REMOTE USER GUIDE Safety Instructions You must keep safety in mind while using this device. Keep these and any other instructions for future reference. Observe Warnings: Carefully follow all warnings on the device and in the operating instructions. Heat: Do NOT place the device near heat sources such as radiators, stoves, heat registers, or other appliances that produce heat. Care and Use Cleaning: Do NOT use liquid, abrasive, solvent, or aerosol cleaners. Use a damp cloth for cleaning. When Not in Use: Remove the batteries if this device is to be left unattended or unused for a long period of time. Refer servicing to qualified personnel when a solid object or liquid has fallen onto or into the device. Do NOT attempt to service this device. Refer all servicing to qualified personnel. Opening covers other than the battery cover will void the warranty. Publishing Information Copyright © 2015. EchoStar Technologies L.L.C., Englewood, Colorado 80112. All rights reserved. The information in this User Guide may change without notice. Revisions may be issued to tell you about such changes. Send comments or questions about this User Guide to [email protected] or Technical Publications, EchoStar Technologies L.L.C, 90 Inverness Circle East, Englewood, Colorado 80112. Document Number: 206231 Printed in DISH is a registered trademark of DISH Network L.L.C. All product names, trade names, or corporate names mentioned in this User Guide are acknowledged to be the proprietary property of the registered owners. 1 Insert the Batteries Push the tab toward the top of the remote to release the battery door latch and then lift the battery door from the remote. Insert 2 AA batteries, making sure to match the plus (+) ends with the plus markings on the battery case. Replace the remote battery cover. 1 2 3 R E M O T E A N T E N NA SYSTEM INFO SYS INFO 2 Pairing Remote to the Hopper® or Joey® Receiver Verify the antenna is installed on the back of your Hopper receiver. Joey receivers have an internal antenna. Turn your receiver and TV on, and press SYSTEM INFO on the front panel. Confirm that you see the System Info screen. Press and release the SAT button on your remote (on the side of the remote). Wait until you hear a tone and see the remote listed on the screen. After pairing, you should hear a series of ascending tones. Confirm that your remote operates your receiver by pressing remote buttons. If this is not working, go back to step 4. 3 2 1 4 5 For the remote to work with either a Hopper® or Joey® receiver, it must be paired. Use the following procedure to pair the remote. Joey: OR Hopper: 3 Arrow/Select Buttons Channel up/ down, navigate through menus, and select a desired option SAT/TV/AUX Mode indicator lights up when sending signals in that mode For the remote to work with either a Hopper® or Joey® receiver, it must be paired. Use the following procedure to pair the remote. CH Channel up/ down, navigate through menus, and select a desired option Skip Forward/ Forward Press to skip forward 10 seconds in a program. Press and hold to forward through the program Skip Back/ Back Press to skip back 10 seconds in a program. Press and hold to reverse the program Back/Live TV Return to previous menu. Press and hold to return to viewing live TV Pause/Play Pauses or plays a live or recorded program SAT Mode To use the features described in this section, make sure you are in SAT mode by pressing the SAT Mode button. Note: Some features may not be available depending on your receiver model. Power & TV Power Left button turns the receiver on/off Right button turns the TV on/off Vol and Mute Buttons Control TV volume Programming required Recall Return to previously viewed channel(s) Number Buttons Enter a channel number or navigate through menus and program guide Home Access receiver features and settings Options Opens contextual options menu for each screen Apps Displays the Apps menu DVR Displays list of recorded programs Info/Help Retrieve info on programs and set a timer. Press and hold for contextual help Guide Display current and future satellite program listings Search Search for programs 4 SAT Mode, continued To use the features described in this section, make sure you are in SAT mode by pressing the SAT Mode button. Note: Some features may not be available depending on your receiver model. Input Swaps the tuner Press this button for SAT Mode SAT LED lights up 5 TV Mode To use the features described in this section, make sure you are in TV mode by pressing the TV Mode button. Remote programming is required. Note: The remote has Limited Mode enabled, which means only the Volume, Mute, and TV Power buttons work in TV Mode (see Enabling or Disabling Limited Mode on page 18). Note: Some features may not be available depending on your TV model. Mute Turn TV volume on or off Input Switch between TV inputs (available only for certain makes and models of TVs) Channel Up/ Down Channel up/ down on the TV Volume Control TV volume Press this button for TV Mode Power & TV Power Left button turns the receiver on/off Right button turns the TV on/off TV Menu Access menu features available on some TVs Up/Down Arrow Button Channel up/ down on the TV Select Button Select a program or menu Number Buttons Enter a channel number 6 DVR Functions • Displays a list of recorded programs. • Plays a live or recorded program. • Pauses a live or recorded program. • Press SKIP BACK to skip back about 10 seconds in a program. Press and hold SKIP BACK to reverse the program four times as fast as normal play. Press BACK twice to reverse at 15 times normal speed, three times to reverse at 60 times normal speed, and four times to reverse at 300 times normal speed. The on- screen bar shows how far you’ve gone. For a live program, you can only reverse back to the last channel change or back one hour, whichever occurs first. • Press SKIP FWD to skip ahead about 30 seconds in the program. Press and hold SKIP FWD (Forward) to fast-forward thro…

Text truncated - open the document above for the full version.

