MG3-3220COX DTA Mini IR/RF4CE Remote 2014

Setup Method A: Conguración del Método A: Popular Brands Marcas famosas URC-3220-R REMOTECONTROLUSER’SGUIDE Guía del usuario remotes.cox.com REMOTES.COX.COM MUG3220-A04 Remove battery cover. Retire la tapa del compartimiento de pilas. Insert 2 AAA batteries. Match the + and – marks. Coloque 2 pilas AA. Haga coincidir las marcas "+" y "-". Replace battery cover. Vuelva a colocar la tapa del compartimiento de pilas. ©Copyright Universal Electronics 2014 DIGIT DÍGITO TV TVs 1 2 3 4 5 6 7 8 9 0 Insignia LG Panasonic Philips/Magnavox Samsung Sanyo Sharp Sony Toshiba Vizio Getting Started Primeros pasos Functional Key Chart Cuadro de teclas de funciones Tip/Consejo: 1 2 3 The POWER button will blink 5 times with each key-press when batteries need replacement. 1 Press the POWER button. Presione la tecla POWER (Encendido del Televisor). 23 2 PARPADEOS = CORRECTA 1 PARPADEO LARGO = INCORRECTA 4 Tip/Consejo: If your brand does not appear on popular TV brand chart, try either Method B or Method C to setup the remote to control your TV. Si la marca que utiliza no aparece en el cuadro de marcas, intente remoto de su TV. Make sure TV is ON before starting remote control setup. Asegúrese de que el televisor esté en la posición ON de encendido antes de comenzar la remoto. Note/Nota: Setup Method B: Conguración del Método B: RF4CE Pairing RF4CE Pairing Press and hold SETUP until the POWER button 1 Press the COX button. Presione la tecla COX. 2 Enter in the 3 Digit code displayed on the TV. 34 Introduzca los 3 dígitos de los códigos que se muestran en el televisor. Press and hold SETUP until the POWER button Mantenga presionada la Botón de encendido parpadee dos veces. blinks twice. tecla SETUP (Congurar) Let go of the button when complete. Suelte la tecla cuando el televisor se apague. La completa. your TV turns o. Setup is conguración está Mantenga presionada la Botón de encendido parpadee dos veces. tecla SETUP (Congurar) The POWER button will El botón POWER parpadeará dos veces para conrmar el éxito Press and hold down the DIGIT button for your TV brand. Mantenga presionada la tecla DIGIT (Dígito) para ver la marca de su TV. El botón de encendido parpadeará 5 veces con cada pulsación de tecla cuando las baterías necesitan ser reemplazadas. TurnsTV ON / OFF Displays main cable MENU Displays program GUIDE Press to stretch or shrink screen Sale del menú actual y vuelve al programa actual Encendido/apagado del televisor Muestra el menu principal de cable Muestra la guía de programación Pulse para ampliar o reducir la pantalla EXITs current menu and returnsto current program Se utiliza para seleccionar opciones de entradas en laTV Usedtocycle through video inputs onTV Muestra información sobre el programa actualmente seleccionado Displays INFO for currently selected program Prensa CC para activar los subtítulos Press CC to to turn close captions Hold for 3 seconds to enter programming Mantenga presionado 3 segunds para ingresar a la conguración Use to navigate and select Utilice para navegar y seleccionar Turns volume up and down Se utiliza para subir el volumen o hacia abajo Use to turn o volume Silencia el volumen del televisor Recall last channel viewed Vuelve al ultimo canal que estuvo Allows for direct access to specic channels Permite el acceso directo a los canales especí? Use to tune channel up or down, also used for page navigation in the guide Se utiliza para sintonizar el canal de arriba de páginas en la guía menu and guide options opciones del menú y la guía size horizontally and vertically tamaño horizontal y verticalmentel abajo también se utiliza para la navegación mirando cerca o fuera on or o FCC NOTICE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interfer ence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, the user is encouraged or try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase or decrease the separation between the equipment and receiver. • Consult the dealer or an experienced remote control/ TV technician for help. • It is strongly recommended that the TV be plugged into a seperate wall outlet. T approval of manufacturer could void the user's authority to operate this equipment. Este equipo ha sido probado y cumple con los límites para un dispositivo digital de clase B, según la parte 15 de las Normas de la FCC. Estos límites están diseñados para proporcionar una protección razonable contra las interferencias perjudiciales en una instalación residencial. Este equipo genera, utiliza y puede irradiar energía de radiofrecuencia y, si no se instala y utiliza de acuerdo con las instrucciones, puede causar interferencias perjudiciales en las comunicaciones de radio. Sin embargo, no hay garantía de que no se produzcan interferencias en una instalación en particular. Si este equipo causa interferencias perjudiciales en la radio o televisión, lo cual puede comprobarse encendiéndolo y apagándolo, se recomienda al usuario que intente corregir la interferencia mediante una o más de las siguientes medidas: • Reorientar o reubicar la antena receptora. • Aumentar la separación entre el equipo y el receptor. • Conectar el equipo a una toma de corriente o un circuito distinto de aquél al que está conectado el receptor. • Consulte al distribuidor oa un técnico de radio / TV con experiencia para obtener ayuda. Con el n de mantener el cumplimiento con las regulaciones de la FCC, los cables blindados deben ser utiliz…

