MG3SC-H1WSirius Conductor Radio

1 SIRIUS CONDUCTOR User Guide 5V DC ANT RESET SECO ND TUNER SIRIUSRadio.book Page 1 Tuesday, November 21, 2006 5:15 PM SIRIUS Conductor Satellite Radio User Guide © 2006 SIRIUS Satellite Radio Inc. SC-H1W ® "SIRIUS" and the SIRIUS dog logo are registered trademarks of Sirius Satellite Radio Inc. SIRIUSRadio.book Page 2 Tuesday, November 21, 2006 5:15 PM SIRIUS Satellite Radio User Guide Table of Contents SIRIUS CONDUCTOR Installation Guide . . . . . . . . . . . . . . . . . . . 1 SIRIUS Satellite Radio: The Best Radio On Radio..........................1 Package Contents ............................................................... 2 Installation ........................................................................... 4 Mounting the Sirius Conductor Tuner .............................................4 Installing the Antenna .......................................................................4 Wiring the Sirius Conductor Tuner..................................................5 Activating Your SIRIUS Subscription ..............................................6 Operation ............................................................................. 6 Satellite Radio Receiver User Guide . . . . . . . . . . . . . . . . . . . . . . . . . 7 Quick Setup ......................................................................... 7 Pairing Your Wireless Controller with Your Radio .........................7 Activating Your SIRIUS Subscription................................ 7 Adding a Device .................................................................. 7 Adding a Device by Entering Its Code .............................................8 Adding a Device by Searching for Its Code ....................................8 Controlling Your Stereo’s Volume and Setting Its Audio Source Using Your Wireless Controller........................................................8 Using the Key and the POWER Key to Turn Your Devices On or Off........................................................................................................9 SIRIUS Modes of Operation ............................................... 9 Normal Mode ......................................................................................9 Display Button..................................................................................10 Channel List Mode ...........................................................................10 Category List Mode..........................................................................10 Menu Options Mode.........................................................................10 Using the Signal Indicator...............................................................10 SIRIUSRadio.book Page 1 Tuesday, November 21, 2006 5:15 PM SIRIUS Satellite Radio User Guide Storing Presets.................................................................. 11 Restoring Factory Default ...............................................................11 Special Display Messages................................................ 12 Out of Range ....................................................................................12 Acquiring Signal ..............................................................................12 Updating Channels ..........................................................................12 Subscription Updated......................................................................12 Antenna Not Detected .....................................................................12 SIRIUS ID Number (SID) ..................................................................12 Invalid Channel ................................................................................12 Multi Radio Control ........................................................... 13 SIRIUS LCD Wireless Controller User Guide . . . . . . . . . . . . . . . . . . . . . . . . 15 Introduction ....................................................................... 15 Features and Functions.................................................... 16 Key Chart (SIRIUS Functions) ........................................................16 Key Chart (General Functions) .......................................................17 Setting Up Your LCD Wireless Controller....................... 18 Re-Pairing or Adding Another Wireless Controller ....... 18 Adding a Node..................................................................................18 Deleting a Node................................................................................19 Adding a Device ................................................................ 19 Adding a Device by Searching for Its Code ..................................19 Adding a Device by Entering Its Code ...........................................20 Using Learning .................................................................. 20 Deleting All Learned Keys...............................................................21 Deleting a Single Learned Key .......................................................21 Choosing Your Audio Source .......................................... 21 Replacing a Device ........................................................... 22 Deleting a Device .............................................................. 22 Viewing a Device Code ..................................................... 22 SIRIUSRadio.book Page 2 Tuesday, November 21, 2006 5:15 PM SIRIUS Satellite Radio User Guide Replacing a Device ........................................................... 23 Setting Volume Control .................................................... 23 Locking Volume Control to Other Devices....................................23 Adding a Device to Volume Lock ...................................................24 Removing a Device from Volume Lock..........................................24 Using Key Mover ............................................................... 24 Deleting Copied Keys .....…

Text truncated - open the document above for the full version.

