Correspondence by Project Project Number: Correspondence Number Memo MG3-2010-1 1) Please provide an explanation on how the device meets the operational requirements of 15.231. Response: The Transmitter turns off immediately after a button is released. The Tx configuration data clock pin remains on for 74us after the FSK data has been processed.

TITLE SCALE 1:1 SIZE DWG. NO A SHEET 1 of 1 REV 01 APPROVALS DATE UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MM. DRAWN CHECKED REVISIONS ECOITEM MASTER DESCRIPTION REV DATE BY TOLERANCES: 0.000 +/- .125 0.00 +/- .25 0.0 +/- .4 0. +/- .7 HOLE DIA: +/- .075 ANGLES: +/- .5 C29782182564INITIAL RELEASE @ DEVELOPMENT 01 02/17/11JW JASON WALKER02/17/11 182564 LABEL / ART, BOTTOM CASE, RMTE, 21.1 IR/UHF, CHINA (TYPE II) Scale: 200% Use this image to create label Scale: 100% Use this image to create label 34.5 20.9 NOTES: 1. ALL DIMENSIONS ARE IN MILLIMETERS, UNLESS OTHERWISE NOTED. 2. PLACE ARTWORK AT LOCATION SHOWN. 3. COLOR OF PRINTING: LIGHT GRAY (PMS 427) 4. MATERIAL: POLYCARBONATE, BLACK LIGHT SATIN TEXTURE, WITH PERMANENT PRESSURE-SENSITIVE BACKING. UL/CSA APPROVED. THICKNESS OF POLYCARBONATE MUST BE LESS THAN OR EQUAL TO .007”. POLYCARBONATE WITH ADHESIVE CANNOT EXCEED THE TOTAL DEPTH OF THE RECESSED AREA. 5. COVER ADHESIVE WITH PROTECTIVE BACKING. 6. THIS PRODUCT IS RoHS COMPLIANT. 7. QUALITY ASSURANCE PROVISIONS: IN ADDITION TO MEETING ALL REQUIREMENTS OUTLINED IN THIS SPECIFICATION, ALL REQUIREMENTS IN THE FOLLOWING ECHOSTAR QUALITY ASSURANCE DOCUMENTS AND THEIR REFERENCES MUST BE MET OR EXCEEDED. A) 124214 SUPPLIER AQL REQUIREMENTS B) 105450 SUPPLIER QA REQUIREMENTS C) 123473765-AA COSMETIC PROVISIONS 182563 21.1 IR/UHF PRO FCC ID: MG3-2010 Made in China EchoStar Technologies L.L.C.

