NJZNTV-2000Internet Set Top Box

Neon Technology Inc

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Oct 03, 2000
Application Purpose: Original Equipment
Date of Application: Aug 31, 2000
Equipment Note: Internet Set Top Box
Company: Neon Technology Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Attestation Statements

ne 0 n fechno/ogy “,:E;aYPZiYGElpwy Tel:1 -877-SET-TOPS Fax:408-263-2 16 1 www.neontech.com info @ neontech.com August 11,200O Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 2 1046 Gentlemen: We, the undersigned, hereby authorize PCTEST Engineering Laboratory, Inc., to act on our behalf in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. Any and all acts carried out by PCTEST Engineering Laboratory, Inc. on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U. S. C. 862. This authorization is effective only until August 11, 200 1 Sincerely, Sr. Production Specialist

Cover Letter(s)

August 28, 2000 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: NEON TECHNOLOGY FCC ID: NJZNTV-2000 Gentlemen: Submitted herewith, on behalf of NEON TECHNOLOGY, is an application for certification of the following Internet Set Top Box: FCC ID: NJZNTV-2000 MODEL(s): NTV-2000 TRADE NAME(s): SurfReady EUT TYPE: Internet Set Top Box Attached is the letter of authorization, measurement report (Radiation emission data, Line Conducted emission data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, schematic diagrams, and user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: NEON TECHNOLOGY

Cover Letter(s)

October 3, 2000 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Ms. Diane Poole SUBJECT: Neon Technology Inc. FCC ID: NJZNTV-2000 731 Confirmation No.: EA98628 Correspondence Reference No.: 16375 Request for Tech. Info.: 9/28/00 Dear Diane: Transmitted herewith, on behalf of Neon Technology Inc. is an amendment provided in response to the request for technical information dated September 28, 2000. 1. We have confirmed that the remote control is infrared only. We trust this information is sufficient to issue the grant as soon as possible. If you have any further questions, please do not hesitate to contact me. cc: Neon Technology Inc.

External Photos

ID Label/Location Info

© 20009 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

© 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000) © 2000 PCTEST Lab NEON TECHNOLOGYFCC ID: NJZNTV-2000 NVLAP Lab Code: 1004310 Internet Set Top Box (Model: NTV-2000)

Test Report

© 2000 PCTEST Engineering Lab., Inc. PCTEST Engineering Laboratory, Inc. 66606660--B Dobbin Road B Dobbin Road •• Columbia, MD 21045 Columbia, MD 21045 •• U.S.A. U.S.A. TEL (410) 290TEL (410) 290--6652 6652 •• FAX (410) 290 FAX (410) 290--66546654 http://www.pctestlab.comhttp://www.pctestlab.com CERTIFICATE OF COMPLIANCE NEON TECHNOLOGY Dates of Tests: August 23-24, 2000 87 W. Montague Expwy. Test Report S/N: B.200810430.NJZ Milpitas, CA 95035 Test Site: PCTEST Lab., MD U.S.A. Attn: Ms. Jennifer Yamba, Sr. Production Specialist FCC ID NJZNTV-2000 APPLICANT NEON TECHNOLOGY Rule Part(s): FCC Part 15 Subpart B Equipment Class: Class B Peripheral Device (JBP) EUT Type: Internet Set Top Box Trade Name(s): SurfReady Model(s): NTV-2000 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 (Note Codes: #37). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Lab Code 100431-0 © 2000 PCTEST Engineering Laboratory, Inc. FCC Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT 1.1 SCOPE 1 2.1 INTRODUCTION (SITE DESCRIPTION) 2 3.1 PRODUCTION INFORMATION 3 4.1 DESCRIPTION OF TESTS (CONDUCTED) 4 4.3 DESCRIPTION OF TESTS (RADIATED) 5 5.1 LIST OF SUPPORT EQUIPMENT 6 6.1 TEST DATA (CONDUCTED) 7 7.1 TEST DATA (RADIATED) 8 8.1 SAMPLE CALCULATIONS 9 9.1 ACCURACY OF MEASUREMENT 10 10.1 LIST OF TEST EQUIPMENT 11 11.1 TEST SOFTWARE USED 12 12.1 CONCLUSION 13 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL & LOCATION ATTACHMENT F: SCHEMATIC DIAGRAM(S) ATTACHMENT G: TEST SETUP PHOTOGRAPHS ATTACHMENT H: EXTERNAL PHOTOGRAPHS ATTACHMENT I: INTERNAL PHOTOGRAPHS ATTACHMENT J: USER’S MANUAL Test Report S/N: B.200810430.NJZ FCC Class B Dates of Tests: August 23-24, 2000 Certification © 2000 PCTEST Lab NEON TECHNOLOGY FCC ID: NJZNTV-2000 1 Internet Set Top Box (NEON Model: NTV-2000) MEASUREMENT REPORT 1.1 Scope Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Applicant Name: NEON TECHNOLOGY Address: 87 W. Montague Expwy. Milpitas, CA 95035 Contact Person: Jennifer Yamba Sr. Production Specialist • FCC ID: NJZNTV-2000 • Equipment Class: B Digital Device / Peripheral (JBP) • EUT Type: Internet Set Top Box • Trade Name(s): SurfReady • Model(s): NTV-2000 • CPU / Frequency: INTEL Pentium – 266MHz • Crystal/Oscillator(s): 14.318, 24.500 MHz • Cable(s): Unshielded Telco, Unshielded RCA, Unshielded Audio Shielded S-Video, Shielded D-Sub • Power Cord: Unshielded • Rule Part(s): FCC Part 15 Subpart B • Test Procedure(s): ANSI C63.4 (1992) • Dates of Tests: August 23-24, 2000 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: B.200810430.NJZ Test Report S/N: B.200810430.NJZ FCC Class B Dates of Tests: August 23-24, 2000 Certification © 2000 PCTEST Lab NEON TECHNOLOGY FCC ID: NJZNTV-2000 2 Internet Set Top Box (NEON Model: NTV-2000) 2.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from NEON TECHNOLOGY Internet Set Top Box FCC ID: NJZNTV-2000. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 2.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. Test Report S/N: B.200810430.NJZ FCC Class B Dates of Tests: August 23-24, 2000 Certification © 2000 PCTEST Lab NEON TECHNOLOGY FCC ID: NJZNTV-2000 3 Internet Set Top Box (NEON Model: NTV-2000) 3.1 Product Information 3.2 Equipment Description The Equipment Under Test (EUT) is the NEON TECHNOLOGY (SurfReady Model: NTV-2000) Internet Set Top Box FCC ID: NJZNTV-2000. CPU / Frequency: INTEL Pentium – 266MHz Crystal/Oscillator(s): 14.318, 24.500 MHz Power Supply Input: 110VAC Power Consumption: 35 W Max Power Cord: Unshielded Port(s)/Input Connector(s): S-Video In, S-Video Out, Composite Video In (x2), Composite Video Out, AC-3 Audio Out, Mini-Audio Out, Mini-Audio In (x2), Parallel Port, VGA Port, Serial Port, USB Port (x2), Auxiliary PS2 Port (x2), 10 base-T Ethernet Port, RJ11 Telephone Jack Cable(s): Unshielded Telco, Unshielded RCA, Unshielded Audio Shielded S-Video…
