N94-HUB-74428Charging Hub

SMART HOME WATER DETECTION 360 LEAK ALERT ™ Zircon Corporation 1580 Dell Avenue, Campbell, CA 95008 [email protected] | www.zircon.com | 408-963-4550 | 800-245-9265 ©2025 Zircon Corporation | P/N 75459 Rev A 10/25 QUICK START GUIDE zircon.com THANK YOU Thank you for choosing the Zircon ® Leak Alert ™ 360 Smart Home Water Leak Detection System! Easily protect your property from costly water damage. The Leak Alert ™ 360 uses high-precision sensors and a secure wireless connection to monitor your home, office, rental, or vacation property. Before you get started, take a moment to review the full instructions. Download the app to stay connected with real-time leak alerts, location tracking, and user management. With robust connectivity and a dependable battery backup, you can protect your property like never before. TABLE OF CONTENTS Section 1: What’s in the Kit Section 2: Get to Know Your Leak Alert ™ 360. Section 3: Easy Set Up Section 4: Alarm Mounting Instructions Section 5: Limited 5 Year Warranty Section 6: FAQ & Troubleshooting Section 7: Full Guide Switches and LED Indicators Section 8: Safety and Information Section 9: FCC zircon.comzircon.com121 1 System Devices Charging Hub + Integrated Alarm IP30 USB Power Adapter 9 FCC This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: – Reorient or relocate the receiving antenna. – Increase the separation between the equipment and receiver. – Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. – Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Radiation Exposure statement - Hub This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Sensors IP67 USB-C Cable Alarm IP30 zircon.comzircon.com112 2 Get to Know Your Leak Alert ™ 360 Charging Hub with Integrated Alarm + Sensor *Internal rechargeable Li-ion Battery Wireless Charging Base USB-C Power Input Internal 85 dB Audible Alarm LED Status Indicators (Find more details at leakalert360.com) *Slow Flash – Pairing *Solid RED Leak *Battery Charging Flash Charging Hub Push Button *On/Off, Status Display, Enter Pairing Mode, Silence Alarm LED Status Indicator *Slow Flash – Pairing *Solid RED Leak *Battery Charging Flash QR Setup Code on Back Precision Water Sensors on back 8 Warnings Indoor use only. Devices not rated for outdoor use. IP Ratings: Sensor IP67; Charging Hub IP30; Alarm IP30 Stop using the battery if it overheats, is damaged, dropped, or modified. Only use the charger supplied with sensors. No self-repairs. Contact the manufacturer for service. Non-replaceable battery – Do not remove, alter, or replace the battery yourself. Keep batteries away from liquids, oils, and extreme heat or cold. Do not use product that is damaged or repaired. Use only a power supply rated at 5V DC, 2A. Using a power supply with incorrect voltage or current may damage the device and void the warranty. Ensure the power supply is certified and compliant with local electrical safety standards. Do not use USB ports from computers or low-power adapters unless they meet the required specifications. Temperature Guidelines To ensure optimal performance and safety, please observe the following temperature limits: Operating Temperature: −10°C to 50°C Charging Temperature: 0°C to 45°C Storage & Transportation Temperature: -10°C to 35°C Using, charging, or storing the device outside these temperature ranges may result in reduced performance, damage, or safety hazards. Cautions Keep battery charged. Recharge the sensor battery once a year or when the low-battery warning appears. Set the detector flat on the floor with the sensing contacts facing down. Avoid metal surfaces. Don’t place the detector on metal; it can cause false alarms. Store and charge batteries in a cool, dry place. Transport and store lithium-ion batteries separately from metals (keys, coins, screws, nails) and liquids. Proper Disposal Don’t throw batteries in the trash – Take them to a battery recycling center or approved collection bin in your local area. zircon.comzircon.com310 7 Full Guide Switches and LED Indicators DEVICEINDICATOR BT Pairing / Setup BT Pairing / Setup BT Pairing / Setup Leak Charging Hub + Integrated Alarm LeakSensor LeakAlarm Battery Charging Battery Charging Battery Charging Firmware Update Firmware Update Firmware Update Other Other …

