MG3-DWZB1-CEDoor/Window Sensor

DWZB1-CE 1.1 2022-12-22 ECOLINK Zigbee 3.0 Door/Window Sensor DWZB1-CE INTRODUCTION Door/Window sensors are designed to secure the perimeter of the residential premise and provide the ability to add various automation services. The Door/Window sensor, which consists of a magnet that attaches to a door or window, will communicate door events to the home security system. When the magnet is moved away from the sensor, a signal will be sent to the control panel that communicates the changed state to the security system. Signals can also be used to activate a chime or convenience lighting based on system settings. SPECIFICATIONS Frequency: 2.4GHz Battery Type: CR123A Battery Operating Temperature: 0 ̊C – 50 ̊C (32°F – 122°F) Storage Temperature: -20 ̊C – 60 ̊C (-4°F – 140°F) Battery Life: 5 Years Dimension: Sensor: 70 x 21 x 22 mm (2.73” x 0.83” x 0.86”) Magnet: 30 x 10 x 11 mm (1.19” x 0.39” x 0.43”) Magnet Spacer: 30 x 10 x 6 mm (1.19” x 0.39” x 0.25”) PAIRING SENSOR This Door/Window sensor needs to be paired before installation. Scanning the QR Code is preferred for pairing with some security system and home controller applications. Note the MAC address can be found by scanning the QR code. 1.Pull the exposed plastic tab from the sensor. (Figure 1) 2.The LED indicator will be lit for three (3) seconds to indicate a successful booting. 3.It will blink three times approximately every 2 – 3 seconds while scanning the network. 4.If network is not found after 3 minutes, the sensor will go into sleep mode. To wake the sensor again, you need to use magnet or tamper (Figure 3) to trigger a paring process, and then sensor will repeat steps from 3 to 4. INSTALLATION 1. Please make sure that the sensor and magnet is located less than 6 mm (0.25 inch) from each other (Figure 4). For optimal performance, it is highly recommended to install the Door/Window sensor on the fixed frame and the magnet on the moving part of the door/window, rotate if necessary. Place the sensor near the top of the door that close to the opening edge of the door. This is the mounting location for the sensor. 2. Use the provided double-sided tape on the sensor. Attach the sensor to the door/window frame. Press firmly and hold in place for a few seconds (Figure 5). Secure it with silicone if needed. For mounting with screws, please use the screw holes located in the battery compartment. (Figure 5) 3. Spacers are used to raise the level of the magnet to be level/closer to sensor. The spacers are 6.5 mm (¼”) thick. If needed, install spacers as shown in Figure 6. 4. Use provided double-sided tape on the magnet. Make sure the alignment of both sensor and magnet is correct. The magnet aligns from the top of the sensor case near the button and LED (Figure 4). Press firmly and hold in place for a few seconds. If the spacer is used, it can be mounted to the door using screws and/or double-sided tape before attaching the magnet. Secure tape-mounted parts with silicone if needed. Figure 5 Figure 6 Figure 1 Figure 2 CR123 Battery Green Pairing LED Indicator Battery Tab / QR Code 3M double sided Tape 6 mm Figure 4 Magnet Spacer Magnet Figure 3 6 mm Tamper Open Battery Cover Wake Sensor Button 6 mm 3M double sided Tape QR Code DWZB1-CE 1.1 2022-12-22 OPERATION 1.The Green Pairing LED will stay off during the normal operation. 2.The sensor is equipped with a tamper switch. If the cover of sensor is removed, the sensor will send an alarm to the home controller or security system. 3.A separation gap of 32 mm (1.25”) to 50 mm (2”) between the sensor and the magnet will report open/close events to your security system or home controller during normal operation. RESET TO FACTORY DEFAULTS & REBOOT If sensor needs to be factory defaulted (for example, to prepare it for joining with a home controller or security system). 1.Depress the top button for five (5) seconds. The sensor should begin rapidly blinking the LED. 2.After holding the button for five seconds the LED will turn on solid for approximately two (2) seconds to confirm the reset function. Release the Button. The sensor should then leave the current paired network, reset to factory default settings, and begin searching for any available home controller or security system. The LED behavior will match that described in the Pairing section. NOTE: If you need to reboot the device, remove the battery for at least 5 seconds, then re-insert the battery. NOTE: Replace Battery with Panasonic CR123A or Sony CR123A only. Use of another battery may negatively impact the performance of the product. TROUBLESHOOTING If device has trouble with pairing to the home controller or security system: 1.Separate the sensor and magnet or trigger tamper. The sensor will re-attempt to pair. 2.If device continues to have trouble pairing, remove the battery for 5 seconds and then re-insert it. 3.If device continues to have trouble pairing, use “Reset to Factory Defaults” procedure to attempt pairing again. If device was communicating with the home controller or security system but is no longer communicating: 1.Move the device to a location closer to the controller. Separate and close the magnet or trigger tamper from the sensor. If the controller successfully shows the sensor’s status, then install a repeater so the system’s range can reach the desired location for the sensor. 2.If the device has been in use for months or years and the failure is sudden, check the controller to see if the device has a low battery. Follow the instructions provided to replace the battery. FCC COMPLIANCE STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of the FCC Rules. These limits are desi…

