M72-PK4586DECT module

PRODUCT SPECIFICATION POLYCOM ED 2.0 DATE 29-06-2011 SIGN HBR Page 1 of 12 Model no.: KT4586 141993XX-DS DECT application module Model no.: KT4586 PRODUCT SPECIFICATION POLYCOM ED 2.0 DATE 29-06-2011 SIGN HBR Page 2 of 12 Model no.: KT4586 141993XX-DS 1. Preface ....................................................................................................................................... 3 2. Features ..................................................................................................................................... 3 3. Circuit description ..................................................................................................................... 4 4. Pin configuration .................................................................................................................... 5 5. Mechanical dimension............................................................................................................ 7 6. PCB integration & soldering ................................................................................................. 8 7. FCC compliance statement .................................................................................................. 11 8. Safety compliance statement .............................................................................................. 12 Proprietary and Confidential The information contained herein is the sole intellectual property of Polycom, Inc. No distribution, reproduction or unauthorized use of these materials is permitted without the expressed written consent of Polycom, Inc. Information contained herein is subject to change without notice and does not represent commitment of any type on the part of Polycom, Inc. Polycom and Accord are registered trademarks of Polycom, Inc. Notice While reasonable effort was made to ensure that the information in this document was complete and accurate at the time of printing, Polycom, Inc., cannot assume responsibility for any errors. Changes and/or corrections to the information contained in this document may be incorporated into future issues. PRODUCT SPECIFICATION POLYCOM ED 2.0 DATE 29-06-2011 SIGN HBR Page 3 of 12 Model no.: KT4586 141993XX-DS 1. Preface The KT4586, DECT application module is used to transfer messaging, data, and voice signals by use of the radio frequency spectrum according to the DECT standard. KT4586 is a fully approved module that complies with the following standards and certifications: EN 301 406 V2.1.1:2009-07 (DECT radio) EN 300 175-1 to 8 (DECT CI) EN 301 489-1 V1.8.1:2008-04, EN 301 489-6 V1.3.1:2008-08 (EMC) IEC 60950-1:2005 (ed. 2.0) +am1:2009, EN 60950-1:2006+A11:2009+A1:2010 (Safety) R&TTE certificate FCC PART 15, Subpart D FCC part 15B FCC SAR RSS-213 This means that by integration on a main board no radio test is required. 2. Features RF range: 1880 – 1930 MHz DECT channels: 60(EU) 30(US) logical duplex channels. Receiver sensitivity: Typ.