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 6 Appendix External Photos for SZCR2504001721AT FCC ID: N94-HUB-74428 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 6 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 6 of 6 - End of the Appendix -

15.2 <> NOTES: UNLESS OTHERWISE SPECIFIED LASER ENGRAVING LOCATION: MAKE FROM PN: 745591. 2 THE PART SHOULD BE LASER ENGRAVED PER ARTWORK 74716-02 3. MODEL, SN, MAC ID, FCC ID & QR CODE: ONLY FOR REFERENCE 15.2 D C B A A B C D 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 PROPRIETARY AND CONFIDENTIAL DIMENSIONS ARE IN mm TOLERANCES: 0 TO 12 ± .15 12.1 TO 24 ± .20 24.1 TO 50 ± .25 50.1 TO 100 ± .30 100.1 TO 200 ± .40 ANGULAR 1/2 INTERPRET GEOMETRIC TOLERANCING PER ASME Y14.5 1994 MATERIAL FINISH SEE NOTES DRAWN CHECKED ENG APPR. MFG APPR. Q.A. DATE ZIRCON Corporation 1580 Dell Avenue Campbell, CA 95008 Ph: (408) 963-4550 Fax: (408) 963-4597 SIZE C DWG. NO. REV. 1 OF 1 WEIGHT: 1:1 REVISIONS REV. DESCRIPTION DATE APPROVED UNLESS OTHERWISE SPECIFIED: TITLE: ZCO DRAWING NOT TO SCALE PART NUMBER THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF ZIRCON CORPORATION. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF ZIRCON CORPORATION IS PROHIBITED. SHEET SCALE SOLIDWORKS MODEL FILE: SOLIDWORKS DRAWING FILE: 74716-01 CHARGING,HUB,BACK, LASER,ENGRAVING B4 74716-01 74716 10/15/25 I.RODRIGUEZ 10/15/25 I.RODRIGUEZ 10/15/25 K. LOPEZ I.RODRIGUEZ I.RODRIGUEZ I.RODRIGUEZ I.RODRIGUEZ I.RODRIGUEZ I.RODRIGUEZ RELEASE TO PRODUCTION REMOVED FCC & CE LOGO, ADDED SGS LOGO & FCC ID NUMBERS. MODIFIED ARTWORK. MODIFIED ARTWORK. MODIFIED ARTWORK. MODIFIED NAME DESC. & ARTWORK. A0 B0 B1 B2 B3 B4 8143 8404 8437 8443 8457 8460 04/10/25 09/08/25 09/23/25 09/26/25 10/10/25 10/15/25 SEE NOTES

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 6 Appendix Internal Photos for SZCR2504001721AT FCC ID: N94-HUB-74428 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 6 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 5 of 6 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 6 of 6 - End of the Appendix -

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172102 Page: 1 of 14 Keny Xu EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: SZCR2504001721AT Applicant: Zircon Corporation Address of Applicant: 1580 Dell Avenue, Campbell, California, 95008, United States Manufacturer: ROMPA ShunXing (JiangMen) Plastics Co., Ltd. Address of Manufacturer: No.290, Qinglan Road, Jianghai District, Jiangman, Guangdong, China Factory: ROMPA ShunXing (JiangMen) Plastics Co., Ltd. Address of Factory: No.290, Qinglan Road, Jianghai District, Jiangman, Guangdong, China Equipment Under Test (EUT): EUT Name: Charging Hub Model No.: 5A4301XX(XX=00 to FF)   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: ZIRCON FCC ID: N94-HUB-74428 Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2025-04-29 Date of Evaluation: 2025-05-22 to 2025-06-10 Date of Issue: 2025-06-10 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172102 Page: 2 of 14 Revision Record Version Chapter Date Modifier Remark 01 2025-06-10 Original Authorized for issue by: Bill Chen/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172102 Page: 3 of 14 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 General Description of E.U.T. ............................................................................................................ 4 3.2 Details of E.U.T. ................................................................................................................................. 4 3.3 Separation Distance ........................................................................................................................... 