MADE IN CHINA *TM & © 1998 HASBRO, INC. Pawtucket, Rhode Island 02862. All Rights Reserved. U.S. Patent Pending © Lucasfilm Ltd. & TM. All rights reserved. AGES 4 & UP Battery Features This device complies with Part 15 of the FCC rules. Operation is subject to the fol- lowing two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including any interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party respon- sible for compliance could void the user's authority to operate the equip- ment. ™ Battery Lightsaber ™ Sound Blaster Sound Scan Area Storage Buttons Power Button Belt Clip 9 volt - + Instruction Sheet Reader 84151 Fisher Design/Tom Schmidt 513.221.2242 Operation 557968.0000 Chip Playing 1.2.3. Turn unit on (fig. 1). Lay chip on Scan Area on front of unit (fig. 2). Listen to one of the random phrases. Remove chip and replace with another chip (fig. 3) or use same chip again. Chip will work with or without figure attached. Chip Storing 1.2.3. Turn unit on. Lay chip on Scan Area on front of unit (fig. 1). Listen to one complete phrase. Then press and hold any one of the four storage buttons (fig. 2) until the loading sound lets you know the chip has been stored. Remove chip. Press the storage button again to hear each of the phrases that were on the chip (fig. 3). (NOTE: this process can be done over and over again.) storage buttons press one Chip Conversation Feature 1. Some figures can talk with other figures. See the figure's package back to determine the conversation feature. Turn unit on. Lay first chip on Scan Area on front of unit (fig. 1). Listen to one of the random phrases. Remove first chip and replace with second chip (fig. 2). This chip will always respond with the same phrase to the first chip. (NOTE: if you store the two chips and play them back in order, the same thing will happen.) 2. Scan Area power chip 1chip 2

HASBRO EUROPE 2 ROUNDWOOD AVENUE, STOCKLEY PARK UXBRIDGE, MIDDLESEX UNITED KINGDOM UB11 1AZ TEL : 0181 569 1234, FAX : 0181 569 1133 HASBRO EUROPE IS THE BUSINESS NAME OF HASBRO INTERNATIONAL, INC., A COMPANY INCORPORATED WITH LIMITED LIABILITY IN THE USA. 22 October 1998 David Maina Radio Frequency Investigation Ltd. Ewhurst Park, Ramsdell Basingstoke, Hampshire England RG26 5RQ Subject : Authority to act on behalf of Hasbro Dear David This letter is to authorise Radio Frequency Investigation Ltd to act on behalf of Hasbro for radio type approval applications worldwide relating to Hasbro Item 84151. Yours Sincerely W.D. Anderson Product Engineering Manager

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ TESTING 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test of: Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To: F.C.C. Part 15:1997 Subpart C. Section 15.225 (Intentional Radiators) Test Report Serial No: RFI/EMCB1/RP37410A This Test Report Is Issued Under The Authority Of Brian Watson Technical Director: Checked By: Tested By:Release Version No: 01 Issue Date: 19 October 1998Test Date: 25 September 1997 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP37410A EMC DepartmentPage 2 of 26 Issue Date: 19 October 1998 Test Of:Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To:F.C.C. Part 15:1997, Subpart C Section 15.225 (Intentional Radiators) This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP37410A EMC DepartmentPage 3 of 26 Issue Date: 19 October 1998 Test Of:Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To:F.C.C. Part 15:1997, Subpart C Section 15.225 (Intentional Radiators) Table of Contents 1. Client Information......................................................................................................4 2. Equipment Under Test (EUT)....................................................................................5 3. Test Specification, Methods And Procedures.........................................................7 4. Deviations From The Test Specification..................................................................8 5. Operation Of The EUT During Testing.....................................................................9 6. Summary Of Test Results.......................................................................................10 7. Measurements, Examinations And Derived Results..............................................11 8. Measurement Uncertainty.......................................................................................16 Appendix 1. Test Equipment Used..............................................................................17 Appendix 2. Measurement Methods............................................................................18 Appendix 3. Test Configuration Drawings..................................................................21 Appendix 4. Graphical Test Results............................................................................24 Appendix 5. Photographs of EUT................................................................................26 RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP37410A EMC DepartmentPage 4 of 26 Issue Date: 19 October 1998 Test Of:Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To:F.C.C. Part 15:1997, Subpart C Section 15.225 (Intentional Radiators) 1. Client Information Company Name: Hasbro Europe Address: 2 Roundwood Avenue Stockley Park Uxbridge Middex UB11 1AZ Contact Name: Mr D Anderson. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP37410A EMC DepartmentPage 5 of 26 Issue Date: 19 October 1998 Test Of:Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To:F.C.C. Part 15:1997, Subpart C Section 15.225 (Intentional Radiators) 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: Commtech Reader Model Name or Number: 84151 Unique Type Identification: None stated by client Serial Number: None stated by client Country of Manufacture: China FCC ID Number: Pending Application Date of Receipt: 5 October 1998 2.2. Description Of EUT The equipment under test is a 13.56 MHz passive tag data download and decoder unit. 2.3. Modifications Incorporated In EUT To enable emission measurements to be made, the EUT was modified to allow for a continuous transmit operation. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP37410A EMC DepartmentPage 6 of 26 Issue Date: 19 October 1998 Test Of:Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To:F.C.C. Part 15:1997, Subpart C Section 15.225 (Intentional Radiators) 2.4. Additional Information Related To Testing Power Supply Requirement: Internal battery supply of + 9 volt Intended Operating Environment: Domestic - Indoor Weight: 240 Gms Dimensions: 80 mm x 200 mm x 60 mm Interface Ports: None 2.5. Support Equipment No support equipment was used to exercise the EUT during testing. RADIO FREQUENCY INVESTIGATION LTD.TEST REPORT S.No: RFI/EMCB1/RP37410A EMC DepartmentPage 7 of 26 Issue Date: 19 October 1998 Test Of:Hasbro Inc. Commtech Reader 84151 13.56 MHz Passive Tag To:F.C.C. Part 15:1997, Subpart C Section 15.225 (Intentional Radiators) 3. Test Specification, Methods And Procedures 3.1. Test Specification Reference: F.C.C. Part 15 Subpart C. Section 15.225 (Intentional Radiators)* Title: Code of Federal Regulations, Part 15 (47CFR15), 1997 Radio Frequency Devices: Intentional Radiators. Comments: A description of the test facility used for this test is on file with, and has been accepted by, the Federal Communications Commission as required by Section 2.948 of Federal Rules. Purpose of Test: To determine whether the equipment complied with the requirements of the specification for the purposes of certification. *Sections 15.209 (Radiated Emissions; general requirements) and 15.225 (Operation with…
