N7KI2Portable Speaker

I2 1. Package contents Waterproof Wireless Speaker User Manual Introduction Thank you for purchasing this product. You can use this item with Pads, Phones, Pods and many types of Smart phone to stream music, and enjoy hands-free calling. In order to get the best results when using the device, please read this manual first before using. Features • IP67 Water resistant Bluetooth Speaker • Perfect fabric speaker with rubber control panel • Rich and powerful sound output ( 15W*2=30W output ) • Unique and patent design • Support TWS function • Type-C port • With adjustable LED light modes • Support TF card Specifications • Bluetooth version: 5.3 • Loudspeaker: φ52mm 4Ω 15W *2 • Built-in battery: 18650 7.4V/2500mAh • Size: φ80.0mm*H220.0mm • SNR: >80dB • Bluetooth Frequency: 2.402-2.480 GHz • Wireless Transmission Distance: up to 10m • Charging time : Approx. 3 hours • Weight: 0.72kg • Sensitivity : - 90dBm • Input: DC5V, 2A • Profile: A2DP/AVRCP/HFP/HSP/OPP/HID/SPP/PBAP/GATT/SM • Audio Decoding: MP2, MP3, WMA, APE, FLAC, AAC, MP4, M4A, WAV(IMA - ADPCM & PCM), AIF, AIFC 1. Connect one end of the included USB Charging Cable to the Charging Port on your speaker. Then plug the other end of the USB Charging Cable into a suitable USB port on your computer, notebook or power bank to recharge your speaker's internal rechargeable battery. 2. When charging, a red LED light will illuminate to indicate that the unit is charging. The red light will turn off when your unit is fully charged(under both turn-on/off speaker status) Important Safety Precautions When using your Bluetooth Mobile Speaker, basic safety precautions should always be followed, including the following: • Keep this product and its accessories away from excessive heat. • Do not operate this device with a damaged cable or after it has malfunctioned or has been damaged in any manner. • No sharp object should be subjected to the speaker/speaker-drivers as it may damage the speakers. • Only use a soft cloth, no harsh abrasives or chemicals to clean, as it may damage the surface finishing. • Ensure the speaker is waterproof by removing all the connected cables and the cap is tightly closed before exposing the speaker to liquid. • Do not expose the speaker to water while charging, as doing so may result in damage to the speaker or the power source. Package contents Charging your Speaker A Quick Look At Your Speaker 2. USB to Type-C charging cable - 50cm 3. User manual 12345 DC 5V 6 7 1. Power on/off Button: To power on your speaker, press and hold the Button. To power off your speaker, Press and hold the Button. Press the Button when music is playing to pause the music. Press the Button when music is paused to begin playing again. 2. Next song / Vol + Button: To skip to the next track, press the Button. To raise the volume, press and hold the Button. 3.Bluetooth Button: Hands free function: - Accepting or ending a call (during music playback included): Upon hearing the incoming call tone, press the Button once to answer the call. This will also pause your music. Press the Button again to end the call. Music will resume. - Rejecting a call (during music playback included): Upon hearing the incoming call tone, press and hold the Button to reject the call. Bluetooth Pairing Procedure 1. Turn on you mobile device and go to the Bluetooth menu. 2. Make sure the speaker is within three meters from the mobile device. 3. Press and hold the Button on your speaker to power on. The LED light will blink blue to indicate that you have entered paring mode. 4. Select “ I2 ” on the Bluetooth device menu. Ensure that the device shows “ Connected ” in the status display. (If a PIN is required, enter 0000.) 5. Press the button twice to disconnect the Bluetooth mode. Reconnecting to a disconnected device 1. If previously connected to a Bluetooth device, the I2 will automatically reconnect with the device when powered on. 2. The speaker will not automatically reconnect if the 10 meters distance is exceeded. Sleeping mode 1. If no Bluetooth device becomes available, the speaker will power off automatically after 10 minutes. 2. If the speaker connected to device without playing music, the speaker will power off automatically after 10 minutes. FCC Requirement: Any changes or modifications not expressly approved by the party responsible for compliance may void the user's authority to operate the device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device shall not cause harmful interference. (2) This device shall accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to meet the limits for a Class B digital device. Pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and canl radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference with radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference with radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to attempt tol correct the interference by one or more of the following measures. -Reorient or relocate the receiving antenna.-Increase separation between equipment and receiver.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. True Wireless Stereo (TWS) Function If you have two I2, you can use them both in sync to listen in True Wireless Stereo (One speaker will play only the left channel, the other will play only the right channel). A. Make sure both I2 are without any Blueto…

