MG3-YD003TV Remote Controller RMF-YD003

Sony Remote Control Quick Reference Guide CONTROLLING YOUR TV 1. Press Power key to turn on the TV. 2. Press any key other than power key to initiate pairing with TV. 3. All paring transaction is behind the scene and no setup is required. Touchpad Area 1. Touch “keypad” area by finger and move it around to navigate GUI interactively 2. Pressing “keypad” area act as “Select” function COMPLIANCE WITH FCC RULES AND REGULATIONS This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, the user is encouraged to try to correct the interference by one or more of the following measures: • Increase or decrease the separation between the equipment and receiver.  Consult the dealer or an experienced remote control/ TV technician for help. This equipment has been verified to comply with the limits for a Class B computing device, pursuant to FCC Rules. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user's authority to operate this equipment. FCC Authorization Label This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2 This device must accept any interference received, including interference that may cause undesired operation. Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. 安全注意事項 根據NCC低功率電波輻射性電機管理辦法 規定: 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或 變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善 至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 ‘La operación de este equipo está sujeta a las siguientes dos condiciones” 1. Es posible que este equipo o dispositivo no cause interferencia perjudicial 2. Este equipo o dispositivo debe aceptar cualquier interferencia. Incluyendo la que pueda causar su operación no deseada.’ ‘Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em caráter primário.’

Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100 Letter of Agency 24.06.2013 TRaC Global Ltd. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK To Whom It May Concern: We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse ACT of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application, is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to this matter. Yours faithfully Universal Electronics Jesse Mendez Staff Engineer, Electrical

Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100 REQUEST FOR CONFIDENTIALITY IN ACCORDANCE WITH FCC RULE 0.459 Date TRaC GLOBAL LTD. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK RE: Certification Application FCC ID: MG3-YD003 To Whom It May Concern: Please be advised that the following information is to be held confidential on behalf of Applicants Name Here.  BOM  Schematics  Techincal Desciption  Block Diagram The application contains technical information which Applicants Name Here deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Jesse Mendez Staff Engineer, Electrical Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100

Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100 Pseudo-random hopping sequence Declaration Date 25/06/2013 TRaC GLOBAL LIMITED 100 FROBISHER BUSINESS PARK MALVERN WORCESTERSHIRE WR14 1BX UK RE: Hopping Decleration FCC ID: MG3-YD003 Hopping Algorithm: All channels are 1 MHz apart and hop through the channels using a pseudo-random hopping sequence. The device hops from channel to channel at a rate of 1600 hops per second. The radio is completely controlled by the associated software stack and application program. The stack controls the hopping sequence, and protocols for establishing a connection with other Bluetooth devices in the near vicinity. Thank you for your attention to this matter. Yours faithfully Universal electronics Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100 Jesse Mendez Staff Engineer, Electrical

Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100 07/08/213 TRaC GLOBAL LTD. 100 Frobisher Business Park Malvern Worcestershire WR14 1BX UK RE: Product Name declaration FCC ID: MG3-YD003 IC ID: 2757A-YD003 To Whom It May Concern: Please be advised that the product name for FCC ID: MG3-YD003 and IC ID: 2757A-YD003 has being altered from “JPN SONY PEACE NFC\CAP REMOTE 2013” to “TV REMOTE CONTROLLER”. Thank you for your attention to this matter. Yours truly, Jesse Mendez Staff Engineer, Electical Universal Electronics 201 E. Sandpointe Ave., 8 th Floor, Santa Ana, CA 927707 [email protected] T: 714.918.9701 Universal Electronics, 201 E. Sandpointe Ave, 8 th Floor Santa Ana, CA 92707 714 918-9500, Fax 714 918-4100

Model : RMF-TP100U RMF-TP100J RMF-TP100C Model : RMF-TP100E Touch Pad Remote Control Touch Pad Remote Control Modelo :RMF-TP100U COFETEL:XXXXXXXXXXXX XXXX-XX-XXXX (01)XXXXXXXXXXXXXXX XXXXX/SDPPI/201X REGISTERED No:XXxxxxxxx/xx DEALER No:XXxxxxxxx/xx XXX-XXXXXXX XXXXXXXXXX RMF-TP100T XXXXXXXXXXX

