MG3-H74470Comcast Xfinity Home Motion Sensor ZB3.0 2020

Universal Electronics Inc

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Mar 26, 2020
Application Purpose: Original Equipment
Date of Application: Mar 26, 2020
Equipment Note: Comcast Xfinity Home Motion Sensor ZB3.0 2020
Frequency Range: 2405.00000000 - 2475.00000000
Company: Universal Electronics Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

UEHM2AZ0 ZigBee 3.0 Wireless Digital Pet Resistant PIR Detector XFINITY HOME Installation Instructions 1. INTRODUCTION The UEHM2AZ0 pet resistant detector is a microprocessor-controlled wireless digital PIR detector supported by ZigBee 3.0. The detector’s features are as follows: A. Red LED B. Green LED C. Tamper Switch Figure 1 – UEHM2AZ0 2. SPECIFICATIONS Detector Type: Two - Dual element low-noise pyroelectric sensor Optical Data: 18 parabolic mirrors for long range 18 parabolic mirrors for close range Max. Coverage: 15 x 15 m, (49.2 x 49.2 ft) / 90° Pet Immunity: Up to 38 kg (85 lb). Not evaluated by UL. Control Panel Compatibility: Series TCA-203 and TCA-300 ELECTRICAL Internal Batteries: Two 3V Lithium batteries, type CR-123A. For UL installations, use Panasonic only Nominal Battery Capacity: 1400 mAh per battery Battery Power Test: Performed immediately upon battery insertion and during each transmission to the panel FUNCTIONAL Alarm Period: 3 seconds Visual Indications: Red LED lights for about 3 seconds upon transmission of alarm & tamper messages and upon motion detection in the walk test mode only (walk test mode available for approx. 15 minutes). Red LED flashes during the power-up stabilization period, or after restoring (pressing) the tamper switch (power-up stabilization period is approx. 1 minutes). LED does not light upon transmissions of supervision messages or alarm detection after termination of walk test mode. Rearm Timer: Rearms the detector 2 minutes after the last alarm. Timer disabled in the walk test mode. WIRELESS Supported Network: ZigBee 3.0 Frequency: 2.405 – 2.480 Ghz as per IEEE 802.15.4 Tamper Alert: Reported when a tamper event occurs and in any subsequent message, until the tamper switch is restored MOUNTING Height: 1.8-2.4 m (6 - 8 ft). For pet rejection, the optimal height is 2.1 m (7 ft) Installation Options: Surface or corner ENVIRONMENTAL Operating Temperatures -10 ̊ C to 55 ̊ C (14 ̊ F to 131 ̊ F) Storage Temperatures -20 ̊ C to 65 ̊ C (-4 ̊ F to 149 ̊ F) COMPLIANCE WITH STANDARDS USA CFR 47 part 15, ANSI/UL 639 PHYSICAL Size (H x W x D) 83 x 61 x 42 mm (3.27 x 2.4 x 1.66”) Weight (with battery) 90 g (3.17 oz) Color White 4. TROUBLESHOOTING If you encounter one of the following problems with the UEHM2AZ0, use the following solutions to resolve the problem: Problem Solution Attempt to pair the sensor is unsuccessful. Reset the detector to default mode and then set to pairing mode (see section 3.5). The sensor and the Touchscreen (control panel) Perform the signal strength testing procedure do not communicate. described in the control panel installation manual. Make sure that the signal is sufficient. If necessary, replace the sensor’s battery. The sensor sends a Low Battery indication. To ensure continuous proper operation, replace the battery within two weeks of the first Low Battery indication. Panel does not arm because of an unrecognized Consult with your installer or system provider before sensor malfunction. you disable a zone. Disable the sensor zone (see the control panel user manual). Note that disabling a sensor zone lowers the overall security level of your system. 5. SPECIAL COMMENTS Even the most sophisticated detectors can sometimes be defeated or may fail to warn due to: DC power failure / improper connection, malicious masking of the lens, tampering with the optical system, decreased sensitivity in ambient temperatures close to that of the human body and unexpected failure of a component part. The above list includes the most common reasons for failure to detect intrusion, but is by no means comprehensive. It is therefore recommended that the detector and the entire alarm system be checked weekly, to ensure proper performance. An alarm system should not be regarded as a substitute for insurance. Home and property owners or renters should be prudent enough to continue insuring their lives and property, even though they are protected by an alarm system. 6. COMPLIANCE WITH STANDARDS FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. To satisfy RF exposure requirements, this device and its antenna must operate with a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. ETL Statement: This device conforms to ANSI/UL STD 639 Installation shall be done in accordance with the Standard for Installation and Classification of Burglar and Holdup Alarm Systems, UL 681. 4 MUG-UEHM2AZ0-GTY_A 01/20/2020MUG-UEHM2AZ0-…

Text truncated - open the document above for the full version.

