NC8MA550H900MHz/5.8GHz 40 Channel Cordless Phone (Handset)

xxThis equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment on and off, the user is encouraged to try to correct the interference with one or more of the following measures: • Reorient or relocate the receiving antenna (that is, the antenna for the radio or television that is "receiving" theinterference). • Reorient or relocate and increase the separation between the telecommunications equipment and thereceiving antenna. FCC Information xxi • Connect the telecommunications equipment into an outlet on a circuit different from that to which the receivingantenna is connected. If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet, "How to Identify and Resolve Radio/TV Interference Problems." This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when ordering copies. FCC Information xxiiThe FCC requires this product to be serviced only by Motorola or its authorized service agents. CAUTION / WARNING : Changes or modifications not expressly approved by Motorola could void not only the user's authority to operate the equipment, but also the limited warranty.Hearing Aid CompatibilityThis telephone system meets the FCC standards for hearing aid compatibility. FCC Information

MA550 Series Cordless Phone Start Here > i WelcomeYour Motorola MA550 at a glance: Earphone jack Use for call waiting and 3-way calling Adjust volume Use if you hear interference or static Redial last number called (up to 32 digits) Mute or unmute; delete phone numbers Place call on hold Scroll Store phone number in memory Format phone number to include or omit area code or 1+ area code Cancel a command; hang up Turn ringer on (up) or off (down) Make or answer a call; hang up Welcome ii For a copy of a large-print version of this guide, or for product-related questions, please contact: 1-800-353-2729 U.S.A. 1-800-461-4575 Canada 1-888-390-6456 TTY (Text Telephone) Or visit us online: www.motorola.com/cordless Product registration is an important step toward enjoying your new Motorola product. Registering helps us facilitate warranty service, and permits us to contact you should your Motorola product require an update or other se rvice. Registration is not required for warranty coverage. To register your product online, visit:www.motorola.com/warranty/cordless Welcome iii Please retain your original dated sales receipt for your records. For warranty service of your Motorola Product, you will need to provide a copy of your dated sales receipt to confirm warranty status.Copyright © 2004 Motorola, Inc. All rights reserved. No part of this publication may be reproduced in any form or by any means or used to make any derivative work (such as translation, transformation or adaptation) without written permission from Motorola, Inc.Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including but not limited Welcome ivto, the implied warranties of merchantability and fitness for a particular purpose. Motorola may make improvements or changes in the product(s) described in this manual at any time.MOTOROLA, the Stylized M Logo, and PhoneWrap are registered in the U.S. Patent and Trademark Office. All other product or service names are the property of their respective owners. Welcome v Welcome............................................ iImportant Safety Instructions ..... viiFCC and Interference Information.................................... xiiiGetting Started ................................ 1Battery Safety Instructions .................. 2Charging the Battery ........................... 3Setting Up the Phone .......................... 6Installation...................................... 11Installing the MA550 Cordless Phone on a Desk.......................................... 12Installing the MA550 Cordless Phone on a Wall ........................................... 13Installing or Removing the Belt Clip .. 17 How to Use .....................................19How to Locate a Lost Handset .......... 20Using Voice Mail ............................... 21Storing a Number into Memory ......... 22Storing a Caller ID Number nto Memory ....................................... 25Dialing a Number from Memory ........ 26Storing and Calling Emergency Numbers ........................ 27Reviewing and Deleting Numbers from Memory ..................................... 28Reviewing Caller ID Records ............ 29Dialing a Number from Caller ID ....... 30Deleting Caller ID Records ............... 31Troubleshooting ............................33Motorola Limited Warranty ..........37 Contents Contents vi Contents vii Important Safety InstructionsFollow these safety precautions when using your cordless phone to reduce the risk of fire, electric shock and injury to persons or property: Reduce risk of fire and shock by ™ Keep all slits and openings of the phone unblocked. Do not set the phone on a heating register or over a radiator. Ensure that proper ventilation is provided at the installation site. š Do not use while wet or while standing in water. › Do not use this product near water (for example, near a bath tub, kitchen sink, or swimming pool). œ Do not allow anything to rest on the power cord. Place the power cord so that it will not be walked on. Safety Information viii  Never insert objects of any kind into the product slits as that may result in fire or shock. ž Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Ÿ Do not disassemble this product. If service or repair work is required, contact the Motorola address found in the back of this user’s guide. Do not overload wall outlets and extension cords. ¡ Avoid using during an electrical storm. Use a surge protector to protect the equipment. ¢ Do not use this cordless phone to report a gas leak, especially if you are in the vicinity of the gas line. Caution! To reduce the risk of fire, use only No. 26 AWG or larger UL Listed or CSA Certified Telecommunication Line Cord. Safety Information ix Unplug this cordless phone immediately from an outlet if: • The power cord or plug is damaged or frayed. • Liquid has been spille d into the product. • The product has been exposed to rain or water. Do not retrieve the handset or base until after you have unplugged the power and phone from the wall. Then retrieve the unit by unplugged cords. • The product has been dropped or the cabinet has been damaged. • The product exhibits a distinct change in performance. Installation Guidelines ™ Read and understand all instructions and save them for future reference. š Follow all warnings and instructions marked on the product. Safety Information x › Do not install this product near a bath tub, sink or shower. œ Operate this phone using only the power source that is indicated on the marking label. If you are unsure of the power supply to your home, consult with your dealer or local power company.  Do not place this product on an unstable cart, stand or table. This pr…

Text truncated - open the document above for the full version.