Report Number: B01118D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report EchoStar Semtech SX1241 Remote 2011 Remote Model: URC-2010BC0-R, EchoStar Model: 21.1 IR/UHF PRO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 18 FCC PART 15 SUBPART B and C TEST REPORT for ECHOSTAR SEMTECH SX1241 REMOTE 2011 REMOTE MODEL: URC-2010BC0-R, ECHOSTAR MODEL: 21.1 IR/UHF PRO Prepared for UNIVERSAL ELECTRONICS, INC. 6101 GATEWAY DRIVE CYPRESS, CALIFORNIA 90630-4841 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 26, 2011 REPORTAPPENDICESTOTAL BODYA B C D E PAGES 19 2 2 2 11 34 70 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B01118D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report EchoStar Semtech SX1241 Remote 2011 Remote Model: URC-2010BC0-R, EchoStar Model: 21.1 IR/UHF PRO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 18 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – EMI 9 4.1.1 Cable Construction and Termination 10 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 11 5.1 EUT and Accessory List 11 5.2 EMI Test Equipment 12 6. TEST SITE DESCRIPTION 13 6.1 Test Facility Description 13 6.2 EUT Mounting, Bonding and Grounding 13 6.3 Facility Environmental Characteristics 13 7. TEST PROCEDURES 14 7.1 RF Emissions 14 7.1.1 Conducted Emissions Test 14 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 15 7.1.3 RF Emissions Test Results 17 7.2 Bandwidth of the Fundamental 18 8. CONCLUSIONS 19 Report Number: B01118D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report EchoStar Semtech SX1241 Remote 2011 Remote Model: URC-2010BC0-R, EchoStar Model: 21.1 IR/UHF PRO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 18 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos  Test Setup Diagram  Antenna and Amplifier Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site – 3 Meters Report Number: B01118D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report EchoStar Semtech SX1241 Remote 2011 Remote Model: URC-2010BC0-R, EchoStar Model: 21.1 IR/UHF PRO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 18 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: EchoStar Semtech SX1241 Remote 2011 Remote Model: URC-2010BC0-R EchoStar Model: 21.1 IR/UHF PRO Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Gemstar Technology (Yangzhou) Company Limited #1 Junsheng Road, Fanshui Town, Industrial Zone, Baoying, Yangzhou, Jiansu Province, China (Post Code: 225819) Applicant: Universal Electronics, Inc. 6101 Gateway Drive Cypress, California 90630-4841 Test Date(s): November 15, 16, and 17, 2010 Test Specifications: EMI requirements CFR Title 47, Part 15, Subpart B Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B01118D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report EchoStar Semtech SX1241 Remote 2011 Remote Model: URC-2010BC0-R, EchoStar Model: 21.1 IR/UHF PRO Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 18 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz The EUT does not directly or indirectly connect to the AC mains, thus this test was not performed. 2 Radiated RF Emissions 10 kHz – 3950 MHz (Transmitter Portion) Complies with the limits of CFR Title 47,…

Text truncated - open the document above for the full version.

RBW 1 MHz VBW 1 MHz 18 dB Offset A IN1 Unit dB  V TRG SWT 2 s P20 TDS Ref Lvl 100 dB  V Ref Lvl 100 dB  V RF Att 10 dB Center 369.5 MHz200 ms/ 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 0.83 dB 1.014028 s 1 [T1] 36.45 dB  V 561.122244 ms 1 [T1] 0.83 dB 1.014028 s D1 63.22 dB  V T1 Date: 17.NOV.2010 16:38:36 Plot Showing Entire Pulse Train RBW 1 MHz VBW 1 MHz A IN1 Unit dB  V TRG P0 TDS Ref Lvl 102 dB  V Ref Lvl 102 dB  V RF Att 10 dB SWT 1 s Center 369.5 MHz100 ms/ 1VIEW D 1MA 10 20 30 40 50 60 70 80 90 2 102 1 1 Delta 1 [T1] -1.58 dB 100.200401 ms 1 [T1] 53.64 dB  V 288.577154 ms 1 [T1] -1.58 dB 100.200401 ms D1 62.3 dB  V D2 66.69 dB  V T1 Date: 16.NOV.2010 08:45:48 Plot Showing Highest 100 mS Period RBW 1 MHz VBW 1 MHz A IN1 Unit dB  V TRG Ref Lvl 102 dB  V Ref Lvl 102 dB  V RF Att 10 dB P0 TDS SWT 100 ms Center 369.5 MHz10 ms/ 1VIEW D 1MA 10 20 30 40 50 60 70 80 90 2 102 1 1 Delta 1 [T1] 1.49 dB 36.072144 ms 1 [T1] 47.80 dB  V 26.252505 ms 1 [T1] 1.49 dB 36.072144 ms D1 62.3 dB  V D2 66.69 dB  V T1  Date: 16.NOV.2010 08:49:12 Time of Pulse = 36.072144 mS Total Duty Cycle = 36.072144 mS / 100 mS = 36.07%