Attestation Statements

201 East Sandpointe Ave, 7 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 January 29, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Gentlemen: This is a letter of authorization to accept that any personnel of Compatible Electronics, Inc.act as an Agent for Universal Electronics, 201 East Sandpointe Ave, 7 th Floor, Santa Ana CA 92707. For a period of one year, any Compatible personnel may do the following: sign applications before the certification body on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the certification body in connection with certification of the following Universal Electronics products. Name of Product: Product name: Comcast Xfinity Home Motion Sensor ZB3.0 2020 Part Number: H74470BA00-00004 FCC ID: MG3-H74470 Under FCC Docket Number 20780 and General Docket Number 80-284 pursuant to Part 15 of the FCC Rules and Regulations. Please also accept this letter as an attestation that neither Universal Electronics nor any of its officers, directors, or persons holding 5% or more of the outstanding stock or shares, voting or non- voting, have been denied federal benefits under section 5301 of the Anti-Drug Abuse act of 1988, 21 U.S.C. 853(a). In addition, Universal Electronics will notify the Federal Communications Commission if, at any time, the situation changes causing Universal Electronics to be denied federal benefits. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9701 Sincerely, Jesse Mendez Staff Engineer, Electrical

Attestation Statements

201 East Sandpointe Ave, 7 th Floor, Santa Ana, CA 92707, Tel: 714 918-9500 January 29, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: TCB application submittal Gentlemen: We, Universal Electronics, would like to declare that the application being submitted for the device with FCC ID: MG3-H74470 has not been submitted to another TCB or FCC for certification. If you have any further questions or need additional information, please feel free to give me a call at 714 918-9701 Sincerely, Jesse Mendez Staff Engineer, Electrical

Cover Letter(s)

201 East Sandpointe Ave, 7 th Floor, Santa Ana, CA 92707 Tel: 714 918-9500 January 29, 2020 Compatible Electronics TCB 114 Olinda Drive Brea, California 92823 Subject: Request for withholding from public disclosure the schematic diagrams, block diagrams, and operational description pursuant to an application for certification for the following universal remote control: Product name: Comcast Xfinity Home Motion Sensor ZB3.0 2020 Part number: H74470BA00-00004 FCC ID: MG3-H74470 Gentlemen: We, Universal Electronics, Inc., would like to request that all schematics, block diagrams, and operational descriptions submitted with our application for certification be withheld from public disclosure per Section 0.459 of the FCC rules. This request is made under the provisions of Section 0.457 (d) of the Commissions rules, and Section 552 (b)(4) of the Freedom of Information Act. These sections authorize the withholding from public inspection, those materials which would be privileged as matter of law if retained by the person submitting them, and materials which would not customarily be released to the public by that person. If you have any further questions or need additional information, please contact the undersigned at (714) 918-9701 Regards, Jesse Mendez, Staff Engineer, Electrical

RF Exposure Info

= where: S = transmitter operating variables: must be blank if dB values are entered P = = 16.634 (dBm) - or - (mW) 7 G = = -1.6 (dBi) - or - (numeric gain) R = = (cm) ( PG)/(4*R 2 *  ) = (mW/cm 2 ) 46.06806808 0.69183 20 (mw) (gain) (cm) ()/(4**  3 ) = (mW/cm 2 ) ()/( ) = (mW/cm 2 ) S S ( P G ) / ( 4 R 2  ) power input to the antenna --------------------------------- >> gain of the antenna - worst case -------------------------- >> 2 *  / POWER DENSITY ESTIMATIONS BASED ON POWER OUTPUT, ANTENNA GAIN, AND DISTANCE FROM ANTENNA maximum power density (mW/cm 2 ) (mW/cm 2 ) ) = distance to the center of the radiation of the antenna -- >> 3.1 20 ( ( SS 31.87131627 ) 400 5026.548246 31.87131627 0.006341 4*

