MO5COPLTWireless Controller for Trolling Motor

CoPilot User’s Manual Contents 1. System Components 2. System Features 3. Installing Your CoPilot 4. Using your CoPilot 5. Audio Modes 6. Miscellaneous CoPilot Information 7. Troubleshooting 8. Frequently Asked Questions 9. Technical Assiatance 10. Technical Specifications 11. Warranty Information 12. Compliance Statements Compliance Statements Compliance Statement ( Part 15.19 ) This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Warning ( Part 15.21 ) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Statement The term "IC" before the certification/registration number only signifies that the Industry Canada technical specifications were met.

A division of Johnson Outdoors, Inc. 1531 E. Madison Avenue, P.O. Box 8129 Mankato MN 56002-8129 (507)345-4623 (507)345-4936 F C C CONFIDENTIALITY Date: 10/1/02 To: FEDERAL COMMUNICATIONS COMMISSION 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Non disclosure for FCC ID: MO5COPLT To Whom It May Concern: Pursuant to 47 CFR Section 0.459, Johnson Outdoors, Inc. hereby requests non disclosure and confidential treatment of the following materials submitted in support of FCC certification application for FCC ID # MO5COPLT. a. Schematic Diagrams b. Operational Description c. Block Diagram Above materials contain trade secrets, proprietary and technical information which would customarily be guarded from competitors under 47 CFR section 0.457(d)(2). Disclosure or publication of any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. Johnson Outdoors, Inc. understands that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Sincerely yours, Paul Salmon, Project Manager / Johnson Outdoors, Inc.

Johnson Outdoors, Inc. CoPilot -wireless control for an electric trolling motor FCC ID#: MO5COPLT Canada ID Number: 4397A-MO5COPLT Photo One CoPilot keypad to control the operation of a Trolling Motor mounted to a fishing boat Johnson Outdoors, Inc. CoPilot -wireless control for an electric trolling motor FCC ID#: MO5COPLT Canada ID Number: 4397A-MO5COPLT Photo Two Close Up of Molded FCC ID Number on the back side of Case. Note: FCC ID Number molded due to product application and physical size of case.

FCC ID LABEL CO-PILOT TRANSMITTER JOHNSON OUTDOORS

Johnson Outdoors, Inc. CoPilot -wireless control for an electric trolling motor FCC ID#: MO5COPLT Canada ID Number: 4397A-MO5COPLT Photo Three CoPilot - Open for Inspection Johnson Outdoors, Inc. CoPilot -wireless control for an electric trolling motor FCC ID#: MO5COPLT Canada ID Number: 4397A-MO5COPLT Photo Four PCB Showing Key Control Lands Johnson Outdoors, Inc. CoPilot -wireless control for an electric trolling motor FCC ID#: MO5COPLT Canada ID Number: 4397A-MO5COPLT Photo Five PCB Showing Antenna and Battery Holder Johnson Outdoors, Inc. CoPilot -wireless control for an electric trolling motor FCC ID#: MO5COPLT Canada ID Number: 4397A-MO5COPLT Photo Six PCB Showing RF Section under battery Holder

