* Consulting * Research * Training * Certification Testing Since 1981 51 Spectrum Waytel: (613) 820-2730 Nepean, Ontariovisit our Web Pages: www.aprel.comfax: (613) 820-4161 Canada K2R 1E6email: [email protected] 17 September, 1999 Federal Communications Commission Equipment Approval Service P.O. Box 358315 Pittsburgh, PA 15251-5315 Re:ADI Ltd. SRT7010/Isonex 3000 Access Phone FCC ID: N6FSRT7010 EAS 92750 Correspondence Ref. # 6738 -Reply Gentlemen: Pursuant to e-mail with your Kwok Chan on Friday May 5, 1999 2:10PM here are ADI’s changes to their documentation (next 7 pages of this PDF file): a. 4 pages from the technical manual which has been updated to Issue 1.03: • page 1.1FCC RF Exposure warning added • page 2-5All references to other antennas deleted • page 4-23Explicit reference to device only providing 4.4dBW • Appendix AExplicit reference to the RF output being 2.75W b. The updated Users Guide with the FCC RF Exposure warning added (2 pages) c. The drawing for the FCC RF Exposure warning label showing the text and where it is to be affixed to the device To simplify cross-referencing these to the original comments I am including the May 5 th e-mail from Kwok Chan to Frank Coperich below, with comments: Frank: This is the ADI wireless local-loop, EAS 92750 - 1. response #1 -we need to scan in the MPE report or Aprel can upload a copy, whichever works. I still have the paper copy of MPE report. I e-mailed a PDF version to Kwok Chan on May 14th which he in turn electronically “dropped in the PDF file for MPE data into the EAS for ADI, EAS 92750”. * Consulting * Research * Training * Certification Testing Since 1981 51 Spectrum Waytel: (613) 820-2730 Nepean, Ontariovisit our Web Pages: www.aprel.comfax: (613) 820-4161 Canada K2R 1E6email: [email protected] 2. response #2 - we need to change the requested Tx frequency range for this device. Do we need to list Rx frequency? See their response. This is in your hands. 3. ADI should change its manual to reflect actual device output. They need to know that the device is only authorized to operate at (or up to) whatever maximum output listed on the grant. Appropriate changes have been made to page 4-23 and Appendix A. 4. response 4 & 5: ADI should provide a copy of the warning statement to be included in the manual and indicate where in the manual. A sample of the warning label and where it will be placed on the device to ensure a 20 cm separation is needed. The warning label should be clearly visible and readable by persons exposed to the transmitter and have the word "WARNING", the required separation distance and purpose (for meeting FCC RF exposure requirements for mobile transmitters). The warning statement in the manual should have similar information with clearer instructions on how to operate the unit to meet the 20 cm separation and/or what are not allowed. 5. response #7 - ADI needs to revise the manual and acknowledge that the half-wave whip will be the only antenna to be used by this device. Appropriate changes have been made to page 2-5. [snip] Kwok Chan Thank you for your cooperation, Sincerely, Paul G. Cardinal Director, Laboratories

LABEL POSITION ON THE UNIT'S FRONT A.00 23.06.99 FIRST ISSUE T. SLUSARCZYK mm N/A UNCLASSIFIED 2:1 1 1 FCC RF EXPOSURE WARNING LABEL NOTES: 1. MATERIAL: 25x50mm RED VINYL LABEL WITH PERMANENT ADHESIVE (OR SIMILAR). 2. ALL LETTERING PERMANENT BLACK ON RED BACKGROUND (ALL CHARACTERS FILLED IN BLACK). 3. ADI PART No LA-00... AMX-LA-01082 AMX-LA-01082 12345678 87654321 A B C D E FF E D C B A USED ON DRAWING NUMBER ZONEAPPROVALCHANGEDATEISS DO NOT SCALE DRAWN CHECKED PASSED APPROVED DATE APPROVED TITLE DCCMDRAWING NUMBER SCALESHEET OF DRAWING PRACTICE AS 1100 DIMENSIONS IN: FINISH SECURITY CLASSIFICATION TSC FILE: a3sheet.dwg (Nov 96) Z1599 TOLERANCES LINEAR±0.50 HOLE CENTRES±0.20 HOLE DIAMETERS±0.10 ANGULAR±0.5° ALL HOLE DIAMETERS STATED ARE FINISHED SIZES AFTER PLATING (IF APPLICABLE) UNLESS OTHERWISE SPECIFIED ALL TOLERANCES ARE PER TABLE SHEET SIZE A3 400 283 CONTRACTORS REF. NUMBER ADI Limited A.C.N. 008 642 751 424 LANE COVE RD NORTH RYDE NSW AUSTRALIAADI c

LABEL POSITION ON THE UNIT'S FRONT A.00 23.06.99 FIRST ISSUE T. SLUSARCZYK mm N/A UNCLASSIFIED 2:1 1 1 FCC RF EXPOSURE WARNING LABEL NOTES: 1. MATERIAL: 25x50mm RED VINYL LABEL WITH PERMANENT ADHESIVE (OR SIMILAR). 2. ALL LETTERING PERMANENT BLACK ON RED BACKGROUND (ALL CHARACTERS FILLED IN BLACK). 3. ADI PART No LA-00... AMX-LA-01082 AMX-LA-01082 B.00 11.10.99 SECOND ISSUE 12345678 87654321 A B C D E FF E D C B A USED ON DRAWING NUMBER ZONEAPPROVALCHANGEDATEISS DO NOT SCALE DRAWN CHECKED PASSED APPROVED DATE APPROVED TITLE DCCMDRAWING NUMBER SCALESHEET OF DRAWING PRACTICE AS 1100 DIMENSIONS IN: FINISH SECURITY CLASSIFICATION TSC FILE: a3sheet.dwg (Nov 96) Z1599 TOLERANCES LINEAR±0.50 HOLE CENTRES±0.20 HOLE DIAMETERS±0.10 ANGULAR±0.5° ALL HOLE DIAMETERS STATED ARE FINISHED SIZES AFTER PLATING (IF APPLICABLE) UNLESS OTHERWISE SPECIFIED ALL TOLERANCES ARE PER TABLE SHEET SIZE A3 400 283 CONTRACTORS REF. NUMBER ADI Limited A.C.N. 008 642 751 424 LANE COVE RD NORTH RYDE NSW AUSTRALIAADI c