Text truncated - open the document above for the full version.

Universal Electronics, Inc. , 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 August 22, 2014 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: This is a letter of authorization to accept that any personnel of Compatible Electronics, Inc. as an Agent for Universal Electronics, 201 East Sandpointe Ave, 8 th Floor, Santa Ana CA 92707, for a period of one year, to sign applications before the certification body on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the certification body in connection with certification of the following Universal Electronics products: Name of Product: Product name: COX DTA Mini IR/RF4CE Remote 2014 Model name: URC-3220BC0-R FCC ID: MG3-3220 Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of the FCC Rules and Regulations. Please also accept this letter as an attestation that neither Universal Electronics nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non- voting, have been denied federal benefits under section 5301 of the Anti-Drug Abuse act of 1988, 21 U.S.C. 853(a). In addition, Universal Electronics will notify the Federal Communications Commission if, at any time, the situation changes causing Universal Electronics to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9500 Ext 9701 Sincerely, Jesse Mendez Staff Engineer Electrical

Universal Electronics, Inc. , 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 August 22, 2014 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Universal Electronics, would like to declare that the application being submitted for the device with FCC ID: MG3-3220 has not been submitted to another TCB or FCC for certification. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9500 Ext 9701 Sincerely, Jesse Mendez Staff Engineer Electrical

Universal Electronics, Inc. , 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 List of Modifications August 22, 2014 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: FCC ID: MG3-3220 List of modifications: COX DTA Mini IR/RF4CE Remote 2014 No modifications were found to be necessary for compliance. If you have any questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez Staff Engineer Electrical

Universal Electronics, Inc. 201 East Sandpointe Ave, 8 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 August 22, 2014 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematic diagrams, block diagrams, and operational description pursuant to an application for certification for the following universal remote control: Product name: COX DTA Mini IR/RF4CE Remote 2014 Model number: URC-3220BC0-R FCC ID: MG3-3220 Gentlemen: We, Universal Electronics, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with our application for certification be withheld from public disclosure per Section 0.459 of the FCC rules. This request is made under the provisions of Section 0.457 (d) of the Commissions rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any further questions or need additional information, please contact the undersigned at (714) 918-9500 ext 9701 Regards, Jesse Mendez, Staff Engineer Electrical

SAR Exclusion Justification This device FCC ID: is excluded from SAR testing by the following justi fication The maximum power that the transmitter is capable o f is 5.01 mW Using the following formula from section 4.3.1 of K DB 447498 at test separation distances ≤ 50 mm [(max. power of channel, including tune-up toleranc e, mW) / (min. test separation distance, mm)] * [ √ f(GHz)] Duty Cycle 11.00% Value 1-g (mW) 10-g (mW) 1.58 (355) -212 "Value" is ≤ 3 , the SAR test exclusion threshold 1-g power limit 10-g power limit 95 238 “source-based” time-averaging based on an inherent property or duty-cycle of a device is allowed. An e xample of this is the determination of exposure from a device that uses d igital technology such as a time-division multiple- access (TDMA) scheme for transmission < 50mm power limits for above caclulation using spe cified frequency MG3-3220 Max Peak Power (dBm) Min Separation distance (mm) Fre quency (Ghz) When the minimum test separation distance is < 5 mm , a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 2.475 5 7 SAREXJUST-B-0-43 REV A 01/21/2014

