NC8KX-TC1486900MHz 40 Channel Analog Cordless Phone w/ CID

CCT Tech Advanced Products Limited

Click to zoom

Application Details

Equipment Class: DXT - Part 15 Low Power Transceiver, Rx Verified
Date of Grant: Mar 20, 2004
Application Purpose: Original Equipment
Date of Application: Mar 20, 2004
Equipment Note: 900MHz 40 Channel Analog Cordless Phone w/ CID
Frequency Range: 925.90000000 - 927.85000000
Company: CCT Tech Advanced Products Limited
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

The unit is Caller ID compatible. To display the caller’s name and phone number, you must subscribe to Caller ID service. PLEASE READ BEFORE USE AND SAVE. Panasonic World Wide Web address: http://www.panasonic.com for customers in the USA or Puerto Rico Charge the battery for 15 hours before initial use. 900 MHz Cordless Phone Operating Instructions Model No.KX-TC1486 Pulse-or-tone dialing capability ∑Handset Cover (p. 8) Order No. PQYNTC1486B one Accessories (included) For extra orders, call 1-800-332-5368. For hearing or speech impaired TTY users, call 1-866-605-1277. ∑AC Adaptor (p. 7) Order No. PQWATC1461M1 one ∑Telephone Line Cord (p. 7) one ∑Belt Clip (p. 27) Order No. PQZHTC1486B one ∑Battery (p. 8) Order No. PQWBTC1461M one 2 Thank you for purchasing your new Panasonic cordless telephone. Please read IMPORTANT SAFETY INSTRUCTIONS on page 34 before use. Read and understand all instructions. Attach your purchase receipt here. Caller ID and Call Waiting Service, where available, are telephone company services. After subscribing to Caller ID, this phone will display a caller’s name and phone number. Call Waiting Caller ID, which displays a second caller’s name and phone number while the user is on another call, requires a subscription to both Caller ID and Call Waiting with Caller ID services (CWID). For your future reference Serial No.Date of purchase (found on the bottom of the unit) Name and address of dealer Before Initial Use For assistance, please call: 1-800-211-PANA(7262) For Best Performance 3 Battery Charge A rechargeable Ni-Cd battery powers the handset. Charge the battery for 15 hours before initial use (p. 8). Raise the antenna. Away from electrical appliances such as a TV or personal computer. In a HIGH and CENTRAL location with no obstructions such as walls. Base Unit Location Calls are transmitted between the base unit and the handset using wireless radio waves. For maximum distance and noise-free operation, the recommended base unit location is: Advanced Operation Phone Book............................ 20 Storing Names and Numbers............................... 20 Finding Stored Items .............. 22 Dialing .................................... 22 Editing .................................... 23 Erasing ................................... 24 Special Features..................... 25 Automatic Security Code Setting .................................. 25 Handset Locator ..................... 25 Temporary Tone Dialing (For Rotary or Pulse Service Users) ................................ 25 Using the PAUSE Button (For PBX Line/Long Distance Calls) ................................... 26 For Call Waiting Service Users.................................... 26 Useful Information Belt Clip................................... 27 Optional Headset.................... 27 Wall Mounting......................... 28 Adding Another Phone.......... 29 Battery Replacement.............. 30 Troubleshooting.....................31 Important Safety Instructions........................... 34 FCC and Other Information... 36 Specifications......................... 39 Index........................................ 40 Warranty.................................. 41 Preparation Location of Controls............... 5 Settings..................................... 7 Connections ............................. 7 Installing the Battery in the Handset.................................. 8 Battery Charge ......................... 8 Ringer Selector ........................ 9 Programmable Functions...... 10 Display Language .................. 10 Dialing Mode .......................... 10 Basic Operation Making Calls........................... 11 Answering Calls..................... 12 Caller ID Service..................... 13 Using the Caller List.............. 15 Viewing the Caller List............ 15 Calling Back from the Caller List........................................ 17 Editing the Caller’s Phone Number ................................ 17 Storing Caller Information in the Phone Book................ 18 Erasing Caller Information...... 19 Contents 4 Location of Controls“ 5 Preparation For assistance, please call: 1-800-211-PANA(7262) Base unit Charge Contacts (p. 9) IN USE/CHARGE Indicator (p. 8, 25) [HANDSET LOCATOR] (p. 25) Antenna (p. 3) Hook (p. 28) “Location of Controls 6 Handset Antenna [PAUSE/REDIAL] (p. 11, 26) Charge Contacts (p. 9) [ /FLASH] (p. 11, 12, 26) [AUTO/PROGRAM] (p. 18, 20, 22) [MUTE/CLEAR] (p. 12, 19, 24) [OFF] (p. 11, 15) RINGER Selector (p. 9) [ ] (TONE) (p. 25) [CH/FUNCTION] (Channel) (p. 10, 11) LOUD/SEARCH Key ([ ], [ ]) (see below) Display (p. 14) [EDIT] (p. 10, 17, 20) Headset Jack (p. 27) Receiver Microphone How to use the LOUD/SEARCH key This key has two active areas that are indicated by arrows. ≥Pressing the up or down arrow allows you ≥—to enter into the Caller List, ≥—to select the function items, ≥—to scroll through your phone book and the Caller List, and ≥—to adjust the receiver volume on the handset. LOUD/ SEARCH Throughout these Operating Instructions, the LOUD/SEARCH key is indicated by the arrows or . [ ] [ ] Settings“ 7 Preparation For assistance, please call: 1-800-211-PANA(7262) Connections Power Outlet (AC 120 V, 60 Hz) Telephone Line Cord Single-Line Telephone Jack (RJ11C) Raise the antenna. AC Adaptor Fasten the AC adaptor cord to prevent it from being disconnected. Hook ≥USE ONLY WITH Panasonic AC ADAPTOR PQWATC1461M1 (Order No. PQWATC1461M1). ≥The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) ≥To connect a standard telephone on the same line, see page 29. ≥If your unit is connected to a PBX which does not support Caller ID services, you cannot access those services. “Settings 8 Battery Charge Place the handset on the base unit and charge for 15 hoursbefore initial use. ≥The IN USE/CHARGE indicator lights and a beep sounds. OR IN USE/CHARGE Indicator Installing the Battery in the Handset Install the battery an…