RBW 1 MHz VBW 1 MHz 18 dB Offset A IN1 Unit dB  V TRG SWT 2 s Ref Lvl 100 dB  V Ref Lvl 100 dB  V RF Att 10 dB Center 375.3 MHz200 ms/ P20 TDS 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 0.90 dB 1.022044 s 1 [T1] 36.81 dB  V 172.344689 ms 1 [T1] 0.90 dB 1.022044 s D1 63.22 dB  V T1 Date: 17.NOV.2010 16:37:33 Plot Showing Entire Pulse Train Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG P20 TDS SWT 500 ms Center 375.2865731 MHz50 ms/ 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 45.46 dB 100.200401 ms 1 [T1] 37.21 dB  V 175.350701 ms 1 [T1] 45.46 dB 100.200401 ms D1 63.22 dB  V T1 Date: 17.NOV.2010 16:17:01 Plot Showing Highest 100 mS Period Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG SWT 100 ms Center 375.2865731 MHz10 ms/ P20 TDS 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] -1.98 dB 35.871743 ms 1 [T1] 36.53 dB  V 38.076152 ms 1 [T1] -1.98 dB 35.871743 ms D1 63.22 dB  V T1  Date: 17.NOV.2010 16:19:49 Time of Pulse = 35.871743 mS Total Duty Cycle = 35.871743 mS / 100 mS = 35.87%

Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG SWT 2 s Center 388.3 MHz200 ms/ P20 TDS 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 0.59 dB 1.014028 s 1 [T1] 36.77 dB  V 561.122244 ms 1 [T1] 0.59 dB 1.014028 s D1 63.22 dB  V T1 Date: 17.NOV.2010 16:31:21 Plot Showing Entire Pulse Train Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG P20 TDS SWT 500 ms Center 388.3 MHz50 ms/ 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 44.86 dB 100.200401 ms 1 [T1] 37.27 dB  V 183.366733 ms 1 [T1] 44.86 dB 100.200401 ms D1 63.22 dB  V T1 Date: 17.NOV.2010 16:28:10 Plot Showing Highest 100 mS Period Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG SWT 100 ms Center 388.3 MHz10 ms/ P20 TDS 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] -0.47 dB 36.072144 ms 1 [T1] 35.41 dB  V 24.248497 ms 1 [T1] -0.47 dB 36.072144 ms D1 63.22 dB  V T1  Date: 17.NOV.2010 16:30:43 Time of Pulse = 36.072144 mS Total Duty Cycle = 36.072144 mS / 100 mS = 36.07%

RBW 1 MHz VBW 1 MHz 18 dB Offset A IN1 Unit dB  V TRG SWT 2 s Ref Lvl 100 dB  V Ref Lvl 100 dB  V RF Att 10 dB Center 394.3 MHz200 ms/ P20 TDS 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 0.75 dB 1.014028 s 1 [T1] 36.40 dB  V 561.122244 ms 1 [T1] 0.75 dB 1.014028 s D1 63.22 dB  V T1 Date: 17.NOV.2010 16:34:32 Plot Showing Entire Pulse Train Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG P20 TDS SWT 500 ms Center 394.3 MHz50 ms/ 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] 43.67 dB 100.200401 ms 1 [T1] 38.04 dB  V 222.444890 ms 1 [T1] 43.67 dB 100.200401 ms D1 63.22 dB  V T1 Date: 17.NOV.2010 16:23:16 Plot Showing Highest 100 mS Period Ref Lvl 100 dB  V Ref Lvl 100 dB  V RBW 1 MHz VBW 1 MHz RF Att 10 dB 18 dB Offset A IN1 Unit dB  V TRG SWT 100 ms Center 394.3 MHz10 ms/ P20 TDS 1VIEW D16 1MA 10 20 30 40 50 60 70 80 90 0 100 1 1 Delta 1 [T1] -0.42 dB 36.072144 ms 1 [T1] 36.80 dB  V 9.418838 ms 1 [T1] -0.42 dB 36.072144 ms D1 63.22 dB  V T1  Date: 17.NOV.2010 16:25:23 Time of Pulse = 36.072144 mS Total Duty Cycle = 36.072144 mS / 100 mS = 36.07%