5 3.4 Test Location ...................................................................................................................................... 6 3.5 Test Facility ........................................................................................................................................ 6 3.6 Deviation from Standards ................................................................................................................... 6 3.7 Abnormalities from Standard Conditions ........................................................................................... 6 4 FCC Radiofrequency radiation exposure limits .................................................................................... 7 4.1 Blanket 1 mW Blanket Exemption ...................................................................................................... 7 4.2 MPE-based Exemption ...................................................................................................................... 7 4.3 SAR-based Exemption ....................................................................................................................... 8 5 Measurement and Calculation ............................................................................................................... 12 5.1 Maximum transmit power ................................................................................................................. 12 5.2 RF Exposure Calculation ................................................................................................................. 13 6 EUT Constructional Details (EUT Photos) ........................................................................................... 14 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172102 Page: 4 of 14 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: AC/DC Adapter： Model:GQ10-050200-ZUU Input:AC 100-240V 50/60Hz 0.35A Output:DC 5.0V 2.0A Rechargeable battery DC 3.7V 1200mAh 4.4Wh (Charging by Type C cable) Cable(s): Type C cable:200cm unshielded RF cable(Provided by the customer): 0.5dB Operation Frequency: 902.68MHz-926.205MHz Modulation Type: GFSK Number of Channels: 26 Channel Spacing: 0.941Mhz Antenna Type: Built-in Antenna Antenna Gain: 1.12dBi Remark:The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. Declaration of EUT Family Grouping: Model No.: 5A4301XX(XX=00 to FF) Only the model 5A430100 was tested, since according to the declaration from the applicant, the electrical circuit design, PCB layout, components used and internal wiring and functions were identical for the above models, with only difference being of model No. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172102 Page: 5 of 14 3.3 Separation Distance Minimum test separation distance: 20cm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. SGS-CSTC Standards Technical Services …

Text truncated - open the document above for the full version.

表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 1 页共 12 页 开发案号Project：Y2409241009 日期Date.：2025.07.11 版本Ver.：A1 承认书 AntennaSPEC 客户名称 Customername ：龙霸顺兴 ( 江门 ) 塑料有限公司 调试项目Customerproject：LSBJQ-01 客户料号CustomerP/N： 博安通料号 B&TP/N ： 74090015 规格描述Spec.:内置天线-915MHz-灰色1.13锡锡线-1代端子 -L=50mm-PCB-61×20×1mm Spec. ： Built-inantenna-915MHz-gray1.13tin-tinwire-1stgeneration terminal-L=50mm-PCB-61x20x1mm 天线类型 Antennatype ：内置天线 Antennatype ： Built-inantenna 供应商名称 Vendorname ：四川博安通通信技术有限公司 Vendorname ： SichuanBoantongCommunicationTechnologyCo.,Ltd 供应商地址 Supplieraddress ：四川省绵阳市经开区塘汛街道文武 中路 218 号 8 幢 5 层 2 、 3 号 Supplieraddress ： No.2and3,5thFloor,Building8,No.218,Wenwu MiddleRoad,TangxunStreet,Economic DevelopmentZone,MianyangCity, SichuanProvince 出厂签章Sealedbycorporation： 编写 compilation 审核 verify 批准 approval 邱翠萍 Qiucuiping 覃麟舒 QinLinshu 刘立华 Liulihua 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 2 页共 12 页 客户承认签章Sealedbycustomer： 检查 check 审核 verify 批准 approval 博安通联系方式ContactinformationofB&T: 业务联系人：徐柳戈 Contactpersonforsales ： Xuliuge 手机 MB ：13881991984邮箱 