Text truncated - open the document above for the full version.

201 E. Sandp ointe Ave, 7 th Floor, Santa Ana, CA 92707, Tel 714 918-9701 CFR 47 §2.911 (d)(7) Agent Designation Attestation Date: 02-07-2023 FCC ID: MG3-DWZB1-CE To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Universal Electronics Inc (MG3) (“the applicant”) as required by section 2.911(d)(7), designates the following agent, located in the United States, for purposes of acting as the applicant’s agent for service of process. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. U. S. Agent Information: Contact Person: Jesse Mendez Company name: Universal Electronics Inc (FRN: 0007413982) Company Address: 201 East Sandpointe Ave 7th Floor, Santa Ana, CA 92707, U.S.A. Email: [email protected] Sincerely yo urs, Jesse Mendez Staff Engineer, Electrical Universal Electronics Inc (MG3)

201 E. Sandpointe Ave, 7 th Floor, Santa Ana, CA 92707, Tel 714 918-9701 CFR 47 §2.911 (d)(5) Attestation Date: 02-20-2023 FCC ID: MG3-DWZB1-CE To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Universal Electronics Inc (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Universal Electronics Inc., (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment and is not an affiliate or subsidiary of an entity identified on the Covered List. Sincerely yours, Jesse Mendez Staff Engineer, Electrical Universal Electronics Inc (MG3)

Hyundai C‐Tech, Inc. dba HCT America, Inc. 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848 || Fax: +1.510.933.8849 Page 1 of 1 12‐22‐2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC Agent Authorization Letter Applicant Universal Electronics Inc Model Name(s) DWZB1‐CE Product Type Door/Window sensor FCC ID MG3‐DWZB1‐CE We, the undersigned, hereby authorize Hyundai C‐Tech, Inc. dba HCT America Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Hyundai C‐Tech, Inc. dba HCT America Inc. on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). We recognize that we are still responsible for the terms and conditions outlined in the HCT America Client Services Agreement. This authorization is valid until further written notice from the applicant. Sincerely, Jesse Mendez Staff Engineer, Electrical Universal Electronics Inc 201 East Sandpointe Ave 7 th Floor Santa Ana, CA 92707, U.S.A. [email protected]

Hyundai C‐Tech, Inc. dba HCT America, Inc. 1726 Ringwood Avenue San Jose, CA 95131 TEL: +1.510.933.8848 || Fax: +1.510.933.8849 Page 1 of 1 12‐22‐2022 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC Request for Confidentiality We hereby request confidential treatment of information accompanying this application as outlined below: Applicant Universal Electronics Inc Model Name(s) DWZB1‐CE Product Type Door/Window sensor FCC ID MG3‐DWZB1‐CE Long‐Term Confidentiality Short‐Term Confidentiality  Block Diagram  Internal Photos  Schematics  External Photos  Operational Description  Test Setup Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. We would like request to hold documents listed under Short‐Term Confidentiality to remain confidential up to 180 days. Sincerely, Jesse Mendez Staff Engineer, Electrical Universal Electronics Inc 201 East Sandpointe Ave 7 th Floor Santa Ana, CA 92707, U.S.A. [email protected]