Scott McCutchan From: Scott McCutchan [[email protected]] Sent: Thursday, December 14, 2006 12:56 PM To: 'Kyle Fujimoto'; '[email protected]' Subject: FCC ID: MG3SC-H1W 12/14/2006 Mr. Fujimoto: In order for processing of this certification application (FCC ID: MG3SC-H1W) to continue, the following issue(s) will have to be addressed: 1) The confidentiality letter must be signed by the contact person associated with the grantee code. 2) Please indicate compliance with section 15.31(e) of the FCC rules. 3) The incorrect equipment code was used for this device. Please correct the application form. The item(s) indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 60 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Please upload responses and/or exhibits to the electronic filing website. Your correspondence number is MG3SC-H1W -1. Best regards, Scott McCutchan Operations Manager Com patible Electronics TCB

Correspondence by Project Project Number: Correspondence NumberMemo MG3SC-H1W -1 1) The confidentiality letter must be signed by the contact person associated with the grantee code. The Confidentiality Letter has been updated. 2) Please indicate compliance with section 15.31(e) of the FCC rules. The 15.31(e) data sheet has been uploaded. 3) The incorrect equipment code was used for this device. Please correct the application form. The Form has been corrected to show the correct equpment code. 931339855

Report Number: B60919D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sirius Conductor Radio Model: SC-H1W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 1 of 15 FCC PART 15, SUBPART B and C TEST REPORT for SIRIUS CONDUCTOR RADIO MODEL: SC-H1W Prepared for UNIVERSAL ELECTRONICS, INC. 6101 GATEWAY DRIVE CYPRESS, CALIFORNIA 90630-4841 Prepared by:_____________________ KYLE FUJIMOTO Approved by:____________________ JAMES ROSS COMPATIBLE ELECTRONICS INC. 114 OLINDA DRIVE BREA, CALIFORNIA 92823 (714) 579-0500 DATE: OCTOBER 4, 2006 REPORT APPENDICES TOTAL BODY A B C D E PAGES 15 2 2 2 15 27 63 This report shall not be reproduced except in full, without the written approval of Compatible Electronics. Report Number: B60919D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sirius Conductor Radio Model: SC-H1W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 2 of 15 TABLE OF CONTENTS Section / Title PAGE GENERAL REPORT SUMMARY 4 SUMMARY OF TEST RESULTS 4 1. PURPOSE 5 2. ADMINISTRATIVE DATA 6 2.1 Location of Testing 6 2.2 Traceability Statement 6 2.3 Cognizant Personnel 6 2.4 Date Test Sample was Received 6 2.5 Disposition of the Test Sample 6 2.6 Abbreviations and Acronyms 6 3. APPLICABLE DOCUMENTS 7 4. DESCRIPTION OF TEST CONFIGURATION 8 4.1 Description Of Test Configuration - EMI 8 4.1.1 Cable Construction and Termination 9 5. LISTS OF EUT, ACCESSORIES AND TEST EQUIPMENT 10 5.1 EUT and Accessory List 10 5.2 EMI Test Equipment 11 6. TEST SITE DESCRIPTION 12 6.1 Test Facility Description 12 6.2 EUT Mounting, Bonding and Grounding 12 7. TEST PROCEDURES 13 7.1 RF Emissions 13 7.1.1 Radiated Emissions (Spurious and Harmonics) Test 13 7.1.2 Radiated Emissions (Spurious and Harmonics) Test (Continued) 14 8. CONCLUSIONS 15 Report Number: B60919D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sirius Conductor Radio Model: SC-H1W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 3 of 15 LIST OF APPENDICES APPENDIX TITLE A Laboratory Recognitions B Modifications to the EUT C Additional Models Covered Under This Report D Diagrams, Charts, and Photos • Test Setup Diagrams • Radiated Emissions Photos • Antenna and Effective Gain Factors E Data Sheets LIST OF FIGURES FIGURE TITLE 1 Conducted Emissions Test Setup 2 Plot Map And Layout of 3 Meter Radiated Site Report Number: B60919D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sirius Conductor Radio Model: SC-H1W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 4 of 15 GENERAL REPORT SUMMARY This electromagnetic emission test report is generated by Compatible Electronics Inc., which is an independent testing and consulting firm. The test report is based on testing performed by Compatible Electronics personnel according to the measurement procedures described in the test specifications given below and in the "Test Procedures" section of this report. The measurement data and conclusions appearing herein relate only to the sample tested and this report may not be reproduced without the written permission of Compatible Electronics, unless done so in full. This report must not be used to claim product endorsement by NVLAP, NIST or any other agency of the U.S. Government. Device Tested: Sirius Conductor Radio Model: SC-H1W S/N: N/A Product Description: See Expository Statement Modifications: The EUT was not modified in order to meet the specifications. Customer: Universal Electronics, Inc. 6101 Gateway Drive Cypress, California 90630-4841 Manufacturer: Kiryung Electronics Corporation 219-6, Gasan-Dong, Kumchun-Ku Seoul, 153-023, South Korea Test Dates: September 18 and 19, 2006 Test Specifications : EMI requirements CFR Title 47, Part 15 Subpart B; and Subpart C, Sections 15.205, 15.209 and 15.249 Test Procedure: ANSI C63.4 Test Deviations: The test procedure was not deviated from during the testing. SUMMARY OF TEST RESULTS TEST DESCRIPTION RESULTS 1 Conducted RF Emissions, 150 kHz – 30 MHz Complies with the Class B limits of CFR Title 47, Part 15, Subpart B. 2 Radiated RF Emissions, 10 kHz – 9300 MHz (Transmitter Portion) Complies with the limits of CFR Title 47, Part 15, Subpart C, section 15.205, 15.209, and 15.249. 3 Radiated RF Emissions, 10 kHz – 9300 MHz (Digital and Receiver Portion) Complies with the Class B limits of CFR Title 47, Part 15, Subpart B. Report Number: B60919D1 FCC Part 15 Subpart B and FCC Section 15.249 Test Report Sirius Conductor Radio Model: SC-H1W Brea Division 114 Olinda Drive Brea, CA 92823 (714) 579-0500 Agoura Division 2337 Troutdale Drive Agoura, CA 91301 (818) 597-0600 Silverado Division 19121 El Toro Road Silverado, CA 92676 (949) 589-0700 Lake Forest Division 20621 Pascal Way Lake Forest, CA 92630 (949) 587-0400 Page 5 of 15 1. PURPOSE This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the Sirius Conductor Radio, Model: SC-H1W. The EMI measurements were performed according to the measurement procedure described in ANSI C63.4. The tests were performed in order to determine whether the electromagnetic emissions …

Text truncated - open the document above for the full version.

HOW THE EUT MEETS THE REQUIREMENTS OF 15.31 (e) FOR THE UNIVERSAL ELECTRONICS, INC. SIRIUS CONDUCTOR RADIO MODEL: SC-H1W The fundamental was maximized on the Lab D test site using a normal test setup with the AC Adapter for each printer connected directly to the AC public mains (115 Vac). Next, the AC Adapter for each printer was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The Variable Auto Transformer allows the Vac input to be varied. The AC Adapter for each printer was then connected to the Staco Energy Products Variable Auto Transformer Model: 3PN1010. The AC input was then dropped to 85% (97.75 Vac) and raised to 115% (132.25 Vac). The actual AC input was measured using a calibrated Fluke Multimeter Model: 87, Serial Number: 956104240, Calibration Due Date: July 15, 2006. The fundamental was then verified again to see that the amplitude did not change. Test Result: The EUT does NOT change amplitude at the fundamental when the AC input voltage is varied between 85% and 115% of the input nominal rated supply voltage.
