MV3-BCONBone Conductor Hearing Enhancer

Instruction Manual R0 Page 2 WEBSITE www.walkersgameear.com GSM, LLC P.O. Box 535189 Grand Prairie, TX 75053-9504 CUSTOMER SERVICE CONTACT & HOURS Toll Free: 877-269-8490 CALL CENTER HOURS Mon – Fri / 8 AM – 5 PM (CST) Contact Us Table of Contents About Your Headset 3 Headset Overview 4 Raptor Use 5 How to Properly Fit the Raptor 6 How to Properly Fit Your Foam Plugs 7 Device Function 8 Connect to Walker’s LINK 9 Walker’s LINK APP Features 10 FCC Compliance 14 Limited Warranty 15 Warranty Registration 16 Page 3 About Your Headset Bone Conducting Technology Unique bone conducting technology further prevents damage to ear drum compared to traditional technologies. Bluetooth Enabled Connect your Raptor headset to your phone to control with ease on our Walker’s LINK app, free on iOS and Android. Sleep Mode Conserve device battery with our automatic device shut off. Extended Battery Life Never cut a session short with over 7 hours of battery life off of a single charge. Page 4 Headset Overview LED Status Light Volume Down Micro USB Charging Port Power On/Off Bluetooth Multifunction Volume Up Page 5 Raptor Use The Walkers Raptor can be used two ways. Enhancement Only Worn alone, the Raptor can provide amplified hearing as needed along with the Bluetooth functions. When used this way there is NO NOISE PROTECTION. DO NOT OPERATE THE RAPTOR IN THIS METHOD WHILE USING A FIREARM. Enhancement & Protection To utilize the Raptor as an Enhancement & Protection device you will need to use a set of the included foam plugs or any other form of in the ear hearing protection. Simply fit the plugs as directed. The Raptor will provide the enhancement & Bluetooth functions via bone conduction while the foam plugs protect hearing from load noises such as gunfire. Page 6 How to Properly Fit the Raptor Raptor should only be worn after foam plugs have been properly fitted. See page 7 for how to properly fit your plugs. 1. Place Raptor on head so that it wraps over your ears and both pads rest on your temples. Note: Raptor should not sit inside the ear. 2. For best audio quality, both pads should make direct contact with the skin on your temples. Obstruction from hair, glasses, or other headware may reduce sound quality. 3. Once your Raptor is fitted, the headset should fit comfortably over your ears, applying a light pressure to your temples. Page 7 How to Properly Fit Your Foam Plugs Your Raptor does not provide hearing protection on its own. Foam plugs must be properly worn to ensure hearing protection from gun shots and other loud noises. Step 1: Compress the foam plug by rolling between your fingers until it becomes malleable. Step 2: Quickly insert the foam plugs into the ear canal as deep as it is comfortable to wear. Step 3: Hold in place for 10 seconds to ensure plug expands and seals in the ear canal. NOTE: Your ear plugs should form a complete seal, blocking out sound. This is critical to achieve the highest NRR Rating and protect your hearing. Outside noises should be significantly reduced. If not remove the plugs and perform step 1-3 again until a good seal is made. Page 8 Device Function Power On Device: Press and hold power button for 2 seconds. Raptor will play an audible “Walker’s” cound clip to indicate the unit has powered on. Ambient Volume Adjust: Volume changes respectively when pressing the Ambient Volume Up or Down controls: • Volume Up increases volume by one stage. • Volume Down decreases volume by one stage. NOTE: When Ambient volume reaches minimum there will be a double beep. When Ambient volume reaches maximum there will be a double beep. Charging the device: Open the Micro USB Connector cover, plug in a Micro USB cable, then plug the other end into a USB power source or adapter. While the device is charging the LED will remain constant red. When fully charged the device’s LED will turn blue. Note: To pair the Raptor to a new device, press and hold the power button from an off state for 7 seconds. This forgets the previously paired device. Raptor will confirm by stating audibly “Pairing” and the LED with flash red and blue. Page 9 Power On Device: Hold the power button on your Walker’s Raptor for 2 seconds to power on the headset. NOTE: To pair the headset to a new phone, continue holding the power button until you hear an audible “Pairing”. Connect to Your Device: Navigate to your devices Bluetooth setting and select “Raptor” from your list of available Bluetooth devices. You will hear an audible “Connected” sound clip confirming a successful connection has been made. Connect to Walker’s LINK 1 2 Connect to Walker’s LINK: After you are connected to your headset, open the app and press the orange Connect button. NOTE: To connect to Walker’s LINK, you must only have ONE Walker’s device actively connected to your phone. 3 Upon first initial start up the Raptor will enter pairing mode automatically and you will hear an audible “Pairing” clip when the Raptor is ready to be connected to your device. The Raptor will also flash Red and Blue when in Pairing mode. Page 10 Walker’s LINK APP Features Volume Adjust: Use the main slider on the app to increase or decrease the ambient volume of your headset. Sleep Mode: To conserve battery life when the earbuds are not in use, the earbuds can be configured to power off after a set time. The earbuds will power off when no button has been pressed for the designated time AND when they are not connected to a device via Bluetooth. OPTIONS: Off | 2 hours | 4 hours | 6 hours Check Fitment: This setting will mute all ambient volume on the headset to allow you to more easily check the seal on your earplugs. Fitment Instructions Press the arrows in the top right of the screen, or swipe right, to access the Fitment Instruction page. On this page, you will find detailed instructions and diagrams to assist in properly fitting your earplugs. To return to main screen of app, press the arrows in the top left corner, or swipe left. Download our free Walker’s LINK app…