1 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 APPENDIX B.1 PHOTOGRAPHS OF EUT EXTERNAL PHOTOS Applicant Universal Electronics, Inc. Model Name DWZB1‐CE FCC ID MG3‐DWZB1‐CE IC ID 2575A‐DWZB1CE Reference Test Report No.: HA221109‐UEI‐012‐R04 2 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 Front View Rear View 3 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 Left Side View Right Side View 4 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 Top View Bottom View

FCC ID: MG3-DWZB1-CE IC: 2575A-DWZB1CE Model: DWZB1-ECO FCC / ISED Label Placement on the Ecolink Door/Window Sensor

1 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 APPENDIX B.2 PHOTOGRAPHS OF EUT INTERNAL PHOTOS Applicant Universal Electronics, Inc. Model Name DWZB1‐CE FCC ID MG3‐DWZB1‐CE IC ID 2575A‐DWZB1CE Reference Test Report No.: HA221109‐UEI‐012‐R04 2 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 Internal View 1 Internal View 2 3 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 Upper Board Front View 1 Upper Board Rear View 2 4 / 4 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA. TEL: +1-510-933-8848 FAX: +1-510-933-8849 Bottom Board Front View 1 Bottom Board Rear View 2

RF EXPOSURE REPORT F C C APPLICANT Universal Electronics Inc MODEL NAME DWZB1‐CE FCC ID MG3‐DWZB1‐CE REPORT NUMBER HA221109-UEI-012-R05 Report No.: HA221109-UEI-012-R05 1 / 8 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 T E S T R E P O R T Date of Issue December 2, 2022 Test Site Hyundai C-Tech, Inc. dba HCT America, Inc. 1726 Ringwood Ave, San Jose, CA 95131, USA Applicant Universal Electronics Inc Applicant Address 201 East Sandpointe Ave 7 th Floor, Santa Ana, CA 92707, U.S.A. FCC ID MG3‐DWZB1‐CE Model Name DWZB1‐CE EUT Type Door/Window Sensor FCC Classification Digital Transmission System (DTS) FCC Rule Part(s) Part 1 (§1.1310 / §1.1307), Part 2 (§2.1091) Test Procedure KDB 447498 D01 v06 The device bearing the trade name and model specified above, has been shown to comply with the applicable technical standards as indicated in the measurement report and was in accordance with the procedures specified in §2.947. The results in this report apply only to the product which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Hyundai C-Tech, Inc. dba HCT America, Inc. certifies that no party to application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 862 Tested By Reviewed By Yongsoo Park Sunwoo Kim Test Engineer Technical Manager Report No.: HA221109-UEI-012-R05 2 / 8 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 REVISION HISTORY The revision history for this document is shown in table. TEST REPORT NO. DATE DESCRIPTION HA221020-UEI-010-R05 December 2, 2022 Initial Release Report No.: HA221109-UEI-012-R05 3 / 8 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 TABLE OF CONTENTS 1. EUT DESCRIPTION ............................................................................................................................................ 4 2. INTRODUCTION ................................................................................................................................................ 5 2.1. RF Exposure Exemptions for Single Source .............................................................................................. 5 2.2. RF Exposure Exemptions for Simultaneous Transmission ......................................................................... 6 3. RESULT ............................................................................................................................................................ 7 3.1. SAR-Based Exemptions Calculation ......................................................................................................... 7 3.2. SUMMARY OF RESULTS .......................................................................................................................... 7 Report No.: HA221109-UEI-012-R05 4 / 8 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 1. EUT DESCRIPTION Model DWZB1-CE EUT Type Door/Window Sensor Power Supply 3 V d.c. (1 x CR123A Lithium Battery) RF Specification IEEE 802.15.4 Transmitter Chain 1 Exemption Analysis 1-mW Test Exemptions SAR-Based Test Exemptions MPE-Based Test Exemptions Antenna Specification 1) Antenna Type : Internal wire antenna Antenna Peak Gain : 0.41 dBm Operating Environment Indoor and outdoor Operating Temperature 0 °C ~ +50 °C Report No.: HA221109-UEI-012-R05 5 / 8 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 2. INTRODUCTION 2.1. RF Exposure Exemptions for Single Source (A) 1-mW Blanket Exemption Per § 1.1307(b)(3)(i)(A), a single RF source is exempt RF device if the available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption applies to all operating configurations and exposure conditions, for the frequency range 100 kHz - 100 GHz, regardless of fixed, mobile, or portable device exposure conditions. This is a standalone exemption, and it cannot be applied in conjunction with any other test exemption. (B) SAR-Based Exemption A more comprehensive exemption, considering a variable power threshold that depends on both the separation distance and power, is provided in § 1.1307(b)(3)(i)(B). This exemption is applicable to the frequency range between 300 MHz - 6 GHz, with test separation distances between 0.5 cm and 40 cm, and for all RF sources in fixed, mobile, and portable device exposure conditions. Accordingly, a RF source is considered an RF exempt device if its available maximum time-averaged (matched conducted) power or its effective radiated power (ERP), whichever is greater, are below a specified threshold (P th ). (C) MPE-Based Exemption MPE-ba…

