MEE-DX-929CB Transceiver

DX 929 Two Way Citizen Band Mobile Transceiver With StarLite Face Plate OWNER’S MANUAL POWER DX 929 VOL SQ OFF MIC GAIN RF GAIN DIMMER PA NB/ANL CB SWRPWR HI OFF TALKBACK LO RX/TX SWR 3 0 SWR 1 2 0 PWR MODS + 4 0 8 0 + 6 0 5 0 3 3 0 4 0 6 0 4 0 2 1 . 5 1 5 1 0 2 0 1 0 0 % M A X + 2 0 7 5 9 dB - 1 - TABLE OF CONTENTS PAGE CHAPTER 1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 CHAPTER 2 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Installing The Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Ignition Noise Interference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 External Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Public Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 CHAPTER 3 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Frequency Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Procedure to Receive and Transmit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Alternate Microphone and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Maintenance And Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 A Few Rules That Should Be Obeyed . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 How Your CB Can Serve You . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Use Channel 9 For Emergency Message Only . . . . . . . . . . . . . . . . . . . . . . 16 - 2 - CHAPTER 1 SPECIFICATIONS GENERAL Model DX 929 Channels 40 Frequency Range 26.965 ~ 27.405 MHz Frequency Control Phase-Lock-Loop (PLL) Synthesizer Frequency Stability 0.001% Temperature Range -30 ° C to +50 ° C Antenna Impedance 50 Ohms Antenna Connectors Standard SO-239 type Input Voltage 13.8V DC Size 7 3/8” (W) x 8 3/4” (D) x 2 1/4” (H) Weight 4.2 lbs. TRANSMITTER RF Power Output AM 3.8 watts Spurious Emission > -60 dB Unwanted Sideband -50 dB Audio Distortion 10% Frequency Response 300 to 2500 Hz Microphone Dynamic RECEIVER Sensitivity for 10 dB (S+N)/N < 0.5 uV Squelch Sensitivity < 0.5 uV Selectivity > -50 dB Image Rejection > 60 dB Hum & Noise > -40 dB AGC Figure of Merit 50 mV for 10 dB Change in Audio Output Audio Power Output 2.5W @ 10% Distortion Audio Response 300 to 2500 Hz (SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE) - 3 - CHAPTER 2 INSTALLATION INSTALLING THE RADIO Choose a convenient location for operation that does not interfere with driver or passenger. This radio is supplied with a universal mounting bracket. When mounting the bracket and radio to your car, make sure it is mechanically strong. Also, provide a good electrical grounding connection to the ch assis of vehicle. Proceed as follows to install the radio. 1. Locate a convenient area in your vehicle for the installation of the radio. Hold the mounting bracket with the radio in the location where the radio is to be installed. Make sure nothing will interfere with eith er the radio or the mounting bolts. Mark and then drill holes for the mounting bracket. 2. Most radio antennas come equipped with a PL-259 plug. Connect this plug to the ANT. Jack in the rear of the radio. 3. Extending from the rear of the radio is a fused red and black wire for the DC connections to the vehicle’s electrical syst em. For best performance, it is strongly recommended that the red lead be taken directly to the positive terminal on the vehicle’s battery and the black lead be connected to the near est chassis ground. (Note: This radio is designed for vehicles with negative ground systems .) Connections should be made using appropriate “crimp on” lugs of a size large enough to make good contact with the bolt used to fasten to the battery and the chassis ground. It is a good safety idea to install a second fuse that would provide protection in case the red wire was to “fray” or get pinched and short to the body of the vehicle, somewhere betw een the battery and the radio. High power radios such as this one requir e large DC current flow when in the TX mode. Poor power connections cause supply voltage drops that can substantially decrease the performance of your radio. A good DC connection is probably one of the most important things for getting the best transmitter performance and in some cases, least receiver noise. 4. Mount the microphon e bracket near the radio in an easily accessible spot using the two screws provided. - 4 - IGNITION NOISE INTERFERENCE With weak signals, you may experience interference of the signal by background noise. This radio has NB and ANL circuits which will help reduce background noise from sources such as your ignition system. However, background electrical noise may come from several sources and all noise may not be eliminated. With extremely weak signals, you can operate this radio with the engine turned off, which should improve reception. If the ignition noise level is too high to allow proper operation under most conditions, you should have your installation of the radio checked by a qualified technician. ANTENNA This radio has a jack in the rear for a standard PL-259 antenna plug. If you are looking for the most range for your transm ission, use a vertically polarized, quarter- wave length antenna. If antenna height is a problem, you may use a shorter, loaded-type whip antenna although you can e…