< -93 dBm [BER,1000 ppm]. Transmit power (NTP): Typ. 23 dBm. , 20.2 dBm (US) Power supply range: 2.0 – 3.45V Current consumption: TBD Temp. Range: -20ºC to +60ºC. Size: 25.0 X 30.0 X 3.0mm. Other features: See data sheet for SC14441 PRODUCT SPECIFICATION POLYCOM ED 2.0 DATE 29-06-2011 SIGN HBR Page 4 of 12 Model no.: KT4586 141993XX-DS 3. Circuit description The module consists mainly of the fully integrated CMOS transceiver and baseband processor SC14441 from SiTel semiconductor intended for DECT 6.0 handsets and base stations. RF switches and other components are added to the design in order to perform the desired functionality required for DECT/GAP. Figure 1 shows the block diagram of the module. The DECT transceiver/baseband SC14441 SC14441 is a 1.8V single chip for DECT applications containing a fully integrated radio transceiver and baseband processor. It is designed to perform the complete transmit and receiver function. The device is designed to operate the frequency synthesizer in a close loop configuration both during transmit and receive mode. Logic output ports are used to control the T/R switch and antenna switch for FAD (Fast Antenna Diversity). The CompactRISC CR 16Cplus microprocessor with a single wire debug port running from ROM controls the protocol stack and the I/O peripherals, keyboard, UART, ACCESS bus, SPI, LED drivers and RF switches. The audio path comprises a 16 bit CODEC with an analog frontend including a high efficiency 4 ohm audio amplifier (class D) and a programmable Gen2DSP supporting various telecommunication algorithms. Detailed information about the chip is available from SiTel semiconductor. T/R SW 29 general purpose I/O ports Figure 1 SC14441 Integrated CMOS transceiver and baseband processor Ant. SW Serial debug interface UART, Full duplex SPI interface Dual ACCESS bus PCM interface 16-bit linear audio CODEC Analog microphone interface. Analog loudspeaker interface. Charge controle LDO & PWR SW circuit To supply QSPI FLASH EEPROM RX Balun TX Balun ULP controle ports DC-DC converter ports Quad SPI bus PRODUCT SPECIFICATION POLYCOM ED 2.0 DATE 29-06-2011 SIGN HBR Page 5 of 12 Model no.: KT4586 141993XX-DS 4. Pin configuration A1 GND B1 GND C1 GND D1 GND E1 VDDPA F1 SOCp A2 GND B2 GND C2 P30 D2 P31 E2 GND F2 P10 A3 GND B3 CP_VOUT1 C3 GND D3 P16 E3 CHARGE_CTRL F3 ADC2 A4 CP_VOUT2 B4 P15 C4 P27 D4 P17 E4 SOCn F4 DC_CTRLN A5 VDDIO B5 GND C5 P14 D5 GND E5 GND F5 ULP_PORT A6 P12 B6 P26 C6 P11 D6 GND E6 GND F6 ULP_VBAT A7 GND B7 P05 C7 GND D7 GND E7 GND F7 ULP_MAIN_CTRL A8 GND B8 GND C8 P00 D8 GND E8 GND F8 RFP0n A9 VBAT B9 P01 C9 GND D9 P24 E9 GND F9 P23 A10 P04 B10 VBATT C10 JTAG D10 VDD E10 P07 F10 P13 A11 RSTn B11 GND C11 VCCRF D11 P25 E11 GND F11 P06 B12 TP2 G1 GND H1 VREFm J1 GND K1 VREFp L1 GND G2 LSRn H2 LSRp J2 MICh K2 MICp L2 MICn M2 TP1 G3 GND H3 P37 J3 GND K3 P32_CIDINp L3 GND G4 P33 H4 ONE_CELL J4 P35 K4 P36 L4 GND G5 GND H5 DC_SENCE J5 GND K5 P34 L5 RFP0 G6 DC_CTRL H6 DC_I J6 RFP1 K6 WLED0 L6 GND G7 GND H7 P22 J7 GND K7 WLED1 L7 GND G…