Report Number: B40820D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for COX DTA MINI IR/RF4CE REMOTE 2014 MODEL: URC-3220BC0-R Prepared for UNIVERSAL ELECTRONICS, INC. 201 EAST SANDPOINTE AVE., 8TH FLOOR SANTA ANA, CA 92707 Prepared by:_____________________ KENNETH LEE Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: AUGUST 21, 2014 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 14 28 64 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B40820D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration - Emissions 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Radiated Emissions (Spurious and Harmonics) Test – Lab B 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test – Lab D 14 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B40820D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams and Charts  Test Setup Diagrams  Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Test Site 2 Plot Map And Layout of Radiated Site 3 Layout of the Semi-Anechoic Test Chamber Report Number: B40820D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R S/N: N/A Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Customer: Universal Electronics, Inc. 201 East Sandpointe Ave. 8 TH Floor , , Santa Ana California 92707 Test Dates: August 19, and 20, 2014 Test Specifications : Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. Report Number: B40820D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Spurious Radiated RF Emissions, 10 kHz – 25,000MHz (Transmitter and Digital portion) Complies with the Class B limits of CFR Title 47, Part 15 Subpart B; and the limits of CFR Title 47, Part 15, Subpart C, section 15.205, 15.209 and 15.249 2 Conducted RF Emissions, 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power and does not connect to the AC mains. Report Number: B40820D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report COX DTA Mini IR/RF4CE Remote 2014 Model: URC-3220BC0-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (…

Text truncated - open the document above for the full version.

Ref Lvl 92 dB  V Ref Lvl 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 20 dB A IN1 Unit dB  VSWT 20 ms Center 2.425 GHz2 ms/ P20 TDS 1VIEW1MA 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] 1.05 dB 1.963928 ms 1 [T1] 40.67 dB  V 17.474950 ms 1 [T1] 1.05 dB 1.963928 ms D1 74 dB  V D2 54 dB  V Date: 19.AUG.2014 07:50:35 Time of One Pulse – Advertising Mode Ref Lvl 92 dB  V Ref Lvl 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 20 dB A IN1 Unit dB  V P20 TDS SWT 1 s Center 2.425 GHz100 ms/ 1VIEW1MA 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] -0.77 dB 400.801603 ms 1 [T1] 41.19 dB  V 458.917836 ms 1 [T1] -0.77 dB 400.801603 ms D1 74 dB  V D2 54 dB  V Date: 19.AUG.2014 07:49:44 Number of Pulses in Worst Case 100 ms Period – Advertising Mode The duty cycle is less than 10%, thus the full 20 dB peak to average ratio is allowed. Duty Cycle = 1.963928 ms / 100 ms = 1.963928% Ref Lvl 92 dB  V Ref Lvl 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 20 dB A IN1 Unit dB  VSWT 10 ms Center 2.425 GHz1 ms/ P20 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] -2.50 dB 1.082164 ms 1 [T1] 37.53 dB  V 7.314629 ms 1 [T1] -2.50 dB 1.082164 ms D1 74 dB  V D2 54 dB  V Date: 19.AUG.2014 07:45:35 Time of One Pulse – Pairing Mode Ref Lvl 92 dB  V Ref Lvl 92 dB  V RBW 1 MHz VBW 3 MHz RF Att 20 dB A IN1 Unit dB  V P20 TDS SWT 200 ms Center 2.425 GHz20 ms/ 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] -1.38 dB 101.402806 ms 1 [T1] 40.70 dB  V 69.338677 ms 1 [T1] -1.38 dB 101.402806 ms D1 74 dB  V D2 54 dB  V Date: 19.AUG.2014 07:40:36 Number of Pulses in Worst Case 100 ms Period – Pairing Mode The duty cycle is less than 10%, thus the full 20 dB peak to average ratio is allowed. Duty Cycle = (1.082164*8) ms / 100 ms = 8.657312%