Text truncated - open the document above for the full version.

APPLICANT: RANGER ELECTRONIC ( SHANGHAI) INC. FCC ID: MEE-DX-929 OPERATIONAL DESCRIPTION: The Ranger Electronic Model DX-929 is a Single Sideband/Amplitude Modulated transmitter/receiver combination intended for mabile operation in the citizens radio service. The transmitter has 40-channel capability in the 26.965 – 27.405 MHz band using phase locked loop (PPL) technology. The PPL provides multiple frequencies from the VCO (Voltage Controlled Oscillator) with quartz crystal accuracy and stability locked to the crystal oscillator reference frequency. The reference crystal oscillator, Q25, frequency is 10.240 MHz. Each channel is capable of operating in the AM/USB/LSB mode. Frequency tolerance is maintained within a frequency tolerance of 0.005%. Audio from the microphone is fed to a microphone amplifier, IC7. The audio is mixed at IC9, the transmitter mixer, with a signal from the Synthesizer. The mixed signal is routed though a low pass filter consisting of L28, 29, and 30. The 27 MHz signal is then fed to a transmit/receive relay circuitry to the antenna. Q46 is an oscillator operating at 10.697 MHz. Q25 is an oscillator with a frequency of 10.240 MHz. The mixer oscillator is Q27 and has a frequency oscillating at 15.36 MHz. The final amplifier is a 27 MHz High Frequency Power Amplifier consisting of a NPN Epitaxial Planar Silicon Transistor. The collector dissipation, Pc is specified at 1.2 Watts and 10 Watts at Tc=50ºC. See the attached DX-929 Block Diagram for additional circuit information.

DX-929 ALIGNMENT (EPT092910Z) 1.0 TEST EQUIPMENT 1.1 PLL SYNTHESIZER / OSCILLATOR FREQUENCY ALIGNMENT ITEM CONNECTS & SETTING ADJUST MEASUREMENT ± ± ± ± ± 1.2 TRANSMITTER ALIGNMENT 1 ITEM CONNECTS & SETTING ADJUST MEASUREMENT 7 ± 2 1.3 RECEIVER ALIGNMENT ITEM CONNECTS & SETTING ADJUST MEASUREMENT ’ 3

