N7SC140TNetweeN

Netween Router User Manual Table of Contents Product & Explainations 3 Product Feature 1. Front of the Netween 3 2. Back of the Netween 5 Netween Default Connection 1. General Internet Network 6 2. Environment using a Modem 7 Netween Default Set 1. Internet Connection Settings 7 1) Auto IP set 8 2) Static IP set 8 3) PPPoE set 9 Components Firmware Upgrade 12 Load Default Setting 13 Installation Precautions 4 2 10 2. Wireless Default Setting and security setting 11 1) How to setting wireless security 11 2) How to setting wireless check 11 3 Netween Router Product Features Specification Wireless Interface CPU WAN Interface LAN Interface Status LED DRAM FLASH Power Operating Temp. Tx Power Rx Sensitivity Antenna IEEE802.11b/g/n (Draft 2.0) 384Mhz MIPS 34bit 1 x 10/100Base-Tx, Auto MDI/MDIX 4 x 10/100Base-Tx, Auto MDI/MDIX Power, WLAN, WAN, LAN x 4, WPS 16Mbytes 4Mbytes Input : 100~240VAC, 50~60Hz Output : 5VDC, 2A 14dBm 2dBm -65dBm @130Mbps -68dBm @54Mbps -84dBm @11Mbps 3 dBi x 2 antenna C140T Wireless -. 802.11n(draft 2.0), 802.11b/g -. 1T1R -. Up to 300Mbps -. Multiple SSID -. SSID broadcast -. Auto transmission speed -. WDS Wireless bridge -. Wi-Fi Multi Media -. Auto Channel Select -. WPS -. OFDM, DSSS, MIMO -. 2.4 Ghz Security -. 64/128/WEP -. WPA/WPA2, WPA-PSK/ WPA2-PSK(TKIP/AES) -. Hidden SSID -. Access Control List -. Packet Filtering -. Web Contents/URL filter -. Parent Control Network Protocol -. PPPoE -. DHCP -. MAC cloning -. Port forwarding -. QoS for MAC and IP -. IGMP Proxy -. DDNS -. UPnP -. VPN Server -. DMZ, Special DMZ -. NAT Others -. Login(ID/PW) -. Auto-Firmware upgrade -. Remote Web management -. System log -. WOL Netween Router Components Netween Router 1M LAN cable User Manual Power Adapter Installation Precautions Read the notes below before installing The power adapter must be a standard adapter that is supplied with Netween adapter products. Must seek professional help when product is damaged, please avoid further deteriorating or opening the case of the product. Be careful not to drop or apply strong collision to the product. Please avoid setting in places with direct sunlight, dust, excessive vibration or unstable places before and after you install the product. If the exterior adapter devices of the Netween are cleaned with alcohol, benzene, acetone, etc. or any flammable liquids, this alteration to the surface will cause chemical changes. In case of contact with other material please wipe the area with a dry cloth. The power being supplied must be stable. In the case of the power supply develops sparks or noises, a power control device must be installed. Never touch the power supply area when the power cord is connected due to risks of electric shocks. When installing or moving the product, power switch must be turned off and all the connected cables must be unplugged. Pay attention not to overload wiring connections when connected the power source. The information contained in this manuscript can be changed without agreement or separate notice of individual users. regulations, some environmental constrains of the product performance and feature limitations may be encountered. We will not take responsibility of any line disability issues during usage of this product. 4 Product & Explaination Power / ON WLAN / Flicker WPS / only flickers when activated WAN / Flicker LAN /Flicker * WPS (Wifi Protected Setup) A feature to set up easily without complex security settings between adaptor and WPS function supported terminals. Shows the power supply is normal Shows wireless is in operating conditions WPS supported devices and confirmation process is in progress Shows external internet cable is connected and data communication is in progress PC and cable is connected and shows data communication is in progress 5 Front of the Netween Reset Power ON/OFF Switch WAN LAN WPS 6 Back of the Netween Netween Default Connection 7 General internet environment Environment using a Modem Netween default set 1.Dynamic IP(DHCP) How to install 2. With modem methods, disconnect the LAN cable that is connected to the modem connected to the PC and have an optical LAN, separate the socket of the terminal from the PC and connect it to the router (WAN port). Make sure the LED of the (WAN) is working normally. 3. After turning on the PC, connect the LAN cable that is enclosed with the product to the PC and into 1 2 3 4, one of the LAN ports of the router. Make sure the LED of 1 2 3 4 are functioning. 4. Reboot the PC and see if the internet working -If internet is automatically connected, internet can be used without additional connection settings Netween router is set to automatically receive IP method in default. Enter address http://192.168.1.1-Expert Setting- WAN Interface Setting 8 Internet connection set 2. Static IP Set when router is connected 1) After accessing to 192.168.1.1 on the internet address bar, change the internet to (Static IP) from (Expert Setting) (Network Setting) (WAN Interface Setting) and enter the given Static IP and click SAVE 2) Savings are completed when the screen turns white and back to its original form. 9 3. PPPoE (ADSL User) Set when router is connected 1) After inserting internet access address 192.168.1.1 go to [Expert Setting][Network Sertting] [WAN Interface Setting] and change the internet connection form to [PPPoE] and insert the user ID and password of the telecommunication company that you have signed up, click SAVE 2) Savings are completed when the screen turns white and back to its original form. 3) After saving, confirm if the wired and wireless internet is working 10 Wireless default setting and security setting - -You can choose type of encryption (Not Certification, WEP, WPA-PSK, WPA-PSK2, etc. ) 1. How to setting wireless security 1)Available change Subsystem Identification 2. How to check wireless security 1) You can choose type of encryption (Not Certification, WEP, WPA-PSK, WPA-PSK2, etc ). For your security, we suggest that change Subsys…