Text truncated - open the document above for the full version.

NOTE:ThisdocumentisissuedbyShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,thetestreportshallnotbereproducedexceptin fullwithoutpriorwrittenpermissionofthecompany.Thetestresultsapplyonlytotheparticularsample(s)testedandtothespecifictestscarried outwhichisavailableonrequestforvalidationandinformationconfirmedatourwebsite. MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page1of 25 REPORTNo.：SZ23020156E01 TESTREPORT APPLICANT:GemstarTechnology(Yangzhou)Co.Ltd PRODUCTNAME: Sensor MODELNAME: EcolinkZigbeeDoorWindowSensor TRADENAME:N/A BRANDNAME:N/A STANDARD(S):IEEEStd149-2021 RECEIPTDATE:2023-02-15 TESTDATE:2023-02-16 ISSUEDATE:2023-02-21 Editedby: FangJinshan(Rapporteur) Approvedby: ChiShide(Supervisor) MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page2of25 REPORTNo.：SZ23020156E01 DIRECTORY 1.TechnicalInformation ........................................................................................................3 1.1.ApplicantandManufacturerInformation ....................................................................3 1.2.EquipmentUnderTest(EUT)Description...................................................................3 2.TestResults........................................................................................................................4 2.1.AppliedReferenceDocuments.....................................................................................4 2.2.TestConditions...............................................................................................................4 2.3.MeasurementUncertainty.............................................................................................4 2.4.TestResultslists.............................................................................................................5 AnnexATestSetupPhotos..................................................................................................6 AnnexBFigures .....................................................................................................................7 1.2DRadiationPattern .........................................................................................................7 2.3DRadiationPattern .......................................................................................................12 AnnexCEUTPhotos ...........................................................................................................15 AnnexDGeneralInformation .............................................................................................25 1.1IdentificationoftheResponsibleTestingLaboratory..............................................25 1.2IdentificationoftheResponsibleTestingLocation..................................................25 1.3TestEquipmentsUtilized..............................................................................................25 ChangeHistory VersionDateReasonforchange 1.02023-02-21Firstedition MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page3of25 REPORTNo.：SZ23020156E01 1.TechnicalInformation Note:ProvidebyApplicant. 1.1.ApplicantandManufacturerInformation Applicant: GemstarTechnology(Yangzhou)Co.Ltd ApplicantAddress: Room606,Guofabuilding,#3110RenminRoad, Suzhou,JiangsuProvince,China Manufacturer:N/A ManufacturerAddress:N/A 1.2.EquipmentUnderTest(EUT)Description WirelessType Zigbee Frequency 2405MHz-2480MHz IMEI N/A SampleNo. 1#&2# MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page4of25 REPORTNo.：SZ23020156E01 2.TestResults 2.1.AppliedReferenceDocuments Leadingreferencedocumentsfortesting: No.IdentityDocumentTitle 1IEEEStd149-2021 IEEERecommendedPracticeforAntenna Measurements 2.2.TestConditions TestEnvironmentConditions ： RelativeHumidity:25...75% Temperature:+10°Cto+30°C 2.3.MeasurementUncertainty Theuncertaintyiscalculatedusingthemethodssuggestedinthe"GuidetotheExpressionof UncertaintyinMeasurement"(GUM)publishedbyISO.Whenthetestresultisacriticalvalue,we willusethemeasurementuncertaintygivethejudgmentresultbasedonthe95%Confidence intervals. ItemMeasurementUncertainty(dB) Gain±0.5 VSWR±0.2 MeasurementUncertainty(95%ConfidenceInterval)K=2 MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page5of25 REPORTNo.：SZ23020156E01 2.4.TestResultslists 2.4.1.GainandEfficiency Frequency (MHz) Gain(dBi)Efficiency(%)Efficiency(dB) 1#2#1#2#1#2# 24000.270.3741.5843.10-3.81-3.66 24050.280.4141.3843.17-3.83-3.65 24100.060.2240.0342.08-3.98-3.76 2420-0.200.0238.1840.71-4.18-3.90 2430-0.44-0.1936.2439.03-4.41-4.09 2440-0.51-0.2435.8738.84-4.45-4.11 2450-0.56-0.2335.6838.65-4.48-4.13 2460-0.65-0.4034.9037.68-4.57-4.24 2470-0.80-0.6133.4735.92-4.75-4.45 2480-1.15-1.0831.8433.76-4.97-4.72 2490-1.47-1.4630.6232.00-5.14-4.95 2500-1.63-1.6630.5731.55-5.15-5.01 MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page6of25 REPORTNo.：…