Test Report

Report Number: B90822D1 FCC Part 15 Subpart B and C; RSS-247 & RSS-GEN Test Report Comcast Xfinity Home Motion Sensor ZB3.0 2020 Model Number: UEHM2AZ0 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 21 FCC PART 15, SUBPART B and C; RSS-247, RSS-GEN TEST REPORT for COMCAST XFINITY HOME MOTION SENSOR ZB3.0 2020 MODEL NUMBER: UEHM2AZ0 UEI PART NUMBER: H74470BA00-00004 Prepared for UNIVERSAL ELECTRONICS INC. 201 E. SANDPOINTE AVE, 8 TH FLOOR SANTA ANA, CALIFORNIA 92707 Prepared by:_____________________ HARVEY SAMACO Approved by:____________________ KYLE FUJIMOTO COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: SEPTEMBER 18, 2019 REPORT APPENDICES TOTAL BODY A B C D E PAGES 21 2 2 2 11 104 142 This report shall not be reproduced, except in full, without the written approval of Compatible Electronics. Report Number: B90822D1 FCC Part 15 Subpart B and C; RSS-247 & RSS-GEN Test Report Comcast Xfinity Home Motion Sensor ZB3.0 2020 Model Number: UEHM2AZ0 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 21 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 5 1. PURPOSE 6 2. ADMINISTRATIVE DATA 7 2.1 Location of Testing 7 2.2 Traceability Statement 7 2.3 Cognizant Personnel 7 2.4 Date Test Sample was Received 7 2.5 Disposition of the Test Sample 7 2.6 Abbreviations and Acronyms 7 3. APPLICABLE DOCUMENTS 8 4. DESCRIPTION OF TEST CONFIGURATION 9 4.1 Description of Test Configuration – Emissions 9 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 Emissions Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 6.3 Measurement Uncertainty 12 7. CHARACTERISTICS OF THE TRANSMITTER 13 7.1 Channel Description and Frequencies 13 8. TEST PROCEDURES 14 8.1 RF Emissions 14 8.1.1 Conducted Emissions Test 14 8.1.2 Radiated Emissions (Spurious and Harmonics) Test 15 8.1.3 RF Emissions Test Results 16 8.1.4 Sample Calculations 17 8.2 DTS Bandwidth 18 8.3 Maximum Conducted Output Power 18 8.4 Emissions in Non-Restricted Bands 19 8.5 RF Band Edges 19 8.6 Spectral Density Test 20 8.7 Variation of the Input Power 20 9. CONCLUSIONS 21 Report Number: B90822D1 FCC Part 15 Subpart B and C; RSS-247 & RSS-GEN Test Report Comcast Xfinity Home Motion Sensor ZB3.0 2020 Model Number: UEHM2AZ0 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 21 LIST OF APPENDICES APPENDIX TITLE A Laboratory Accreditations and Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated and Conducted Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Layout of the Semi-Anechoic Test Chamber 2 Conducted Emissions Test Setup LIST OF TABLES TABLE TITLE 1 Radiated Emissions Test Results (Monopole Antenna) 2 Radiated Emissions Test Results (PIFA Antenna) Report Number: B90822D1 FCC Part 15 Subpart B and C; RSS-247 & RSS-GEN Test Report Comcast Xfinity Home Motion Sensor ZB3.0 2020 Model Number: UEHM2AZ0 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 21 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product certification, approval or endorsement by NVLAP, NIST or any agency of the federal government. Device Tested: Comcast Xfinity Home Motion Sensor ZB3.0 2020 Model Number: UEHM2AZ0 UEI Part number: H74470BA00-00004 Product Description: See Expository Statement. Modifications: The EUT was not modified during the testing. Customer: Universal Electronics, Inc. 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 Test Dates: August 20-23, 2019 Test Specifications covered by accreditation: Emissions requirements CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.207, 15.209, and 15.247; RSS-247 Issue 2 (2017) and RSS-Gen Issue 5 (2018) Test Procedure: ANSI C63.4 and ANSI C63.10 Report Number: B90822D1 FCC Part 15 Subpart B and C; RSS-247 & RSS-GEN Test Report Comcast Xfinity Home Motion Sensor ZB3.0 2020 Model Number: UEHM2AZ0 Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Newbury Park Division 1050 Lawrence Drive Newbury Park, CA 91320 (805) 480-4044 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 21 SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz This test was not performed because the EUT is battery powered only. 2 Spurious Radiated RF Emissions, 30 MHz – 1000 MHz The EUT complies with the Class B limits of CFR Title 47, Part 15 Subpart B; the limits of CFR Title 47, Part 15, Subpart C, section 15.209 and 15.247 Highes…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Jesse Mendez(Staff Engineer Electrical)

[email protected]714-918-9701Fax: 714-918-4100

Technical Contact

Compatible Electronics, Inc.Kyle Fujimoto

[email protected]714-579-0500

114 Olinda Drive · Brea, California · United States

Test Firm

Compatible Electronics, Inc.Michael Christensen

[email protected]714-579-0500Fax: 714-579-1850

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	46.07 mW

Confidentiality

Long Term

Grant Notes

Output power is conducted. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions and instructions for satisfying RF exposure compliance.