Text truncated - open the document above for the full version.

AttestationStatements (KINGTA TECHNOLOGY CO., (Date)：2024/09/25 TO:Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA RE: Attestation Statements Part 2.911(d)(7) request for(GC:N7K) ( K I N GTA T E CH N OLOG Y CO., LTD), the undersigned, hereby authorizeLucky Cowboy Global Services, LLCto act as our designated U.S. agent for service of process, LTD)accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Lucky Cowboy Global Services, LLCaccepts the responsibility to act as designated U.S. agent for service of process. Applicant Information： Company Name:K I N GTA T E CH N OLOG Y CO., LTD Contact Name: Marco Pan Address:R oomFloor 2,Building 10/ Floor 4, Building 9, Futing industrial zone, Zhucun, Guanlan, Longhua FRN: 0021736640 Telephone No:0755-26639494 Email:[email protected] Signature [name]Marco Pan U.S. Agent Information: Company Name: Lucky Cowboy Global Services, LLC Address: 2213 S. Braeswood Blvd. #12E Houston, TX 77030 USA FRN:0033510934 Contact Name:Louie Liu Telephone No: +1 (713) 992-3369 Email: [email protected] Signature [LouieLiu]

KINGTA TECHNOLOGY CO., LTD (2024/ 1 0 /08) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for(FCC ID：N7KI2) [KINGTA TECHNOLOGY CO., LTD] (“the applicant”) certifies that the equipment for which authorization is soughtis not“covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. (Applicant signature) (Applicant printed name)：Marco Pan Sincerely, KINGTA TECHNOLOGY CO., LTD (2024/ 1 0 /08) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for(FCC ID：N7KI2) [ KINGTA TECHNOLOGY CO., LTD (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name)： Marco Pan

modeldifferenceletter TheabovemodelsareidenticalinPCBlayout,internalstructureandcircuit. Thedifferenceisthecommercialusemode Product Name :Portable Speaker Model No. :I2, HKSB23Decibelvibe Tnz Sleek 8 FCC ID :N7KI2 l <Signature> Name ： MarcoPan Title ：/ Company ：KINGTATECHNOLOGYCO.,LTD

KINGTA TECHNOLOGY CO., LTD Schematic (2024/ 1 0 /08) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Product ： Portable Speaker /Model：I2) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the s Blockdiagram Operationdescription requiredtobesubmittedwiththisapplicationbepermanentlywithheldfrompublic review. Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoour Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, <Signature> Name：Marco Pan Title ： / Company ： KINGTA TECHNOLOGY CO., LTD

KINGTA TECHNOLOGY CO., LTD (2024/ 1 0 /08) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize(BlueAsia of Technical Services(Shenzhen) <Signature> Name：Marco Pan Title：/ Company ： KINGTA TECHNOLOGY CO., LT Co.,Ltd. ） toactonourbehalfinallmattersrelatingtoapplicationforequipmentauthorization, includingthesigningofalldocumentsrelatingtothesematters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, D

ModelNo.: I2

Product :Portable Speaker FCC ID:N7KI2 Model:I2

ThetestreportiseffectiveonlywithbothsignatureandspecializedstampandTheresult(s)showninthisreportreferonlytothesample(s)tested.Without writtenapprovalofBlueAsia,thisreportcan ’ tbereproducedexceptinfull.Theresultsdescribedinthisreportdonotrepresentthequalityorcharacteristicsofthe sampledbatch,nordotheyrepresentanysimilaroridenticalproductsthatarenotexplicitlystated. ModelNo.: I2

RFExposureevaluation FCCID:N7KI2 TestStandard: KDB447498D04GeneralRFExposure Guidancev01 Accordingto447498D04InterimGeneralRFExposureGuidancev01 Antgain=1.7dBi MaxOutputpower=1.449dBm@EDR@2402MHz ERP=1.449dBm+1.7dBi-2.15=0.999dBm So worsecase： 10^0.0999=1.2586mW<2.79mW ComplywithRFexposureexemptionlimit.