Text truncated - open the document above for the full version.

ReportNo.:EED32M00099401Page86of97 PHOTOGRAPHSOFEUTConstructionalDetails TestmodelNo:GWP-BCON ViewofProduct-1 ViewofProduct-2 ReportNo.:EED32M00099401Page87of97 ViewofProduct-3 ViewofProduct-4 ReportNo.:EED32M00099401Page88of97 ViewofProduct-5 ViewofProduct-6 ReportNo.:EED32M00099401Page89of97 ViewofProduct-7 ViewofProduct-8

GWP-BCON L R INPUT: 5V 200mA Model: GWP-BCON Made in China FCC ID: MV3-BCON IC: 9029A-BCON WWYY00001 INPUT: 5V 200mA FCC ID: MV3-BCON IC: 9029A-BCON Bone Conductor Hearing Enhancer Model: GWP-BCON Made in China Bone Conductor Hearing Enhancer Label: 10x2.5mm Material: clear PET Print: white Laser( Chenlin 2020-05-09 Steven Pantone:Black Silk screen printing Pantone:Cool gray 9 C Silk screen printing Pantone:Cool gray 9 C Silk screen printing

GWP-SF-BCON L R INPUT: 5V 200mA Model: GWP-SF-BCON Made in China Model: GWP-SF-BCON Made in China FCC ID: MV3-BCON IC: 9029A-BCON WWYY00001 INPUT: 5V 200mA FCC ID: MV3-BCON IC: 9029A-BCON Bone Conductor Hearing Enhancer Bone Conductor Hearing Enhancer Label: 10x2.5mm Material: clear PET Print: white Laser( Chenlin 2020-05-09 Steven Pantone:Black Silk screen printing Pantone:Cool gray 9 C Silk screen printing Pantone:Cool gray 9 C Silk screen printing

ReportNo.:EED32M00099401Page90of97 ViewofProduct-9 ViewofProduct-10 ReportNo.:EED32M00099401Page91of97 ViewofProduct-11 ViewofProduct-12 ReportNo.:EED32M00099401Page92of97 ViewofProduct-13 ViewofProduct-14 ReportNo.:EED32M00099401Page93of97 ViewofProduct-15 ViewofProduct-16 ReportNo.:EED32M00099401Page94of97 ViewofProduct-17 ViewofProduct-18 ReportNo.:EED32M00099401Page95of97 ViewofProduct-19 ViewofProduct-20 ReportNo.:EED32M00099401Page96of97 ViewofProduct-21 ViewofProduct-22 ReportNo.:EED32M00099401Page97of97 ViewofProduct-23 ViewofProduct-24 ***EndofReport*** Thetestreportiseffectiveonlywithbothsignatureandspecializedstamp,Theresult(s)showninthis reportreferonlytothesample(s)tested.WithoutwrittenapprovalofCTI,thisreportcan’tbereproduced exceptinfull.

