSTRY CO., LTD. (“the Applicant”) accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. GLAMORA CREATIONS INC (U.S. agent) accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Company Name: GLAMORA CREATIONS INC Address: 10501 Wilshire Blvd, Los Angeles, CA 90024, United States FRN: 0038647285 Tel.: 9498863877 Email: [email protected] Signed by (printed name): Yuanyou Feng Signature: Applicant: CHENG UEI PRECISION INDUSTRY CO., LTD. Add: No.18, Chung Shan Road, Tu Cheng District, New Taipei City, Taiwan, R.O.C. FRN: 0037287026 Tel: 02-22699888 Email: Jim_chen @foxlink.com Signed by (printed name): Jim Chen Signature:

QA-FR-170-B CHENG UEI PRECISION INDUSTRY CO., LTD. Add: No.18, Chung Shan Road, Tu Cheng District, New Taipei City, Taiwan, R.O.C. Tel: (02)2269-9888 Fax: (02)2268-9340 E-mail: [email protected] FCC Authorization Date: 2026-07-20 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, CHENG UEI PRECISION INDUSTRY CO., LTD., hereby authorizes China Certification ICT Co., Ltd (Dongguan) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by China Certification ICT Co., Ltd (Dongguan) on our behalf shall have the same effect as our own action. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Client’s signature Contact Person: Jim Chen Title: Supervisor

QA-FR-171-A CHENG UEI PRECISION INDUSTRY CO., LTD. Add: No.18, Chung Shan Road, Tu Cheng District, New Taipei City, Taiwan, R.O.C. Tel: (02)2269-9888 Fax: (02)2268-9340 E-mail: [email protected] FCC Confidential Authorization Date: 2026-07-20 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID:M6E-APC630 In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, CHENG UEI PRECISION INDUSTRY CO., LTD. hereby requests long-term confidential treatment of information accompanying this application as outlined below: • Block Diagram • Schematics • Operation Description • BOM • U-NII Device Security Declaration The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely, Signature: Printed Name: Jim Chen Title: Supervisor

China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-EXP Page 1 / 4 EUT EXTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-EXP Page 2 / 4 China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-EXP Page 3 / 4 China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-EXP Page 4 / 4 Port *****END *****

Dual-Band Gigabit ceiling wireless AP Model: APC630 Power Input: DC 12V/PoE 48V IP : apc630.tech Username: admin Password: admin MAC:A4-59-D3-70-23-80 SN:APC6302502000002 IC: 6632B-APC630 CAN ICES(B)/NMB(B) FCC ID: M6E-APC630 Made in Philippines P/N:25040800009PH

China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page1/ 7 EUT INTERNAL PHOTOGRAPHS China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page2/ 7 2.4G Wifi Antenna port (Chain 0) 2.4G Wifi Antenna port (Chain 1) 5G Wifi Antenna port (Chain 2) 5G Wifi Antenna port (Chain 0) 5G Wifi Antenna port (Chain 1) 5G Wifi Antenna (Chain 2) 5G Wifi Antenna (Chain 1) 5G Wifi Antenna (Chain 0) 2.4G Wifi Antenna (Chain 1) 2.4G Wifi Antenna (Chain 0) China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page3/ 7 China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page4/ 7 China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page5/ 7 2.4G_Wifi Antenna(Chain 0) 2.4G_Wifi Antenna(Chain 1) China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page6/ 7 5G_Wifi Antenna(Chain 0) 5G_Wifi Antenna(Chain 1) China Certification ICT Co., Ltd (Dongguan) EXHIBIT No.: 2603T12344E-RF-INP Page7/ 7 5G_Wifi Antenna(Chain 2) *****END *****