Text truncated - open the document above for the full version.

CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com EUT External Photographs CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com

CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Label Photographs

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com EUT Internal Photographs CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 1 of 2 RF EXPOSURE EVALUATION Applicant : Center Network Solution Applicant Address : Suwon industrial, District2, 990-1, Gosaek-dong, Gwonsun-gu, Suwon-si, Gyeonggi-do, Korea Kind of Product : NetweeN Equipment model name : C140T Antenna type : Dipole antenna Gain 3 dBi Frequency Range : 2400 – 2483.5 MHz Number of channels : 802.11b/g/n(20 MHz) : 11 802.11n(40 MHz) : 7 CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Page 2 of 2 ** MPE Calculations ** No Evaluation Required if power is below this threshold. (60 /f(GHz) - 802.11b/g/n(20 MHz) Frequency (MHz) mW Low 2412 Middle 2437 High 2462 24.37 - 802.11n(40 MHz) Frequency (MHz) mW Low 2422 Middle 2437 High 2452 24.47 For multiple co-located transmitters operating simultaneously the total power density can be calculated by summing the Power * Gain product (in linear units) of each transmitter. LIMITS 1.0 mW/cm 2 RESULTS Mode EIRP (dBm) EIRP (mW) MPE Distance (cm) Power Density (mW/cm 2 ) Results 802.11b/g/n(20MHz) 18.02 63.39 20 0.06613 Complies 802.11n(40 MHz) 17.63 57.94 20 0.06045 Complies S = (P1*G1)/ (4R 2 π) = (0.21) / (4 * 20 2 * π) S = Power Density in mW/cm 2 Px = Power of transmitter x in mW Gx = Numeric gain of antenna x R = distance in cm

CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 1 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) TEST REPORT For FCC Test Report No.: CTK-2012-00478 Date of Issue: June 4,2012 FCC ID:N7SC140T Model/Type No.: C140T Kind of Product: NetweeN Applicant:Center Network Solution Applicant Address : Suwon industrial, District2, 990-1, Gosaek-dong, Gwonsun-gu, Suwon-si, Gyeonggi-do, Korea Manufacturer: Center Network Solution Manufacturer Address : Suwon industrial, District2, 990-1, Gosaek-dong, Gwonsun-gu, Suwon-si, Gyeonggi-do, Korea Contact Person: Song, Jin Seok / Team Manager Telephone:+82-31-423-1001 Received Date: April 2, 2012 Test period:Start : April 4, 2012End : May 25, 2012 Test Results: In ComplianceNot in Compliance The test results presented in this report relate only to the object tested. Tested byReviewed by Won-Jae, Hwang Test Engineer Young-Joon, Park Technical Manager Date: June 4, 2012Date: June 4, 2012 CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 2 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) REPORT REVISION HISTORY DateRevisionPage No June 4, 2012Issued (CTK-2012-00478)All This report shall not be reproduced except in full, without the written approval of CTK Co., Ltd. This document may be altered or revised by CTK Co., Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by CTK Co., Ltd. will constitute fraud and shall nullify the document. CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 3 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) TABLE OF CONTENTS REPORT REVISION HISTORY...........................................................................................2 1.0 General Product Description................................................................................4 1.1 Tested Frequency...............................................................................................4 1.2 Device Modifications...........................................................................................5 1.3 Peripheral Devices.............................................................................................5 1.4 Calibration Details of Equipment Used for Measurement.........................................5 1.5 Test Facility.......................................................................................................5 1.6 Laboratory Accreditations and Listings..................................................................6 2 Summary of tests....................................................................................................7 2.1 Technical Characteristic Test......................................................................................8 2.1.1 6dB Bandwidth............................................................................................8 2.1.2 Maximum peak Conducted Output Power...................................................... 18 2.1.3 Power Spectral Density............................................................................... 20 2.1.4 Band - edge..............................................................................................30 2.1.5 Field Strength of Emissions......................................................................... 43 Test Data.............................................................................................................. 44 2.1.6 AC Conducted Emissions............................................................................. 47 APPENDIX A – Test Equipment Used For Tests................................................................. 50 CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 4 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 1.0 General Product Description Equipment model name C140T Serial numberPrototype EUT conditionPre-production, not damaged Frequency Range 802.11b/g/n(20 MHz) : 2412 MHz - 2462 MHz 802.11n(40 MHz) : 2422 MHz - 2452 MHz RF output power 802.11b : 15.02 dBm 802.11g : 14.79 dBm 802.11n(20 MHz) : 14.75 dBm 802.11n(40 MHz) : 14.63 dBm Number of channels 802.11b/g/n(20 MHz) : 11 802.11n(40 MHz) : 7 Channel Spacing5 MHz Transfer Rate 802.11b : 11 / 5.5 / 2 / 1 Mbps 802.11g : 54 / 48 / 36 / 24 / 18 / 12 / 9 / 6 Mbps 802.11n : up to 300 Mbps Type of Modulation 802.11b : DSSS 802.11g/n : OFDM Duty cycle TX power1.0 Power Source5 Vdc Antenna TypeDipole antenna Gain: 3 dBi 1.1 Tested Frequency 802.11b, 802.11g, 802.11n (20MHz) LOWMIDHIGH Frequency (MHz)241224372462 802.11n (40MHz) LOWMIDHIGH Frequency (MHz)242224372452 CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 5 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 1.2 Device Modifications The following modifications were necessary for compliance: Not applicable 1.3 Peripheral Devices DeviceManufacturerModel No.Serial No. Switching Adapter (for EUT)Shenzhen Yonghao Techno…

