MG3-3050Intel Platinum Trail Remote 2013

98 interference received, including interference that may cause undesired operation. FCC Radio Frequency Interference Requirements This device contains a wireless adapter that, when operating in the frequency range 5.15 to 5.25 GHz, remains indoors to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage the wireless adapter installed. Note: The combined radiated output power of the wireless modules installed is far below the FCC radio frequency exposure limits. Nevertheless, this device should be used in such a manner that the potential for human contact during normal operation is minimized. To avoid the possibility of exceeding the FCC radio frequency exposure limits, you should keep a distance of at least 8 inches (20 centimeters) between you (or any other person in the vicinity) and the antenna that is built into this device. Details of the authorized configurations can be found at http://www.fcc.gov/oet/ea/ by entering the FCC ID numbers on the device. FCC Notice Class B digital device This device has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against the device creating harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: –Reorient or relocate the receiving antenna –Increase the separation between the device and receiver –Connect the device to an outlet on a circuit different from that to which the receiver is connected –Contact AudienceCare for help Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any Questions? Contact AudienceCare at (855) 662-8388

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 August 22, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: This is a letter of authorization to accept that any personnel of Compatible Electronics, Inc. as an Agent for Universal Electronics, 201 East Sandpointe Ave, 8 th Floor, Santa Ana CA 92707, for a period of one year, to sign applications before the certification body on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the certification body in connection with certification of the following Universal Electronics products: Name of Product: Product name: Intel Platinum Trail Remote 2013 Model name: URC-3050BC0-R FCC ID: MG3-3050 Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of the FCC Rules and Regulations. Please also accept this letter as an attestation that neither Universal Electronics nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non- voting, have been denied federal benefits under section 5301 of the Anti-Drug Abuse act of 1988, 21 U.S.C. 853(a). In addition, Universal Electronics will notify the Federal Communications Commission if, at any time, the situation changes causing Universal Electronics to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9500 Ext 9701 Sincerely, Jesse Mendez Staff Engineer, Electrical Universal Electronics

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 August 22, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Universal Electronics, would like to declare that the application being submitted for the device with FCC ID: MG3-3050 has not been submitted to another TCB or FCC for certification. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9500 Ext 9701 Sincerely, Jesse Mendez Staff Engineer, Electrical Universal Electronics

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 List of Modifications August 22, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: FCC ID: MG3-3050 List of modifications: Intel Platinum Trail Remote 2013, URC-3050BC0-R No modifications were found to be necessary for compliance. If you have any questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez Staff Engineer, Electrical Universal Electronics Inc.

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 12 September, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: The user manual is currently under development. Any product shipped prior to user manual being completed will contain the Information in the User statement. Additionally, as soon as the User Manual is complete, a copy will be provided to the FCC. If you have any questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez Staff Engineer, Electrical Universal Electronics Inc.

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 August 22, 2013 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematic diagrams, block diagrams, and operational description pursuant to an application for certification for the following universal remote control: Product name: Intel Platinum Trail Remote 2013 Model number: URC-3050BC0-R FCC ID: MG3-3050 Gentlemen: We, Universal Electronics, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with our application for certification be withheld from public disclosure per Section 0.459 of the FCC rules. This request is made under the provisions of Section 0.457 (d) of the Commissions rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any further questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez, Staff Engineer, Electrical

Correspondence by Project Project Number: Correspondence NumberMemo MG3-3050-1 1) The test report only has data for the 2.4 GHz operation, however the FCC notice information provides information regarding the 5 GHz band. Please explain why the FCC notice information describes operation in the 5 GHz band and provide additional information if necessary. Response: Intel has confirmed back to us (UEI) that the reference of 5 GHz is not in reference to the remote, but something else within the overall product bundle. Untitled Documenthttp://www.celectronics.com/CorrespondenceByProject.asp?ProjectNum... 1 of 19/10/2013 6:34 PM

SAR TEST EXCLUSION This device, FCC ID: MG3-3050, is excluded from SAR testing by the following justification. The maximum power that the transmitter IC is capable of is 1 mW. By using the following formula from section 4.3.1 of KDB 447498: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]*[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR and using the minimum test separation distance of 5 mm, the resulting calculated SAR value is: (1 mW)/5 mm) * (√2.48 GHz) = 0.31 This value is below the exclusion threshold for both the 1-g SAR and 10-g extremity SAR requirements.

Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for INTEL PLATINUM TRAIL REMOTE 2013 MODEL: URC-3050BC0-R Prepared for UNIVERSAL ELECTRONICS, INC. 201 EAST SANDPOINTE AVENUE, 8 TH FLOOR SANTA ANA, CALIFORNIA 92707 Prepared by:_____________________ JAMES ROSS Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: AUGUST 29, 2013 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 14 31 67 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models D Diagram, Charts, and Photos  Test Setup Diagram  Antenna and Amplifier Factors  Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site LIST OF TABLES TABLE TITLE 1.0 Radiated Emission Results Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Universal Electronics, Inc. 201 East Sandpointe Avenue, 8 th Floor Santa Ana, California 92707 Test Date(s): August 1 and 30, 2013 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power and does not connect to the AC mains. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the emissions tests performed on the Intel Platinum Trail Remote 2013, Model: URC-3050BC0-R (EUT). The Emissions measure…

Text truncated - open the document above for the full version.

Ref Lvl 97 dB  V Ref Lvl 97 dB  V RBW 1 MHz VBW 3 MHz RF Att 10 dB A IN1 Unit dB  V P0 TDS SWT 100 ms Center 2.43 GHz10 ms/ 1VIEW1AP 0 10 20 30 40 50 60 70 80 90 -3 97 1 1 Delta 1 [T1] -2.56 dB 1.402806 ms 1 [T1] 42.65 dB  V 54.709419 ms 1 [T1] -2.56 dB 1.402806 ms D1 54 dB  V D2 74 dB  V Date: 22.AUG.2013 08:05:22 Pairing Mode Time of 1 Pulse = 1.402806 mS Number of Pulses in 100 mS =1 Total Duty Cycle: 1.402806 % The maximum 20 dB Peak to Average ratio can be taken. Ref Lvl 97 dB  V Ref Lvl 97 dB  V RF Att 10 dB A Unit dB  V RBW 1 MHz VBW 3 MHz IN1 SWT 100 ms Center 2.402 GHz10 ms/ P0 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 90 -3 97 1 1 Delta 1 [T1] -0.72 dB 601.202405  s 1 [T1] 38.18 dB  V 79.358717 ms 1 [T1] -0.72 dB 601.202405  s D1 54 dB  V D2 74 dB  V Date: 22.AUG.2013 07:52:50 Advertising Mode Time of 1 Pulse = 0.601202405 mS Number of Pulses in 100 mS = 3 Total Duty Cycle: 1.803607215 % The maximum 20 dB Peak to Average ratio can be taken.

Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D11 (30 MHz ─ 1000 MHz) FRONT VIEW UNIVERSAL ELECTRONICS, INC. INTEL PLATINUM TRAIL REMOTE 2013 MODEL: URC-3050BC0-R FCC SUBPART B AND C – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D12 (30 MHz ─ 1000 MHz) REAR VIEW UNIVERSAL ELECTRONICS, INC. INTEL PLATINUM TRAIL REMOTE 2013 MODEL: URC-3050BC0-R FCC SUBPART B AND C – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D13 (ABOVE 1 GHz) FRONT VIEW UNIVERSAL ELECTRONICS, INC. INTEL PLATINUM TRAIL REMOTE 2013 MODEL: URC-3050BC0-R FCC SUBPART B AND C – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS Report Number: B30829A1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Intel Platinum Trail Remote 2013 Model: URC-3050BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page D14 (ABOVE 1 GHz) REAR VIEW UNIVERSAL ELECTRONICS, INC. INTEL PLATINUM TRAIL REMOTE 2013 MODEL: URC-3050BC0-R FCC SUBPART B AND C – RADIATED EMISSIONS PHOTOGRAPH SHOWING THE EUT CONFIGURATION FOR MAXIMUM EMISSIONS