RF EXPOSURE EVALUATION REPORT Applicant: CHENG UEI PRECISION INDUSTRY CO., LTD. Address: No.18, Chung Shan Road, Tu Cheng District, New Taipei City, Taiwan, R.O.C. FCC ID: M6E-APC630 Product Name: Dual-Band Gigabit ceiling wireless AP Standard(s): 47 CFR §1.1307, 47 CFR §2.1091 47 CFR §15.247(i), 47 CFR §15.407(f) The above equipment has been tested and found compliant with the requirement of the relative standards by China Certification ICT Co., Ltd (Dongguan) Report Number: 2603T12344E-RF-00D Date Of Issue: 2026/8/19 Reviewed By: Calvin Chen Title: RF Test Supervisor Reviewed By: Sun Zhong Title: Manager Test Laboratory: China Certification ICT Co., Ltd (Dongguan) Room 101 & 201, Building 2, 256 Pingdong Road, Dalang Town, Dongguan City, Guangdong, China. Tel: +86-769-83085888 www.ccttt.com.cn China Certification ICT Co., Ltd (Dongguan) Report No.: 2603T12344E-RF-00D Report Template: RF-FCC MPE-A/0 Page 2 of 7 Test Facility The Test site used by China Certification ICT Co., Ltd (Dongguan) to collect test data is located on the Room 101 & 201, Building 2, 256 Pingdong Road, Dalang Town, Dongguan City, Guangdong, China. The lab has been recognized as the FCC accredited lab under the KDB 974614 D01 and is listed in the FCC Public Access Link (PAL) database, FCC Registration No. : 442868, the FCC Designation No. : CN1314. The lab has been recognized by Innovation, Science and Economic Development Canada to test to Canadian radio equipment requirements, the CAB identifier: CN0123. Declarations China Certification ICT Co., Ltd (Dongguan) is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with a triangle symbol “▲”. Customer model name, addresses, names, trademarks etc. are not considered data. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report cannot be reproduced except in full, without prior written approval of the Company. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. This report may contain data that are not covered by the accreditation scope and shall be marked with an asterisk “★”. Each test item follows the test standard(s) without deviation. China Certification ICT Co., Ltd (Dongguan) Report No.: 2603T12344E-RF-00D Report Template: RF-FCC MPE-A/0 Page 3 of 7 CONTENTS DOCUMENT REVISION HISTORY .......................................................................................... 4 1. GENERAL INFORMATION .................................................................................................... 5 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ....................................................... 5 2. RF EXPOSURE EVALUATION .............................................................................................. 6 2.1 RF EXPOSURE EVALUATION ............................................................................................................... 6 2.1.1 Applicable Standard ....................................................................................................................................... 6 2.1.2 Calculation formula: ...................................................................................................................................... 6 2.1.3 Calculated Data: ............................................................................................................................................. 7 China Certification ICT Co., Ltd (Dongguan) Report No.: 2603T12344E-RF-00D Report Template: RF-FCC MPE-A/0 Page 4 of 7 DOCUMENT REVISION HISTORY Revision Number Report Number Description of Revision Date of Revision 1.0 2603T12344E-RF-00D Original Report 2026/8/19 China Certification ICT Co., Ltd (Dongguan) Report No.: 2603T12344E-RF-00D Report Template: RF-FCC MPE-A/0 Page 5 of 7 1. GENERAL INFORMATION 1.1 Product Description for Equipment under Test (EUT) EUT Name: Dual-Band Gigabit ceiling wireless AP EUT Model: APC630 Rated Input Voltage: DC 12V from DC Port or DC 48V from PoE EUT Received Date: 2026/5/21 EUT Received Status: Good China Certification ICT Co., Ltd (Dongguan) Report No.: 2603T12344E-RF-00D Report Template: RF-FCC MPE-A/0 Page 6 of 7 2. RF EXPOSURE EVALUATION 2.1 RF Exposure Evaluation 2.1.1 Applicable Standard According to subpart 15.247(i),15.407(f) and subpart §1.1310, systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. Limits for Maximum Permissible Exposure (MPE) (§1.1310, §2.1091) (B) Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f²) 30 30–300 27.5 0.073 0.2 30 300–1500 / / f/1500 30 1500–100,000 / / 1.0 30 f = frequency in MHz; * = Plane-wave equivalent power density; According to §1.1310 and §2.1091 RF exposure is calculated. 2.1.2 Calculation formula: Prediction of power density at the distance of the applicable MPE limit S = PG/4R² = power density (in appropriate units, e.g. mW/cm 2 ); P = power input to the antenna (in appropriate units, e.g., mW); G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain; R = distance to the center of radiation of the antenna (appropriate units, e.g., cm); For simultaneously transmit system, the calculated power density should comply with: China Certification ICT Co., Ltd (Dongguan) Report No.: 2603T12344E-RF-00D Report Template: RF-FCC MPE-A/0 Page 7 of 7 2.1.3 Calculated Data: Operation Modes Frequency (MHz) Antenna Gain ▲ Conducted output power including Tune-up Tolerance ▲ Evalu…