Text truncated - open the document above for the full version.

CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 26 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 802.11n(20 MHz) Power Density Measurement CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 27 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 28 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 802.11n(40MHz) Power Density Measurement CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 29 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 30 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 2.1.4 Band - edge Procedure: The bandwidth at 20dB down from the highest inband spectral density is measured with a spectrum analyzer connected to the antenna terminal, while EUT is operating in transmission mode at the appropriate frequencies. After the trace being stable, Use the marker-to-peak function to measure 20 dB down both sides of the intentional emission. The spectrum analyzer is set to: Center frequency = the highest, middle and the lowest channels RBW = 100 kHzVBW =100 kHz Span = 50 MHzDetector function= peak Trace = max holdSweep = auto Measurement Data: Complies - All conducted emission in any 100 kHz bandwidth outside of the spread spectrum band was at least 20dB lower than the highest inband spectral density. Therefore the applying equipment meets the requirement. Minimum Standard:> 20 dBc See next pages for actual measured spectrum plots. CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 31 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 802.11b Band–edge Measurements CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 32 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) Band – edge (at 20 dB blow) – Low channel(802.11b) Frequency Range = 30 MHz ~ 10 th harmonic Band – edge (at 20 dB blow) – Mid channel(802.11b) Frequency Range = 30 MHz ~ 10 th harmonic CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 33 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) Band – edge (at 20 dB blow) – High channel(802.11b) Frequency Range = 30 MHz ~ 10 th harmonic CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 34 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 802.11g Band–edge Measurements CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 35 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) Band – edge (at 20 dB blow) – Low channel(802.11g) Frequency Range = 30 MHz ~ 10 th harmonic Band – edge (at 20 dB blow) – Mid channel(802.11g) Frequency Range = 30 MHz ~ 10 th harmonic CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 36 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) Band – edge (at 20 dB blow) – High channel(802.11g) Frequency Range = 30 MHz ~ 10 th harmonic CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 37 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) 802.11n(20MHz) Band–edge Measurements CTKCo., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970Fax: +82-31-339-9855 www.e-ctk.com Test Report No.: CTK-2012-00478 Date: June 4, 2012 Page 38 of 50 This Report shall not be reproduced except in full without the written approval of CTK Form No.: CTK-RF-EF-Part15 Subpart C(Rev.2) Band – edge (at 20 dB blow) – Low channel(802.11n(20MHz)) Frequency Range = 30 MHz ~ 10 th harmoni…

Text truncated - open the document above for the full version.

CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Test Setup Photos and Configuration Conducted Voltage Emissions at AC Power Ports CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com Radiated Electric Field Emissions CTK Co., Ltd. 386-1, Ho-dong, Cheoin-gu, Yongin-si, Gyeonggi-do, 449-100, Korea Tel: +82-31-339-9970 Fax: +82-31-339-9855 www.e-ctk.com