E-mail ： [email protected] 技术联系人：覃麟舒 Contactpersonfortechnical: QinLinshu 手机 MB ：18776877518邮箱 E-mail ：[email protected] 品质联系人：谭杰鑫 ContactpersonforQuality: Tanjiexin 手机MB：18181766292邮箱 E-mail ：[email protected] 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 3 页共 12 页 文件制定 / 修订 / 废止履历表 Documentmaking/revising/abolishingresume 版本 Version 日期 Date 制定/修订内容 Develop/revisecontent 制定 Formulate 核准 approval A02024.12.17 首次制定 Firstformulation 邱翠萍 Qiucuiping 覃麟舒/刘立华 Wangbingyang / Liulihua A0-07032025.07.03 添加供应商和天线信息 Addvendorandantennainformation 许张金 Xuzhangjin 覃麟舒/刘立华 Wangbingyang/Liulihua A12025.07.11 更新供应商名称 Updatethevendorname 许张金 Xuzhangjin 覃麟舒/刘立华 Wangbingyang/Liulihua 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 4 页共 12 页 目录 Contents 1 、封面Cover ································································1 2 、目录 Directory·····························································4 3 、产品图面 Productdrawing··············································5~6 4 、性能参数表 PerformanceparametersTable··························7 5 、电气性能测试报告 Electricalperformancetestreport··············8 6 、材料成份及有害物质表 ListofMaterialCompositionand HazardousSubstance··························································9 7 、包装规范 packagingspecification······································10 8 、天线安装位置示意图 AntennainstallationpositionDiagram·····11 9 、可靠性测试要求 Reliabilitytestrequirements·······················11~12 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 5 页共 12 页 3 、产品图面 Productdrawing 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 6 页共 12 页 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 7 页共 12 页 4 、性能参数 Properties&parameter 电气参数Electricalparameter 频率范围 FreqRange 902-928MHz 输入阻抗 CharacteristicImpedance 50Ω 驻波比 VSWR ≤2.0 功率容量 TheMaxinputpower <10w 增益 Gain ≥0dBi ， ≤2dBi 极化方式 Polarizationmode 线极化 Linearpolarization 辐射方向 Radiationdirection 全向 omnidirectional 接头型号 Jointtype 端子 IPEXconnector 机械参数Mechanicalparameter 总长 Length 50±3mm 端子维持力 Maintaintheforce ≥ 1kgf 同轴电缆 Coaxialcable 灰色1.13锡锡线 Gray1.13tin-tinwire 盐雾测试 Saltspraytest 24H 环境参数Environmentparameter 工作温度 OperatingTemp -30 °C ~65 °C 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 8 页共 12 页 5、电气性能测试报告Electricaltestreport（整机测试Wholemachinetesting） 天线S11参数图AntennaS11parameterdiagram 驻波比数据Standingwaveratiodata Freq/MHz902915928 VSWR1.2891.0761.290 天线暗室测试数据Antennadarkroomtestdata 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 9 页共 12 页 天线方向图 Antennadirectiondiagram 900MHz 915MHz 930MHz 6 、材料成分及有害物质表ListofMaterialCompositionandHazardousSubstances 项 次 It em 规格 Specifi cation 材质 Texture of material RoHS检验结果（PPM） ROHSTestResults（PPM） ICP检测编号 ICPtestnumber 检测时间 Testtime CdPbHg Cr+6PBBPBDE 1 线wire FEPNDNDNDNDNDNDNGBPC240001312412024/1/16 镀锡铜线 Tinned wire NDNDNDNDNDNDA22403769951010012024/7/1 2 端子 Terminal PBTNDNDNDNDNDNDA2240126395101004E2024/3/16 磷青铜 Phosphor Bronze ND6NDNDNDNDCANEC240009773012024/1/22 3 PCB FR-4ND17NDNDNDNDCANEC240197907092024/9/14 OSPNDNDNDNDNDNDCANEC240040133012024/3/14 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 10 页共 12 页 产品包装规范 PACKINGCRITERION 产品料号 P/N ：74090015 产品规格:内置天线-915MHz-灰色1.13锡锡线-1代端子-L=50mm-PCB-61×20×1mm Spec：Built-inantenna-915MHz-gray1.13tin-tinwire-1stgenerationterminal-L= 50mm-PCB-61x20x1mm 一、标签要求（根据客户名称参考对应的成品标签制作要求，无要求即按普通标签要求） contentsoflabel(accordingtothecustomer'sname,refertothecorrespondingfinishedproduct labelproductionrequirements.Ifthereisnorequirement,itwillfollowtheordinarylabel requirements.) 内外标签长10cm宽6cm左右 Theinnerandouterlabelsareabout10cmlongand6cmwid 需方 buyer ************* 供方 vender 中山市博安通通信技术有限公司 ZhongshanB&TCommunicationTechnologyCo.,Ltd 四川博安通通信技术有限公司 SichuanB&TTechnologyCo.,Ltd. 物料编码 PurchaseNo ************* 生产单号 MaterialNo. ***************** 品名规格 Namespecification ******** 检验员 QC ** 数量/单位 Q’ty/Unit ***** 日期 Manufacturedate ****.**.* 追溯码 Tracecode ******** 流水号 Serialnumber ** 二、装箱要求Packingrequirement 作业说明Operatingdescription： 1．内包装innerpacking： 产品50PCS/小袋/smallbag 200PCS/大袋bigbag 2．外包装outerpacking： 根据实际包装定数量Quantityaccordingtoactualpacking/箱carton 注意事项Notice： 1．是否要增设隔板、珍珠棉Whethertoaddpartitions,pearlcotton； 2．标签的贴附，如ROHS等Labeling,suchasROHS； 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 11 页共 12 页 8 、天线整机安装示意图 AntennainstallationpositionDiagram 9 、可靠性测试要求 Reliabilitytestrequirements 表单编号Formnumber：B&T-QR-EN-002版本version：B3 第 12 页共 12 页