ReportNo. : EED32M00099402Page1 of 8 1 C OVERPAGE RF Expo sureEvaluationReport Product Trademark : Bone Conductor Hearing Enhancer : Walker’s Model/Typereference:GWP-BCON,GWP-SF-BCON,GWP-BCON-XXX, GWP-SF-BCON-XXX(WhereX=0 to 9 or A to Z) SerialNumber: N/A ReportNumber: EED32M00099402 FCC: MV3-BCON Dateof Issue: May 28, 2020 TestStandards:47 CFRPart 1.1307 47 CFRPart 2.1093 KDB447498D01GeneralRF ExposureGuidancev06 Testresult: PASS Prepared for: C ountryMateTechnologyLtd. 5/F, Blk E, HingYip Center, 31 HingYip Street,KwunTong,Kln, HongKong Prepa red by : C entreTestingInternationalGroupCo., Ltd. HongweiIndustrialZone,Bao ’an 70 District, Shenzhen,Guangdong,China TEL:+86-755-33683668 FAX:+86-755-33683385 Com piledby:Reviewedby: SunlightSunWareXin Approvedby:Date:May 28, 2020 SamChuang C heckNo .: 3096302697 ReportNo.:EED32M00099402Page2of8 2Version VersionNo.DateDescription 00May28,2020Original ReportNo.:EED32M00099402Page3of8 3Contents Page 1COVERPAGE....................................................................................................................................................................1 2VERSION.............................................................................................................................................................................2 3CONTENTS.........................................................................................................................................................................3 4GENERALINFORMATION..............................................................................................................................................4 4.1C LIENT I NFORMATION ...................................................................................................................................................4 4.2G ENERAL D ESCRIPTIONOF EUT................................................................................................................................4 4.3P RODUCT S PECIFICATIONSUBJECTIVETOTHISSTANDARD .......................................................................................4 4.4T EST L OCATION ............................................................................................................................................................5 4.5D EVIATIONFROM S TANDARDS .....................................................................................................................................5 4.6A BNORMALITIESFROM S TANDARD C ONDITIONS .........................................................................................................5 4.7O THER I NFORMATION R EQUESTEDBYTHE C USTOMER .............................................................................................5 5SAREVALUATION...........................................................................................................................................................6 5.1RFE XPOSURE C OMPLIANCE R EQUIREMENT ..............................................................................................................6 5.1.1StandardRequirement......................................................................................................................................6 5.1.2Limits....................................................................................................................................................................6 5.1.3EUTRFExposure..............................................................................................................................................7 PHOTOGRAPHSOFEUTCONSTRUCTIONALDETAILS..........................................................................................8 ReportNo.:EED32M00099402Page4of8 4GeneralInformation 4.1ClientInformation Applicant: CountryMateTechnologyLtd. AddressofApplicant: 5/F,BlkE,HingYipCenter,31HingYipStreet,KwunTong,Kln,HongKong Manufacturer: CountryMateTechnologyLtd. AddressofManufacturer: 5/F,BlkE,HingYipCenter,31HingYipStreet,KwunTong,Kln,HongKong Factory: ConcordElectronic(Huizhou)Ltd. AddressofFactory: 21,PingAnRd,ShuikouStreet,HuiChengDistrict,HuizhouCity, GuangdongProvince,China 4.2GeneralDescriptionofEUT ProductName:BoneConductorHearingEnhancer ModelNo.(EUT): GWP-BCON,GWP-SF-BCON,GWP-BCON-XXX,GWP-SF-BCON-XXX (WhereX=0to9orAtoZ) TestModelNo.: GWP-BCON TradeMark: Walker’s EUTSupportsRadios application: BT5.0Singlemode,2402MHzto2480MHz 4.3 ProductSpecificationsubjectivetothisstandard FrequencyRange:2402MHz~2480MHz ModulationType:GFSK,π/4DQPSK,8DPSK TestPowerGrade: ReferencereportEED32M00099401 TestSoftwareofEUT: Bluetest3 AntennaType: ChipAntenna AntennaGain: 0.8dBi PowerSupply:LithiumPolymerBatteryModel:SP8514253.8V300mAh1.14Wh MaxConductedPeakOutput Power: BT:8.389dBm TheMaxConductedPeakOutputPowerdatarefertothereport EED32M00099401 SampleReceivedDate: Apr.24,2020 SampletestedDate: Apr.24,2020toMay18,2020 Thetestedsample(s)andthesampleinformationareprovidedbytheclient. ModelNo.:GWP-BCON,GWP-SF-BCON,GWP-BCON-XXX,GWP-SF-BCON-XXX(WhereX=0to9orAtoZ) OnlythemodelGWP-BCONwastested,sincetheirelectricalcircuitdesign,layout,componentsusedandinternal wiringareidentical.AOnlytheColororPackageisdifferent. ReportNo.:EED32M00099402Page5of8 4.4TestLocation Alltestswereperformedat: CentreTestingInternationalGroupCo.,Ltd BuildingC,HongweiIndustrialParkBlock70,Bao'anDistrict,Shenzhen,China Telephone:+86(0)75533683668Fax:+86(0)75533683385 Notestsweresub-contracted. FCCDesignationNo.:CN1164 4.5DeviationfromStandards None. 4.6AbnormalitiesfromStandardConditions None. 4.7OtherInformationRequestedbytheCustomer None. ReportNo.:EED32M00099402Page6of8 5SAREvaluation 5.1RFExposureComplianceRequirement 5.1.1StandardRequirement AccordingtoKDB447498D01GeneralRFExposureGuidancev06 StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-gheador bodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,bymeasurementor numericalsimul…