Text truncated - open the document above for the full version.

Users Manual

37 Useful Information For assistance, please call: 1-800-211-PANA(7262) “ WHEN PROGRAMMING EMERGENCY NUMBERS AND(OR) MAKING TEST CALLS TO EMERGENCY NUMBERS: 1) Remain on the line and briefly explain to the dispatcher the reason for the call. 2) Perform such activities in the off-peak hours, such as early morning or late evenings. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Privacy of communications may not be ensured when using this phone. CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this device. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. The USOC jack is RJ11C and the jack is Part 68 compliance.

External Photos

External photos FCC ID: NC8KX-TC1486 External photos FCC ID: NC8KX-TC1486

ID Label/Location Info

KX-TC1486B BASE LABEL DRAWING DATE: 02 FEB 2004

Internal Photos

Internal photos FCC ID: NC8KX-TC1486 Base assembly Base Main PCB comp side (View 1) Internal photos FCC ID: NC8KX-TC1486 Base Main PCB comp side (View 2) Base Main PCB solder side Internal photos FCC ID: NC8KX-TC1486 Base page key PCB front side Base page key rear side Internal photos FCC ID: NC8KX-TC1486 Base Oscillator PCB comp side Base Oscillator PCB solder side Internal photos FCC ID: NC8KX-TC1486 Handset assembly Handset Main PCB comp side (View 1) Internal photos FCC ID: NC8KX-TC1486 Handset Main PCB comp side (View 2) Handset Main PCB display side Internal photos FCC ID: NC8KX-TC1486 Handset Oscillator PCB comp side Handset Oscillator PCB solder side