Text truncated - open the document above for the full version.

• POLYCOM Modular Approval Request Letter Date: 2011-07-11 FCC 10: M72-PK4586 Type of Equipment: .:::D-=Ec::::C:....:.T--'M.!..!.o""d".,u::..cle"'--______ Model name: Polycom KIRK KT4586A The following requirements according to FCC Part 15.212 are met: RF shielding The radio portion has his own shielding (see external photos). ii Buffered modulationldata inputs, has been integrated in the chipset iii Power supply regulation, is integrated iv Antenna requirements section 15.203, 15.204 band 15.204 c The module comes with two permanently attached antennas. The spurious emission requirements are fulfilled (see attached test report). v Stand alone test configuration Please referring to test set up configuration photo vi Labelling The module has its own label. The instruction for labelling rules for the host device has been stated in the users manual vii Compliance on specific rule or operating requirements The required FCC rules has been fulfilled and all instructions for maintaining compliance has been clearly stated in the users manual viii RF Exposure, RF exposure requirements are fulfilled for mobile configuration. The installation of the module is restricted to mobile host devices what is clearly stated in the installation instruction of the user manual. For portable applications OEM integrators need SAR evaluation and an own FCC 10. Direc Cor orate Technical Cornplia Polycorn Inc 4750 Willow Road Pleasanton CA 94588-2708

Sign ture POLYCOM Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 5/12/2011 To whom it may concern : We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: M72~PK4586 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Yuk Wan Director Corporate Technical Compliance Polycom Inc

POLYCOM Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 5/12/2011 Request for Confidentiality Company name: Polycom Inc FCC 10: M72-PK4586 FCC Part 15 Certification Gentlemen, In accordance with 0.459 of CFR 47, Polycom Inc hereby requests confidentiality of following attachments: Block Diagrams, Circuit Description, Schematics, Parts List, Operational Description for the subject application . These documents contain detailed system and equipment description and related information about the product which Polycom Inc considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Polycom Inc considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, n Director - orporate Technical Compliance Polycom Inc 4750 Willow Road Pleasanton CA 94588-2708

Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Photos EUT Front EUT Back Page 45 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Module Top Module Back Page 46 of 170

Project No.: G0M-1105-1119 06_KT4586 Label Sample page 1 Model No.: KT4586 FCC ID: M72-PK4586 IC: 1849C-PK4586 Project No.: G0M-1105-1119 07_KT4586 Label Location page 2 Model No.: KT4586 FCC ID: M72-PK4586 IC: 1849C-PK4586

Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Photos EUT Front EUT Back Page 45 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Module Top Module Back Page 46 of 170

POLYCOM Declaration concerning Antenna Specification It is hereby declared that the product Modell\Jo. : Polycom KIRK KT4586 Module FCC 10: M72-PK4586 fulfills the requirement in FCC test relating to the antenna type. The device specifi ed above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna:!...!I\J~/A...!...-________ Type of antenna: PCB monopole Gain of the antenna: 1.2 dBi Frequency range: 1920 - 1930M l-!z The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: ~P~o~ly~c~o~m~ln~c~__________ Address: 4750 Willow Road City: Pleasanton CA ZIP / Postal code: ~94...:...:5=8=8c....:-2=..!7-=0=8_____ Country: ~U~S~A!-.-_______ N o :;; I E Place: Polycom Corporate Technical Compliance Date: _____ o ~ .~ aJ (f) 1:5 Signature: ::l ~ ""0 o a:: <fl J c ~ ::; w .D '" ""0 OJ ""0 .~ 0...

Eurofins Product Service GmbH Storkower Str. 38c, 15526 Reichenwalde, Phone +49-33631-888 0 Germany Fax +49-33631-888 660 EUROFINS PRODUCT SERVICE GMBH RF-EXPOSURE A SSESSMENT FCC 47 CFR 2.1091 IC RSS-102 Polycom KIRK KT4586 Module KT4586 FCC ID: M72-PK4586 IC: 1849C-PK4586 REPORT NUMBER: G0M-1105-1119-C-2 Test Report No.: G0M-1105-1119-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 2 of 13 TABLE OF CONTENTS 1 General Information 3 1.1 Notes 3 1.2 Testing laboratory 4 1.3 Details of approval holder 5 1.4 Application details 5 1.5 Acronyms and abbreviations 5 1.6 Reference standards 6 1.7 Test item 7 1.8 Referenced documents 7 1.9 Additional information 7 2 Exposure Assessment 8 2.1 Device Types 8 2.2 Exposure Categories 8 2.3 MPE Limits 9 2.4 Exposure assessment 12 Test Report No.: G0M-1105-1119-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 13 1.2 Testing laboratory EUROFINS PRODUCT SERVICE GMBH Storkower Strasse 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 660 DA KKS ACCREDITED TESTING LABORATORY DA KKS-REGISTRATION NUMBER: D-PL-12092-01-01 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 Test location, where different: Name : ./. Street : ./. Town : ./. Country : ./. Telephone : ./. Fax : ./. Test Report No.: G0M-1105-1119-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 13 1.3 Details of approval holder Name : Polycom Inc. Street : 4750 Willow Road Town : Pleasanton, CA, 94588-2708 Country : USA Telephone : +44 1753 723011 Fax : +44 1600 715 799 Contact : Mr. Tony Griffiths Telephone : +44 1753 723011 Manufacturer: (if applicable) Name : Polycom (Denmark) A/S Street : Langmarksvej 34 Town : 8700 Horsens Country : Denmark 1.4 Application details Date of receipt of application : 11.05.2011 Date of receipt of test item : 11.05.2011 Date of assessment : 27.06.2011 1.5 Acronyms and abbreviations EUT : Equipment under Test TX : Transmission RX : Reception RBW : Measurement Resolution Bandwidth Pol : Measurement Polarization N/A : Not applicable Test Report No.: G0M-1105-1119-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 13 1.6 Reference standards Technical standards : FCC 47 CFR 1.1310 FCC 47 CFR 2.1091 FCC 47 CFR 2.1093 OET Bulletin 65 : ” Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Elec tromagnetic Fields” 1997 RSS-102 Issue 4 : “Radio Frequency (RF) Exposure Com pliance of Radiocommunication Apparatus (All Frequency Bands)”, 2010 Safety Code 6: “Limits of Human Exposure to Radiofre quency Electromagnetic Energy in the Frequency Range from 3 kHz to 300 GHz”, 2009 IEEE C95.3 : “IEEE Recommended Practice for Measure ments and Computations of Radio Frequency Electro magnetic Fields With Respect to Human Exposure to Such Fields, 100 kHz–300 GHz”, 2002 Health Canada : “Technical Guide for Interpretation and Compliance Assessment of Health Canada’s Radiofre quency Exposure Guidelines”, 2009 Test Report No.: G0M-1105-1119-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 13 1.7 Test item Description of test item : Polycom KIRK KT4586 Module Type identification : KT4586 Serial Number : None Hardware version : 004 Software version : 001 Radiation sources included : UPCS Equipment type : Radio module Exposure Category : Uncontrolled / General public Device type : Mobile 1.8 Referenced documents FCC/IC test report - FP : G0M-1105-1119-C-3 Eurofins Product Service GmbH FCC/IC test report - PP : G0M-1105-1119-C-4 Eurofins Product Service GmbH 1.9 Additional information None Test Report No.: G0M-1105-1119-C-2 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 13 2 Exposure Assessment 2.1 Device Types Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re- located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is nor- mally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. (47 CFR 2.1091) Portable A portable device is defined as a transmitting device designed to be used so that the radiating struc- ture(s) of the device is/are within 20 centimeters of the body of the user. (47 CFR 2.1093) 2.2 Exposure Categories Occupational / Controlled Exposure In general, occupational/controlled exposure limits are applicable to situations in which persons are exposed as a consequence of their employment, who have been made fully aware of the potential for exposure and can exercise control over their exposure. This exposure category is also applicable when the exposure is of a transient nature due to incidental passage through a location where the exposure levels may be higher than the general population/uncontrolled limits, but the exposed person is fully aware of the potential for exposure and can exercise control over his or her exposure by leav- ing the area or by some other appropriate means. Awareness of the potential for RF exposure in a workplace or similar environment can be provided through specific training as part of a RF safety pro- gram. If appropriate, warning signs and labels can also be used to establish such awareness by pro- viding prominent information on the risk of potential exposure and instructions on methods to minimize such exposure risks. Gen…

