Mr. Fujimoto: In order for processing of this application (FCC ID: MG32481) to continue, the following issue(s) will have to be addressed: 1) The test data uses a duty cycle correction factor to determine the average reading, however, this is only permitted for transmitters that use pulsed modulation and the operational description only mentions FSK modulation as being used. Please provide data that is averaged by using the appropriate averaging method since FSK modulation is being used or please explain why the use of this duty cycle correction factor is being used. 2) The test report mentions that the antenna is hardwired, however, photos show a PCB trace style antenna. Please clarify the antenna type. 3) The “Instruction to the User” statement that is required in the owner’s manual is missing the statement “which can be verified by turning the equipment off and on”. Please submit a corrected owner’s manual with the corrected “Instruction to the User” statement. 4) The file for the internal photos is too large. Please reduce the size of the file to less than 3 Mb and re-submit. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is MG32481 -1.

Correspondence by Project Project Number: Correspondence Number Memo MG32481 -1 1) The test data uses a duty cycle correction factor to determine the average reading, however, this is only permitted for transmitters that use pulsed modulation and the operational description only mentions FSK modulation as being used. Please provide data that is averaged by using the appropriate averaging method since FSK modulation is being used or please explain why the use of this duty cycle correction factor is being used. Response: The modulation is both FSK AND Pulse modulation, thus a duty cycle correction factor is required. 2) The test report mentions that the antenna is hardwired, however, photos show a PCB trace style antenna. Please clarify the antenna type. Response: The test report has been revised to show that it is a PCB trace style antenna. 3) The “Instruction to the User” statement that is required in the owner’s manual is missing the statement “which can be verified by turning the equipment off and on”. Please submit a corrected owner’s manual with the corrected “Instruction to the User” statement. Response: The remote control RF Tx and uC clock turn off automatically if there is no key press. This is essentially the equivalent of turning the remote on/off to determine if it is causing harmful interference. In short, the turning on/off is a normal operational function of the remote when a customer presses and releases keys. This is why this statement was not included. 4) The file for the internal photos is too large. Please reduce the size of the file to less than 3 Mb and re-submit. Response: The Internal Photos have been split up so 307582602 that each file is less than 3 MB.

Report Number: B60503D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report DirecTV RC32RF Model: URC-2481RG0-X Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 16 FCC PART 15, SUBPART B and C TEST REPORT for DIRECTV RC32RF MODEL: URC-2481RG0-X Prepared for UNIVERSAL ELECTRONICS, INC. 6101 GATEWAY DRIVE CYPRESS, CALIFORNIA 90630-4841 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: JUNE 1, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 16 2 2 2 12 11 45 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60503D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report DirecTV RC32RF Model: URC-2481RG0-X Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 16 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 Radiated Emissions (Spurious and Harmonics) Test 13 7.2 Radiated Emissions (Spurious and Harmonics) Test (continued) 14 7.3 Bandwidth of the Fundamental 15 8. CONCLUSIONS 16 Report Number: B60503D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report DirecTV RC32RF Model: URC-2481RG0-X Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 16 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Plot Map And Layout of Radiated Site Report Number: B60503D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report DirecTV RC32RF Model: URC-2481RG0-X Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 16 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: DirecTV RC32RF Model: URC-2481RG0-X S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Manufacturer: Universal Electronics, Inc. 6101 Gateway Drive Cypress, California 90630-4841 Test Date: May 3, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.231 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz - 30 MHz This test was not performed because the EUT is battery powered only and does not connect to the AC public mains. 2 Radiated RF Emissions, 10 kHz - 4400 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B60503D1 FCC Part 15 Subpart B and FCC Section 15.231 Test Report DirecTV RC32RF Model: URC-2481RG0-X Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 16 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the DirecTV RC32RF Model: URC-2481RG0-X. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the Class B specification limits defined by CFR Title 47, Part 15, Subpart B; and Subpart C, sections 15.205, 15.209, and 15.231. Report Number: B60503D1 FCC Part 15 Subpart B and FCC…

Text truncated - open the document above for the full version.

