MG3-2035Remote controller unit

Report No: GZ12060119-1 FCC ID: MG3-2035 Page 2 of 20 CONTENT TEST REPORT......................................................................................................................................... 1 CONTENT................................................................................................................................................. 2 1. General Description ...................................................................................................................... 3 1.1 Product Description......................................................................................................... 3 1.2 Related Submittal (s) / Grants....................................................................................... 3 1.3 Test Methodology............................................................................................................ 3 1.4 Test Facility....................................................................................................................... 3 1.5 Measurement Uncertainty.............................................................................................. 4 2. System Test Configuration ........................................................................................................... 4 2.1 Justification....................................................................................................................... 4 2.2 EUT Exercising Software................................................................................................ 4 2.3 Special Accessories........................................................................................................ 4 2.4 Equipment Modification.................................................................................................. 4 2.5 Support Equipment List and Description...................................................................... 4 3. Summary of Test Results .............................................................................................................. 5 3.1 Antenna Requirement..................................................................................................... 5 3.2 Conducted Emission....................................................................................................... 5 3.3 Radiated Emission........................................................................................................... 6 3.4 Band Edges Measurement........................................................................................... 12 Report No: GZ12060119-1 FCC ID: MG3-2035 Page 3 of 20 1. General Description 1.1 Product Description The Equipment Under Test (EUT) is a transmitter, model: UES HW DC750 RF4CE 1 CHIP, it’s powered by 3V DC. The main function of EUT is working as a TV controller. Antenna Type: internal, PCB antenna. We found that the unit met the requirements of FCC part 15.249. The worst case’s test data was presented in this test report. 1.2 Related Submittal (s) / Grants The FCC ID of corresponding transmitter for this transmitter is MG3-2035. 1.3 Test Methodology Radiated emission measurements were performed in semi-anechoic chamber room according to the procedures in ANSI C63.4 :2009.For radiated emission measurement, three orthogonal axes of device were tested, only the worst case data was shown in the report. All radiated tests were performed at an antenna to EUT distance of 3 meters, unless stated otherwise in the "Justification Section" of this Application. 1.4 Test Facility The Radiated Emission test is performed at: Compliance Certification Services (Shenzhen) Inc. located at No.10-1Mingkeda Logistics Park, No.18Huanguan South RD. Guanlan Town, Baoan District Shenzhen China. This test facility and site measurement data have been fully placed on file with the FCC, test firm registration number is 441872. Test Equipment List Serial No. Equipment Manufacturer Model No. Cal. Date Due Date 100783 Receiver R&S ESCI 19-Mar-12 19-Mar-13 D286 Horn Antenna SCHWARZBECK BBHA9120D 19-Mar-12 19-Mar-13 US4430039 9 PSA Series Spectrum Analyzer Agilent E4446A 19-Mar-12 19-Mar-13 5082 Bilog Antenna SCHAFFNER CBL6143 03-Jun-12 03-Jun-13 1411843 Amplifier MITEQ AM-1604- 3000 18-Mar-12 18-Mar-13 Report No: GZ12060119-1 FCC ID: MG3-2035 Page 4 of 20 1.5 Measurement Uncertainty Radiated Emission: 3.79dB in the frequency range of 30MHz-200MHz, 3.62dB in the frequency range of 200MHz-1000MHz, 5.04dB in the frequency above 1GHz at a level of confidence of 95%. When determining the test conclusion, the Measurement Uncertainty of test has been considered. 2. System Test Configuration 2.1 Justification The system was configured for testing in a typical fashion (as a customer would normally use it), and in the confines as outlined in ANSI C63.4 :2009. The EUT was powered by 3V DC in the testing. Type of modulation: O-QPSK modulation, and only the worst data was reported in this report. For maximizing emissions, the unit was placed in the center of the turntable, and the turntable was rotated through 360°, the antenna height was varied from 1 meter to 4 meters above the ground plane, and the antenna polarization was changed. This step by step procedure for maximizing emissions led to the data reported in Chapter 3. 2.2 EUT Exercising Software There was no special software to exercise the device. 2.3 Special Accessories No special accessories used. 2.4 Equipment Modification Any modifications installed previous to testing by Universal Electronics Inc will be incorporated in each production model sold/leased in the United States. No modifications were installed by Intertek Testing Services Shenzhen Ltd. Guangzhou Branch. 2.5 Support Equipment List and Description N/A Report No: GZ12060119-1 FCC ID: MG3-2035 Page 5 of 20 3. Summary of Test Results FCC Rules Description of Test Result 15.203 Antenna Requirement Pass 15.249 Radiated Emission Pass 15.249 Band Edges Measurement Pass Remark: When de…

Text truncated - open the document above for the full version.