Text truncated - open the document above for the full version.

EUROFINS PRODUCT SERVICE GMBH Testing Cert #1983.01 TEST - REPORT FCC PART 15 D for Isochronous UPCS devices RSS-213 for LE-PCS devices Polycom KIRK KT4586 Module KT4586 FCC ID: M72-PK4586 IC: 1849C-PK4586 Test report no.:G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Phone +49-33631-888 00 Germany Fax +49-33631-888 660 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1. General Information 4 1.1 Notes 4 1.2 Testing laboratory 5 1.2.1 Location 5 1.2.2 Details of accreditation status 5 1.3 Details of approval holder 5 1.4 Application details 6 1.5 Test item 6 1.6 Test standards 8 2. Technical test 9 2.1 Summary of test results 9 2.2 Test environment 9 2.3 Test equipment utilized 10 3. Results of Examinations and tests (enclosure) 11 3.1 Examinations and Test Procedures 12 3.1.1 Coordination with fixed microwave service 12 3.1.2 Reference to Subpart B 12 3.1.3 Conducted limits AC Power line 13 3.1.4 Antenna requirement 14 3.1.5 Modulation techniques 14 3.1.6 Emission bandwidth 15 3.1.7 Peak transmit power 18 3.1.8 Power spectral density 19 3.1.9 Directional gain of antenna 20 3.1.10 Automatic discontinuation of transmission 21 3.1.11 Radio frequency radiation exposure 22 3.1.12 Monitoring threshold; Least interfered channel 23 3.1.13 Monitoring of intended transmit window and maximum reaction time 26 3.1.14 Monitoring bandwidth, Monitoring reaction time 28 3.1.15 Random waiting interval 29 3.1.16 Duration of Transmisssion 30 3.1.17 Connection acknowledgements, Unacknowledged transmissions 31 3.1.18 Selected channel confirmation, segment occupancy 32 3.1.19 Monitoring antenna 33 3.1.20 Duplex connections 34 3.1.21 Alternative monitoring interval for co-located devices 36 3.1.22 Fair access to spectrum 36 3.1.23 Radiated spurious emissions, generally requirements 37 3.1.24 Emissions inside and outside the sub-bands 40 3.1.25 Frame period 42 3.1.26 Frequency stability 44 Page 2 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Photos 45 Annex B Conducted limits AC Power line 48 Annex C Emission bandwidth 50 Annex D Occupied Bandwidth 54 Annex E Peak Transmit Power 57 Annex F Power spectral density 59 Annex G Monitoring threshold 61 Annex H Monitoring of intended transmit window and maximum reaction time 66 Annex I Monitoring bandwidth 68 Annex J Duration of Transmission 72 Annex K Connection acknowledgement 73 Annex L Selected Channel 76 Annex M Duplex connections 77 Annex N Emission inside and outside the sub-band; Spurious Emission 80 Annex O Frame period 84 Annex P Frequency Stability 86 Annex Q Transmitter radiated spurious emissions 89 Annex R Receiver radiated spurious emissions 162 Page 3 of 170 Page 4 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory 1.2.1 Location EUROFINS PRODUCT SERVICE GMBH Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2 Details of accreditation status DAR ACCREDITED TESTING LABORATORY DAR-R EGISTRATION NUMBER: DAT-P-268/08 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 1.3 Details of approval holder Name : Polycom Inc. Street : 4750 Willow Road Town : Pleasanton, CA, 94588-2708 Country : USA Telephone : +44 1753 723011 Contact : Mr. Tony Griffiths Telephone : +44 1753 723011 E-mail : [email protected] Page 5 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Application details Date of receipt of application : 11.05.2011 Date of receipt of test item : 11.05.2011 Date of test : 13.05.2011 – 20.05.2011 1.5 Test item Description of test item : Isochronous UPCS device, cordless phone based on DECT modified technology. Function Portable part Base station Repeater Description of test item : Polycom KIRK KT4586 Module Type identification : KT4586 Serial number : without Photos : See annex Technical data Frequency bands : 1920 – 1930 MHz Operating Channel numbers Test Frequencies Channel center frequency (MHz) 4 F L 1921.536 3 1923.264 2 1924.992 1 1926.720 0 F H 1928.448 Number of channels : 60 (in time and spectrum window, declared by manufacturer) Operating modes : MC/TDMA/TDD Type of modulation : GFSK Page 6 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Max. slot type: single slot double slot Fixed point-to-point operation: Yes/No Antenna Type Gain [dBi] internal external 1 & 2 pcb antenna 1.2dBi Antenna diversity : Antenna Diversity supported Tx Rx 1 & 2 Host device : none Classification : related to radio frequency radiation exposure Fixed Device Mobile Device (Human Body distance > 20cm) Portable Device (Human Body distance < 20cm) Power supply : 2.5VDC (2 x Mignon Accu) 120VAC Adapter(charging mode) Data connection : Connection used None PSTN Data Networks others Remark: Devices intended to be connected to PSTN have to be applied for FCC PART 68 registration, in USA and for Industry Canada standard CS-03. Page 7 of 170 Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Manufacturer: (if applicable) Name : Polycom (Denmark) A/S Street : Langmarksvej 34 Town : 8700 Horsens Country : Denmark 1.6 Test standards Technical standard : FCC PART 15, Subpart D; RSS-213 Test method and procedure: Following requirements of FCC Part 15 D, RS…