Radio Test Report for Universal Electronics on TV REMOTE CONTROLLER Document No: TRA-014307-00-47-00-A Total number of pages: 79 TRaC Wireless Test Report : TRA-014307-00-47-00-A Applicant : Universal Electronics Apparatus : TV REMOTE CONTROLLER Specification(s) : CFR47 Part 15.247 & RSS-210 Annex 8 FCCID : MG3-YD003 Unique Product Number : 2575A-YD003 Purpose of Test : Certification Authorised by : (Radio Product Manager) Issue Date : 7 th August 2013 Authorised Copy Number : PDF TRaC Global Test Report: TRA-014307-00-47-00-A 3 Contents Section 1: Introduction 4 1.1 General 4 1.2 Tests Requested By 5 1.3 Manufacturer 5 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Notes relating to the assessment 7 1.7 Deviations from Test Standards 8 Section 2: Measurement Uncertainty 9 2.1 Measurement Uncertainty Values 9 Section 3: Modifications 11 3.1 Modifications Performed During Assessment 11 Appendix A: Formal Emission Test Results 12 A1 Transmitter Peak Output Power 13 A2 Conducted Spurious Emissions 14 A3 Radiated Emissions 18 A4 20dB Bandwidth and Channel Separation 26 A5 Hopping frequencies 27 A6 Channel Occupancy 28 A7 Antenna Gain 29 A8 Unintentional Radiated Emissions 30 Appendix B: Supporting Graphical Data 33 Appendix C: Additional Test and Sample Details 67 C1 Test samples 68 C2 EUT operating mode during testing 69 C3 EUT Configuration Information 70 C4 List of EUT Ports 71 C5 Details of Equipment Used 72 Appendix D: Additional Information 73 Appendix E: Calculation of the duty cycle correction factor 74 Appendix F: Photographs and Figures 75 Appendix G: MPE Calculation 78 TRaC Global Test Report: TRA-014307-00-47-00-A 4 Section 1: Introduction 1.1 General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed by: TRaC Global [ ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Global [X] Unit 1 Pendle Place Skelmersdale West Lancashire, WN8 9PN United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: Daniel Winstanley Author(s): Daniel Winstanley This report must not be reproduced except in full without prior written permission from TRaC Global Ltd. TRaC Global Test Report: TRA-014307-00-47-00-A 5 1.2 Tests Requested By All testing in this report was requested by: Universal Electronics 201 E. Sandpointe Ave 8th Floor Santa Ana CA 92707 USA 1.3 Manufacturer Gemstar Technology (China) Co., Ltd. Gemstar Industrial Park, 45# Shiguang Road, Zhong’er Village, Zhongcun Town, Panyu District Guangzhou City, Guangdong Province 511495, P.R China 1.4 Apparatus Assessed The following products were assessed between 23 rd – 29 th July 2013 TV REMOTE CONTROLLER. Model Number: RMF-YD003 The above equipment is a FHSS transmitter operating in the 2400 MHz to 2483.5 MHz band. TRaC Global Test Report: TRA-014307-00-47-00-A 6 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type Regulation Measurement standard Result Title 47 of the CFR: Part 15 Subpart (c) RSS-210 Issue 8 December 2012 Radiated spurious emissions (Restricted bands) 15.247 Annex 8 A8.5 ANSI C63.10:2009 Pass Conducted spurious emissions (Non-restricted bands) 15.247 Annex 8 A8.5 ANSI C63.10:2009 Pass AC Power conducted emissions 15.207 RSS-Gen Section 7.2.2 ANSI C63.10:2009 N/A Note 1 20dB Bandwidth and Channel Spacing 15.247(a)(1)(i) Annex 8 A8.1(b) ANSI C63.10:2009 Pass Conducted Carrier Power 15.247(b)(2) Annex 8 A8.4(2) ANSI C63.10:2009 Pass Hopping Frequencies 15.247(a)(1) Annex 8 A8.1(d) ANSI C63.10:2009 Pass Channel Occupancy 15.247(a)(1)(i) Annex 8 A8.1(d) ANSI C63.10:2009 Pass Unintentional Radiated Spurious Emissions 15.109 RSS-Gen Section 7.2.3 ANSI C63.10:2009 Pass Note 1: The TV REMOTE CONTROLLER is a battery power device. Abbreviations used in the above table: ANSI C 63.10:2009 is outside the scope of the laboratories UKAS accreditation. Mod : Modification RSS Radio Standards Specification CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions TRaC Global Test Report: TRA-014307-00-47-00-A 7 1.6 Notes relating to the assessment With regard to this assessment, the following points should be noted: The results contained in this report relate only to the items tested and were obtained in the period between the date of initial receipt of samples and the date of issue of the report. The apparatus was set up and exercised using the configurations, modes of operation and arrangements defined in this report only. Particular operating modes, apparatus monitoring methods and performance criteria required by the standards tested to have been performed except where identified in Section 1.7 of this test report (Deviations from Test Standards). For emissions testing, throughout this test report, “Pass” indicates that the results for the sample as tested were below the specified limit (refer also to Section 2, Measurement Uncertainty). Where relevant, the apparatus was only assessed using the monitoring methods and susceptibility criteria defined in this report. All testing with the exception of testing at the Open Area Test Site was performed under the following environmental conditions: Temperature : 20 to 23 °C Humidity : 45 to 75 % All dates used in this report are in the format dd/mm/yy. This assessment has been performed in accor…