Website:www.cblueasia.com Tel:+86-755-23059481 Email:[email protected] ThetestreportiseffectiveonlywithbothsignatureandspecializedstampandTheresult(s)showninthisreportreferonlytothesample(s)tested.Without writtenapprovalofBlueAsia,thisreportcan ’ tbereproducedexceptinfull.Theresultsdescribedinthisreportdonotrepresentthequalityorcharacteristicsofthe sampledbatch,nordotheyrepresentanysimilaroridenticalproductsthatarenotexplicitlystated. TestReport Applicant:KINGTATECHNOLOGYCO.,LTD Address: Floor2,Building10/Floor4,Building9,Futing industrialzone,Zhucun,Guanlan,Longhua ShenzhenChina ProductName:PortableSpeaker BrandMark:N/A Model:I2 Seriesmodel:HKSB23,DecibelvibeTnzSleek8 ReportNumber:BLA-EMC-202409-A2202 FCCID:N7KI2 DateofReceipt:2024.09.06 DateofTest:2024.09.07to2024.09.13 TestStandard:47CFRPart15,SubpartC15.247 TestResult:Pass Compiledby:Reviewby:Approvedby: IssuedDate:2024.09.14 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Address:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China ReportNo.:BLA-EMC-202409-A2202 Page 2 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] TableofContents 1Generalinformation......................................................................................................................................................5 1.1Generalinformation.................................................................................................................................................5 1.2GeneraldescriptionofEUT.....................................................................................................................................5 2Testsummary................................................................................................................................................................6 3TestConfiguration........................................................................................................................................................7 3.1Testmode................................................................................................................................................................7 3.2OperationFrequencyeachofchannel....................................................................................................................7 3.3Testchannel.............................................................................................................................................................8 3.4Auxiliaryequipment.................................................................................................................................................8 3.5Testenvironment.....................................................................................................................................................8 4Laboratoryinformation................................................................................................................................................9 4.1Laboratoryandaccreditations.................................................................................................................................9 4.2Measurementuncertainty........................................................................................................................................9 5Testequipment............................................................................................................................................................10 6Testresult....................................................................................................................................................................12 6.1Antennarequirement.............................................................................................................................................12 6.2ConductedemissionsatACpowerline(150kHz-30MHz)..................................................................................13 6.3ConductedpeakoutputPower..............................................................................................................................17 6.420dBBandwidth....................................................................................................................................................18 6.5ConductedBandEdgesMeasurement.................................................................................................................19 6.6Conductedspuriousemissions.............................................................................................................................20 6.7CarrierFrequenciesSeparation............................................................................................................................21 6.8HoppingChannelNumber.....................................................................................................................................22 6.9DwellTime.............................................................................................................................................................23 6.10Radiatedspuriousemissions..............................................................................................................................24 6.11Radiatedemissionswhichfallintherestrictedbands.........................................................................................35 7AppendixA..................................................................................................................................................................42 7.1MaximumConductedOutputPower.....................................................................................................................42 7.2-20dBBandwidth...................................................................................................................................................47 7.3OccupiedChannelBandwidth...................…

Text truncated - open the document above for the full version.