56.5 34.5 SCALE 100% 51.38 163.18 MA550-USA LABEL DRAWING DATE : 25 MAY 2004 HS Label Size: 28.5mm x 48mm BU Label Size: 56mm x 34mm

Internal photos FCC ID: NC8MA550H Handset assembly Handset Main PCB comp side (View 1) Internal photos FCC ID: NC8MA550H Handset Main PCB comp side (View 2) Handset Main PCB display side Internal photos FCC ID: NC8MA550H Handset Oscillator PCB comp side Handset Oscillator PCB solder side

• The test results reported in this report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report shall not be reproduced except in full without prior authorization form Intertek Testing Services Limited FCC ID: NC8MA550H Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2741 1693 Website: www.hk.intertek-etlsemko.com E CCT R&D Ltd. Application For Certification 900MHz/5.8GHz 40 Channel Analog Modulation Cordless Phone with Caller ID - Handset (FCC ID: NC8MA550H) 04082042 TL/Ann Choy June 14, 2004 INTERTEK TESTING SERVICES FCC ID: NC8MA550H i LIST OF EXHIBITS INTRODUCTION EXHIBIT 1: General Description EXHIBIT 2: System Test Configuration EXHIBIT 3: Emission Results EXHIBIT 4: Equipment Photographs EXHIBIT 5: Product Labelling EXHIBIT 6: Technical Specifications EXHIBIT 7: Instruction Manual EXHIBIT 8: Security Code Information INTERTEK TESTING SERVICES FCC ID: NC8MA550H ii MEASUREMENT/TECHNICAL REPORT CCT R&D Ltd. - MODEL: MA55X series FCC ID: NC8MA550H This report concerns (check one:) Original Grant X Class II Change Equipment Type : Cordless Telephone (example : computer, modem, transmitter, etc.) Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until : date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37 ? Yes No X If no, assumed Part 15, Subpart C for intentional radiator - the new 47 CFR [12-08-03 Edition] Provision. Report prepared by: Tommy Leung Intertek Testing Services. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone : 852-2173-8538 Fax: 852-2741-1693 INTERTEK TESTING SERVICES FCC ID: NC8MA550H iii Table of Contents 1.0 General Description ............................................................................................2 1.1 Product Description..........................................................................................2 1.2 Related Submittal(s) Grants ............................................................................3 1.3 Test Methodology ............................................................................................3 1.4 Test Facility ......................................................................................................3 2.0 System Test Configuration ...................................................................................5 2.1 Justification.......................................................................................................5 2.2 EUT Exercising Software.................................................................................5 2.3 Support Equipment List and Description.........................................................6 2.4 Measurement Uncertainty ...............................................................................7 2.5 Equipment Modification ...................................................................................7 3.0 Emission Results ...................................................................................................9 3.1 Field Strength Calculation .............................................................................10 3.2 Radiated Emission Configuration Photograph - Handset.............................11 3.3 Radiated Emission Data - Handset ...............................................................12 3.4 Radiated Emission on the bandedge ............................................................15 4.0 Equipment Photographs .....................................................................................18 5.0 Product Labelling .................................................................................................20 6.0 Technical Specifications .....................................................................................22 7.0 Instruction Manual ...............................................................................................24 8.0 Security Code Information ..................................................................................26 INTERTEK TESTING SERVICES FCC ID: NC8MA550H iv List of attached file Exhibit type File Description filename Test Report Test Report report.pdf Operation Description Technical Description descri.pdf Test Setup Photo Radiated Emission for Handset config photos.doc External Photo External Photo external photos.doc Internal Photo Internal Photo internal photos.doc Block Diagram Block Diagram block.pdf Schematics Circuit Diagram circuit.pdf ID Label/Location Label Artwork and Location label.pdf User Manual User Manual manual.pdf User Manual FCC Information fcc information.pdf INTERTEK TESTING SERVICES FCC ID: NC8MA550H 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: NC8MA550H 2 1.0 General Description 1.1 Product Description The MA550 is a 900MHz/5.8GHz 40 Channel Analog Modulation Cordless Phone with Caller ID - Handset. The unit is capable of either tone or pulse dialing. The internal power supply's isolation is accomplished through a power transformer having an adequate dielectric rating. The circuit wiring is consistent under the requirement of part 68. The handset unit consists of a keypad with twelve standard keys (0,...9,*,#), nine function keys (frmt, C, CID Up, CID down, mute/delete, mem, redial, hold, flash/settings), and one channel switch key. A Talk key is provided to control pick/release telephone line in a toggle base. The base unit has a page key, which is used to page the handset unit. The antennas used in base unit and handset are integral, and the tested sample is a prototype. The model MA550 is one of the model MA55X series, and the letter “X” at the end of the model numbers is in term of number from “0” to “9” with different color…

Text truncated - open the document above for the full version.

The Worst Case Configuration Photographs FCC ID: NC8MA550H Radiated Emission – Handset Front View Rear View