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172101 Page: 1 of 60 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2504001721AT Applicant: Zircon Corporation Address of Applicant: 1580 Dell Avenue, Campbell, California, 95008, United States Manufacturer: ROMPA ShunXing (JiangMen) Plastics Co., Ltd. Address of Manufacturer: No.290, Qinglan Road, Jianghai District, Jiangman, Guangdong, China Factory: ROMPA ShunXing (JiangMen) Plastics Co., Ltd. Address of Factory: No.290, Qinglan Road, Jianghai District, Jiangman, Guangdong, China Equipment Under Test (EUT): EUT Name: Charging Hub Model No.: 5A4301XX(XX=00 to FF)   Please refer to section 2 of this report which indicates which model was actually tested and which were electrically identical. Trade Mark: ZIRCON FCC ID: N94-HUB-74428 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2025-04-29 Date of Test: 2025-05-22 to 2025-06-10 Date of Issue: 2025-06-10 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172101 Page: 2 of 60 Revision Record Version Chapter Date Modifier Remark 01 2025-06-10 Original Authorized for issue by: Bill Chen/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172101 Page: 3 of 60 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Declaration of EUT Family Grouping: Model No.: 5A4301XX(XX=00 to FF) Only the model 5A430100 was tested, since according to the declaration from the applicant, the electrical circuit design, PCB layout, components used and internal wiring and functions were identical for the above models, with only difference being of model No. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR250400172101 Page: 4 of 60 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 6 4.3 Measurement Uncertainty .................................................................................................................. 7 4.4 Test Location ...................................................................................................................................... 8 4.5 Test Facility ........................................................................................................................................ 8 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ........................................................................................... 8 5 Equipment List .......................................................................................................................................... 9 6 Radio Spectrum Technical Requirement ............................................................................................. 11 6.1 Antenna Requirement ...................................................................................................................... 11 6.1.1 Test Requirement: ....................................................................................................................... 11 6.1.2 Conclusion ................................................................................................................................... 11 7 Radio Spectrum Matter Test Results .................................................................................................... 12 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ............................................................. 12 7.1.1 E.U.T. Operati…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Appendix Test Setup Photos for SZCR2504001721AT FCC ID: N94-HUB-74428 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions Below 1GHz 9K-30MHz SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 3 of 3 30M-1GHz Radiated Spurious Emissions Above 1GHz - End of the Appendix -