L.S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, WI 53012 262-375-4400 Fax: 262-375-4248 Compliance Testing of the Johnson Outdoors’ “Co-Pilot” Transmitter Prepared For: Johnson Outdoors, Inc. Attn.: Mr. Paul Salmon 1531 E. Madison Avenue Mankato, MN 56002-8129 Test Report Number: 302371 TX Test Date: October 11 th , 2002 All results of this report relate only to the items that were tested. This report may not be reproduced, except in full, without written approval of L.S. Compliance, Inc. ________________________________________________________________________ Page 2 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX Table of Contents Section Description Type of Test Page # Index 2 1 L. S. Compliance in Review 3 2 A2LA Certificate of Accreditation 4 3 A2LA Scope of Accreditation 5 4 Validation Letter- U.S. Competent Body for EMC Directive 89/336/EEC 6 5 Signature Page 7 6 Product General Information 8 7 Introduction 8 8 Purpose 8 9 Product Description 9 10 Test Requirements 9 11 Summary of Test Report 9 12 Radiated Emission Test 10-18 Appendices A Calculations 19-20 B Test Equipment List 21 ________________________________________________________________________ Page 3 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 1. L.S. Compliance in Review L. S. Compliance, Inc. is located in Cedarburg, Wisconsin – United States. We may be contacted by: Mail: L. S. Compliance, Inc. W66 N220 Commerce Court Cedarburg, Wisconsin 53102 Phone: 262-375-4400 Fax: 262-375-4248 E-Mail: [email protected] As an EMC testing laboratory, our accreditation and assessments are recognized through the following: A2LA – American Association for Laboratory Accreditation Accreditation based on ISO/IEC 17025: 2001 With electrical (EMC) Scope of Accreditation A2LA Certificate Number: 1255.01 U.S. Conformity Assessment Body (CAB) Validation Validated by the European Commission as a U.S. conformity assessment Body operating under the U.S./EU, Mutual Recognition Agreement (MRA) operating under the European Union EMC Directive 89/336/EEC, Article 10.2 Date of Validation: January 16, 2001 Federal Communications Commission (FCC) – USA Listing of 3 Meter Semi-Anechoic Chamber based on 47CFR 2.948 FCC Registration Number: 90756 Listing of 3 and 10 Meter OATS based on 47CFR 2.948 FCC Registration Number: 90757 Industry Canada On-file, 3 Meter Semi-Anechoic Chamber based on 47CFR 2.948 File Number: IC 3088 On-file 3 and 10 meter OATS based on RSS-210 File Number: IC 3088-A ________________________________________________________________________ Page 4 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 2. A2LA Certificate of Accreditation ________________________________________________________________________ Page 5 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 3. A2LA Scope of Accreditation ________________________________________________________________________ Page 6 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 4. Validation Letter – U.S. Competent Body for EMC Directive 89/336/EEC ________________________________________________________________________ Page 7 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 5. Signature Page November 21, 2002 Prepared By: ________________________________________________________ Teresa A. White, Document Coordinator Date November 21, 2002 Tested By: ________________________________________________________ Abtin Spantman, EMC Engineer Date November 21, 2002 Approved By: ________________________________________________________ Kenneth L. Boston, EMC Lab Manager Date PE #31926 Licensed Professional Engineer Registered in the State of Wisconsin, United States ________________________________________________________________________ Page 8 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 6. Product and General Information Johnson Outdoors Co-Pilot Transmitter, Rev 5.0 P11 434 MHz Manufacturer: Model Number: Serial Number: Frequency Range: Test Voltage: 3.0 VDC Environmental Conditions in the Test Lab: Temperature: 20-25? C Atmospheric Pressure: 86kPa-106kPa Humidity: 30-60% 7. Introduction On October 11 th , 2002, a series of Radiated Emissions tests were performed on one sample of the Johnson Outdoors’ “Co-Pilot” transmitter, Serial Number P11. This product operates by means of RF transmission of short burst of data containing a command code, in a simplex fashion. The transmitter is designed to operate with frequency modulation, at a center frequency of 433.92 MHz. These tests were performed using the test procedure outlined in ANSI C63.4, 2001 for intentional radiators, and in accordance with the limits set forth in FCC Part 15.231, for a periodic operation of a low power transmitter. 8. Purpose The above-mentioned tests were performed in order to determine the compliance of the equipment under test (EUT), with limits contained in various provisions of Title 47CFR, FCC Part 15, including: 15.205, 15.209, 15.231a, 15.231b, and 15.231c. All radiated emission tests were performed to measure the emissions in the frequency bands described in Section 12i of this report, and to determine whether said emissions are below the limits established by the aforementioned standards. These tests were performed in accordance with the procedures described in the American National Standard for methods of measurements of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (ANSI C63.4, 2001). Also used as a reference, for the EMI Receiver specification, is the International Special Committee on Radio Interference – CISPR 16-1, 1999. ________________________________________________________________________ Page 9 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Num…

Text truncated - open the document above for the full version.

________________________________________________________________________ Page 12 of 21 L.S. Compliance, Inc. Prepared For: Johnson Outdoors Test Report Number: 302371 TX 12f. Photo of Setup for Radiated Emissions Test EUT placed in horizontal orientation inside the 3 Meter Semi-Anechoic Chamber