Text truncated - open the document above for the full version.

RF TEST REPORT FCC / ISED APPLICANT Universal Electronics Inc. MODEL NAME DWZB1‐CE FCC ID MG3‐DWZB1‐CE ISED ID 2575A‐DWZB1CE REPORT NUMBER HA221109‐UEI‐012‐R04 Report No.: HA221109-UEI-012-R04 1 / 41 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 TEST REPORT Date of Issue December 2, 2022 Te s t S ite Hyundai C- Tech, Inc. dba HCT America, Inc. 1726 Ringwood Ave, San Jose, CA 95131, USA Applicant Universal Electronics Inc. Applicant Address 201 East Sandpointe Ave 7 th Floor, Santa Ana, CA 92707, U.S.A. FCC ID MG3-DWZB1-CE ISED ID 2575A-DWZB1CE Model Name DWZB1-CE EUT Type Door/Window Sensor Modulation Type OQPSK FCC Classification Digital Transmission System (DTS) FCC Rule Part(s) Part 15.247 ISED Rule Part(s) RSS-247 Issue 2 (February 2017), RSS-Gen Issue 5 (March 2019) Te s t Procedure ANSI C63.10-2013, KDB 558074 D01 v05r02 The device bearing the trade name and model specified above, has been shown to comply with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures required. The results of testing in this report apply only to the product which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Hyundai C-Tech, Inc. dba HCT America, Inc. certifies that no party to application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C 862 Tested By Reviewed By Yo n g s o o Park Sunwoo Kim Test Engineer Technical Manager Report No.: HA221109-UEI-012-R04 2 / 41 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 REVISION HISTORY The revision history for this document is shown in table. TEST REPORT NO. DATE DESCRIPTION HA221109-UEI-012-R04 December 2, 2022 Initial Release Report No.: HA221109-UEI-012-R04 3 / 41 This document may not be copied or reproduced (reprinted) without written consent by Hyundai C-Tech, Inc. dba HCT America, Inc. Hyundai C-Tech, Inc. dba HCT America, Inc., 1726 Ringwood Avenue, San Jose, CA 95131, USA TEL: +1-510-933-8848 FAX: +1-510-933-8849 TABLE OF CONTENTS 1. GENERAL INFORMATION .................................................................................................................................. 4 2. METHODOLOGY ............................................................................................................................................... 6 3. INSTRUMENT CALIBRATION .............................................................................................................................. 6 4. FACILITIES AND ACCREDITATIONS ...................................................................................................................... 7 5. ANTENNA REQUIREMENTS ............................................................................................................................... 8 6. MEASUREMENT UNCERTAINTY ......................................................................................................................... 9 7. DESCRIPTION OF TESTS ................................................................................................................................... 10 8. SUMMARY OF TEST RES ULTS ........................................................................................................................... 22 9. TEST RESULT ................................................................................................................................................... 24 9.1. 6 dB BANDWIDTH / 99% BANDWIDTH MEASUREMENT.......................................................................... 24 9.2. OUTPUT POWER .................................................................................................................…

Text truncated - open the document above for the full version.