Universal Electronics, Inc. , 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 April 28, 2015 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: This is a letter of authorization to accept that any personnel of Compatible Electronics, Inc. as an Agent for Universal Electronics, 201 East Sandpointe Ave, 8 th Floor, Santa Ana CA 92707, for a period of one year, to sign applications before the certification body on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the certification body in connection with certification of the following Universal Electronics products: Name of Product: Product name: EchoStar 52.0 Melbourne 2014 Model name: URC-2024BC0-R FCC ID: MG3-2024 Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of the FCC Rules and Regulations. Please also accept this letter as an attestation that neither Universal Electronics nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non- voting, have been denied federal benefits under section 5301 of the Anti-Drug Abuse act of 1988, 21 U.S.C. 853(a). In addition, Universal Electronics will notify the Federal Communications Commission if, at any time, the situation changes causing Universal Electronics to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9500 Ext 9701 Sincerely, Jesse Mendez Staff Engineer Electrical

Universal Electronics, Inc. , 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 April 28, 2015 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Universal Electronics, would like to declare that the application being submitted for the device with FCC ID: MG3-2024 has not been submitted to another TCB or FCC for certification. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9500 Ext 9701 Sincerely, Jesse Mendez Staff Engineer Electrical

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 April 28, 2015 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematic diagrams, block diagrams, and operational description pursuant to an application for certification for the following universal remote control: Product name: EchoStar 52.0 Melbourne 2014 Model number: URC-2024BC0-R FCC ID: MG3-2024 Gentlemen: We, Universal Electronics, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with our application for certification be withheld from public disclosure per Section 0.459 of the FCC rules. This request is made under the provisions of Section 0.457 (d) of the Commissions rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any further questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez, Staff Engineer Electrical

Universal Electronics, Inc. , 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 List of Modifications April 28, 2015 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: FCC ID: MG3-2024 List of modifications: EchoStar 52.0 Melbourne 2014, URC-2024BC0-R No modifications were needed for compliance. If you have any questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez Staff Engineer Electrical

EchoStar Technologies L.L.C. Made in China Patent Pending

SAR Exclusion Justification This device FCC ID: is excluded from SAR testing by the following justi fication The maximum power that the transmitter is capable o f is 1.94 mW Using the following formula from section 4.3.1 of K DB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up toleranc e, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 100.00% Value 1-g (mW) 10-g (mW) 0.61 (355) -212 "Value" is ≤ 3 , the SAR test exclusion threshold 1-g power limit 10-g power limit 95 238 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An e xample of this is the determination of exposure from a device that uses d igital technology such as a time-division multiple- access (TDMA) scheme for transmission < 50mm power limits for above caclulation using spe cified frequency MG3-2024 Max Peak Power (dBm) Min Separation distance (mm) Fre quency (Ghz) When the minimum test separation distance is < 5 mm , a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 2.475 5 2.87 SAREXJUST-B-0-43 REV A 01/21/2014

Report Number: B50423D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for ECHOSTAR 52.0 MELBOURNE 2014 MODEL: URC-2024BC0-R Prepared for UNIVERSAL ELECTRONICS, INC. 201 EAST SANDPOINTE AVE., 8TH FLOOR SANTA ANA, CA 92707 Prepared by:_____________________ KENNETH LEE Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: APRIL 23, 2015 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 13 27 62 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B50423D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - Emissions 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Radiated Emissions (Spurious and Harmonics) Test – Lab B 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test – Lab D 14 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B50423D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site 2 Layout of the Semi-Anechoic Test Chamber Report Number: B50423D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R EchoStar model number: 52.0 S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Customer: Universal Electronics, Inc. 201 East Sandpointe Ave., 8 TH Floor Santa Ana California, 92707 Test Dates: February 23, 2015 and April 23, 2015 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B50423D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 10 kHz – 25,000 MHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.205, 15.209 and 15.249 2 Conducted RF Emissions, 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power and does not connect to the AC mains. Report Number: B50423D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report EchoStar 52.0 Melbourne 2014 Model: URC-2024BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division…