FUNCTION OF DEVICES MODEL DX-929 NO. Reference NO. Description Function 1. Q1 2SC1675L Noise Blanker 2. Q2 2SC1675L Noise Blanker 3. Q3 2SC945P Noise Blanker 4. Q4 2SC945P Noise Blanker 5. Q5 2SC945P Noise Blanker 6. Q6 2SA733P Noise Blanker 7. Q7 2SC945P Noise Blanker 8. Q8 2SC1674L AM Mixer 9. Q9 2SC1675L AM 2 nd IF 10. Q10 2SC1675L AM 2 nd IF 11. Q11 2SC1675L AM 2 nd IF 12. Q14 2SC945P Meter Control 13. Q16 2SC945P PRE-Amplifier 14. Q17 2SC1674L RF Amplifier 15. Q18 2SJ310 Mixer 16. Q19 2SJ310 Mixer 17. Q24 DTC114ES AM Detector 18. Q25 2SC1675L Reference Oscillator 19. Q27 2SC1675L Loop Oscillator 20. Q28 2SC1675L Loop Mixer 21. Q29 2SC1675L Buffer 22. Q30 2SA1282 TX/RX SW 23. Q31 2SC945P TX/RX SW 24. Q33 2SA1282 TX/RX SW 25. Q62 2SA1282 DIM Control 26. Q35 2SC945P Regulator 27. Q36 DTC124ES Squelch SW 28. Q37 2SA1869 Regulator 29. Q38 2SA733 MOD ALC 30. Q39 2SC945P MIC ALC 31. Q40 2SC945P R.B Oscillator 32. Q60 DTA124ES PA SW 33. Q42 2SC945P AF SW 34. Q43 DTC114ES Talkback SW NO. Reference NO. Description Function 35. Q44 2SC945P Squelch Control 36. Q46 2SC1675L Loop Oscillator 37. Q47 2SC1969 TX Power 38. Q49 2SC2166C TX Driver 39. Q51 2SC2538 TX Driver 40. Q52 2SC1906 TX Driver 41. Q53 2SC945P MOD Amplifier 42. Q54 2SB754Y MOD Amplifier 43. Q55 2SA1869 MOD Amplifier 44. Q57 2SC945P MOD ALC 45. IC1 LM324 RX AGC Circuit 46. IC2 IC07A VCO Circuit 47. IC3 RCI-8719-99 PLL Circuit 48. IC7 BA4558 MIC Amplifier 49. IC8 TA7222AP AF Power Amplifier 50. IC9 TDA6130 TX Mixer 51. 52. 53. 54. 55. 56. 57. 58. 59. 60. 61. 62. 63. 64. 65.

APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 REPORT #: R\Ranger_MEE\370AUT3\370AUT3TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS LIST APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 TEST REPORT: PAGE 1......COVER SHEET – GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIP. CONTINUED & RF POWER OUTPUT PAGE 3......AUDIO FREQUENCY RESPONSE PAGE 4-5....AUDIO INPUT VS MODULATION GRAPH PAGE 6......OCCUPIED BANDWIDTH TEST PROCEDURES PAGE 7......OCCUPIED BANDWIDTH PLOT PAGE 8......OCCUPIED BANDWIDTH PLOT –CW PAGE 9......OVER MODULATION TRANSIENT RESPONSE PAGE 10.....OVER MODULATION TRANSIENT RESPONSE PLOTS PAGE 11.....SPURIOUS EMISSIONS AT ANTENNA TERMINALS TEST PROCEDURE PAGE 12.....UNWANTED EMISSIONS PAGE 13.....METHOD OF MEASURING RADIATED EMISSIONS PAGE 14.....FREQUENCY STABILITY PAGE 15-17..LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1...SCHEMATICS EXHIBIT 2...BLOCK DIAGRAM EXHIBIT 3...EXTERNAL PHOTOGRAPHS EXHIBIT 4...INTERNAL PHOTOGRAPHS EXHIBIT 5...FCC ID LABEL SAMPLE AND SKETCH OF LOCATION EXHIBIT 6...PARTS LIST EXHIBIT 7...TUNING PROCEDURE EXHIBIT 8...CIRCUIT DESCRIPTION EXHIBIT 9...OWNER’S MANUAL EXHIBIT 10..TEST SETUP PHOTOGRAPH EXHIBIT 11..AMPLIFIER SPECIFICATION APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 REPORT #: R\Ranger_MEE\370AUT3\370AUT3TestReport.doc Page 1 of 17 GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c)(1)(2) RANGER ELECTRONIC COMMUNICATIONS. will manufacture the FCC ID: MEE-DX-929 CITIZENS BAND 40 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95 SUBPART D. RANGER ELECTRONIC COMMUNICATIONS. 70 PEI NEI STREET, SHULIN 238 TAIPEI HSIEN, TAIWAN 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as Exhibit # 10. 2.983 (d) TECHNICAL DESCRIPTION 2.1033(c)(4) Type of Emission: 6KOOA3E 95.633 ALLOWED AUTHORIZED BANDWIDTH = 8.0 kHz 95.625 Frequency Range: 26.965 – 27.405 MHz Calculation: Max modulation (M) in kHz = 3 kHz Bn = 2*M = 2*3 kHz = 6 kHz Amplitude Modulation ` Power Range and Controls: There are NO user Power controls. 2.1033(c)(7) Maximum Output Power Rating as defined in the rules: 4 Watts carrier power when transmitting emissions type A3E. 2.1033(c)(8) DC 13.8 Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 13.8 Volts DC Ice = 1.98 A. Pin = 27.32 Watts 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included as Exhibit # 8. 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as Exhibit # 2. The block diagram is included as Exhibit # 1. 2.1033(c)(11) A photograph for drawing of the FCC ID Label and the where it will be placed on the device is included as Exhibit # 5. 2.1033(c)(12) Photographs of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, label for controls, including any view under shields are included as Exhibit # 3-4. APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 REPORT #: R\Ranger_MEE\370AUT3\370AUT3TestReport.doc Page 2 of 17 2.1033(c)(13) Digital modulation. This unit does not use digital modulation. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. 2.1046 RF power output. The EUT was connected to a resistive coaxial attenuator of normal load impedance, and the unmodulated output power was measured by means of an R.F. Power Meter. With applied voltage of 13.8 VDC, output measurement results are: Power Output = 3.8 Watts Transmitter 50 ohm under test Resistive Wattmeter Power Supply 95.645(a) No control, switch, or other type adjustment, which, when manipulated can results in a violation of the rules. 95.655 All frequency determining elements, including crystals, PLL integrated circuits, and channel selection are permanently mounted and soldered internal to the transmitter and cannot be accessed through the front panel or from the enclosure exterior. 95.667 Dissipation rating of the final amplifier which supplies RF power to the antenna terminal must not exceed 10 W. This EUT uses 2SC2078, 27 MHz High Frequency Power Amplifier. The specification sheet is shown as Exhibit 11. Collector dissipation is listed at 1.2 Watts. 95.669 External Controls: This EUT meets the applicable provisions of 95.669. External controls are limited to the control functions as described in Chapter 3 of the users manual. 95.671 The serial number of each unit will be implemented in accordance with 95.671. Please see label sample submitted. 95.673 A copy of Part 95, Subpart D, of the FCC rules, current at the time of packing of the transmitter will be furnished with each EUT marketed. APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 REPORT #: R\Ranger_MEE\370AUT3\370AUT3TestReport.doc Page 3 of 17 2.1047 Modulation characteristics: 2.1047(a) AUDIO FREQUENCY RESPONSE The audio frequency response was measured in accordance with EIA Specification RS-382A. The audio frequency response curve is shown below. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. AUDIO FREQUENCY RESPONSE GRAPH Ranger Electronic Comm. DX-929 -70 -68 -66 -64 -62 -60 -58 -56 -54 -52 100100010000 Frequency dBmV audio response APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 REPORT #: R\Ranger_MEE\370AUT3\370AUT3TestReport.doc Page 4 of 17 2.1047(b) Audio input versus modulation The audio input level needed for a particular percentage of modulation was measured in accordance with EIA Specification RS-382A. The audio input curves versus modulation are below. Curves are provided for audio input frequencies of 300, 1000, and 2500 Hz. MODULATION LIMITING PLOT – 300 Hz Ranger Electronic Comm. DX-929 0 20 40 60 80 100 -65-55-45-35-25-15 dBmV % 300 Hz APPLICANT: RANGER ELECTRONIC COMMUNICATIONS. FCC ID: MEE-DX-929 REPORT #: R\Ranger_MEE\370AUT3\370AUT3TestReport.doc Page 5 of 17 MODULATION LIM…

Text truncated - open the document above for the full version.