Text truncated - open the document above for the full version.

EUROFINS PRODUCT SERVICE GMBH Testing Cert #1983.01 TEST - REPORT FCC PART 15 D for Isochronous UPCS devices RSS-213 for LE-PCS devices Polycom KIRK KT4586 Module KT4586 FCC ID: M72-PK4586 IC: 1849C-PK4586 Test report no.:G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Phone +49-33631-888 00 Germany Fax +49-33631-888 660 Test Report No.: G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany TABLE OF CONTENTS 1. General Information 4 1.1 Notes 4 1.2 Testing laboratory 5 1.2.1 Location 5 1.2.2 Details of accreditation status 5 1.3 Details of approval holder 5 1.4 Application details 6 1.5 Test item 6 1.6 Test standards 8 2. Technical test 9 2.1 Summary of test results 9 2.2 Test environment 9 2.3 Test equipment utilized 10 3. Results of Examinations and tests (enclosure) 11 3.1 Examinations and Test Procedures 12 3.1.1 Coordination with fixed microwave service 12 3.1.2 Reference to Subpart B 12 3.1.3 Conducted limits AC Power line 13 3.1.4 Antenna requirement 14 3.1.5 Modulation techniques 14 3.1.6 Emission bandwidth 15 3.1.7 Peak transmit power 17 3.1.8 Power spectral density 18 3.1.9 Directional gain of antenna 19 3.1.10 Automatic discontinuation of transmission 20 3.1.11 Radio frequency radiation exposure 21 3.1.12 Monitoring threshold; Least interfered channel 22 3.1.13 Monitoring of intended transmit window and maximum reaction time 25 3.1.14 Monitoring bandwidth, Monitoring reaction time 27 3.1.15 Random waiting interval 28 3.1.16 Connection acknowledgements, Unacknowledged transmissions 29 3.1.17 Selected channel confirmation, segment occupancy 30 3.1.18 Monitoring antenna 31 3.1.19 Duplex connections 32 3.1.20 Alternative monitoring interval for co-located devices 34 3.1.21 Fair access to spectrum 34 3.1.22 Radiated spurious emissions, generally requirements 35 3.1.23 Emissions inside and outside the sub-bands 38 3.1.24 Frame period 40 3.1.25 Frequency stability 42 Page 2 of 172 Test Report No.: G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Annex A Photos 43 Annex A Conducted limits AC Power line 46 Annex B Emission bandwidth 48 Annex C Occupied Bandwidth 52 Annex D Peak Transmit Power 55 Annex E Power spectral density 61 Annex F Monitoring threshold 64 Annex G Monitoring of intended transmit window and maximum reaction time 69 Annex H Monitoring bandwidth 71 Annex I Connection acknowledgement 75 Annex J Selected Channel 79 Annex K Emission inside and outside the sub-band; Spurious Emission 80 Annex L Frame period 84 Annex M Frequency Stability 86 Annex N Transmitter radiated spurious emissions 91 Annex O Receiver radiated spurious emissions 164 Page 3 of 172 Page 4 of 172 Test Report No.: G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.2 Testing laboratory 1.2.1 Location EUROFINS PRODUCT SERVICE GMBH Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telefon : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2 Details of accreditation status DAR ACCREDITED TESTING LABORATORY DAR-R EGISTRATION NUMBER: DAT-P-268/08 R ECOGNIZED NOTIFIED BODY EMC R EGISTRATION NUMBER: BNetzA-bS EMV-07/61 R ECOGNIZED NOTIFIED BODY R&TTE R EGISTRATION NUMBER: BNetzA-bS-02/51-53 FCC FILED TEST LABORATORY R EG.-NO. 96970 A2LA ACCREDITED TESTING LABORATORY C ERTIFICATE NO. 1983.01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY BLUETOOTH QUALIFICATION REVIEW BOARD I NDUSTRY CANADA FILED TEST LABORATORY R EG. NO. IC 3470 1.3 Details of approval holder Name : Polycom Inc. Street : 4750 Willow Road Town : Pleasanton, CA, 94588-2708 Country : USA Telephone : +44 1753 723011 Contact : Mr. Tony Griffiths Telephone : +44 1753 723011 E-mail : [email protected] Page 5 of 172 Test Report No.: G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany 1.4 Application details Date of receipt of application : 11.05.2011 Date of receipt of test item : 11.05.2011 Date of test : 13.05.2011 – 20.05.2011 1.5 Test item Description of test item : Isochronous UPCS device, cordless phone based on DECT modified technology. Function Portable part Base station Repeater Description of test item : Polycom KIRK KT4586 Module Type identification : KT4586 Serial number : without Photos : See annex Technical data Frequency bands : 1920 – 1930 MHz Operating Channel numbers Test Frequencies Channel center frequency (MHz) 4 F L 1921.536 3 1923.264 2 1924.992 1 1926.720 0 F H 1928.448 Number of channels : 60 (in time and spectrum window, declared by manufacturer) Operating modes : MC/TDMA/TDD Type of modulation : GFSK Page 6 of 172 Test Report No.: G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Max. slot type: single slot double slot Fixed point-to-point operation: Yes/No Antenna Type Gain [dBi] internal external 1 & 2 pcb antenna 1.2dBi Antenna diversity : Antenna Diversity supported Tx Rx 1 & 2 Host device : none Classification : related to radio frequency radiation exposure Fixed Device Mobile Device (Human Body distance > 20cm) Portable Device (Human Body distance < 20cm) Power supply : 3.0VDC 120VAC Adapter Data connection : Connection used None PSTN Data Networks others Remark: Devices intended to be connected to PSTN have to be applied for FCC PART 68 registration, in USA and for Industry Canada standard CS-03. Page 7 of 172 Test Report No.: G0M-1105-1119-C-3 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Manufacturer: (if applicable) Name : Polycom (Denmark) A/S Street : Langmarksvej 34 Town : 8700 Horsens Country : Denmark 1.6 Test standards Technical standard : FCC PART 15, Subpart D; RSS-213 Test method and procedure: Following requirements of FCC Part 15 D, RSS-213 and ANSI C63.17-2006 Additional information: The row scheme for frequency generation, radio channels, receiver parameters, synchr…

Text truncated - open the document above for the full version.

Test Report No.: G0M-1105-1119-C-4 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Test Setup radiated measurements Test Setup conducted measurements Page 47 of 170
