Configuración - Método B:Método de Emparejamiento de RF: Configuración del Control de TV utilizando Entrada Directa de Código Búsqueda de Código Configuración – Método C: Bloqueo de los Controles de Volumen a un Dispositivo Bloqueo de TV / Vídeo Tecla a Un Dispositivo Configuración – Método A: Marcas famosas Modo de aprendizaje La tecla de Modo parpadeará 5 veces con cada pulsación de tecla cuando sea necesario reemplazar las pilas. De forma predeterminada, las teclas de volumen quedarán bloqueado en el modo TV. Siga estos pasos para bloquear las teclas de volumen para un solo dispositivo, sin importar el modo seleccionado, si lo desea. Mantenga presionado la tecla SETUP (Congurar) hasta que una tecla de modo parpadee dos veces. Luego presione 975. La tecla de modo parpadee dos veces más. Posición controles remotos de 2-5 centímetros de separación To cancel the volume control lock: 1 - Press and hold SETUP until a mode key blinks twice. 2 - Press the Mute key. The mode key will blink 4 times upon successful unlock. Para cancelar el bloqueo de control de volumen: 1 - Presione y mantenga presionada la tecla SETUP (Congurar) hasta que la tecla de modo parpadee dos veces. 2 - Presione la tecla Silencio. La tecla de modo parpadeará 4 veces al desbloqueo exitoso. De forma predeterminada, la tecla TV / Vídeo controlar cualquier dispositivo en función del modo seleccionado. Siga estos pasos para bloquear la tecla de TV/Video en un solo dispositivo, sin importar lo que se selecciona el modo. By default, the TV/Video key will control any device depending on the mode selected. Follow these steps to lock the TV/Video key to just one device no matter what mode is selected. Para cancelar el bloqueo del interruptor de entrada: 1 - Presione y mantenga presionada la tecla SETUP (Congurar) hasta que la tecla de modo parpadee dos veces. 2 - Presione la tecla TV/Video. Luego la tecla Exit To TV. La tecla de modo parpadeará 4 veces al desbloqueo exitoso. 2 Blinks = Success 1 Long Blink = Failure 2 Parpadeos = Correcta, 1 Parpadeo Largo = Incorrecta Code Search Locking Volume Controls to One Device Setup Method C: Locking TV/Video Key to One Device Consejo:Tip/ Consejo:Tip/ By default, the volume keys will be locked to TV mode. Follow these steps to lock the volume keys to just one device no matter which mode is selected, if desired. Press and hold SETUP until a mode key blinks twice. Then press 975. The mode key will blink twice again. 1 Press and hold the desired key on the teaching remote until the mode key blinks twice. Repeat steps 2 and 3 to learn other keys. To exit: press and hold SETUP until a mode key blinks twice. 3 Learning Mode The mode key will blink 5 times with each key-press when batteries need replacement. Setup Method A:Popular Brands Setup Using Direct Code Entry MUG6251-S_A12 Setup Method B:RF Paring Method: Position remotes 1-2 inches apart. CONTROL REMOTO: GUÍA DEL USUARIO MXV4 RF REMOTE CONTROL USER’S GUIDE Mantenga presionado la tecla deseada en el control que ensena hasta que la tecla de modo parpadee dos veces. Repita los pasos 2 y 3 para aprender otras teclas. Para salir: mantenga presionado la tecla SETUP (Congurar) hasta que una tecla de modo parpadee dos veces. Presione la tecla de modo que corresponda al equipo que está utilizando para cambio de entradas audio/video. Press the mode key that corresponds with the device you use for changing audio/video inputs. 3 Presione la tecla TV/Video. Press the TV/Video key. 2 Consejo:Tip/ Consejo:Tip/ Presione la tecla del modo deseado, luego la tecla para ser enseñado. Press the desired mode key, then the key to be taught. 2 2 Blinks = Success 1 Long Blink = Failure 2 Parpadeos = Correcta, 1 Parpadeo Largo = Incorrecta Presione la tecla de modo que corresponda al equipo que está utilizando para controles de volumen. Press the mode key that corresponds to the device you use for volume controls. 3 ? 2 Presione la tecla aumentar volumen (VOL +). Press VOL + key. 1 2 Remove sticker and secure the RF Adapter to the top of the set-top box as shown. Retire la etiqueta y asegure el Adaptador de RF a la parte superior de la caja de conexión como se muestra. Install batteries. Instale las pilas. 3 4 5 4 Presione la tecla de encendido/ apagado (POWER) para probar con su equipo. Si el equipo se apaga, la conguración se ha completado. Press POWER key to test with your device. If the device turns o, setup is complete. Presione la tecla de modo para el equipo que desee congurar. La tecla de modo permanece encendida. Press the mode key for the device you wish to set up. The mode key stays lit. 2 Presione y mantenga presionada la tecla OK (Aceptar). Press and hold the OK key. 3 Suelte la tecla OK (Aceptar) cuando su equipo se apague. Release the OK key when your device turns o. 4 5 Si el equipo no se apaga, repita el MÉTODO DE CONFIGURACIÓN B utilizando el próximo código que corresponda a su marca o utiilice Metodo de Conguración C. If device does not turn o, repeat SETUP METHOD B using the next code for your brand or use Setup Method C. When successfully paired, the green RF Adapter LED will stop blinking and will stay on. Cuando se ha producido el emparejamiento, el LED verde dejará de parpadear y permanecerá encendida. © Universal Electronics 2012 1 2 4 3 Presione y mantenga presionada la tecla SETUP (Congurar) hasta que el LED parpadea dos veces. Presione la tecla de modo para el equipo que desee congurar. La tecla de modo permanece encendida. Busque su equipo y marca en las tablas que guran a continuación y observe el código de número (Número) asignado a su marca. Mantenga presionada la tecla del numero que corresponda a la marca de su equipo. Suelte la tecla cuando su equipo se apague. La conguración para ese equipo se ha completado. 2 PARPADEOS = CORRECTA 1 PARPADEO LARGO = INCORRECTA Si la marca que utiliza no aparece en la tabla de marcas a la derecha, realice la conguración utilizando ya sea ENTRADA DIRECTA DE CÓDIGO (B) o …
Text truncated - open the document above for the full version.