Test Report

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization form Intertek Testing Services Limited FCC ID: NC8KX-TC1486 Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2741 1693 Website: www.hk.intertek-etlsemko.com CCT R&D Ltd. Application For Certification 900MHz 40 Channel Analog Modulation Cordless Phone with Caller ID (FCC ID: NC8KX-TC1486) 04035601 TL/Ann Choy March 12, 2004 INTERTEK TESTING SERVICES FCC ID: NC8KX-TC1486 i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Security Code Information INTERTEK TESTING SERVICES FCC ID: NC8KX-TC1486 ii MEASUREMENT/TECHNICAL REPORT CCT R&D Ltd. - MODEL: KX-TC1486B FCC ID: NC8KX-TC1486 This report concerns (check one:) Original Grant X Class II Change Equipment Type : Cordless Telephone (example : computer, modem, transmitter, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37 ? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-08-03 Edition] Provision. Report prepared by: Tommy Leung Intertek Testing Services. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone : 852-2173-8538 Fax: 852-2741-1693 INTERTEK TESTING SERVICES FCC ID: NC8KX-TC1486 iii Table of Contents 1.0 General Description.......................................................................................... 2 1.1 Product Description ........................................................................................2 1.2 Related Submittal(s) Grants...........................................................................3 1.3 Test Methodology...........................................................................................3 1.4 Test Facility ....................................................................................................3 2.0 System Test Configuration ..................................................................................5 2.1 Justification.....................................................................................................5 2.2 EUT Exercising Software ...............................................................................5 2.3 Support Equipment List and Description........................................................6 2.4 Measurement Uncertainty ..............................................................................7 2.5 Equipment Modification..................................................................................7 3.0 Emission Results ..................................................................................................9 3.1 Field Strength Calculation ............................................................................10 3.2 Radiated Emission Configuration Photograph - Base Unit ..........................11 3.3 Radiated Emission Data - Base Unit............................................................12 3.4 Radiated Emission Configuration Photograph - Handset ............................15 3.5 Radiated Emission Data - Handset..............................................................16 3.6 Radiated Emission on the bandedge ...........................................................19 3.7 Line Conducted Configuration Photograph - Base Unit...............................21 3.8 Line Conducted Emission Data - Base Unit.................................................22 4.0 Equipment Photographs ....................................................................................25 5.0 Product Labelling ...............................................................................................27 6.0 Technical Specifications ...................................................................................29 7.0 Instruction Manual ..............................................................................................31 8.0 Security Code Information................................................................................33 INTERTEK TESTING SERVICES FCC ID: NC8KX-TC1486 iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission for Base config photos.doc Test Setup Photo Radiated Emission for Handset config photos.doc Test Report Emission Plot emission.pdf Test Setup Photo Conducted Emission config photos.doc Test Report Conducted Emission Test Result conduct.pdf External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf User Manual FCC Information fcc information.pdf INTERTEK TESTING SERVICES FCC ID: NC8KX-TC1486 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: NC8KX-TC1486 2 1.0 General Description 1.1 Product Description The KX-TC1486B is a 900MHz 40 Channel Analog Modulation Cordless Phone with Caller ID. The unit is capable of either tone or pulse dialing. The internal power supply's isolation is accomplished through a power transformer having an adequate dielectric rating. The circuit wiring is consistent under the requirement of part 68. The handset unit consists of a keypad with twelve standar…

Text truncated - open the document above for the full version.

Test Report

Report No.:04035601 Talk Mode Ctrl No.:N/A PAGE 1 Tested By:Hong, Report No.:04035601 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement: x QP / + AV Meas Time: 1 s Subranges: 16 Acc Margin: 20dB Transducer No. Start Stop Name 21 9k 30M EW0698 0 10 20 30 40 50 60 70 80 90 dBuV 100 0.15 MHz 30110 F15Q F15A Report No.:04035601 Talk Mode Ctrl No.:N/A Tested By:Hong, Report No.:04035601 Scan Settings (1 Range) |--------- Frequencies -----------||----------- Receiver Settings ------------| Start Stop Step IF BW Detector M-Time Atten Preamp OpRge 150k 30M 5k 10k PK+AV 10ms AUTO LN OFF 60dB Final Measurement Results: no Results

Test Setup Photos

The Worst Case Configuration Photographs FCC ID: NC8KX-TC1486 Radiated Emission – Base Front View Rear View The Worst Case Configuration Photographs FCC ID: NC8KX-TC1486 Radiated Emission – Handset Front View Rear View The Worst Case Configuration Photographs FCC ID: NC8KX-TC1486 Conducted Emission Front View Rear View The Worst Case Configuration Photographs FCC ID: NC8KX-TC1486 Conducted Emission Side View