ReportNo.:BLA-EMC-202409-A2202 Page 21 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.7CarrierFrequenciesSeparation TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.2 TestMode(Pre-Scan)TX TestMode(FinalTest)TX 6.7.1Limit 2/3ofthe20dBbandwidthbaseonthetransmissionpowerislessthan0.125W 6.7.2Testsetup 6.7.3Testdata Pass:PleaserefertoappendixAfordetails ReportNo.:BLA-EMC-202409-A2202 Page 22 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.8HoppingChannelNumber TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.3 TestMode(Pre-Scan)TX TestMode(FinalTest)TX 6.8.1Limit Frequencyrange(MHz)Numberofhoppingchannels(minimum) 902-928 50for20dBbandwidth<250kHz 25for20dBbandwidth≥250kHz 2400-2483.515 5725-585075 6.8.2Testsetup 6.8.3Testdata Pass:PleaserefertoappendixAfordetails ReportNo.:BLA-EMC-202409-A2202 Page 23 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.9DwellTime TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.4 TestMode(Pre-Scan)TX TestMode(FinalTest)TX 6.9.1Limit Frequency(MHz)Limit 902-928 0.4swithina20speriod(20dBbandwidth<250kHz) 0.4swithina10speriod(20dBbandwidth≥250kHz) 2400-2483.50.4swithinaperiodof0.4smultipliedbythenumberofhoppingchannels 5725-58500.4swithina30speriod 6.9.2Testsetup 6.9.3Testdata Pass:PleaserefertoappendixAfordetails ReportNo.:BLA-EMC-202409-A2202 Page 24 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.10Radiatedspuriousemissions TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section6.4,6.5,6.6 TestMode(Pre-Scan)TX TestMode(FinalTest)TX 6.10.1Limit Frequency(MHz) Field strength(microvolts/meter) Measurement distance(meters) 0.009-0.4902400/F(kHz)300 0.490-1.70524000/F(kHz)30 1.705-30.03030 30-881003 88-2161503 216-9602003 Above9605003 Remark:TheemissionlimitsshownintheabovetablearebasedonmeasurementsemployingaCISPR quasi-peakdetectorexceptforthefrequencybands9-90kHz,110-490kHzandabove1000MHz.Radiated emissionlimitsinthesethreebandsarebasedonmeasurementsemployinganaveragedetector,thepeakfield strengthofanyemissionshallnotexceedthemaximumpermittedaveragelimitsspecifiedabovebymorethan20 dBunderanyconditionofmodulation. ReportNo.:BLA-EMC-202409-A2202 Page 25 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.10.2Testsetup Below1GHz： 30MHz-1GHz： Above1GHz： ReportNo.:BLA-EMC-202409-A2202 Page 26 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.10.3Procedure a)Forbelow1GHz,theEUTwasplacedonthetopofarotatingtable0.8metersabovethegroundat a3or10metersemi-anechoicchamber.Thetablewasrotated360degreestodeterminethe positionofthehighestradiation. b)Forabove1GHz,theEUTwasplacedonthetopofarotatingtable1.5metersabovethegroundat a3meterfully-anechoicchamber.Thetablewasrotated360degreestodeterminethepositionof thehighestradiation. c)TheEUTwasset3or10metersawayfromtheinterference-receivingantenna,whichwasmounted onthetopofavariable-heightantennatower. d)Theantennaheightisvariedfromonemetertofourmetersabovethegroundtodeterminethe maximumvalueofthefieldstrength.Bothhorizontalandverticalpolarizationsoftheantennaare settomakethemeasurement. e)Foreachsuspectedemission,theEUTwasarrangedtoitsworstcaseandthentheantennawas tunedtoheightsfrom1meterto4meters(forthetestfrequencyofbelow30MHz,theantennawas tunedtoheights1meter)andtherotatabletablewasturnedfrom0degreesto360degreestofind themaximumreading. f)Thetest-receiversystemwassettoPeakDetectFunctionandSpecifiedBandwidthwithMaximum HoldMode. g)IftheemissionleveloftheEUTinpeakmodewas10dBlowerthanthelimitspecified,thentesting couldbestoppedandthepeakvaluesoftheEUTwouldbereported.Otherwisetheemissionsthat didnothave10dBmarginwouldbere-testedonebyoneusingpeak,quasi-peakoraverage methodasspecifiedandthenreportedinadatasheet. h)TesttheEUTinthelowestchannel,themiddlechannel,thehighestchannel. i)TheradiationmeasurementsareperformedinX,Y,ZaxispositioningforTransmittingmode,and foundtheXaxispositioningwhichitistheworstcase. j)Repeataboveproceduresuntilallfrequenciesmeasuredwascomplete. Note1:Scanfrom9kHzto25GHz,thedisturbanceabove12.75GHzandbelow30MHzwasverylow.Thepoints markedonaboveplotsarethehighestemissionscouldbefoundwhentesting,soonlyabovepointshadbeen displayed.Theamplitudeofspuriousemissionsfromtheradiatorwhichareattenuatedmorethan20dBbelowthe limitneednotbereported.Fundamentalfrequencyisblockedbyfilter,andonlyspuriousemissionisshown. Note2:Forfrequenciesabove1GHz,thefieldstrengthlimitsarebasedonaveragelimits.However,thepeakfield strengthofanyemissionshallnotexceedthemaximumpermittedaveragelimitsspecifiedabovebymorethan20 dBunderanyconditionofmodulation.Fortheemissionswhosepeaklevelislowerthantheaveragelimit,only thepeakmeasurementisshowninthereport. Note3:ThefieldstrengthiscalculatedbyaddingtheAntennaFactor,CableFactor&Preamplifier.Thebasic equationwithasamplecalculationisasfollows: Level(dBuV)=Reading(dBuV)+Factor(dB/m) ReportNo.:BLA-EMC-202409-A2202 Page 27 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 6.10.4Testdata Below1GHz [Testmode:TX];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202409-A2202 Page 28 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] [Testmode:TX];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202409-A2202 Page 29 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] Above1GHz: [Testmode:TXlowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202409-A2202 P…