Ref Lvl -15 dBm Ref Lvl -15 dBm RBW 1 MHz VBW 1 MHz RF Att 0 dB A IN1 Unit dBm P0 SWT 200 ms Center 2.425 GHz20 ms/ 1VIEW1AP -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 -115 -15 1 1 Delta 1 [T1] 0.29 dB 2.404810 ms 1 [T1] -85.52 dBm 10.631238 ms 1 [T1] 0.29 dB 2.404810 ms D1 -33 dBm D2 -53 dBm Date: 18.JAN.2013 14:51:49 Time of one pulse train is less than 10 mS in a 100 mS period for acquisition mode. Ref Lvl -15 dBm Ref Lvl -15 dBm RBW 1 MHz VBW 1 MHz RF Att 0 dB A IN1 Unit dBm P0 SWT 200 ms Center 2.425 GHz20 ms/ 1VIEW1AP -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 -115 -15 1 1 Delta 1 [T1] -0.61 dB 2.004008 ms 1 [T1] -85.27 dBm 36.282541 ms 1 [T1] -0.61 dB 2.004008 ms D1 -33 dBm D2 -53 dBm Date: 18.JAN.2013 14:58:17 Time of one pulse train for data mode = 2.004008 mS Ref Lvl -15 dBm Ref Lvl -15 dBm RBW 1 MHz VBW 1 MHz RF Att 0 dB A IN1 Unit dBm P0 SWT 200 ms Center 2.425 GHz20 ms/ 1VIEW1AP -110 -100 -90 -80 -70 -60 -50 -40 -30 -20 -115 -15 1 1 Delta 1 [T1] -0.33 dB 78.557114 ms 1 [T1] -85.27 dBm 36.282541 ms 1 [T1] -0.33 dB 78.557114 ms D1 -33 dBm D2 -53 dBm Date: 18.JAN.2013 14:58:47 Time of pulse train with blanking interval = 78.557114 mS Duty Cycle = 2.004008 mS / 78.5577114 mS = 2.55% The maximum 20 dB Peak to Average Ratio can be applied because they duty cycle is less than 10 percent.
Report Number: B30114D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15 SUBPART B and C TEST REPORT for Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R Prepared for UNIVERSAL ELECTRONICS, INC. 201 EAST SANDPOINTE AVENUE, 8 TH FLOOR SANTA ANA, CALIFORNIA 92707 Prepared by:_____________________ ALEX BENITEZ Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JANUARY 24, 2013 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 13 25 60 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B30114D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description of Test Configuration – Emissions 8 4.1.1 Cable Construction and Termination 8 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 9 5.1 EUT and Accessory List 9 5.2 Emissions Test Equipment 10 6. TEST SITE DESCRIPTION 11 6.1 Test Facility Description 11 6.2 EUT Mounting, Bonding and Grounding 11 6.3 Facility Environmental Characteristics 11 7. TEST PROCEDURES 12 7.1 RF Emissions 12 7.1.1 Conducted Emissions Test 12 7.1.2 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.3 RF Emissions Test Results 15 8. CONCLUSIONS 16 Report Number: B30114D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered UnderThis Report D Diagram, Charts, and Photos Test Setup Diagram Antenna and Amplifier Factors Radiated Emissions Photos E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of Radiated Test Site Report Number: B30114D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY Compatible Electronics Inc. generates this electromagnetic emission test report, which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: Universal Electronics, Inc. 201 East Sandpointe Avenue, 8 th Floor Santa Ana, California 92707 Manufacturer: Gemstar Technology Company, Ltd. Gemstar Industrial Park, Shi Guang Road Number 45 Zhongcun Town, Panyu Guangdong Province, China 511495 Test Date(s): December 18 and 19, 2012 January 14, 2013 Test Specifications: Emissions requirements CFR Title 47, Part 15, Subpart B and Subpart C, Sections 15.205, 15.209, and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions 150 kHz to 30 MHz This test was not performed because the EUT operates on battery power. 2 Radiated RF Emissions 10 kHz to 25000 MHz (Transmitter and Digital Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.249. Report Number: B30114D1 FCC Part 15 Subpart B and C, Section 15.205, 15.209 and 15.249 Test Report Motorola MXv4RF Remote 2012 Model: URC-6251BC0-XXXX-R Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the emissions tests…
Text truncated - open the document above for the full version.
