Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for UEI PULSE RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Prepared for UNIVERSAL ELECTRONICS, INC. 201 EAST SANDPOINTE AVENUE, 8 TH FLOOR SANTA ANA, CALIFORNIA 92707 Prepared by:_____________________ ALEX BENITEZ Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: MARCH 5, 2013 REPORTAPPENDICESTOTAL BODYA B C D E PAGES 16 2 2 2 13 47 82 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagram, Charts, and Photos Test Setup Diagram Antenna and Amplifier Factors Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURETITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of the Radiated TestSite Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested:UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R S/N: N/A Product Description:See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: Universal Electronics, Inc. 201 East Sandpointe Avenue, 8 th Floor Santa Ana, California 92707 Manufacturer: Gemstar Technology Company, LTD. Gemstar Industrial Park, Shi Guang Road Number 45 Zhongcun Town, Panyu Guangdong Province, China 511495 Test Date(s): February 25 and 26, and March 4, 2013 Test Specifications:Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TESTDESCRIPTIONRESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualificat…

Text truncated - open the document above for the full version.

Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E25 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E26 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E27 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E28 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E29 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E30 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E31 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E32 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E33 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E34 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E35 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E36 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page E37 Report Number: B30304D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report UEI Pulse RF4CE-GP 2012 Model: URC-2068BC2-XXXX-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 9130…

Text truncated - open the document above for the full version.

102 dB  V 92 dB  V 102 dB  V 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 0 dB A IN1 Unit dB  V P0 TDF Max/Ref Lvl SWT 200 ms Center 2.424358717 GHz20 ms/ 1AP1VIEW 2VIEW2MA 10 20 30 40 50 60 70 80 90 2 102 1 1 Delta 1 [T1] 0.77 dB 2.805611 ms 1 [T1] 24.78 dB  V 129.458918 ms 1 [T1] 0.77 dB 2.805611 ms D2 54 dB  V Date: 12.MAR.2013 07:07:53 Time of One Pulse for Acquisition Mode = 2.805611 mS 102 dB  V 92 dB  V 102 dB  V 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 0 dB A IN1 Unit dB  V P0 TDF Max/Ref Lvl SWT 200 ms Center 2.424358717 GHz20 ms/ 1AP1VIEW 2VIEW2MA 10 20 30 40 50 60 70 80 90 2 102 11 Delta 1 [T1] -0.02 dB 73.346693 ms 1 [T1] 24.79 dB  V 56.112224 ms 1 [T1] -0.02 dB 73.346693 ms D2 54 dB  V Date: 12.MAR.2013 07:08:49 Time of pulse train with blanking interval = 76.152304 mS (73.346693 mS shown above + 2.805611 mS for Pulse Itself) Duty Cycle for Acquisition Mode = 2.805611 mS / 76.152304 mS = 3.68% The maximum 20 dB Peak to Average Ratio can be applied because they duty cycle is less than 10 percent. 102 dB  V 92 dB  V 102 dB  V 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 0 dB A IN1 Unit dB  V Max/Ref Lvl SWT 200 ms Center 2.424358717 GHz20 ms/ P0 TDF 1VIEW1MA 10 20 30 40 50 60 70 80 90 2 102 1 1 Delta 1 [T1] 0.17 dB 2.805611 ms 1 [T1] 25.70 dB  V 44.488978 ms 1 [T1] 0.17 dB 2.805611 ms D2 54 dB  V Date: 12.MAR.2013 07:14:25 Time in Data Mode = 2.805611 mS 102 dB  V 92 dB  V 102 dB  V 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 0 dB A IN1 Unit dB  V Max/Ref Lvl SWT 200 ms Center 2.424358717 GHz20 ms/ P0 TDF 1VIEW1MA 10 20 30 40 50 60 70 80 90 2 102 1 1 Delta 1 [T1] -0.73 dB 71.743487 ms 1 [T1] 27.13 dB  V 14.028056 ms 1 [T1] -0.73 dB 71.743487 ms D2 54 dB  V Date: 12.MAR.2013 07:15:22 Time of pulse train with blanking interval = 71.743487 mS Duty Cycle for Data Mode = 2.805611 mS / 71.743487 mS = 3.91% The maximum 20 dB Peak to Average Ratio can be applied because they duty cycle is less than 10 percent.