Text truncated - open the document above for the full version.

ReportNo.:BLA-EMC-202409-A2202 Page 41 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] [Testmode:TXHighchannel];[Polarity:Vertical] TestResult:Pass DH1,DH3,DH5allhavebeentested,duringthetest,GFSK,pi/4DQPSK,8DPSK,modulationwereall pre-scannedOnlytheGFSKoftheworstmodewouldberecordedinthisreport. ReportNo.:BLA-EMC-202409-A2202 Page 42 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7AppendixA 7.1MaximumConductedOutputPower ConditionModeFrequency(MHz)AntennaConductedPower(dBm)Limit(dBm)Verdict NVNT1-DH12402Ant11.42421Pass NVNT1-DH12441Ant11.41621Pass NVNT1-DH12480Ant10.51521Pass NVNT2-DH12402Ant11.44921Pass NVNT2-DH12441Ant11.44221Pass NVNT2-DH12480Ant10.45621Pass NVNT3-DH12402Ant11.38321Pass NVNT3-DH12441Ant11.43121Pass NVNT3-DH12480Ant10.51821Pass PowerNVNT1-DH12402MHzAnt1 PowerNVNT1-DH12441MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 43 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] PowerNVNT1-DH12480MHzAnt1 PowerNVNT2-DH12402MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 44 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] PowerNVNT2-DH12441MHzAnt1 PowerNVNT2-DH12480MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 45 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] PowerNVNT3-DH12402MHzAnt1 PowerNVNT3-DH12441MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 46 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] PowerNVNT3-DH12480MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 47 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.2-20dBBandwidth ConditionModeFrequency(MHz)Antenna-20dBBandwidth(MHz)Limit-20dBBandwidth(MHz)Verdict NVNT1-DH12402Ant10.986N/APass NVNT1-DH12441Ant10.928N/APass NVNT1-DH12480Ant10.993N/APass NVNT2-DH12402Ant11.308N/APass NVNT2-DH12441Ant11.322N/APass NVNT2-DH12480Ant11.294N/APass NVNT3-DH12402Ant11.32N/APass NVNT3-DH12441Ant11.324N/APass NVNT3-DH12480Ant11.29N/APass -20dBBandwidthNVNT1-DH12402MHzAnt1 -20dBBandwidthNVNT1-DH12441MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 48 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] -20dBBandwidthNVNT1-DH12480MHzAnt1 -20dBBandwidthNVNT2-DH12402MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 49 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] -20dBBandwidthNVNT2-DH12441MHzAnt1 -20dBBandwidthNVNT2-DH12480MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 50 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] -20dBBandwidthNVNT3-DH12402MHzAnt1 -20dBBandwidthNVNT3-DH12441MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 51 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] -20dBBandwidthNVNT3-DH12480MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 52 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.3OccupiedChannelBandwidth ConditionModeFrequency(MHz)Antenna99%OBW(MHz) NVNT1-DH12402Ant10.86177 