Ref Lvl 92 dB
V Ref Lvl 92 dB
V RF Att 10 dB A Unit dB
V P0 TDS SWT 150 ms Center 433.9500601 MHz15 ms/ RBW 100 kHz VBW 100 kHz IN1 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] -0.53 dB 72.444890 ms 1 [T1] 19.03 dB
V 10.821643 ms 1 [T1] -0.53 dB 72.444890 ms D1 54 dB
V Date: 3.MAY.2006 09:55:02 Total Time of Pulse Train with Blanking Interval = 72.444890 mS Ref Lvl 92 dB
V Ref Lvl 92 dB
V RF Att 10 dB A Unit dB
V P0 TDS SWT 150 ms Center 433.9500601 MHz15 ms/ RBW 100 kHz VBW 100 kHz IN1 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] -0.92 dB 45.090135 ms 1 [T1] 18.50 dB
V 83.266533 ms 1 [T1] -0.92 dB 45.090135 ms D1 54 dB
V Date: 3.MAY.2006 09:55:59 Total Time of Pulse Train = 45.090135 mS Total Time at 0% = 27.354755 mS Ref Lvl 92 dB
V Ref Lvl 92 dB
V RF Att 10 dB A Unit dB
V RBW 100 kHz VBW 100 kHz IN1 SWT 60 ms Center 433.9500601 MHz6ms/ P0 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] 13.34 dB 3.126253 ms 1 [T1] 48.16 dB
V 12.144289 ms 1 [T1] 13.34 dB 3.126253 ms D1 54 dB
V Date: 3.MAY.2006 09:56:54 Total Time of the Large Pulse = 3.126253 mS Ref Lvl 92 dB
V Ref Lvl 92 dB
V RF Att 10 dB A Unit dB
V RBW 100 kHz VBW 100 kHz IN1 SWT 60 ms Center 433.9500601 MHz6ms/ P0 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] 5.25 dB 841.683367
s 1 [T1] 50.19 dB
V 50.621242 ms 1 [T1] 5.25 dB 841.683367
s D1 54 dB
V Date: 3.MAY.2006 09:57:47 Total Time of the One Small Pulse = 841.683367 uS Ref Lvl 92 dB
V Ref Lvl 92 dB
V RF Att 10 dB A Unit dB
V RBW 100 kHz VBW 100 kHz IN1 SWT 60 ms Center 433.9500601 MHz6ms/ P0 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] -6.67 dB -1.442886 ms 1 [T1] 56.96 dB
V 35.230461 ms 1 [T1] -6.67 dB -1.442886 ms D1 54 dB
V Date: 3.MAY.2006 09:58:20 Total Time of the One Medium Pulse = 1.442886 mS Ref Lvl 92 dB
V Ref Lvl 92 dB
V RF Att 10 dB A Unit dB
V RBW 100 kHz VBW 100 kHz IN1 SWT 60 ms Center 433.9500601 MHz6ms/ P0 TDS 1VIEW1AP 0 10 20 30 40 50 60 70 80 -8 92 1 1 Delta 1 [T1] 25.53 dB 2.044088 ms 1 [T1] 48.22 dB
V 12.024048 ms 1 [T1] 25.53 dB 2.044088 ms D1 54 dB
V Date: 3.MAY.2006 10:01:29 Delta Between Maximum and Minimum Amplitude = 25.53 dB Total Number of Large Pulses = 1 * 3.126253 mS = 3.126253 mS Total Number of Small Pulses = 12 * 841.683367 uS = 10.1002004 mS Total Number of Medium Pulses = 9 * 1.442886 mS = 12.9859764 mS Total Time at 100% Amplitude = 26.2124298 mS Total Time of Minimum Amplitude = 18.8777052 mS Amplitude difference between 100% and Minimum Amplitude = 25.53 dB Effective On Time of Minimum Amplitude Portion = 998.73254 uS Total Duty Cycle = 27.21116234 ms / 72.444890 ms = 37.5611894 %