NVNT1-DH12441Ant10.85981 NVNT1-DH12480Ant10.86411 NVNT2-DH12402Ant11.6896 NVNT2-DH12441Ant11.2534 NVNT2-DH12480Ant11.1911 NVNT3-DH12402Ant11.6480 NVNT3-DH12441Ant11.2498 NVNT3-DH12480Ant11.1807 OBWNVNT1-DH12402MHzAnt1 OBWNVNT1-DH12441MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 53 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] OBWNVNT1-DH12480MHzAnt1 OBWNVNT2-DH12402MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 54 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] OBWNVNT2-DH12441MHzAnt1 OBWNVNT2-DH12480MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 55 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] OBWNVNT3-DH12402MHzAnt1 OBWNVNT3-DH12441MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 56 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] OBWNVNT3-DH12480MHzAnt1 ReportNo.:BLA-EMC-202409-A2202 Page 57 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.4BandEdge ConditionModeFrequency(MHz)AntennaHoppingModeMaxValue(dBc)Limit(dBc)Verdict NVNT1-DH12402Ant1No-Hopping-55.56-20Pass NVNT1-DH12480Ant1No-Hopping-54.1-20Pass NVNT2-DH12402Ant1No-Hopping-53.14-20Pass NVNT2-DH12480Ant1No-Hopping-54.71-20Pass NVNT3-DH12402Ant1No-Hopping-54.15-20Pass NVNT3-DH12480Ant1No-Hopping-55.35-20Pass BandEdgeNVNT1-DH12402MHzAnt1No-HoppingRef BandEdgeNVNT1-DH12402MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202409-A2202 Page 58 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdgeNVNT1-DH12480MHzAnt1No-HoppingRef BandEdgeNVNT1-DH12480MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202409-A2202 Page 59 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdgeNVNT2-DH12402MHzAnt1No-HoppingRef BandEdgeNVNT2-DH12402MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202409-A2202 Page 60 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdgeNVNT2-DH12480MHzAnt1No-HoppingRef BandEdgeNVNT2-DH12480MHzAnt1No-HoppingEmission

ReportNo.:BLA-EMC-202409-A2202 Page 61 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdgeNVNT3-DH12402MHzAnt1No-HoppingRef BandEdgeNVNT3-DH12402MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202409-A2202 Page 62 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdgeNVNT3-DH12480MHzAnt1No-HoppingRef BandEdgeNVNT3-DH12480MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202409-A2202 Page 63 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] ReportNo.:BLA-EMC-202409-A2202 Page 64 of 96 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.5BandEdge(Hopping) ConditionModeFrequency(MHz)AntennaHoppingModeMaxValue(dBc)Limit(dBc)Verdict NVNT1-DH12402Ant1Hopping-53.21-20Pass NVNT1-DH12480Ant1Hopping-53.11-20Pass NVNT2-DH12402Ant1Hopping-54.1-20Pass NVNT2-DH12480Ant1Hopping-53.89-20Pass NVNT3-DH12402Ant1Hopping-53.96-20Pass NVNT3-DH12480Ant1Hopping-52.94-20Pass BandEdge(Hopping)NVNT1-DH12402MHzAnt1HoppingRef BandEdge(Hopping)NVNT1-DH12402MHzAnt1HoppingEmis…
